Specifications
EAU72940
Dimensions:Overall length: 1990 mm (78.3 in)
Overall width: 690 mm (27.2 in)
Overall height: 1135 mm (44.7 in)
Seat height:
785 mm (30.9 in)
Wheelbase: 1385 mm (54.5 in)
Ground clearance: 140 mm (5.51 in)Weight:Curb weight:142 kg (313 lb)Engine:Combustion cycle:
4-stroke
Cooling system: Liquid cooled
Valve train: SOHC
Number of cylinders:
Single cylinder
Displacement: 155 cm
3
Bore  stroke:
58.0  58.7 mm (2.28  2.31 in)
Compression ratio:
11.0 : 1
Starting system: Electric starter Lubrication system:
Wet sump
Engine oil:Recommended brand:YAMALUBE
Type: SAE 10W-40
Recommended engine oil grade:
API service SG type or higher, JASO stan-
dard MA or MB
Engine oil quantity:
Periodic oil change:1.10 L (1.16 US qt, 0.97 Imp.qt)Final transmission oil:Type:SAE 10W-30 type SE motor oil
Quantity: 0.20 L (0.21 US qt, 0.18 Imp.qt)
Coolant reservoir (up to the maximum level
mark):
0.25 L (0.26 US qt, 0.22 Imp.qt)
Radiator (including all routes):
0.56 L (0.59 US qt, 0.49 Imp.qt)Air filter:Air filter element:Oil-coated paper element
V-belt filter element:
Dry elementFuel:Recommended fuel:Regular unleaded gasoline only
Fuel tank capacity:
8.0 L (2.1 US gal, 1.8 Imp.gal)
Fuel injection:Throttle body: ID mark:52S1 01Spark plug(s):Manufacturer/model: NGK / CPR9EA-9
Spark plug gap: 0.8–0.9 mm (0.031–0.035 in)Clutch:Clutch type:Dry, centrifugal automaticTransmission:Primary reduction ratio:
1.000
Final drive: Gear
Secondary reduction ratio: 10.320 (46 / 13 )×(35 / 12)
Transmission type:
V-belt automatic
Gear ratio:Chassis:Frame type: Underbone
Caster angle: 23.8 
Trail:
84 mm (3.3 in)Front tire:Type:Tubeless
Size:
100 / 80 - 16M/C 50P
