8-4
MODEL YBR 125K
Brakes:
Front brake type Drum brake
Operation Right hand operation
Rear brake type Drum brake
Operation Right foot operation
Suspension:
Front Telescopic fork
Rear Swingarm (New monocross suspension)
Shock absorber:
Front Coil spring, Oil damper
Rear Gas, Coil spring, Oil damper
Front 120 mm ( 5.0 in)
Rear 105 mm ( 4.0 in)
Electrical:
Ignition system CDI
Generator system AC Magneto generator
Battery type / capacity 12N 5,5-3B / 12V 5,5 Ah
8-4
MODEL YBR 125K
Brakes:
Front brake type Drum brake
Operation Right hand operation
Rear brake type Drum brake
Operation Right foot operation
Suspension:
Front Telescopic fork
Rear Swingarm (New monocross suspension)
Shock absorber:
Front Coil spring, Oil damper
Rear Gas, Coil spring, Oil damper
Front 120 mm ( 5.0 in)
Rear 105 mm ( 4.0 in)
Electrical:
Ignition system CDI
Generator system AC Magneto generator
Battery type / capacity 12N 5,5-3B / 12V 5,5 Ah
8-5
MODEL YBR 125K
Headlight type: Halogen bulb
Bulb wattage x quantity:
Headlight 12V 35w /35w (1pc)
tail / Brake light 12V 5w / 21w (1pc)
Flasher light 12V 10w (4pc)
Indicator light wattage x quantity:
Panel 12V x 3,4W (2pc)
Neutral lamp 14V x 3W (1pc)
Headlight 14V x 3W (1pc)
Flasher light 14V x 3W (2pc)
8-5
MODEL YBR 125K
Headlight type: Halogen bulb
Bulb wattage x quantity:
Headlight 12V 35w /35w (1pc)
tail / Brake light 12V 5w / 21w (1pc)
Flasher light 12V 10w (4pc)
Indicator light wattage x quantity:
Panel 12V x 3,4W (2pc)
Neutral lamp 14V x 3W (1pc)
Headlight 14V x 3W (1pc)
Flasher light 14V x 3W (2pc)
