clock YAMAHA YFM660R 2001 Owners Manual

4-29
Yuki_DATA2:HM00G210_YFM660R-60:YFM350-4.frameEL
EBU00092
Fuel tank cap
Remove the fuel tank cap by turning it counter-
clockwise.
EBU00093
Fuel cock
The fuel cock supplies fuel from the fuel tank to
the carburetor.
The fuel cock has three positions.
OFF: With the lever in this position fuel will
not flow. Always turn the lever to this
position when the engine is not running.
ON: With the lever in this position, fuel flows
to the carburetor. Normal riding is done
with the lever in this position.
RES: This indicates reserve. If you run out of
fuel while riding, turn the lever to this
position. THEN FILL THE FUEL TANK AT
THE FIRST OPPORTUNITY. After refuel-
ling, return the fuel cock lever to the
“ON” position.
1. Fuel tank cap
2. Bouchon de réservoir de carburant
1. Tapón del depósito de combustible

6-11
Yuki_DATA2:HM00G210_YFM660R-60:YFM350-6.frameEL
EBU00816
Reverse knob operation and reverse driving
CAUTION:
Before shifting, stop the machine and return
the throttle lever to its closed position. Other-
wise the transmission may be damaged.
1. Bring the machine to a complete stop, re-
turn the throttle lever to the closed posi-
tion, apply the clutch lever, and shift the
transmission into first gear.
2. While applying the rear brake pedal, turn
the reverse knob clockwise with your right
hand.
3. Shift the transmission into reverse by
pressing down on the shift pedal.
NOTE:
When in reverse, the reverse indicator light
should be on. If the light does not come on, ask
a Yamaha dealer to inspect the machine.
1. Reverse knob
2. Shift pedal
1. Bouton de marche arrière
2. Pédale de sélection
1. Botón de marcha atrás
2. Pedal del cambio

8-111
Yuki_DATA2:HM00G210_YFM660R-60:YFM350-8.frameEL
1. Bulb holder
1. Fixation d’ampoule
1. Portabombillas
1. Bulb 2. Bulb holder
1. Ampoule 2. Fixation d’ampoule
1. Bonbilla 2. Portabombillas
7. Push the bulb holder inward, turn it coun-
terclockwise and remove the defective
bulb.
WARNING
The headlight bulb is hot when it is on and im-
mediately after it is turned off. Wait for the
bulb to cool down before touching or remov-
ing it. You can be burned, or a fire could start if
the bulb touches something flammable.
8. Put a new bulb into position and secure it
in place with the bulb holder.
9. Install the bulb holder cover.
CAUTION:
Make sure the bulb holder cover is securely fit-
ted over the bulb holder and seated against
the reflector.
10. Align the projections with the holders, in-
stall the headlight unit into the case, and
install the screw.
11. Install the headlight cover in the original
position, and then install the screw.

8-115
Yuki_DATA2:HM00G210_YFM660R-60:YFM350-8.frameEL
1. Lens 2. Screw (× 2)
1. Lentille 2. Vis (× 2)
1. Lente 2. Tornillo (× 2)
1. Bulb
1. Ampoule
1. Bonbilla
EBU00800
Tail/brake light bulb replacement
1. Remove the screws and the lens.
2. Remove the defective bulb by pushing it
inward and turning it counterclockwise.
3. Install a new bulb by pushing it inward
and turning it clockwise.
4. Install the lens and tighten the screws.
CAUTION:
Do not over-tighten the screws as the lens
may break.
