PERIODIC MAINTENANCE AND MINOR REPAIR
6-15
6
EW000132
WARNING
@ After extensive tests, the tires men-
tioned below have been approved
by Yamaha Motor Co., Ltd. for this
model. No guarantee for handling
characteristics can be given if tire
combinations other than what is ap-
proved are used on this motorcycle.
The front and rear tires should be of
the same manufacture and design.
Always use the tire valves and valve
cores listed below. Be sure to install
the valve caps securely, as these
are important to prevent air pres-
sure leakage. @
CE-41E
CE-42EEAU01230
WheelsTo ensure maximum performance,
long service, and safe operation, note
the following:l
Always inspect the wheels before
a ride. Check for cracks, bends or
warpage of the wheels. If any ab-
normal condition exists in a wheel,
consult a Yamaha dealer. Do not
attempt even small repairs to the
wheel. If a wheel is deformed or
cracked, it must be replaced.
l
Tires and wheels should be bal-
anced whenever either one is
changed or replaced. Failure to
have a wheel balanced can result
in poor performance, adverse han-
dling characteristics and short-
ened tire life.
l
Ride at moderate speeds after
changing a tire since the tire sur-
face must first be broken in for it to
develop its optimal characteristics.
FRONT
Manufacturer Size Type
Dunlop 150/80-16 71H D404F
Type
Tire valve TR412
Valve core #9000A
REAR
Manufacturer Size Type
Dunlop 150/90B15M/C 74H D404
Type
Tire valve PVR59A
Valve core #9000
E_4YP_Periodic.fm Page 15 Wednesday, October 6, 1999 10:05 AM

8-1
8
EAU01038
8-SPECIFICATIONSSpecifications
Model XVZ1300A
Dimensions
Overall length 2,480 mm
Overall width 950 mm
Overall height 1,160 mm
Seat height 715 mm
Wheelbase 1,695 mm
Ground clearance 150 mm
Minimum turning radius 3,400 mm
Basic weight (with oil and full
fuel tank)
330 kg
Engine
Engine type Liquid cooled 4-stroke, DOHC
Cylinder arrangement V type 4-cylinder
Displacement 1,294 cm
3
Bore ´ stroke 79 ´ 66 mm
Compression ratio 10:1
Starting system Electric starter
Lubrication system Wet sumpEngine oil
Ty p e
Recommended engine oil
classification API Service SE, SF, SG type or
higher
Quantity
Periodic oil change 3.5 L
With oil filter replacement 3.7 L
Total amount 4.3 L
-20˚ -10˚ 0˚
10˚20˚ 30˚
40˚50˚C
SAE 10W/30
SAE 15W/40SAE 20W/40SAE 20W/50
SAE 10W/40
CAUTION:Be sure to use motor oils that do not contain anti-friction
modifiers. Passenger car motor oils (often labeled
“Energy Conserving”) contain anti-friction additives which
will cause clutch and/or starter clutch slippage, resulting in
reduced component life and poor engine performance.
