Specifications
8-2
8
2nd:2.063 (33/16)
3rd: 1.571 (33/21)
4th:
1.250 (30/24)
5th: 1.042 (25/24)
6th: 0.929 (26/28)
Chassis:
Frame type:Backbone
Caster angle: 28.0 °
Trail: 126 mm (5.0 in)
Front tire:
Type:Tubeless
Size: 110/80R19M/C 59V
Manufacturer/model:
BRIDGESTONE/BW501
Rear tire:
Type:Tubeless
Size:
150/70R17M/C 69V
Manufacturer/model: BRIDGESTONE/BW502
Loa din g:
Maximum load:
212 kg (467 lb)
(Total weight of rider, passenger, cargo
and accessories)
Tire air pressure (measure d on col d
tires):
1 person:
Front:
225 kPa (2.25 kgf/cm², 33 psi)
Rear: 250 kPa (2.50 kgf/cm², 36 psi)
2 persons: Front: 225 kPa (2.25 kgf/cm², 33 psi)
Rear: 290 kPa (2.90 kgf/cm², 42 psi)
Front wheel:
Wheel type:Spoke wheel
Rim size:
19M/C x MT2.50
Rear wheel:
Wheel type:Spoke wheel
Rim size:
17M/C x MT4.00
Unifie d b rake system:
Operation:
Activated by front brake
Front brake:
Type:
Hydraulic dual disc brake
Specified brake fluid: DOT 4
Rear brake:
Type:
Hydraulic single disc brake
Specified brake fluid: DOT 4
Front suspension:
Type:
Telescopic fork
Spring: Coil spring
Shock absorber: Hydraulic damper
Wheel travel:
190 mm (7.5 in)
Rear suspension:
Type:Swingarm (link suspension)
Spring:
Coil spring
Shock absorber: Gas-hydraulic damper
Wheel travel: 190 mm (7.5 in)
Electrical system:
System voltage:12 V
Ignition system: TCI
Charging system:
AC magneto
UBP8E0E0.book Page 2 Thursday, December 8, 2016 7:25 PM

Specifications
8-3
8
Battery:
Model:YTZ12S
Voltage, capacity:
12 V, 11.0 Ah (10 HR)
Hea dlig ht:
Bulb type:
Halogen bulb
Bul b watta ge:
Headlight:
H7, 55.0 W
Brake/tail light: LED
Front turn signal light:
LED
Rear turn signal light:
LED
Auxiliary light: 5.0 W
License plate light: 5.0 W
Meter lighting:
LED
Neutral indicator light: LED
High beam indicator light: LED
Oil level warning light:
LED
Turn signal indicator light: LED
Engine trouble warning light: LED
ABS warning light:
LED
Cruise control “SET” indicator light: LED
Cruise control “ON” indicator light: LED
Immobilizer system indicator light:
LED
Traction control system indicator/warning
light:
LED
Fuse(s):
Main fuse:50.0 A
Terminal fuse 1:
3.0 A Headlight fuse:
20.0 A
Brake light fuse: 1.0 A
Signaling system fuse:
7.5 A
Ignition fuse: 20.0 A
Parking lighting fuse: 7.5 A
Radiator fan motor fuse:
20.0 A
Fuel injection system fuse: 20.0 A
ABS control unit fuse: 7.5 A
ABS motor fuse: 30.0 A
ABS solenoid fuse:
20.0 A
Cruise control fuse: 1.0 A
Backup fuse: 7.5 A
Electronic throttle valve fuse:
7.5 A
O/P (option) fuse: 20.0 A
UBP8E0E0.book Page 3 Thursday, December 8, 2016 7:25 PM

Consumer information
9-1
9
EAU53562
Id entification num bers
Record the vehicle identification num-
ber, engine serial number, and the
model label information in the spaces
provided below. These identification
numbers are needed when registering
the vehicle with the authorities in your
area and when ordering spare parts
from a Yamaha dealer.
VEHICLE IDENTIFICATION NUMBER:
ENGINE SERIAL NUMBER:
MODEL LABEL INFORMATION:
EAU26401Vehicle i dentification num ber The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.
TIP
The vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in your
area.
EAU26442En
gine serial num ber
The engine serial number is stamped
into the crankcase.
EAU26471Mo del la bel
The model label is affixed to the frame
under the rider seat. (See page 3-30.)
Record the information on this label in
1. Vehicle identification number
1
1. Engine serial number
1. Model label
1
1
UBP8E0E0.book Page 1 Thursday, December 8, 2016 7:25 PM

Consumer information
9-2
9the space provided. This information
will be needed when ordering spare
parts from a Yamaha dealer.
EAU69910
Dia
gnostic connector
The diagnostic connector is located as
shown.
1. Diagnostic connector
1
UBP8E0E0.book Page 2 Thursday, December 8, 2016 7:25 PM

Consumer information
9-3
9
EAU74701
Vehicle data record ing
This model’s ECU stores certain vehi-
cle data to assist in the diagnosis of
malfunctions and for research and de-
velopment purposes. This data will be
uploaded only when a special Yamaha
diagnostic tool is attached to the vehi-
cle, such as when maintenance checks
or service procedures are performed.
Although the sensors and recorded
data will vary by model, the main data
points are:
 Vehicle status and engine perfor-
mance data
 Fuel-injection and emission-relat-
ed data
Yamaha will not disclose this data to a third party except:  With the consent of the vehicle
owner
 Where obligated by law
 For use by Yamaha in litigation
 For general Yamaha-conducted
research purposes when the data
is not related to an individual vehi-
cle nor owner
UBP8E0E0.book Page 3 Thursday, December 8, 2016 7:25 PM

10-1
10
Index
A
ABS ....................................................... 3-24
ABS warning light ................................... 3-5
Air filter element .................................... 6-17
Auxiliary DC jack ................................... 3-42
Auxiliary light bulb, replacing ................ 6-35
B
Battery .................................................. 6-30
Brake and clutch fluids, changing ........ 6-26
Brake and clutch levers, checking and
lubricating ........................................... 6-27
Brake and shift pedals, checking and
lubricating ........................................... 6-27
Brake fluid level, checking .................... 6-25
Brake lever ............................................ 3-23
Brake lever free play, checking............. 6-23
Brake light switches.............................. 6-23
Brake pedal........................................... 3-24
C
Canister................................................. 6-10
Care ........................................................ 7-1
Carriers ................................................. 3-38
Catalytic converter ................................ 3-30
Clutch lever ................................. 3-22, 6-22
Coolant ................................................. 6-16
Cowlings, removing and installing .......... 6-7
Cruise control indicator lights ................. 3-4
Cruise control switches ........................ 3-21
Cruise control system ............................. 3-6
D
Data recording, vehicle ........................... 9-3
Diagnostic connector.............................. 9-2
Dimmer/Pass switch ............................. 3-20
D-mode (drive mode) ............................ 3-20
E
Engine break-in....................................... 5-4
Engine idling speed, checking .............. 6-18
Engine oil and oil filter cartridge ........... 6-10
Engine serial number .............................. 9-1
Engine trouble warning light ................... 3-5
F
Final gear oil.......................................... 6-14
Front and rear brake pads, checking.... 6-24
Front fork, adjusting.............................. 3-34
Front fork, checking .............................. 6-29
Fuel ....................................................... 3-28
Fuel consumption, tips for reducing ....... 5-4
Fuel tank cap ........................................ 3-27
Fuel tank overflow hose ........................ 3-29
Fuses, replacing.................................... 6-32
H
Handlebar switches .............................. 3-20
Hazard switch....................................... 3-21
Headlight bulb, replacing ..................... 6-33
High beam indicator light ....................... 3-4
Horn switch .......................................... 3-21
I
Identification numbers ............................ 9-1
Ignition circuit cut-off system............... 3-40
Immobilizer system ................................ 3-1
Immobilizer system indicator light.......... 3-5
Indicator lights and warning lights ......... 3-4
L
License plate light bulb, replacing........ 6-38
Luggage strap holders ......................... 3-39
M
Main switch/steering lock....................... 3-2
Maintenance and lubrication, periodic ... 6-4
Maintenance, emission control system.................................................. 6-3
Matte color, caution ............................... 7-1
Menu switch ......................................... 3-21
Model label ............................................. 9-1
Multi-function meter unit ........................ 3-9
N
Neutral indicator light ............................. 3-4
O
Oil level warning light ............................. 3-4
P
Parking ................................................... 5-5
Part locations ......................................... 2-1
R
Rider seat ............................................. 3-30
Rider seat height, adjusting.................. 3-31
S
Safety information .................................. 1-1
Select switch ........................................ 3-21
Shifting ................................................... 5-3
Shift pedal ............................................ 3-22
Shock absorber assembly, adjusting ... 3-36
Sidestand ............................................. 3-39
Sidestand, checking and lubricating .... 6-28
Spark plugs, checking ............................ 6-9
Specifications ......................................... 8-1
Starting the engine ................................. 5-2
Steering, checking................................ 6-29
Stop/Run/Start switch .......................... 3-21
Storage ................................................... 7-4
Supporting the motorcycle................... 6-39
Swingarm pivots, lubricating ................ 6-28
UBP8E0E0.book Page 1 Thursday, December 8, 2016 7:25 PM

Index
10-2
10
T
Throttle grip and cable, checking and
lubricating .......................................... 6-26
Throttle grip free play, checking........... 6-18
Tires...................................................... 6-19
Tool kit.................................................... 6-2
Traction control system........................ 3-25
Traction control system indicator light ... 3-5
Troubleshooting ................................... 6-39
Troubleshooting charts ........................ 6-40
Turn signal indicator lights ..................... 3-4
Turn signal light and brake/tail light ..... 6-37
Turn signal switch ................................ 3-21
V
Valve clearance .................................... 6-19
Vehicle identification number ................. 9-1
W
Wheel bearings, checking .................... 6-30
Wheels.................................................. 6-22
Windshield............................................ 3-33
UBP8E0E0.book Page 2 Thursday, December 8, 2016 7:25 PM

A5-tate_Blank.fm Page 1 Thursday, November 24, 2011 4:30 PM

A5-tate_Blank.fm Page 1 Thursday, November 24, 2011 4:30 PM

DIC183
Original instructions
PRINTED ON RECYCLED PAPERPRINTED IN JAPAN
2016.12-0.3×1 CR (E)
