6-6
PERIODIC MAINTENANCE AND MINOR REPAIR
62. Pull the rear of the panel out,
and then slide the panel forward
to release it in the front.To install the panel
1. Secure the front of the panel,
and then push the rear of the
panel in.
2. Install the bolt.
EAU03184
Panel B
To remove the panel1. Slide the lock cover open, insert
the key into the lock, and then
turn it 1/4 turn clockwise.
1
a
1. Lock cover
a. Unlock.
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 36

6-7
PERIODIC MAINTENANCE AND MINOR REPAIR
6 2. Pull the rear of the panel out with
the key inserted in the lock, and
then slide the panel forward to
release it in the front.To install the panel
1. Secure the front of the panel,
and then push the rear of the
panel in with the key inserted in
the lock.
2. Turn the key counterclockwise to
the original position, remove it,
and then close the lock cover.
EAU03329
Checking the spark plugs
Spark plugs, checking
The spark plugs are important engine
components, which are easy to
check. Since heat and deposits will
cause any spark plug to slowly erode,
the spark plugs should be removed
and checked in accordance with the
periodic maintenance and lubrication
chart. In addition, the condition of the
spark plugs can reveal the condition
of the engine.
To remove a spark plug
1. Remove the spark plug cap.
1
1. Spark plug cap
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 37

6-16
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EWA00012
wBecause loading has an enormous
impact on the handling, braking,
performance and safety character-
istics of your motorcycle, you
should keep the following precau-
tions in mind.
8NEVER OVERLOAD THE
MOTORCYCLE! Operation of
an overloaded motorcycle may
result in tire damage, loss of
control, or severe injury. Make
sure that the total weight of
rider, passenger, cargo, and
accessories does not exceed
the specified maximum load
for the vehicle.
8Do not carry along loosely
packed items, which can shift
during a ride.
8Securely pack the heaviest
items close to the center of the
motorcycle and distribute the
weight evenly on both sides.8Adjust the suspension and tire
air pressure with regard to the
load.
8Check the tire condition and
air pressure before each ride.
Tire air pressure
(measured on cold tires)
Load* Front Rear
Up to 90 kg175 kPa
(1.75 kgf/cm
2,
1.75 bar)200 kPa
(2.00 kgf/cm
2,
2.00 bar)
90 kg–maximum175 kPa
(1.75 kgf/cm
2,
1.75 bar)200 kPa
(2.00 kgf/cm
2,
2.00 bar)
Maximum load* 183 kg
* Total weight of rider, passenger, cargo and
accessories
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 46

6-29
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU03164
Checking and lubricating the
brake and clutch levers
Brake and clutch levers, checking and lubricating
The operation of the brake and clutch
levers should be checked before
each ride, and the lever pivots should
be lubricated if necessary.
EAU03165
Checking and lubricating the
sidestand
Sidestand, checking and lubricating
The operation of the sidestand
should be checked before each ride,
and the sidestand pivot and metal-to-
metal contact surfaces should be
lubricated if necessary.
EW000113
wIf the sidestand does not move up
and down smoothly, have a
Yamaha dealer check or repair it.
EAU02939
Checking the front fork
Front fork, checking
The condition and operation of the
front fork must be checked as follows
at the intervals specified in the peri-
odic maintenance and lubrication
chart.
To check the condition
EW000115
wSecurely support the motorcycle
so that there is no danger of it
falling over.Check the inner tubes for scratches,
damage and excessive oil leakage.
Recommended lubricant:
Lithium-soap-based grease
(all-purpose grease)
Recommended lubricant:
Lithium-soap-based grease
(all-purpose grease)
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 59

6-30
PERIODIC MAINTENANCE AND MINOR REPAIR
6To check the operation
1. Place the motorcycle on a level
surface and hold it in an upright
position.
2. While applying the front brake,
push down hard on the handle-
bars several times to check if the
front fork compresses and
rebounds smoothly.
EC000098
cCIf any damage is found or the front
fork does not operate smoothly,
have a Yamaha dealer check or
repair it.
EAU00794
Checking the steering
Steering, checking
Worn or loose steering bearings may
cause danger. Therefore, the opera-
tion of the steering must be checked
as follows at the intervals specified in
the periodic maintenance and lubrica-
tion chart.
1. Place a stand under the engine
to raise the front wheel off the
ground.
EW000115
wSecurely support the motorcycle
so that there is no danger of it
falling over.
2. Hold the lower ends of the front
fork legs and try to move them
forward and backward. If any
free play can be felt, have a
Yamaha dealer check or repair
the steering.
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 60

6-35
PERIODIC MAINTENANCE AND MINOR REPAIR
6 3. Unhook the headlight bulb hold-
er, and then remove the defec-
tive bulb.
EW000119
wHeadlight bulbs get very hot.
Therefore, keep flammable prod-
ucts away from a lit headlight bulb,
and do not touch the bulb until it
has cooled down.4. Place a new headlight bulb into
position, and then secure it with
the bulb holder.
EC000105
cCDo not touch the glass part of the
headlight bulb to keep it free from
oil, otherwise the transparency of
the glass, the luminosity of the
bulb, and the bulb life will be
adversely affected. Thoroughly
clean off any dirt and fingerprints
on the headlight bulb using a cloth
moistened with alcohol or thinner.5. Install the headlight bulb cover,
and then connect the coupler.
1
a
1. Headlight bulb holder a. Do not touch this area.
1
1. Bulb cover
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 65

6-38
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU03239
Front wheel
Front wheel
To remove the front wheel
Removing
EW000122
w8It is advisable to have a
Yamaha dealer service the
wheel.
8Securely support the motorcy-
cle so that there is no danger
of it falling over.1. Disconnect the speedometer
cable from the front wheel.2. Loosen the front wheel axle
pinch bolt, then the wheel axle.
3. Lift the front wheel off the ground
according to the procedure on
page 6-37.
4. Pull the wheel axle out, and then
remove the wheel.
ECA00048
cCDo not apply the brake after the
wheel has been removed together
with the brake disc, otherwise the
brake pads will be forced shut.
1
1 2
1. Speedometer cable 1. Front wheel axle pinch bolt
2. Wheel axle
To service the rear wheel
Raise the rear wheel off the ground
by using a motorcycle stand or, if a
motorcycle stand is not available, by
placing a jack either under each side
of the frame in front of the rear wheel
or under each side of the swingarm.
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 68

6-40
PERIODIC MAINTENANCE AND MINOR REPAIR
62. Lift the rear wheel off the ground
according to the procedure on
page 6-37.
3. Disconnect the brake torque rod
from the brake shoe plate by
removing the nut and the bolt.
4. Remove the brake pedal free
play adjusting nut, and then dis-
connect the brake rod at the
brake camshaft lever.5. Loosen the locknut and the drive
chain adjusting nut on both ends
of the swingarm.
6. Remove the axle nut, and then
pull the wheel axle out.
7. Push the wheel forward, and
then remove the drive chain from
the rear sprocket.
NOTE:
The drive chain does not need to be
disassembled in order to remove and
install the wheel.8. Remove the wheel.
2
14
3
5
1
32
1. Brake torque rod nut
2. Brake torque rod
3. Brake pedal free play adjusting nut
4. Brake rod
5. Brake camshaft lever1. Locknut
2. Drive chain adjusting nut
3. Wheel axle
EAU03189
Rear wheel
Wheel (rear)
To remove the rear wheel
Removing
EW000122
w8It is advisable to have a
Yamaha dealer service the
wheel.
8Securely support the motorcy-
cle so that there is no danger
of it falling over.1. Loosen the axle nut and the
brake torque rod nut at the brake
shoe plate.
1
1. Axle nut
5JX-28199-E2 honbun 10/11/01 2:14 PM Page 70
