fuel type YAMAHA XVS950CU 2016 Owners Manual

Instrument and control functions
3-13
3
3. Wipe up any spilled fuel immedi-ately. NOTICE: Immediately
wipe off spille d fuel with a clean,
d ry, soft cloth, since fuel may
d eteriorate painted surfaces or
plastic parts.
[ECA10072]
4. Be sure to securely close the fuel tank cap.
WARNING
EWA15152
Gasoline is poisonous an d can
cause injury or death. Han dle gaso-
line with care. Never siphon gasoline
b y mouth. If you shoul d swallow
some gasoline or inhale a lot of g as-
oline vapor, or get some g asoline in
your eyes, see your doctor imme di- ately. If g
asoline spills on your skin,
wash with soap an d water. If gaso-
line spills on your clothin g, chan ge
your clothes.
EAU57691
NOTICE
ECA11401
Use only unlea ded g asoline. The use
of lea ded g asoline will cause severe
d amag e to internal en gine parts,
such as the valves an d piston rin gs,
as well as to the exhaust system.Your Yamaha engine has been de-
signed to use regular unleaded gaso-
line with a research octane number of
95 or higher. If knocking (or pinging)
occurs, use a gasoline of a different brand or premium unleaded fuel. Use
of unleaded fuel will extend spark plug
life and reduce maintenance costs.
Gasohol
There are two types of gasohol: gaso-
hol containing ethanol and that con-
taining methanol. Gasohol containing
ethanol can be used if the ethanol con-
tent does not exceed 10% (E10). Gas-
ohol containing methanol is not
recommended by Yamaha because it
can cause damage to the fuel system
or vehicle performance problems.
1. Fuel tank filler tube
2. Maximum fuel level
2
1
Recommen
ded fuel:
Regular unleaded gasoline (Gasohol
[E10] acceptable)
Fuel tank capacity:
12 L (3.2 US gal, 2.6 Imp.gal)
Fuel reserve amount (when the fuel
level warnin g lig ht comes on):
2.8 L (0.74 US gal, 0.62 Imp.gal)
U2DEE1E0.book Page 13 Friday, September 4, 2015 4:52 PM

Specifications
8-1
8
Dimensions:Overall length:2290 mm (90.2 in)
Overall width:
830 mm (32.7 in)
Overall height: 1120 mm (44.1 in)
Seat height: 690 mm (27.2 in)
Wheelbase:
1570 mm (61.8 in)
Ground clearance: 130 mm (5.12 in)
Minimum turning radius: 3.3 m (10.83 ft)Wei ght:Curb weight:
For non-ABS models 247 kg (545 lb)
For ABS models 251 kg (553 lb)Engine:Combustion cycle:
4-stroke
Cooling system:
Air cooled
Valve train: SOHC
Cylinder arrangement: V-type
Number of cylinders:
2-cylinder
Displacement: 942 cm³
Bore × stroke:
85.0 × 83.0 mm (3.35 × 3.27 in) Compression ratio:
9.0 : 1
Starting system: Electric starter
Lubrication system:
Wet sump
Engine oil:Recommended brand:
YAMALUBE
SAE viscosity grades:
10W-40
Recommended engine oil grade: API service SG type or higher, JASO
standard MA
Engine oil quantity: Oil change:
3.70 L (3.91 US qt, 3.26 Imp.qt)
With oil filter removal: 4.00 L (4.23 US qt, 3.52 Imp.qt)Air filter:Air filter element:
Oil-coated paper elementFuel:Recommended fuel:Regular unleaded gasoline (Gasohol [E10]
acceptable)
Fuel tank capacity: 12 L (3.2 US gal, 2.6 Imp.gal)
Fuel reserve amount:
2.8 L (0.74 US gal, 0.62 Imp.gal)Fuel injection:Throttle body:ID mark: 1TP1 01
Spark plu g(s):Manufacturer/model:
NGK/CPR7EA-9
Spark plug gap:
0.8–0.9 mm (0.031–0.035 in)Clutch:Clutch type:Wet, multiple-discDrivetrain:Primary reduction ratio:1.674 (72/43)
Final drive: Belt
Secondary reduction ratio:
2.333 (70/30)
Transmission type: Constant mesh 5-speed
Gear ratio: 1st: 3.067 (46/15)
2nd: 2.063 (33/16)
3rd:
1.579 (30/19)
4th: 1.259 (34/27)
5th: 1.042 (25/24)Chassis:Frame type:Double cradle
Caster angle: 29.0 °
