overheating YAMAHA XMAX 300 2021 Owners Manual

Operation and important rid ing points
6-1
6
EAU15952
Read the Owner’s Manual carefully to
become familiar with all controls. If
there is a control or function you do not
understand, ask your Yamaha dealer.
WARNING
EWA10272
Failure to familiarize yourself with
the controls can lead to loss of con-
trol, which coul d cause an acci dent
or injury.
EAU16842
En gine break-inThere is never a more important period
in the life of your engine than the period
between 0 and 1600 km (1000 mi). For
this reason, you should read the fol-
lowing material carefully.
Since the engine is brand new, do not
put an excessive load on it for the first
1600 km (1000 mi). The various parts in
the engine wear and polish themselves
to the correct operating clearances.
During this period, prolonged full-throt-
tle operation or any condition that
might result in engine overheating
must be avoided.
EAU34323
0–1000 km (0–600 mi)
Avoid prolonged operation above 4500
r/min. NOTICE: After 1000 km (600
mi) of operation, be sure to replace
the en gine oil, final transmission oil
an d the oil filter element.
[ECA12932]
1000–1600 km (600–1000 mi)
Avoid prolonged operation above 5400
r/min. 1600 km (1000 mi) an
d b eyon d
The vehicle can now be operated nor-
mally.
NOTICE
ECA10311
 Keep the en gine spee d out of
the tachometer red zone.
 If any en gine trou ble shoul d oc-
cur during the en gine break-in
period , imme diately have a
Yamaha dealer check the vehi-
cle.
UBBAE0E0.book Page 1 Thursday, September 24, 2020 3:19 PM

11-1
11
IndexAABS warning light ................................... 4-2
Acceleration and deceleration ................ 6-3
Air filter and V-belt case air filter
elements ............................................. 7-15
Anti-lock brake system (ABS) ............... 4-14
Auxiliary DC jack ................................... 4-25
Auxiliary lights ....................................... 7-32BBattery .................................................. 7-29
Brake fluid, changing ............................ 7-25
Brake fluid level, checking .................... 7-23
Brake lever, front .................................. 4-13
Brake lever, rear.................................... 4-14
Brake levers, lubricating ....................... 7-26
Brake/tail light ....................................... 7-32
Braking.................................................... 6-3CCables, checking and lubricating ......... 7-25
Canister................................................. 7-10
Care ........................................................ 8-1
Catalytic converter ................................ 4-20
Centerstand and sidestand, checking
and lubricating .................................... 7-27
Coolant ................................................. 7-14DData recording, vehicle ......................... 10-2
Diagnostic connector............................ 10-2
Dimmer/Pass switch ............................. 4-12EEmergency mode.................................. 7-37
Engine break-in....................................... 6-1
Engine oil and oil filter element ............. 7-10
Engine overheating ............................... 7-36 Engine serial number ............................ 10-1
FFinal transmission oil ............................ 7-13
Front and rear brake lever free play,
checking............................................. 7-22
Front and rear brake pads, checking ... 7-23
Front fork, checking ............................. 7-27
Front turn signal light............................ 7-32
Fuel ....................................................... 4-18
Fuel consumption, tips for reducing ...... 6-4
Fuel tank cap ........................................ 4-17
Fuel tank overflow hose ....................... 4-19
Fuses, replacing ................................... 7-30HHandlebar position, adjusting .............. 4-24
Handlebar switches .............................. 4-12
Hazard switch....................................... 4-13
Headlights ............................................ 7-31
High beam indicator light ....................... 4-1
Horn switch .......................................... 4-12IIdentification numbers .......................... 10-1
Ignition circuit cut-off system ............... 4-27
Indicator lights and warning lights ......... 4-1KKey, handling of smart and mechanical keys ...................................................... 3-3LLicense plate light bulb, replacing........ 7-33MMain switch ............................................ 3-8
Maintenance and lubrication, periodic ... 7-4
Maintenance, emission control system.................................................. 7-3 Malfunction indicator light (MIL)..............4-1
Matte color, caution ................................8-1
Model label ...........................................10-1
Multi-function display .............................4-4
OOperating range of the smart key
system ..................................................3-2PPanel, removing and installing ................7-8
Parking ....................................................6-4
Part locations ..........................................2-1SSafe-riding points....................................1-5
Safety information ...................................1-1
Shock absorber assemblies, adjusting .............................................4-25
Sidestand ..............................................4-26
Smart key ................................................3-5
Smart key battery, replacing ...................3-6
Smart key system ...................................3-1
Smart key system indicator light.............4-2
Smart key system, troubleshooting ......7-34
Spark plug, checking ..............................7-9
Specifications .........................................9-1
Speedometer ..........................................4-3
Starting off ..............................................6-3
Starting the engine ..................................6-2
Steering, checking ................................7-28
Stop/Run/Start switch ..........................4-13
Storage ...................................................8-3
Storage compartments .........................4-20TTachometer .............................................4-3
