light YAMAHA XVS650 2002 Owner's Manual

PERIODIC MAINTENANCE AND MINOR REPAIR
6-38
6
EW000103
WARNING
_ After adjusting the brake pedal free
play, check the operation of the
brake light. _
EAU01008
Troubleshooting Although Yamaha motorcycles receive
a thorough inspection before shipment
from the factory, trouble may occur dur-
ing operation. Any problem in the fuel,
compression, or ignition systems, for
example, can cause poor starting and
loss of power.
The following troubleshooting chart
represents a quick and easy procedure
for checking these vital systems your-
self. However, should your motorcycle
require any repair, take it to a Yamaha
dealer, whose skilled technicians have
the necessary tools, experience, and
know-how to service the motorcycle
properly.
Use only genuine Yamaha replace-
ment parts. Imitation parts may look
like Yamaha parts, but they are often
inferior, have a shorter service life and
can lead to expensive repair bills.
U5SCE0.book Page 38 Thursday, June 7, 2001 11:24 AM

MOTORCYCLE CARE AND STORAGE
7-2
7


Do not use any harsh chemical
products on plastic parts. Be
sure to avoid using cloths or
sponges which have been in
contact with strong or abrasive
cleaning products, solvent or
thinner, fuel (gasoline), rust re-
movers or inhibitors, brake flu-
id, antifreeze or electrolyte.


Do not use high-pressure wash-
ers or steam-jet cleaners since
they cause water seepage and
deterioration in the following ar-
eas: seals (of wheel and swing-
arm bearings, fork and brakes),
electric components (couplers,
connectors, instruments, switch-
es and lights), breather hoses
and vents.


For motorcycles equipped with
a windshield: Do not use strong
cleaners or hard sponges as
they will cause dulling or
scratching. Some cleaning
compounds for plastic may
leave scratches on the wind-
shield. Test the product on a
small hidden part of the wind-
shield to make sure that it does
not leave any marks. If the wind-
shield is scratched, use a quali-
ty plastic polishing compound
after washing.
@After normal useRemove dirt with warm water, a mild
detergent, and a soft, clean sponge,
and then rinse thoroughly with clean
water. Use a toothbrush or bottlebrush
for hard-to-reach areas. Stubborn dirt
and insects will come off more easily if
the area is covered with a wet cloth for
a few minutes before cleaning.After riding in the rain, near the sea or
on salt-sprayed roadsSince sea salt or salt sprayed on roads
during winter are extremely corrosive in
combination with water, carry out the
following steps after each ride in the
rain, near the sea or on salt-sprayed
roads.NOTE:@ Salt sprayed on roads in the winter may
remain well into spring. @
U5SCE0.book Page 2 Thursday, June 7, 2001 11:24 AM

SPECIFICATIONS
8-4
8
Wheels
XVS650
Front
Type Spoke wheel
Size 19 × MT 2.50
19 M/C × MT 2.50
Rear
Type Spoke wheel
Size 15 M/C × MT 3.50
XVS650A
Front
Type Spoke wheel
Size 16 × MT 3.00
16 M/C × MT 3.00
Rear
Type Spoke wheel
Size 15 M/C × MT 3.50
Brakes
Front
Type Single disc brake
Operation Right hand
Fluid DOT 4
Rear
Type Drum brake
Operation Right footSuspension
Front Telescopic fork
Rear Swingarm (monocross)
Spring/shock absorber
Front Coil spring / oil damper
Rear Coil spring / gas-oil damper
Wheel travel
XVS650
Front 140 mm
Rear 86 mm
XVS650A
Front 140 mm
Rear 98 mm
Electrical systems
Ignition system Transistorized coil ignition
(digital)
Charging system
Type A.C. magneto
Standard output 14 V, 20 A @ 5,000 r/min
Battery
Model GT12B-4
Voltage, capacity 12 V, 10 Ah
Headlight typeQuartz bulb (halogen)
U5SCE0.book Page 4 Thursday, June 7, 2001 11:24 AM

SPECIFICATIONS
8-5
8
Bulb voltage, wattage × quantity
Headlight 12 V, 60/55 W × 1
Auxiliary light 12 V, 4 W × 1
Tail/brake light 12 V, 5/21 W × 1
Turn signal light 12 V, 21 W × 4
Meter lighting 12 V, 1.7 W × 1
Neutral indicator light 12 V, 1.7 W × 1
High beam indicator light 12 V, 1.7 W × 1
Turn signal indicator light 12 V, 1.7 W × 1
Engine trouble warning light 12 V, 1.7 W × 1
Fuses
Main fuse 30 A
Ignition fuse 10 A
Signaling system fuse 10 A
Headlight fuse 15 A
Carburetor heater fuse 15 A
U5SCE0.book Page 5 Thursday, June 7, 2001 11:24 AM

10-INDEXAAir filter element, cleaning ...................... 6-13
Anti-theft alarm ........................................3-3BBattery ................................................... 6-29
Brake and clutch levers, checking
and lubricating ..................................... 6-26
Brake and shift pedals, checking
and lubricating ..................................... 6-26
Brake fluid, changing ............................. 6-25
Brake fluid level, checking...................... 6-24
Brake lever...............................................3-6
Brake lever free play, adjusting .............. 6-20
Brake light switch (rear), adjusting ......... 6-22
Brake pads and shoes, checking ........... 6-23
Brake pedal..............................................3-6
Brake pedal position and free play,
adjusting .............................................. 6-21CCables, checking and lubricating............ 6-25
Carburetors, adjusting............................ 6-14
Care.........................................................7-1
Clutch lever ..............................................3-5
Clutch lever free play, adjusting ............. 6-19
Conversion table ......................................8-6DDimmer switch .........................................3-4EEngine break-in........................................5-5
Engine oil and oil filter element.................6-9
Engine stop switch ...................................3-4
Engine trouble warning light .................... 3-2FFinal gear oil .......................................... 6-12
Front fork, checking ............................... 6-27
Fuel ......................................................... 3-7
Fuel cock ................................................. 3-9
Fuel consumption, tips for reducing ......... 5-4
Fuel tank cap ........................................... 3-7
Fuses, replacing .................................... 6-31HHandlebar switches ................................. 3-3
Headlight bulb, replacing ....................... 6-32
Helmet holder ........................................ 3-13
High beam indicator light ......................... 3-2
Horn switch ............................................. 3-4IIdentification numbers ............................. 9-1
Idling speed, adjusting ........................... 6-15
Ignition circuit cut-off system.................. 3-17
Indicator and warning lights ..................... 3-2KKey identification number ........................ 9-1LLight switch.............................................. 3-4
Luggage strap holders ........................... 3-16MMain switch/steering lock ......................... 3-1
Model label .............................................. 9-2
NNeutral indicator light ...............................3-2PPanels, removing and installing ................6-5
Parking.....................................................5-5
Part locations ...........................................2-1
Pass switch ..............................................3-4
Periodic maintenance and
lubrication chart .....................................6-2
Pre-operation check list ............................4-1SSafety information ....................................1-1
Seats (XVS650) .....................................3-11
Passenger seat.................................3-11
Rider seat .........................................3-11
Seats (XVS650A) ...................................3-12
Passenger seat.................................3-12
Rider seat .........................................3-12
Shifting .....................................................5-3
Shift pedal (XVS650)................................3-5
Shift pedal (XVS650A) .............................3-5
Shift points (for Switzerland only) .............5-4
Shock absorber assembly, adjusting ......3-15
Sidestand ...............................................3-17
Sidestand, checking and lubricating .......6-27
Spark plugs, checking ..............................6-7
Specifications ...........................................8-1
Speedometer unit.....................................3-3
Starter (choke) knob...............................3-10
Starting a warm engine ............................5-2
Starting the engine ...................................5-1
Start switch ..............................................3-4
U5SCE0.book Page 1 Thursday, June 7, 2001 11:24 AM

INDEX
Steering, checking ................................. 6-28
Storage.................................................... 7-4
Storage compartment ............................ 3-13
Supporting the motorcycle ..................... 6-34TThrottle cable free play, adjusting .......... 6-15
Throttle grip and cable, checking
and lubricating ..................................... 6-25
Tires ...................................................... 6-16
Tool kit..................................................... 6-1
Troubleshooting..................................... 6-38
Troubleshooting chart ............................ 6-39
Turn signal indicator light ......................... 3-2
Turn signal light or tail/brake light bulb,
replacing ............................................. 6-33
Turn signal switch .................................... 3-3VValve clearance, adjusting ..................... 6-16
Vehicle identification number ................... 9-1WWheel bearings, checking...................... 6-29
Wheel (front).......................................... 6-35
Installing........................................... 6-35
Removing......................................... 6-35
Wheel (rear) .......................................... 6-36
Installing........................................... 6-37
Removing......................................... 6-36
Wheels .................................................. 6-19
