Consumer information
9-1
9
EAU53562
Identification numbersRecord the vehicle identification num-
ber, engine serial number, and the
model label information in the spaces
provided below. These identification
numbers are needed when registering
the vehicle with the authorities in your
area and when ordering spare parts
from a Yamaha dealer.
VEHICLE IDENTIFICATION NUMBER:
ENGINE SERIAL NUMBER:
MODEL LABEL INFORMATION:
EAU26401
Vehicle identification number
The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.TIPThe vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in your
area.
EAU26442
Engine serial number
The engine serial number is stamped
into the crankcase.
EAU26542
Model label
1. Vehicle identification numberZAUM1630
1
1. Engine serial number
1. Model label
1
ZAUM1369
1
UBCNE0E0.book Page 1 Monday, February 4, 2019 10:04 AM

Consumer information
9-2
9The model label is affixed to the frame
under the seat. (See page 3-18.) Re-
cord the information on this label in the
space provided. This information will
be needed when ordering spare parts
from a Yamaha dealer.
EAU69910
Diagnostic connectorThe diagnostic connector is located as
shown.
EAU85300
Vehicle data recordingThis model’s ECU stores certain vehi-
cle data to assist in the diagnosis of
malfunctions and for research, statisti-
cal analysis and development purpos-
es.
Although the sensors and recorded
data will vary by model, the main data
points are:
Vehicle status and engine perfor-
mance data
Fuel-injection and emission-relat-
ed data
This data will be uploaded only when a
special Yamaha diagnostic tool is at-
tached to the vehicle, such as when
maintenance checks or service proce-
dures are performed.
Vehicle data uploaded will be handled
appropriately according to the follow-
ing Privacy Policy.
Privacy Policy
1. Diagnostic connectorZAUM1370
1
https://www.yamaha-motor.eu/eu/
privacy/privacy-policy.aspx
UBCNE0E0.book Page 2 Monday, February 4, 2019 10:04 AM

Consumer information
9-3
9 Yamaha will not disclose this data to a
third party except in the following cas-
es. In addition, Yamaha may provide
vehicle data to a contractor in order to
outsource services related to the han-
dling of vehicle data. Even in this case,
Yamaha will require the contractor to
properly handle the vehicle data we
provided and Yamaha will appropriate-
ly manage the data.
With the consent of the vehicle
owner
Where obligated by law
For use by Yamaha in litigation
When the data is not related to an
individual vehicle nor owner
UBCNE0E0.book Page 3 Monday, February 4, 2019 10:04 AM

10-1
10
IndexAABS ....................................................... 3-14
ABS warning light ................................... 3-4
Air filter element and check hose,
replacing and cleaning ....................... 6-15
Auxiliary DC connector ......................... 3-21
Auxiliary light bulb, replacing ................ 6-35BBattery .................................................. 6-29
Brake and clutch levers, checking and
lubricating ........................................... 6-26
Brake and shift pedals, checking and
lubricating ........................................... 6-26
Brake fluid, changing ............................ 6-22
Brake fluid level, checking .................... 6-21
Brake lever ............................................ 3-13
Brake lever free play, checking............. 6-19
Brake light switches.............................. 6-20
Brake pedal........................................... 3-13CCables, checking and lubricating ......... 6-25
Canister................................................. 6-10
Care ........................................................ 7-1
Catalytic converter ................................ 3-17
Clutch lever ........................................... 3-12
Clutch lever free play, adjusting ........... 6-19
Coolant ................................................. 6-13
Coolant temperature warning light ......... 3-4DData recording, vehicle ........................... 9-2
Diagnostic connector.............................. 9-2
Dimmer switch ...................................... 3-12
Drive chain, cleaning and lubricating .... 6-24
Drive chain slack................................... 6-23
EEngine break-in ...................................... 5-4
Engine oil and oil filter cartridge ........... 6-10
Engine overheating ............................... 6-39
Engine serial number .............................. 9-1
Engine trouble warning light ................... 3-4FFront and rear brake pads, checking ... 6-20
Front fork, checking ............................. 6-28
Fuel ....................................................... 3-15
Fuel consumption, tips for reducing ...... 5-3
Fuel tank breather hose and overflow
hose ................................................... 3-17
Fuel tank cap ........................................ 3-15
Fuses, replacing ................................... 6-31HHandlebar switches .............................. 3-11
Hazard switch....................................... 3-12
Headlight bulb, replacing ..................... 6-33
Helmet holding cable ........................... 3-18
High beam indicator light ....................... 3-4
Horn switch .......................................... 3-12IIdentification numbers ............................ 9-1
Ignition circuit cut-off system ............... 3-22
Immobilizer system ................................ 3-1
Immobilizer system indicator light .......... 3-5
Indicator lights and warning lights ......... 3-3LLicense plate light ................................ 6-36MMain switch/steering lock....................... 3-2
Maintenance and lubrication, periodic ... 6-5Maintenance, emission control
system ..................................................6-3
Matte color, caution ................................7-1
Model label .............................................9-1
Multi-function meter unit .........................3-5
NNeutral indicator light ..............................3-4OOil pressure warning light .......................3-4PParking ....................................................5-4
Part locations ..........................................2-1
Pass switch ...........................................3-12RRear suspension, lubricating ................6-27SSafety information ...................................1-1
Seat .......................................................3-18
Shifting ....................................................5-2
Shift pedal .............................................3-13
Shock absorber assembly, adjusting ....3-20
Sidestand ..............................................3-21
Sidestand, checking and lubricating.....6-27
Spark plugs, checking ............................6-9
Specifications .........................................8-1
Start/Engine stop switch .......................3-12
Starting the engine ..................................5-1
Steering, checking ................................6-29
Storage ...................................................7-3
Supporting the motorcycle ...................6-37
Swingarm pivots, lubricating ................6-28TTail/brake light ......................................6-35
UBCNE0E0.book Page 1 Monday, February 4, 2019 10:04 AM

Index
10-2
10
Throttle grip and cable, checking and
lubricating........................................... 6-25
Throttle grip free play, checking ........... 6-15
Tires ...................................................... 6-16
Tool kit .................................................... 6-2
Troubleshooting.................................... 6-37
Troubleshooting chart .......................... 6-38
Turn signal indicator lights ..................... 3-3
Turn signal light bulb, replacing ........... 6-36
Turn signal switch................................. 3-12VValve clearance .................................... 6-16
Vehicle identification number ................. 9-1WWheel bearings, checking .................... 6-29
Wheels .................................................. 6-18YYamalube.............................................. 6-13
