oil filter YAMAHA XVS650A 2001 Owners Manual

DESCRIPTION
2-2
2
Right view (XVS650)8. Engine oil filter element (page 6-9)
9. Battery (page 6-29)
10. Fuses (page 6-31)
11. Main switch/steering lock (page 3-1)
12. Air filter element (page 6-13)
13. Brake pedal (page 3-6)
E_5bn.book Page 2 Wednesday, October 4, 2000 7:51 PM

DESCRIPTION
2-4
2
Right view (XVS650A)8. Engine oil filter element (page 6-9)
9. Battery (page 6-29)
10. Fuses (page 6-31)
11. Main switch/steering lock (page 3-1)
12. Air filter element (page 6-13)
13. Brake pedal (page 3-6)
E_5bn.book Page 4 Wednesday, October 4, 2000 7:51 PM

OPERATION AND IMPORTANT RIDING POINTS
5-4
5
EAU00424
Tips for reducing fuel
consumption Fuel consumption depends largely on
your riding style. Consider the following
tips to reduce fuel consumption:l
Thoroughly warm up the engine.
l
Turn the starter (choke) off as
soon as possible.
l
Shift up swiftly, and avoid high en-
gine speeds during acceleration.
l
Do not rev the engine while shift-
ing down, and avoid high engine
speeds with no load on the engine.
l
Turn the engine off instead of let-
ting it idle for an extended length
of time (e.g., in traffic jams, at traf-
fic lights or at railroad crossings).
EAU01128
Engine break-in There is never a more important period
in the life of your engine than the period
between 0 and 1,600 km. For this rea-
son, you should read the following ma-
terial carefully.
Since the engine is brand new, do not
put an excessive load on it for the first
1,600 km. The various parts in the en-
gine wear and polish themselves to the
correct operating clearances. During
this period, prolonged full-throttle oper-
ation or any condition that might result
in engine overheating must be avoided.
EAU01171*
0–1,000 km
Avoid prolonged operation above
1/3 throttle.
1,000–1,600 km
Avoid prolonged operation above
1/2 throttle.
EC000056*
CAUTION:@ After 1,000 km of operation, the en-
gine oil and final gear oil must be
changed, and the oil filter element
replaced. @1,600 km and beyond
The vehicle can now be operated
normally.
EC000049
CAUTION:@ If any engine trouble should occur
during the engine break-in period,
immediately have a Yamaha dealer
check the vehicle. @
E_5bn.book Page 4 Wednesday, October 4, 2000 7:51 PM

6
PERIODIC MAINTENANCE AND MINOR REPAIR
Owner’s tool kit .................................................... 6-1
Periodic maintenance and lubrication chart ......... 6-2
Removing and installing panels ........................... 6-5
Checking the spark plugs .................................... 6-7
Engine oil and oil filter element ............................ 6-9
Final gear oil ...................................................... 6-11
Cleaning the air filter element ............................ 6-13
Adjusting the carburetors ................................... 6-14
Adjusting the engine idling speed ...................... 6-15
Adjusting the throttle cable free play .................. 6-15
Adjusting the valve clearance ............................ 6-16
Tires ................................................................... 6-16
Spoke wheels .................................................... 6-19
Adjusting the clutch lever free play .................... 6-19
Adjusting the brake lever free play ..................... 6-20
Adjusting the brake pedal position and
free play ........................................................... 6-21
Adjusting the rear brake light switch .................. 6-22
Checking the front brake pads and
rear brake shoes .............................................. 6-23
Checking the brake fluid level ............................ 6-24
Changing the brake fluid .................................... 6-25Checking and lubricating the cables ................. 6-25
Checking and lubricating the throttle grip and
cable ............................................................... 6-25
Checking and lubricating the brake and
shift pedals ...................................................... 6-26
Checking and lubricating the brake and
clutch levers .................................................... 6-26
Checking and lubricating the sidestand ............ 6-27
Checking the front fork ...................................... 6-27
Checking the steering ....................................... 6-28
Checking the wheel bearings ............................ 6-29
Battery ............................................................... 6-29
Replacing the fuses .......................................... 6-31
Replacing the headlight bulb ............................. 6-32
Replacing a turn signal light bulb or the tail/
brake light bulb ................................................ 6-33
Supporting the motorcycle ................................ 6-34
Front wheel ....................................................... 6-35
Rear wheel ........................................................ 6-36
Troubleshooting ................................................. 6-38
Troubleshooting chart ........................................ 6-39
E_5bn.book Page 1 Wednesday, October 4, 2000 7:51 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-3
6
10
*Wheels• Check runout, spoke tightness and for damage.
• Tighten spokes if necessary.ÖÖÖÖ
11*Tires• Check tread depth and for damage.
• Replace if necessary.
• Check air pressure.
• Correct if necessary.ÖÖÖÖ
12*Wheel bearings• Check bearing for looseness or damage.ÖÖÖÖ
13*Swingarm• Check operation and for excessive play.ÖÖÖÖ
• Lubricate with molybdenum disulfide grease. Every 50,000 km
14*Steering bearings• Check bearing play and steering for roughness.ÖÖÖÖÖ
• Lubricate with lithium-soap-based grease. Every 20,000 km
15*Chassis fasteners• Make sure that all nuts, bolts and screws are properly tightened.ÖÖÖÖ Ö
16 Sidestand• Check operation.
• Lubricate.ÖÖÖÖ Ö
17*Sidestand switch• Check operation.ÖÖÖÖÖ Ö
18*Front fork• Check operation and for oil leakage.ÖÖÖÖ
19*Rear shock absorber
assembly• Check operation and shock absorber for oil leakage.ÖÖÖÖ
20*Carburetors• Check starter (choke) operation.
• Adjust engine idling speed and synchronization.ÖÖÖÖÖ Ö
21 Engine oil• Change.ÖÖÖÖÖ Ö
22 Engine oil filter element•Replace.ÖÖÖ
23 Final gear oil• Check oil level and vehicle for oil leakage.ÖÖ Ö
• Change.ÖÖÖ
24*Front and rear brake
switches• Check operation.ÖÖÖÖÖ Ö
25 Moving parts and cables• Lubricate.ÖÖÖÖ Ö NO. ITEM CHECK OR MAINTENANCE JOBODOMETER READING (´1,000 km)
ANNUAL
CHECK
1 10203040
E_5bn_Periodic.fm Page 3 Thursday, December 14, 2000 1:31 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-9
6
EAU03835
Engine oil and oil filter
element The engine oil level should be checked
before each ride. In addition, the oil
must be changed and the oil filter ele-
ment replaced at the intervals specified
in the periodic maintenance and lubri-
cation chart.
To check the engine oil level
1. Place the motorcycle on a level
surface and hold it in an upright
position.NOTE:_ Make sure that the motorcycle is posi-
tioned straight up when checking the oil
level. A slight tilt to the side can result in
a false reading. _2. Start the engine, warm it up for
several minutes, and then turn it
off.3. Wait a few minutes until the oil set-
tles, and then check the oil level
through the check window located
at the bottom-left side of the crank-
case.
NOTE:_ The engine oil should be between the
minimum and maximum level marks. _4. If the engine oil is below the mini-
mum level mark, add sufficient oil
of the recommended type to raise
it to the correct level.To change the engine oil (with or
without oil filter element replace-
ment)
1. Start the engine, warm it up for
several minutes, and then turn it
off.
2. Place an oil pan under the engine
to collect the used oil.
3. Remove the engine oil filler cap
and drain bolt to drain the oil from
the crankcase.1. Engine oil level check window
2. Maximum level mark
3. Minimum level mark
4. Engine oil filler capLeft side
1. Engine oil drain bolt
2. Oil pan
E_5bn.book Page 9 Wednesday, October 4, 2000 7:51 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-10
6
NOTE:_ Skip steps 4–7 if the oil filter element is
not being replaced. _4. Remove the outer and inner oil fil-
ter element covers by removing
the bolts.5. Remove the oil filter element and
O-ring.
6. Install a new oil filter element and
the O-ring.
7. Install the oil filter element covers
by installing the bolts.
8. Install the engine oil drain bolt, and
then tighten it to the specified
torque.1. Outer oil filter element cover
2. Bolt (´ 3)Right side
1. Inner oil filter element cover
2. Bolt (´ 5)
1. Oil filter element
2. O-ringTightening torque:
Engine oil drain bolt:
43 Nm (4.3 m·kg)
E_5bn.book Page 10 Wednesday, October 4, 2000 7:51 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-11
69. Add the specified amount of the
recommended oil, and then install
and tighten the oil filler cap.
EC000072
CAUTION:_ l
In order to prevent clutch slip-
page (since the engine oil also
lubricates the clutch), do not
mix any chemical additives with
the oil or use oils of a higher
grade than “CD”. In addition, do
not use oils labeled “ENERGY
CONSERVING II” or higher.
l
Make sure that no foreign mate-
rial enters the crankcase.
_10. Start the engine, and then let it idle
for several minutes while checking
it for oil leakage. If oil is leaking,
immediately turn the engine off
and check for the cause.
11. Turn the engine off, and then
check the oil level and correct it if
necessary.
EAU02943*
Final gear oil The final gear case must be checked
for oil leakage before each ride. If any
leakage is found, have a Yamaha deal-
er check and repair the motorcycle. In
addition, the final gear oil level must be
checked and the oil changed as follows
at the intervals specified in the periodic
maintenance and lubrication chart.
EW000066
WARNING
@ l
Make sure that no foreign mate-
rial enters the final gear case.
l
Make sure that no oil gets on
the tire or wheel.
@To check the final gear oil level
1. Place the motorcycle on a level
surface and hold it in an upright
position. Recommended engine oil:
See page 8-1.
Oil quantity:
Without oil filter element
replacement:
2.6 L
With oil filter element
replacement:
2.8 L
Total amount (dry engine):
3.2 L
E_5bn.book Page 11 Wednesday, October 4, 2000 7:51 PM

SPECIFICATIONS
8-2
8
Quantity
Without oil filter element
replacement 2.6 L
With oil filter element
replacement 2.8 L
Total amount (dry engine) 3.2 L
Final gear oil
Type Hypoid gear oil SAE 80
(API GL4) or multigrade hypoid
gear oil SAE 80W-90
Final gear case capacity 0.19 L
Air filterDry type element
Fuel
Type Regular unleaded gasoline
Fuel tank capacity 16 L
Reserve amount 3 L
Carburetor
Manufacturer MIKUNI
Model ´ quantity BDS28 ´ 2
CAUTION:Be sure to use motor oils that do not contain anti-friction
modifiers. Passenger car motor oils (often labeled
“ENERGY CONSERVING II”) contain anti-friction additives
which will cause clutch and/or starter clutch slippage, result-
ing in reduced component life and poor engine performance.
Spark plug
Manufacturer/model NGK / DPR7EA-9 or
DENSO / X22EPR-U9
Gap 0.8– 0.9 mm
Clutch typeWet, multiple-disc
Transmission
Primary reduction system Spur gear
Primary reduction ratio 1.789
Secondary reduction system Shaft drive
Secondary reduction ratio 3.070
Transmission type Constant-mesh 5-speed
Operation Left foot
Gear ratio 1st 2.714
2nd 1.900
3rd 1.458
4th 1.167
5th 0.967
Chassis
Frame type Double cradle
Caster angle 35°
Tr a i l
XVS650 153 mm
XVS650A 145 mm
E_5bn.book Page 2 Wednesday, October 4, 2000 7:51 PM

10-INDEXAAir filter element, cleaning ...................... 6-13
Anti-theft alarm ........................................3-3BBattery ................................................... 6-29
Brake and clutch levers, checking
and lubricating ..................................... 6-26
Brake and shift pedals, checking
and lubricating ..................................... 6-26
Brake fluid, changing ............................. 6-25
Brake fluid level, checking...................... 6-24
Brake lever...............................................3-6
Brake lever free play, adjusting .............. 6-20
Brake light switch (rear), adjusting ......... 6-22
Brake pads and shoes, checking ........... 6-23
Brake pedal..............................................3-6
Brake pedal position and free play,
adjusting .............................................. 6-21CCables, checking and lubricating............ 6-25
Carburetors, adjusting............................ 6-14
Care.........................................................7-1
Clutch lever ..............................................3-5
Clutch lever free play, adjusting ............. 6-19
Conversion table ......................................8-6DDimmer switch .........................................3-4EEngine break-in........................................5-4
Engine oil and oil filter element.................6-9
Engine stop switch ...................................3-4
Engine trouble warning light .................... 3-2FFinal gear oil .......................................... 6-11
Front fork, checking ............................... 6-27
Fuel ......................................................... 3-7
Fuel cock ................................................. 3-8
Fuel consumption, tips for reducing ......... 5-4
Fuel tank cap ........................................... 3-7
Fuses, replacing .................................... 6-31HHandlebar switches ................................. 3-3
Headlight bulb, replacing ....................... 6-32
Helmet holder ........................................ 3-12
High beam indicator light ......................... 3-2
Horn switch ............................................. 3-4IIdentification numbers ............................. 9-1
Idling speed, adjusting ........................... 6-15
Ignition circuit cut-off system.................. 3-16
Indicator and warning lights ..................... 3-2KKey identification number ........................ 9-1LLight switch.............................................. 3-4
Luggage strap holders ........................... 3-15MMain switch/steering lock ......................... 3-1
Model label .............................................. 9-2
NNeutral indicator light ...............................3-2PPanels, removing and installing ................6-5
Parking.....................................................5-5
Part locations ...........................................2-1
Pass switch ..............................................3-4
Periodic maintenance and
lubrication chart .....................................6-2
Pre-operation check list ............................4-1SSafety information ....................................1-1
Seats (XVS650) .....................................3-10
Passenger seat.................................3-10
Rider seat .........................................3-10
Seats (XVS650A) ...................................3-11
Passenger seat.................................3-11
Rider seat .........................................3-11
Shifting .....................................................5-3
Shift pedal (XVS650)................................3-5
Shift pedal (XVS650A) .............................3-5
Shock absorber assembly, adjusting ......3-14
Sidestand ...............................................3-15
Sidestand, checking and lubricating .......6-27
Spark plugs, checking ..............................6-7
Specifications ...........................................8-1
Speedometer unit.....................................3-3
Starter (choke) knob.................................3-9
Starting a warm engine ............................5-2
Starting the engine ...................................5-1
Start switch ..............................................3-4
Steering, checking..................................6-28
E_5bn.book Page 1 Wednesday, October 4, 2000 7:51 PM
