Specifications
8-3
8
Rear suspension:
Type:
Unit swing
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel:
84 mm (3.3 in)
Electrical system:
System voltage:
12 V
Ignition system:
TCI
Charging system:
AC magneto
Battery:
Model:
GT9B-4
Voltage, capacity:
12 V, 8.0 Ah
Headlight:
Bulb type:
Halogen bulb
Bulb voltage, wattage × quantity:
Headlight:
12 V, 55.0 W × 2
Brake/tail light:
LED
Front turn signal light:
12 V, 10.0 W × 2
Rear turn signal light:
12 V, 10.0 W × 2
Auxiliary light:
12 V, 5.0 W × 2 (YP125R,
YP125RA_CYP/GBR/GRC/IRL/SVN)
Auxiliary light:
LED (YP125RA_CYP/GRC/IRL/SVN)
License plate light:
12 V, 5.0 W × 1
Meter lighting:
LED
High beam indicator light:
LED
Turn signal indicator light:
LED
Fuel level warning light:
LED
Engine trouble warning light:
LED
ABS warning light:
LED (YP125RA)
Fuse:
Main fuse:
30.0 A
Headlight fuse:
20.0 A
Signaling system fuse:
10.0 A
Ignition fuse:
10.0 A
Radiator fan motor fuse:
7.5 A
Turn signal light and hazard fuse:
10.0 A
ECU fuse:
10.0 A
ABS control unit fuse:
10.0 A (YP125RA)
ABS motor fuse:
30.0 A (YP125RA)
ABS solenoid fuse:
20.0 A (YP125RA)
Backup fuse:
10.0 A
U2DME2E0.book Page 3 Tuesday, June 30, 2015 11:38 AM

Consumer information
9-1
9
EAU40793
Identification numbers
Record the vehicle identification num-
ber and model label information in the
spaces provided below for assistance
when ordering spare parts from a
Yamaha dealer or for reference in case
the vehicle is stolen.
VEHICLE IDENTIFICATION NUMBER:
MODEL LABEL INFORMATION:
EAU26411Vehicle identification number
The vehicle identification number is
stamped into the frame.
TIP
The vehicle identification number is
used to identify your vehicle and may
be used to register it with the licensing
authority in your area.
EAU26461Model label
The model label is affixed to the loca-
tion shown. Record the information on
this label in the space provided. This
information will be needed when order-
ing spare parts from a Yamaha dealer.
1. Vehicle identification number
ZAUM0683
1
1. Model label
