Page 5 of 96
Table of contents
Safety information............................1-1
Further safe-riding points ................1-5
Description........................................2-1
Left view ..........................................2-1
Right view........................................2-2
Controls and instruments ................2-3
Instrument and control functions....3-1
Immobilizer system .........................3-1
Main switch/steering lock ...............3-2
Indicator lights and warning
lights ............................................3-4
Multi-function meter unit .................3-6
Handlebar switches.......................3-14
Front brake lever ...........................3-15
Rear brake lever ............................3-16
ABS (for ABS models) ...................3-16
Fuel tank cap.................................3-17
Fuel................................................3-18
Catalytic converters .....................3-19
Seat ...............................................3-20
Storage compartments .................3-21
Adjusting the shock absorber
assemblies .................................3-22
Sidestand ......................................3-23
Ignition circuit cut-off system........3-24
For your safety – pre-operation
checks...............................................4-1
Operation and important riding
points.................................................5-1
Starting the engine ..........................5-2
Starting off.......................................5-3
Acceleration and deceleration.........5-3
Braking ............................................5-4
Tips for reducing fuel
consumption ................................5-5
Engine break-in ...............................5-5
Parking ............................................5-6
Periodic maintenance and
adjustment........................................6-1
Owner’s tool kit ...............................6-2Periodic maintenance chart for the
emission control system.............. 6-3
General maintenance and
lubrication chart........................... 6-4
Removing and installing panels ...... 6-7
Checking the spark plug ................. 6-9
Engine oil ...................................... 6-10
Final transmission oil .................... 6-12
Coolant ......................................... 6-13
Air filter and V-belt case air filter
elements and check hoses........ 6-14
Checking the throttle grip free
play ............................................ 6-16
Valve clearance ............................. 6-16
Tires .............................................. 6-17
Cast wheels .................................. 6-19
Checking the front and rear brake
lever free play ............................ 6-19
Checking the front and rear brake
pads........................................... 6-20
Checking the brake fluid level....... 6-21
Changing the brake fluid............... 6-22
Checking and lubricating the
cables ........................................ 6-23
Checking and lubricating the
throttle grip and cable ............... 6-23
Lubricating the front and rear
brake levers ............................... 6-24
Checking and lubricating the
centerstand and sidestand ........ 6-24
Checking the front fork ................. 6-25
Checking the steering ................... 6-25
Checking the wheel bearings ....... 6-26
Battery .......................................... 6-26
Replacing the fuses ...................... 6-28
Replacing a headlight bulb ........... 6-30
Auxiliary lights ............................... 6-30
Tail/brake light .............................. 6-31
Front turn signal light .................... 6-31
Replacing a rear turn signal light
bulb............................................ 6-32
Replacing the license plate light
bulb............................................ 6-33
Troubleshooting ............................ 6-33
Troubleshooting charts ................. 6-34
U2DLE2E0.book Page 1 Thursday, July 2, 2015 6:20 PM
Page 40 of 96
For your safety – pre-operation checks
4-1
4
EAU63440
Inspect your vehicle each time you use it to make sure the vehicle is in safe oper-
ating condition. Always follow the inspection and maintenance procedures and
schedules described in the Owner’s Manual.
WARNING
EWA11152
Failure to inspect or maintain the vehicle properly increases the possibility
of an accident or equipment damage. Do not operate the vehicle if you find
any problem. If a problem cannot be corrected by the procedures provided
in this manual, have the vehicle inspected by a Yamaha dealer.
Before using this vehicle, check the following points:
ITEM CHECKS PAGE
Fuel• Check fuel level in fuel tank.
• Refuel if necessary.
• Check fuel line for leakage.3-18
Engine oil• Check oil level in engine.
• If necessary, add recommended oil to specified level.
• Check vehicle for oil leakage.6-10
Final transmission oil• Check vehicle for oil leakage. 6-12
Coolant• Check coolant level in reservoir.
• If necessary, add recommended coolant to specified
level.
• Check cooling system for leakage.6-13
Front brake• Check operation.
• If soft or spongy, have Yamaha dealer bleed hydraulic
system.
• Check brake pads for wear.
• Replace if necessary.
• Check fluid level in reservoir.
• If necessary, add specified brake fluid to specified level.
• Check hydraulic system for leakage.6-19,
6-20,
6-21
Rear brake• Check operation.
• If soft or spongy, have Yamaha dealer bleed hydraulic
system.
• Check brake pads for wear.
• Replace if necessary.
• Check fluid level in reservoir.
• If necessary, add specified brake fluid to specified level.
• Check hydraulic system for leakage.6-19,
6-20,
6-21
Throttle grip• Make sure that operation is smooth.
• Check throttle grip free play.
• If necessary, have Yamaha dealer adjust throttle grip
free play and lubricate cable and grip housing.6-16,
6-23
U2DLE2E0.book Page 1 Thursday, July 2, 2015 6:20 PM
Page 89 of 96
Specifications
8-2
8
Clutch:
Clutch type:
Dry, centrifugal automatic
Transmission:
Primary reduction ratio:
(1.000)
Final drive:
Gear
Secondary reduction ratio:
40/15 × 40/14 (7.619)
Transmission type:
V-belt automatic
Operation:
Centrifugal automatic type
Chassis:
Frame type:
Underbone
Caster angle:
28.00 °
Trail:
100 mm (3.9 in)
Front tire:
Type:
Tubeless
Size:
120/70-15 M/C 56P(METZELER)-
56S(MICHELIN)
Manufacturer/model:
METZELER / FEELFREE
Manufacturer/model:
MICHELIN / CITYGRIP
Rear tire:
Type:
Tubeless
Size:
140/70-14 M/C 68P(METZELER)-
68S(MICHELIN)
Manufacturer/model:
METZELER / FEELFREE
Manufacturer/model:
MICHELIN / CITYGRIP
Loading:
Maximum load:
181 kg (399 lb) (YP250RA)
185 kg (408 lb) (YP250R)
(Total weight of rider, passenger, cargo
and accessories)
Tire air pressure (measured on cold
tires):
Loading condition:
0–90 kg (0–198 lb)
Front:
190 kPa (1.90 kgf/cm², 28 psi)
Rear:
220 kPa (2.20 kgf/cm², 32 psi)
Loading condition:
90–181 kg (198–399 lb) (YP250RA)
90–185 kg (198–408 lb) (YP250R)
Loading condition:
90 kg - maximum load
Front:
210 kPa (2.10 kgf/cm², 30 psi)
Rear:
250 kPa (2.50 kgf/cm², 36 psi)
Front wheel:
Wheel type:
Cast wheel
Rim size:
15 x MT3.5
Rear wheel:
Wheel type:
Cast wheel
Rim size:
14 x MT3.75
Front brake:
Type:
Single disc brake
Operation:
Right hand operation
Specified brake fluid:
DOT 4
Rear brake:
Type:
Single disc brake
Operation:
Left hand operation
Specified brake fluid:
DOT 4
Front suspension:
Type:
Telescopic fork
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel:
110 mm (4.3 in)
U2DLE2E0.book Page 2 Thursday, July 2, 2015 6:20 PM
Page 92 of 96
10-1
10
Index
A
ABS (for ABS models) ........................... 3-16
ABS warning light (for ABS models) ....... 3-4
Acceleration and deceleration ................ 5-3
Air filter and V-belt case air filter
elements ............................................. 6-14
Auxiliary lights ....................................... 6-30
B
Battery .................................................. 6-26
Brake fluid, changing ............................ 6-22
Brake fluid level, checking .................... 6-21
Brake lever, front .................................. 3-15
Brake lever, rear.................................... 3-16
Brake levers, lubricating ....................... 6-24
Braking.................................................... 5-4
C
Cables, checking and lubricating ......... 6-23
Care ........................................................ 7-1
Catalytic converters .............................. 3-19
Centerstand and sidestand, checking
and lubricating .................................... 6-24
Coolant ................................................. 6-13
D
Dimmer switch ...................................... 3-14
E
Engine break-in....................................... 5-5
Engine oil .............................................. 6-10
Engine trouble warning light ................... 3-4
F
Final transmission oil ............................ 6-12
Front and rear brake lever free play,
checking ............................................. 6-19
Front and rear brake pads, checking.... 6-20
Front fork, checking .............................. 6-25
Front turn signal light ............................ 6-31
Fuel ....................................................... 3-18
Fuel consumption, tips for reducing ....... 5-5
Fuel level warning light ........................... 3-4
Fuel tank cap ........................................ 3-17
Fuses, replacing.................................... 6-28
H
Handlebar switches .............................. 3-14
Hazard switch ....................................... 3-14
Headlight bulb, replacing ...................... 6-30
High beam indicator light........................ 3-4
Horn switch ........................................... 3-14
I
Identification numbers ............................ 9-1
Ignition circuit cut-off system ............... 3-24
Immobilizer system ................................. 3-1Immobilizer system indicator light.......... 3-5
Indicator lights and warning lights ......... 3-4
Info switch ............................................ 3-15
L
License plate light bulb, replacing........ 6-33
M
Main switch/steering lock....................... 3-2
Maintenance and lubrication, periodic ... 6-4
Maintenance, emission control
system.................................................. 6-3
Matte color, caution ............................... 7-1
Model label ............................................. 9-1
Multi-function meter unit ........................ 3-6
P
Panels, removing and installing.............. 6-7
Parking ................................................... 5-6
Part locations ......................................... 2-1
Pass switch .......................................... 3-14
S
Safe-riding points ................................... 1-5
Safety information .................................. 1-1
Seat ...................................................... 3-20
Shock absorber assemblies,
adjusting............................................. 3-22
Sidestand ............................................. 3-23
Spark plug, checking ............................. 6-9
Specifications ......................................... 8-1
Starting off.............................................. 5-3
Starting the engine ................................. 5-2
Start switch .......................................... 3-14
Steering, checking................................ 6-25
Storage ................................................... 7-4
Storage compartments ........................ 3-21
T
Tail/brake light ...................................... 6-31
Throttle grip and cable, checking and
lubricating .......................................... 6-23
Throttle grip free play, checking........... 6-16
Tires ...................................................... 6-17
Tool kit.................................................... 6-2
Troubleshooting ................................... 6-33
Troubleshooting charts ........................ 6-34
Turn signal indicator lights ..................... 3-4
Turn signal light bulb (rear),
replacing ............................................ 6-32
Turn signal switch ................................ 3-14
V
Valve clearance .................................... 6-16
Vehicle identification number ................. 9-1
U2DLE2E0.book Page 1 Thursday, July 2, 2015 6:20 PM
