Page 21 of 96

YAMAHA XMAX 250 2016 Owners Manual Instrument and control functions
3-7
3 The electric tachometer allows the rid-
er to monitor the engine speed and
keep it within the ideal power range.
NOTICE
ECAM1150
Do not operate the engine in the

Page 22 of 96

YAMAHA XMAX 250 2016 Owners Manual Instrument and control functions
3-8
3Pushing the “TRIP” button switches
the display between the odometer
mode and the various tripmeter modes
in the following order:
Odo (odometer) → Trip (trip

Page 23 of 96

YAMAHA XMAX 250 2016 Owners Manual Instrument and control functions
3-9
3 4. Release the “RESET” button, and
the oil trip value will reset to zero.
TIP
If the engine oil is changed before the
oil change indicator comes on (i.e. be-

Page 24 of 96

YAMAHA XMAX 250 2016 Owners Manual Instrument and control functions
3-10
32. Check that the V-belt replacement
indicator comes on for a few sec-
onds and then goes off.
3. If the V-belt replacement indicator
does not come on, have a Ya

Page 25 of 96

YAMAHA XMAX 250 2016 Owners Manual Instrument and control functions
3-11
3 The temperature displayed may vary
from the ambient temperature. Push-
ing the “INFO” button switches the
ambient temperature display to the
battery voltage

Page 26 of 96

YAMAHA XMAX 250 2016 Owners Manual Instrument and control functions
3-12
3
TIP
After resetting an average fuel con-
sumption display, “_ _._” is shown for
that display until the vehicle has trav-
eled 1 km (0.6 mi).
Instantaneous f

Page 27 of 96

YAMAHA XMAX 250 2016 Owners Manual Instrument and control functions
3-13
3 Self-diagnosis device
This model is equipped with a self-di-
agnosis device for various electrical
circuits.
If a problem is detected in any of those
circuits,

Page 28 of 96

YAMAHA XMAX 250 2016 Owners Manual Instrument and control functions
3-14
3
EAU1234H
Handlebar switches
Left
Right
EAU12351Pass switch “ ”
Press this switch to flash the headlight.
EAU12401Dimmer switch “ / ”
Set this switch to

Page 29 of 96

YAMAHA XMAX 250 2016 Owners Manual Instrument and control functions
3-15
3
NOTICE
ECA10062
Do not use the hazard lights for an
extended length of time with the en-
gine not running, otherwise the bat-
tery may discharge.
EAUM3720Trip/i

Page 30 of 96

YAMAHA XMAX 250 2016 Owners Manual Instrument and control functions
3-16
3
EAU12952
Rear brake lever
The rear brake lever is located on the
left side of the handlebar. To apply the
rear brake, pull this lever toward the
handlebar grip.
