PERIODIC MAINTENANCE AND ADJUSTMENT
6-16
6
4. Add coolant or distilled water to
raise the coolant to the maximum
level mark, install the coolant res-
ervoir cap. WARNING! Remove
only the coolant reservoir cap.
Never attempt to remove the ra-
diator cap when the engine is
hot.
[EWA15161]
NOTICE: If coolant is
not available, use distilled water
or soft tap water instead. Do not
use hard water or salt water
since it is harmful to the engine.
If water has been used instead
of coolant, replace it with cool-
ant as soon as possible, other-
wise the cooling system will not
be protected against frost and
corrosion. If water has been
added to the coolant, have a
Yamaha dealer check the anti- freeze content of the coolant as
soon as possible, otherwise the
effectiveness of the coolant will
be reduced. [ECA10472] EAU33031
Changing the coolant
The coolant must be changed at the in-
tervals specified in the periodic mainte-
nance and lubrication chart. Have a
Yamaha dealer change the coolant.
WARNING! Never attempt to remove
the radiator cap when the engine is
hot.
[EWA10381]
EAU36764
Air filter element The air filter element must be replaced
at the intervals specified in the periodic
maintenance and lubrication chart.
Have a Yamaha dealer replace the air
filter element.
Coolant reservoir capacity (up to
the maximum level mark):
0.26 L (0.27 US qt, 0.23 Imp.qt)
U23PE2E0.book Page 16 Monday, August 1, 2011 4:25 PM
Page 74 of 108
PERIODIC MAINTENANCE AND ADJUSTMENT
6-17
6
EAU44734
Checking the engine idling
speed Check the engine idling speed and, if
necessary, have it corrected by a
Yamaha dealer.
EAU21384
Checking the throttle grip free
play The throttle grip free play should mea-
sure 3.0 –5.0 mm (0.12 –0.20 in) at the
inner edge of the throttle grip. Periodi-
cally check the throttle grip free play
and, if necessary, have a Yamaha deal-
er adjust it.
EAU21401
Valve clearance The valve clearance changes with use,
resulting in improper air-fuel mixture
and/or engine noise. To prevent this
from occurring, the valve clearance
must be adjusted by a Yamaha dealer
at the intervals specified in the periodic
maintenance and lubrication chart.
Engine idling speed: 1050 –1150 r/min
1. Throttle grip free play
1
U23PE2E0.book Page 17 Monday, August 1, 2011 4:25 PM
Page 81 of 108
PERIODIC MAINTENANCE AND ADJUSTMENT
6-24
6
EAU23095
Checking and lubricating the
cables The operation of all control cables and
the condition of the cables should be
checked before each ride, and the ca-
bles and cable ends should be lubricat-
ed if necessary. If a cable is damaged
or does not move smoothly, have a
Yamaha dealer check or replace it.
WARNING! Damage to the outer housing of cables may result in in-
ternal rusting and cause interfer-
ence with cable movement. Replace
damaged cables as soon as possi-
ble to prevent unsafe conditions.[EWA10711] EAU23114
Checking and lubricating the
throttle grip and cable The operation of the throttle grip should
be checked before each ride. In addi-
tion, the cable should be lubricated by a
Yamaha dealer at the intervals speci-
fied in the periodic maintenance chart.
The throttle cable is equipped with a
rubber cover. Make sure that the cover
is securely installed. Even though the
cover is installed correctly, it does not
completely protect the cable from water
entry. Therefore, use care not to pour
water directly onto the cover or cable
when washing the vehicle. If the cable
or cover becomes dirty, wipe clean with
a moist cloth.
EAU44273
Checking and lubricating the
brake and shift pedals The operation of the brake and shift
pedals should be checked before each
ride, and the pedal pivots should be lu-
bricated if necessary.
Recommended lubricant:
Yamaha Chain and Cable Lube or
engine oil
U23PE2E0.book Page 24 Monday, August 1, 2011 4:25 PM
Page 94 of 108
PERIODIC MAINTENANCE AND ADJUSTMENT
6-37
6
EAU42503
Troubleshooting charts Starting problems or poor engine performance
Check the fuel level in
the fuel tank.1. Fuel
There is enough fuel.There is no fuel.
Check the compression.
Supply fuel.
The engine does not start.
Check the compression.
Operate the electric starter.2. Compression
There is compression.
There is no compression.
Check the ignition. Have a Yamaha dealer
check the vehicle.
Remove the spark plugs
and check the electrodes.3. Ignition
Wipe off with a dry cloth and correct the
spark plug gaps, or replace the spark plugs.
Have a Yamaha dealer check the vehicle.
The engine does not start.
Have a Yamaha dealer
check the vehicle.
The engine does not start.
Check the battery.
Operate the electric starter.4. Battery
The engine turns over
quickly.
The engine turns over
slowly.
The battery is good.Check the battery lead connections,
and have a Yamaha dealer charge
the battery if necessary.
DryWet
Operate the electric starter.
U23PE2E0.book Page 37 Monday, August 1, 2011 4:25 PM
Page 95 of 108
PERIODIC MAINTENANCE AND ADJUSTMENT
6-38
6
Engine overheating
WARNING
EWAT1040
Do not remove the radiator cap when the engine and radiator are hot. Scalding hot fluid and steam may be
blown out under pressure, which could cause serious injury. Be sure to wait until the engine has cooled.
Place a thick rag, like a towel, over the radiator cap, and then slowly rotate the cap counterclockwise to the de-
tent to allow any residual pressure to escape. When the hissing sound has stopped, press down on the cap
while turning it counterclockwise, and then remove the cap.
TIPIf coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant
as soon as possible.
Wait until the
engine has cooled.
Check the coolant level in the
reservoir and radiator.
The coolant level
is OK.The coolant level is low.
Check the cooling system
for leakage.
Have a Yamaha dealer checkand repair the cooling system.Add coolant. (See TIP.)
Start the engine. If the engine overheats again,
have a
Yamaha dealer check
and repair the cooling system.
There is
leakage.
There is
no leakage.
U23PE2E0.book Page 38 Monday, August 1, 2011 4:25 PM
Page 99 of 108
MOTORCYCLE CARE AND STORAGE
7-4
7
2. Fill up the fuel tank and add fuel
stabilizer (if available) to prevent
the fuel tank from rusting and the
fuel from deteriorating.
3. Perform the following steps to pro- tect the cylinders, piston rings, etc.
from corrosion.a. Remove the spark plug caps and spark plugs.
b. Pour a teaspoonful of engine oil into each spark plug bore.
c. Install the spark plug caps onto the spark plugs, and then place
the spark plugs on the cylinder
head so that the electrodes are
grounded. (This will limit spark-
ing during the next step.)
d. Turn the engine over several times with the starter. (This will
coat the cylinder walls with oil.)
WARNING! To prevent dam- age or injury from sparking,
make sure to ground the
spark plug electrodes while
turning the engine over.
[EWA10951]
e. Remove the spark plug caps from the spark plugs, and then
install the spark plugs and the
spark plug caps.
4. Lubricate all control cables and the pivoting points of all levers and
pedals as well as of the side-
stand/centerstand.
5. Check and, if necessary, correct the tire air pressure, and then lift
the motorcycle so that both of its
wheels are off the ground. Alterna-
tively, turn the wheels a little every
month in order to prevent the tires
from becoming degraded in one
spot.
6. Cover the muffler outlet with a plastic bag to prevent moisture
from entering it.
7. Remove the battery and fully charge it. Store it in a cool, dry
place and charge it once a month.
Do not store the battery in an ex-
cessively cold or warm place [less
than 0 ° C (30 °F) or more than 30
° C (90 °F)]. For more information
on storing the battery, see page
6-28.
TIPMake any necessary repairs before
storing the motorcycle.
U23PE2E0.book Page 4 Monday, August 1, 2011 4:25 PM
Page 104 of 108
INDEXAABS ....................................................... 3-20
ABS warning light.................................... 3-7
Air filter element .................................... 6-16
Anti-theft alarm (optional)...................... 3-15
Auxiliary DC jack ................................... 3-35
Auxiliary light bulb, replacing ................ 6-34BBattery................................................... 6-28
Brake and clutch fluids, changing ......... 6-23
Brake and clutch levers, checking and lubricating ........................................... 6-25
Brake and shift pedals, checking and lubricating ........................................... 6-24
Brake fluid level, checking .................... 6-22
Brake lever ............................................ 3-18
Brake lever free play, checking ............. 6-20
Brake light switches .............................. 6-21
Brake pedal ........................................... 3-19CCables, checking and lubricating .......... 6-24
Care ........................................................ 7-1
Carriers ................................................. 3-31
Catalytic converter ................................ 3-24
Centerstand and sidestand, checking and lubricating .................................... 6-26
Clutch lever .................................. 3-17, 6-20
Coolant.................................................. 6-15
Coolant temperature warning light .......... 3-5
Cowlings, removing and installing........... 6-8DDimmer switch ...................................... 3-16
D-mode (drive mode) .............................. 3-1
EEngine break-in ...................................... 5-3
Engine idling speed, checking .............. 6-17
Engine oil and oil filter cartridge ........... 6-11
Engine stop switch................................ 3-16
Engine trouble warning light ................... 3-7FFinal gear oil ......................................... 6-14
Front and rear brake pads, checking .... 6-21
Front fork, adjusting .............................. 3-28
Front fork, checking .............................. 6-27
Fuel....................................................... 3-23
Fuel consumption, tips for reducing........ 5-3
Fuel tank breather hose and overflow hose ................................................... 3-24
Fuel tank cap ........................................ 3-22
Fuses, replacing ................................... 6-29HHandlebar switches .............................. 3-16
Hazard switch ....................................... 3-17
Headlight bulb, replacing ...................... 6-31
High beam indicator light ........................ 3-5
Horn switch ........................................... 3-16IIdentification numbers ............................ 9-1
Ignition circuit cut-off system ................ 3-33
Immobilizer system ................................. 3-1
Immobilizer system indicator light........... 3-8
Indicator lights and warning lights .......... 3-4LLicense plate light bulb, replacing ........ 6-33
Luggage strap holders .......................... 3-32MMain switch/steering lock........................ 3-3 Maintenance and lubrication, periodic..... 6-4
Maintenance, emission control system ... 6-3
Matte color, caution ................................. 7-1
Model label .............................................. 9-1
Multi-function meter unit .......................... 3-8
NNeutral indicator light .............................. 3-5OOil level warning light .............................. 3-5PParking .................................................... 5-4
Part locations .......................................... 2-1
Pass switch ........................................... 3-16RRider seat .............................................. 3-25
Rider seat height, adjusting................... 3-26SSafety information ................................... 1-1
Shifting .................................................... 5-2
Shift pedal ............................................. 3-18
Shock absorber assembly, adjusting .... 3-30
Sidestand .............................................. 3-32
Spark plugs, checking ........................... 6-10
Specifications .......................................... 8-1
Starting the engine .................................. 5-1
Start switch............................................ 3-16
Steering, checking................................. 6-27
Storage.................................................... 7-3
Swingarm pivots, lubricating ................. 6-26TTail/brake light ....................................... 6-32
Throttle grip and cable, checking and
lubricating ........................................... 6-24
Throttle grip free play, checking ............ 6-17
U23PE2E0.book Page 1 Monday, August 1, 2011 4:25 PM
