fuses YAMAHA XT1200ZE 2015 Owners Manual

TABLE OF CONTENTS
Battery ...........................................6-28
Replacing the fuses .......................6-30
Replacing a headlight bulb............6-31
Replacing an auxiliary light bulb....6-33
Turn signal light and tail/brake light ............................................6-35
Replacing a license plate light bulb ............................................6-35
Troubleshooting ............................6-36
Troubleshooting charts .................6-37
MOTORCYCLE CARE AND
STORAGE ..........................................7-1
Matte color caution .........................7-1
Care .................................................7-1
Storage ............................................7-4
SPECIFICATIONS ..............................8-1
CONSUMER INFORMATION ............9-1
Identification numbers .....................9-1
INDEX ...............................................10-1
U2KBE1E0.book Page 2 Monday, August 18, 2014 9:42 AM

DESCRIPTION
2-2
2
EAU10421
Right view
1
5
6
9
7
8
2
3
4
1. Rear brake fluid reservoir (page 6-23)
2. Electronically adjustable suspension system (page 3-37)
3. Fuses (page 6-30)
4. Fuse box (page 6-30)
5. Owner’s tool kit (page 6-2)
6. Battery (page 6-28)
7. Engine oil filler cap (page 6-11)
8. Engine oil level check window (page 6-11) 9. Brake pedal (page 3-28)U2KBE1E0.book Page 2 Monday, August 18, 2014 9:42 AM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-30
6
EAU58961
Replacing the fusesThe fuse boxes and the ABS motor
fuse are located behind cowling A, and
the main fuse, the cruise control fuse
and the brake light fuse are located be-
hind cowling B. (See page 6-8.)
If a fuse is blown, replace it as follows.1. Turn the key to “OFF” and turn off the electrical circuit in question. 2. Remove the blown fuse, and then
install a new fuse of the specified
amperage. WARNING! Do not
use a fuse of a hi gher ampera ge
ratin g than recommen ded to
avoi d causin g extensive d am-
a g e to the electrical system an d
possi bly a fire.
[EWA15132]
1. ABS motor fuse
2. ABS motor spare fuse
3. Main fuse
4. Spare fuse
5. Cruise control fuse
6. Brake light fuse
7. Fuse box123
5
67
4
1. Headlight fuse
2. ABS solenoid fuse
3. Electronic throttle valve fuse
4. Fuel injection system fuse
5. Backup fuse (for clock and immobilizer sys-
tem)
6. Radiator fan motor fuse
7. Ignition fuse
8. Signaling system fuse
9. ABS control unit fuse
10.Auxiliary DC jack fuse
11.Parking lighting fuse
12.O/P (option) fuse
13.Suspension fuse
14.Spare fuse
13456
2
7
8
9
10
14
13
11
12
14
U2KBE1E0.book Page 30 Monday, August 18, 2014 9:42 AM

PERIODIC MAINTENANCE AND ADJUSTMENT
6-31
6
3. Turn the key to “ON” and turn on
the electrical circuit in question to
check if the device operates.
4. If the fuse immediately blows again, have a Yamaha dealer
check the electrical system.
EAU39014
Replacin g a hea dlig ht bul bThis model is equipped with halogen
bulb headlights. If a headlight bulb
burns out, replace it as follows.NOTICE
ECA10651
Take care not to d amage the follow-
in g parts:
 Hea dlig ht bul b
Do not touch the glass part of
the hea dlig ht bul b to keep it free
from oil, otherwise the transpar-
ency of the glass, the luminosity
of the bul b, an d the bul b life will
b e a dversely affected . Thor-
ou ghly clean off any dirt an d fin-
g erprints on the head lig ht bul b
usin g a cloth moistene d with al-
cohol or thinner.
 Hea dlig ht lens
Do not affix any type of tinted
film or stickers to the hea dlig ht
lens.
Do not use a hea dlig ht bul b of a
watta ge hi gher than specified .
Specified fuses:
Main fuse:
50.0 A
Headlight fuse: 20.0 A
Brake light fuse: 1.0 A
Parking lighting fuse:
7.5 A
Signaling system fuse: 7.5 A
Ignition fuse: 20.0 A
Radiator fan motor fuse:
20.0 A
Backup fuse: 7.5 A
Electronic throttle valve fuse: 7.5 A
Fuel injection system fuse:
20.0 A
ABS solenoid fuse: 20.0 A
ABS control unit fuse: 7.5 A
ABS motor fuse:
30.0 A
Suspension fuse: 15.0 A
Cruise control fuse: 1.0 A
Auxiliary DC jack fuse:
3.0 A
O/P (option) fuse: 20.0 A
U2KBE1E0.book Page 31 Monday, August 18, 2014 9:42 AM

SPECIFICATIONS
8-3
8
Electrical system:Ignition system:TCI
Charging system:
AC magnetoBattery:Model:YTZ12S
Voltage, capacity:
12 V, 11.0 AhHea dlig ht:Bulb type:
Halogen bulbBul b volta ge, watta ge × quantity:Headlight:
12 V, 55.0 W × 2
Tail/brake light: LED
Front turn signal light:
LED
Rear turn signal light: LED
Auxiliary light: 12 V, 5.0 W × 2
License plate light:
12 V, 5.0 W × 1
Meter lighting: LED
Neutral indicator light: LED
High beam indicator light:
LED
Oil level warning light: LED Turn signal indicator light:
LED
Engine trouble warning light: LED
ABS warning light:
LED
Cruise control “SET” indicator light: LED
Cruise control “ON” indicator light: LED
Immobilizer system indicator light:
LED
Traction control system indicator/warning
light:
LED
Suspension warning light: LED
Fuses:Main fuse:
50.0 A
Headlight fuse: 20.0 A
Brake light fuse: 1.0 A
Signaling system fuse:
7.5 A
Ignition fuse: 20.0 A
Parking lighting fuse: 7.5 A
Radiator fan motor fuse:
20.0 A
Fuel injection system fuse: 20.0 A ABS control unit fuse:
7.5 A
ABS motor fuse: 30.0 A
ABS solenoid fuse:
20.0 A
Suspension fuse: 15.0 A
Cruise control fuse: 1.0 A
Auxiliary DC jack fuse:
3.0 A
Backup fuse: 7.5 A
Electronic throttle valve fuse: 7.5 A
O/P (option) fuse:
20.0 A
U2KBE1E0.book Page 3 Monday, August 18, 2014 9:42 AM

10-1
10
INDEX
AABS....................................................... 3-28
ABS warning light ................................... 3-5
Air filter element.................................... 6-17
Auxiliary DC jack .................................. 3-45
Auxiliary light bulb, replacing ............... 6-33BBattery .................................................. 6-28
Brake and clutch fluids, changing ........ 6-24
Brake and clutch levers, checking and lubricating........................................... 6-25
Brake and shift pedals, checking and
lubricating........................................... 6-25
Brake fluid level, checking.................... 6-23
Brake lever............................................ 3-27
Brake lever free play, checking ............ 6-21
Brake light switches ............................. 6-22
Brake pedal .......................................... 3-28CCare ........................................................ 7-1
Carriers ................................................. 3-42
Catalytic converter ............................... 3-33
Centerstand and sidestand, checking
and lubricating ................................... 6-26
Clutch lever.................................. 3-26, 6-21
Coolant ................................................. 6-15
Cowlings, removing and installing.......... 6-8
Cruise control indicator lights................. 3-4
Cruise control switches ........................ 3-25
Cruise control system............................. 3-7DDimmer/Pass switch............................. 3-25
D-mode (drive mode)............................ 3-24
EElectronically adjustable suspension system warning light ............................ 3-6
Engine break-in ...................................... 5-3
Engine idling speed, checking ............. 6-17
Engine oil and oil filter cartridge........... 6-11
Engine serial number ............................. 9-1
Engine trouble warning light .................. 3-5FFinal gear oil ......................................... 6-14
Front and rear brake pads, checking ... 6-22
Front fork, checking ............................. 6-27
Fuel ...................................................... 3-32
Fuel consumption, tips for reducing ...... 5-3
Fuel tank breather hose and overflow
hose ................................................... 3-33
Fuel tank cap........................................ 3-31
Fuses, replacing ................................... 6-30HHandlebar switches ............................. 3-24
Hazard switch ...................................... 3-25
Headlight bulb, replacing ..................... 6-31
High beam indicator light ....................... 3-4
Horn switch .......................................... 3-25IIdentification numbers ........................... 9-1
Ignition circuit cut-off system .............. 3-43
Immobilizer system ................................ 3-1
Immobilizer system indicator light ......... 3-6
Indicator lights and warning lights ......... 3-4LLicense plate light bulb, replacing ....... 6-35
Luggage strap holders ......................... 3-42
MMain switch/steering lock ....................... 3-2
Maintenance and lubrication, periodic ... 6-4
Maintenance, emission control
system .................................................. 6-3
Matte color, caution................................ 7-1
Menu switch ......................................... 3-25
Model label ............................................. 9-1
Multi-function meter unit ...................... 3-10NNeutral indicator light ............................. 3-4OOil level warning light .............................. 3-4PParking.................................................... 5-4
Part locations.......................................... 2-1RRider seat.............................................. 3-34
Rider seat height, adjusting .................. 3-35SSafety information................................... 1-1
Select switch ........................................ 3-26
Shifting.................................................... 5-2
Shift pedal............................................. 3-27
Sidestand.............................................. 3-43
Spark plugs, checking .......................... 6-10
Specifications ......................................... 8-1
Start/Engine stop switch ...................... 3-25
Starting the engine ................................. 5-1
Steering, checking ................................ 6-28
Storage ................................................... 7-4
Suspension, adjusting the front and
rear ..................................................... 3-37
Swingarm pivots, lubricating ................ 6-27
