Replacin g the hea dlig ht bul bThis model is equipped with a halogen
bulb headlight. If the headlight bulb
burns out, replace it as follows.NOTICE
ECA10661
Do not touch the g lass part of the
hea dlig ht bul b to keep it free from
oil, otherwise the transparency of
the glass, the luminosity of the bul b,
an d the bul b life will b e adversely af-
fected . Thorou ghly clean off any d irt
an d fin gerprints on the hea dlig ht
b ul b usin g a cloth moistene d with al-
cohol or thinner.1. Remove the headlight unit by re- moving the screws. 2. Disconnect the headlight coupler,
and then remove the headlight
bulb cover.
3. Unhook the headlight bulb holder, and then remove the burnt-out
bulb. 4. Place a new headlight bulb into
position, and then secure it with
the bulb holder.
5. Install the bulb cover, and then connect the coupler.
TIPWhen installing the headlight bulb cov-
er, make sure the “TOP” mark faces
upwards.
1. Do not touch the glass part of the bulb.
1. Screw
1. Headlight bulb cover
2. Headlight coupler
11
2
1. Headlight bulb holder
2. Headlight bulb
21
U2SSE2E0.book Page 30 Monday, July 20, 2015 2:28 PM

Periodic maintenance an d a djustment
6-31
6
6. Install the headlight unit by install-
ing the screws.
7. Have a Yamaha dealer adjust the headlight beam if necessary.
EAU45226
Replacin g the auxiliary li ght
b ul b If the auxiliary light bulb burns out, re-
place it as follows.
1. Remove the headlight unit. (See page 6-30.)
2. Remove the auxiliary light bulb socket (together with the bulb) by
pulling it out.
3. Remove the burnt-out bulb by pulling it out. 4. Insert a new bulb into the socket.
5. Install the socket (together with
the bulb) by pushing it in.
6. Install the headlight unit.
1. “TOP” mark
TOP
1
1. Auxiliary light bulb socket
1
1. Auxiliary light bulb
1
U2SSE2E0.book Page 31 Monday, July 20, 2015 2:28 PM

Specifications
8-2
8
Chassis:Frame type:Double cradle
Caster angle:
34.0 °
Trail: 109 mm (4.3 in)Front tire:Type:
Tubeless
Size: 120/70 21M/C 62H
Manufacturer/model: BRIDGESTONE/EXEDRA G721 GRear tire:Type: Tubeless
Size: 210/40R18M/C 73H
Manufacturer/model:
BRIDGESTONE/EXEDRA G852 RADIAL GLoa din g:Maximum load:
204 kg (450 lb)
(Total weight of rider, passenger, cargo
and accessories)Tire air pressure (measure d on col d
tires):Up to 90 kg (198 lb) load:
Front:250 kPa (2.50 kgf/cm², 36 psi)
Rear:
280 kPa (2.80 kgf/cm², 41 psi) 90 kg (198 lb) load - maximum load:
Front:
250 kPa (2.50 kgf/cm², 36 psi)
Rear: 280 kPa (2.80 kgf/cm², 41 psi)
Front wheel:Wheel type:
Cast wheel
Rim size: 21M/C x MT3.50Rear wheel:Wheel type:
Cast wheel
Rim size: 18M/C x MT7.50Front brake:Type:
Hydraulic single disc brake
Specified brake fluid: DOT 4Rear brake:Type:
Hydraulic single disc brake
Specified brake fluid: DOT 4Front suspension:Type:
Telescopic fork
Spring: Coil spring
Shock absorber: Hydraulic damper
Wheel travel:
135 mm (5.3 in)
Rear suspension:Type:Swingarm (link suspension)
Spring:
Coil spring
Shock absorber: Gas-hydraulic damper
Wheel travel: 100 mm (3.9 in)Electrical system:System voltage:12 V
Ignition system: TCI
Charging system:
AC generatorBattery:Model:YTX20L-BS
Voltage, capacity:
12 V, 18.0 Ah (10 HR)Hea dlig ht:Bulb type:
Halogen bulbBul b watta ge × quantity:Headlight:
H4, 60.0 W/55.0 W x 1
Brake/tail light: LED
Front turn signal light:
LED
Rear turn signal light: LED
