oil filter YAMAHA YFM660R 2001 Owners Manual

ER
Yuki_DATA2:HM00G210_YFM660R-60:YFM350TOC-E.frame
OPERATION ........................................... 6-1
Starting a cold engine ....................... 6-3
Starting a warm engine ..................... 6-9
Warming up ........................................ 6-9
Reverse knob operation and
reverse driving ............................... 6-11
Shifting ............................................. 6-15
To start out and accelerate .............. 6-17
To decelerate .................................... 6-21
Engine break-in ................................ 6-23
Parking .............................................. 6-27
Parking on a slope ........................... 6-29
Accessories and loading ................. 6-31
Accessories....................................... 6-31
Loading ............................................. 6-33
RIDING YOUR ATV ................................ 7-1
Getting to know your ATV ................. 7-3
Ride with care and good judgement 7-5
Be careful where you ride ............... 7-27
Turning your ATV ............................ 7-39
Climbing uphill ................................. 7-45
Riding downhill ................................ 7-55
Crossing a slope ............................... 7-59
Crossing through shallow water .... 7-63
Riding over rough terrain ................ 7-67
Sliding and skidding ........................ 7-69What to do if... .................................. 7-73
What to do... ..................................... 7-73
PERIODIC MAINTENANCE AND
ADJUSTMENT ....................................... 8-1
Owner’s manual and tool kit ............. 8-3
Periodic maintenance/lubrication ..... 8-7
Panel removal and installation ....... 8-15
Engine oil and oil filter cartridge .... 8-17
Cooling system ................................ 8-31
Changing the coolant ...................... 8-33
Spark plug inspection ...................... 8-41
Air filter element cleaning ............... 8-45
Carburetor adjustment .................... 8-51
Idle speed adjustment ..................... 8-53
Valve clearance adjustment ............ 8-55
Reverse lock release cable
adjustment ..................................... 8-55
Throttle lever adjustment ................ 8-57
Front and rear brake pad
inspection ....................................... 8-59
Brake fluid level inspection ............. 8-61
Brake fluid replacement .................. 8-65
Front brake adjustment ................... 8-67
Rear brake adjustment .................... 8-69
Parking brake adjustment ............... 8-71
Clutch lever free play adjustment .... 8-756
7
8

5-15
Yuki_DATA2:HM00G210_YFM660R-60:YFM350-5.frameEL
CAUTION:
Be sure to use motor oils that do not contain
anti-friction modifiers. Passenger car motor
oils (often labeled “Energy Conserving”) con-
tain anti-friction additives which will cause
clutch and/or starter clutch slippage, resulting
in reduced component life and poor engine
performance.
Oil quantity:
Total amount:
2.3 L
With oil filter cartridge replacement:
1.95 L
Periodic oil change:
1.9 L

8-7
Yuki_DATA2:HM00G210_YFM660R-60:YFM350-8.frameEL
EBU00262
PERIODIC MAINTENANCE/LUBRICATION
ITEM ROUTINEINITIAL EVERY
1
month3
months6
months6
months1
year
Valves*• Check valve clearance.
• Adjust if necessary.
Cooling system• Check coolant leakage.
• Repair if necessary.
• Replace coolant every 24 months.
Spark plug• Check condition.
• Adjust gap and clean.
• Replace if necessary.
Air filter element• Clean.
• Replace if necessary.Every 20~40 hours
(More often in wet or dusty areas.)
Carburetor*• Check and adjust idle speed/starter operation.
• Adjust if necessary.
Crankcase breather
system*• Check breather hose for cracks or damage.
• Replace if necessary.
Exhaust system*• Check for leakage.
• Retighten if necessary.
• Replace gasket if necessary.
Fuel line*• Check fuel hose for cracks or damage.
• Replace if necessary.
Engine oil• Replace (Warm engine before draining.)
Engine oil filter cartridge• Replace if necessary.
Drive chain• Check and adjust slack/alignment/clean/lube.
Brakes*• Check operation/fluid leakage/See NOTE Page 8-8.
• Correct if necessary.
Clutch*• Check operation.
• Adjust if necessary.

8-17
Yuki_DATA2:HM00G210_YFM660R-60:YFM350-8.frameEL
1. Engine oil tank
2. Engine oil filler cap
3. Maximum level mark
4. Minimum level mark
1. Réservoir d’huile de moteur
2. Bouchon de remplissage de l’huile de moteur
3. Repère de niveau maximum
4. Repère de niveau minimum
1. Depósito de aceite de motor
2. Tapa de relleno de aceite de motor
3. Marca de nivel máximo
4. Marca de nivel mínimo
EBU00812
Engine oil and oil filter cartridge
The engine oil level should be checked before
each ride. In addition, the oil must be changed
and the oil filter cartridge replaced at the inter-
vals specified in the periodic maintenance and
lubrication chart.
To check the engine oil level
1. Place the ATV on a level surface.
2. Start the engine, warm it up until the en-
gine oil has reached a normal tempera-
ture of 60˚C, let it continue to idle for ten
seconds, and then turn the engine off.
NOTE:
To achieve the proper engine oil temperature
for an accurate oil level reading, the engine
must have first completely cooled down, and
then warmed up again for several minutes to
normal operating temperature.
3. Wait a few minutes until the oil settles, re-
move the engine oil tank filler cap, wipe
the dipstick clean, insert it back into the
filler hole (without screwing it in), and
then remove it again to check the oil level.

8-21
Yuki_DATA2:HM00G210_YFM660R-60:YFM350-8.frameEL
1. Engine guard 2. Bolt (
× 6)
1. Protège-carter 2. Boulon (
× 6)
1. Protector del motor 2. Perno (
× 6)
To change the engine oil (with or without oil
filter cartridge replacement)
1. Remove the engine guard by removing
the bolts.
2. Start the engine, warm it up for several
minutes, and then turn it off.
3. Place an oil pan under the engine to col-
lect the used oil.

8-23
Yuki_DATA2:HM00G210_YFM660R-60:YFM350-8.frameEL
1. Engine oil crankcase drain bolt
1. Boulon de vidange du carter d’huile de moteur
1. Perno de drenaje de aceite de motor del cárter
4. Remove the crankcase drain bolt.
5. Check the washer for damage, and re-
place it if necessary.
6. Remove the engine oil tank filler cap and
the drain bolt.
NOTE:
Skip steps 7–8 if the oil filter cartridge is not be-
ing replaced.
1. Engine oil tank drain bolt
1. Boulon de vidange du réservoir d’huile de moteur
1. Perno de drenaje de aceite de motor del motor

8-25
Yuki_DATA2:HM00G210_YFM660R-60:YFM350-8.frameEL
1. Engine oil filter cartridge
2. Oil filter wrench
1. Cartouche du filtre à huile de moteur
2. Clé pour filtre à huile
1. Cartucho del filtro de aceite de motor
2. Llave para filtros de aceite
7. Remove the oil filter cartridge with an oil
filter wrench.
NOTE:
An oil filter wrench is available at a nearby
Yamaha dealer.
8. Install a new oil filter cartridge and tighten
it to the specified torque with an oil filter
wrench.
9. Install the crankcase engine oil drain bolt
and the engine oil tank drain bolt, then
tighten them to the specified torques. Tightening torque:
Oil filter cartridge:
17 Nm (1.7 m·kg)
Tightening torques:
Crankcase engine oil drain bolt:
30 Nm (3.0 m·kg)
Engine oil tank drain bolt:
25 Nm (2.5 m·kg)

8-47
Yuki_DATA2:HM00G210_YFM660R-60:YFM350-8.frameEL
1. Unlock
1. Déverrouiller
1. Levántelo
1. Guide 2. Air filter element
3. Element plate
1. Guide 2. Élément du filtre à air
3. Plaquette de retenue d’élément
1. Guía 2. Elemento filtrante
3. Element plate
5. Squeeze the excess solvent out of the fil-
ter element and let it dry.
CAUTION:
Do not twist the filter element when squeez-
ing it.
6. Inspect the element and replace it if dam-
aged.
7. Apply foam air filter oil to the element. If
foam air filter oil is not available, motor oil
may be used.
NOTE:
The element should be wet but not dripping.
8. Pull the element over its frame.
9. Install the element assembly.
10. Install the air filter case cover and be sure
to connect the hose.

Yuki_DATA2:HM00G210_YFM660R-60:YFM350-SPEC-E.frame
10-2
ER
10
10
10
10
10
10
10
10
10
10
101
Engine oil:
Type-20°-10°0°10°20°30°40°50°C
5W/30
10W/30
10W/40
20W/50
20W/40
15W/40
Recommended engine oil classification API Service SE, SF, SG type or higher
Quantity:
Periodic oil change
With oil filter cartridge replacement
Total amount1.9 L
1.95 L
2.3 L MODEL YFM660R
CAUTION:
Be sure to use motor oils that do not contain anti-
friction modifiers. Passenger car motor oils (often
labeled “Energy Conserving”) contain anti-friction
additives which will cause clutch and/or starter
clutch slippage, resulting in reduced component
life and poor engine performance.
