DESCRIPTION
2
Left view (XJ600S) ............................................................................. 2-1
Right view (XJ600S) ........................................................................... 2-2
Controls and instruments (XJ600S) ................................................... 2-3
Left view (XJ600N) ............................................................................. 2-4
Right view (XJ600N) .......................................................................... 2-5
Controls and instruments (XJ600N) ................................................... 2-6
E_4br.book Page 1 Wednesday, July 25, 2001 1:40 PM

2-1
2
EAU00026
2-DESCRIPTION Left view (XJ600S)1. Fuel cock (page 3-11)
2. Helmet holder (page 3-13)
3. Fuse box (page 6-29)
4. Luggage strap holders (page 3-15)
5. Seat lock (page 3-12)6. Shock absorber assembly
spring preload adjusting ring (page 3-14)
7. Shift pedal (page 3-8)
E_4br.book Page 1 Wednesday, July 25, 2001 1:40 PM

DESCRIPTION
2-2
2
Right view (XJ600S)8. Tail/brake light
9. Storage compartment (page 3-14)
10. Seat (page 3-12)
11. Fuel tank (page 3-9)
12. Headlight (page 6-30)
13. Brake pedal (page 3-9)
E_4br.book Page 2 Wednesday, July 25, 2001 1:40 PM

DESCRIPTION
2-3
2
Controls and instruments (XJ600S)14. Clutch lever (page 3-7)
15. Left handlebar switches (page 3-6)
16. Starter (choke) lever (page 3-12)
17. Speedometer unit (page 3-4)
18. Tachometer (page 3-5)
19. Right handlebar switches (page 3-7)
20. Brake lever (page 3-8)
21. Throttle grip (page 6-13)
22. Main switch/steering lock (page 3-1)E_4br.book Page 3 Wednesday, July 25, 2001 1:40 PM

DESCRIPTION
2-4
2
Left view (XJ600N)1. Steering lock (page 3-3)
2. Fuel cock (page 3-11)
3. Helmet holder (page 3-13)
4. Fuse box (page 6-29)
5. Luggage strap holders (page 3-15)6. Seat lock (page 3-12)
7. Shock absorber assembly spring
preload adjusting ring (page 3-14)
8. Shift pedal (page 3-8)
E_4br.book Page 4 Wednesday, July 25, 2001 1:40 PM

DESCRIPTION
2-5
2
Right view (XJ600N)9. Tail/brake light
10. Storage compartment (page 3-13)
11. Seat (page 3-12)
12. Fuel tank (page 3-9)
13. Headlight (page 6-30)
14. Brake pedal (page 3-9)
E_4br.book Page 5 Wednesday, July 25, 2001 1:40 PM

DESCRIPTION
2-6
2
Controls and instruments (XJ600N)15. Clutch lever (page 3-7)
16. Left handlebar switches (page 3-6)
17. Starter (choke) lever (page 3-12)
18. Speedometer unit (page 3-5)
19. Tachometer (page 3-5)
20. Right handlebar switches (page 3-7)
21. Brake lever (page 3-8)
22. Throttle grip (page 6-13)
23. Main switch (page 3-1)
E_4br.book Page 6 Wednesday, July 25, 2001 1:40 PM

E_4br.book Page 7 Wednesday, July 25, 2001 1:40 PM

3
INSTRUMENT AND CONTROL FUNCTIONS
Main switch/steering lock ..................................... 3-1
Steering lock (for XJ600N).................................... 3-3
Indicator and warning lights ................................ 3-3
Speedometer unit (for XJ600S) ........................... 3-4
Speedometer unit (for XJ600N) ........................... 3-5
Tachometer .......................................................... 3-5
Handlebar switches ............................................. 3-6
Clutch lever .......................................................... 3-7
Shift pedal ............................................................ 3-8
Brake lever .......................................................... 3-8
Brake pedal .......................................................... 3-9
Fuel tank cap ....................................................... 3-9Fuel ................................................................... 3-10
Fuel tank breather hose (for Germany only) ..... 3-11
Fuel cock ........................................................... 3-11
Starter (choke) lever .......................................... 3-12
Seat ................................................................... 3-12
Helmet holders .................................................. 3-13
Storage compartment ....................................... 3-14
Adjusting the shock absorber assembly ............ 3-14
Luggage strap holders ...................................... 3-15
Sidestand .......................................................... 3-15
Ignition circuit cut-off system ............................. 3-16
E_4br.book Page 1 Wednesday, July 25, 2001 1:40 PM

3-1
3
EAU00027
3-INSTRUMENT AND CONTROL FUNCTIONS
EAU00029
Main switch/steering lock The main switch/steering lock controls
the ignition and lighting systems, and is
used to lock the steering. The various
positions are described below.
EAU00036
ON
All electrical systems are supplied with
power, and the engine can be started.
The key cannot be removed.
EAU00038
OFF
All electrical systems are off. The key
can be removed.
EAU00040
LOCK (for XJ600S)
The steering is locked, and all electrical
systems are off. The key can be re-
moved.
To lock the steering1. Turn the handlebars all the way to
the left.
2. Push the key in from the “OFF” po-
sition, and then turn it to “LOCK”
while still pushing it.
3. Remove the key.
To unlock the steeringPush the key in, and then turn it to
“OFF” while still pushing it.
XJ600S
XJ600N
