EBU00015
1-CONTENTS
LOCATION OF THE WARNING AND
SPECIFICATION LABELS ...................... 1-1
SAFETY INFORMATION ......................... 2-1
DESCRIPTION AND MACHINE
IDENTIFICATION ................................... 3-1
Identification number records .............. 3-3
Key identification number .................... 3-5
Vehicle identification number .............. 3-5
Model label .......................................... 3-7
CONTROL FUNCTIONS ........................ 4-1
Main switch........................................... 4-1
Indicator and warning lights ................. 4-3
Handlebar switches ........................... 4-11
Throttle lever ..................................... 4-15
Speed limiter ..................................... 4-17
Clutch lever ....................................... 4-19
Brake lever ......................................... 4-19
Brake pedal ........................................ 4-21
Parking brake .................................... 4-23
Shift pedal ......................................... 4-27
Reverse knob “REV”.......................... 4-27
1234
Fuel tank cap .................................... 4-29
Fuel cock ........................................... 4-29
Starter (choke) .................................. 4-31
Seat.................................................... 4-33
Front shock absorber adjustment ...... 4-35
Rear shock absorber adjustment ....... 4-37
PRE-OPERATION CHECKS .................. 5-1
Front and rear brakes .......................... 5-5
Fuel ...................................................... 5-9
Engine oil ........................................... 5-13
Coolant .............................................. 5-17
Chain ................................................. 5-19
Throttle lever ..................................... 5-21
Fittings and Fasteners ...................... 5-21
Lights ................................................. 5-21
Switches............................................. 5-21
Tires .................................................. 5-23
How to measure tire pressure ........... 5-27
Tire wear limit .................................... 5-29
5
U5LP61.book Page 1 Monday, August 27, 2001 3:49 PM

OPERATION ...........................................6-1
Starting a cold engine ..........................6-3
Starting a warm engine ........................6-9
Warming up ..........................................6-9
Reverse knob operation and
reverse driving .................................6-11
Shifting ................................................6-15
To start out and accelerate ................6-17
To decelerate .....................................6-21
Engine break-in ..................................6-23
Parking ...............................................6-27
Parking on a slope ..............................6-29
Accessories and loading ....................6-31
Accessories ........................................6-31
Loading ..............................................6-33
RIDING YOUR ATV..................................7-1
Getting to know your ATV .....................7-3
Ride with care and good judgement .....7-5
Be careful where you ride ...................7-27
Turning your ATV ................................7-39
Climbing uphill.....................................7-45
Riding downhill ....................................7-55
Crossing a slope .................................7-59
Crossing through shallow water ..........7-63
Riding over rough terrain ....................7-67
Sliding and skidding ............................7-69
67
What to do if ... ................................... 7-73
What to do ... ...................................... 7-73
PERIODIC MAINTENANCE AND
ADJUSTMENT ........................................ 8-1
Owner’s manual and tool kit ................ 8-3
Periodic maintenance/lubrication ......... 8-7
Panel removal and installation ........... 8-15
Engine oil and oil filter cartridge ......... 8-17
Cooling system ................................... 8-31
Changing the coolant.......................... 8-33
Spark plug inspection ......................... 8-41
Air filter element cleaning .................. 8-45
Carburetor adjustment ....................... 8-51
Idle speed adjustment ....................... 8-53
Throttle lever adjustment ................... 8-55
Valve clearance adjustment .............. 8-57
Front and rear brake pad inspection... 8-59
Inspecting the brake fluid level ........... 8-61
Brake fluid replacement ...................... 8-65
Front brake adjustment ...................... 8-67
Rear brake adjustment ....................... 8-69
Parking brake adjustment ................... 8-71
Adjusting the rear brake light switch ... 8-75
Clutch lever free play adjustment ...... 8-77
Drive chain slack check ..................... 8-79
Drive chain slack adjustment .............. 8-81
8
U5LP61.book Page 2 Monday, August 27, 2001 3:49 PM

3-1
EBU00032
DESCRIPTION AND MACHINE
IDENTIFICATION1. Seat
2. Fuel tank cap
3. Engine oil tank
4. Brake pedal
5. Headlight
6. Fuel cock
7. Throttle stop screw
8. Coolant reservoir
9. Tail/brake light10. Shift pedal
11. Clutch lever
12. Handlebar switches
13. Parking brake
14. Main switch
15. Reverse knob
16. Throttle lever
17. Brake leverNOTE:The machine you have purchased may differ
slightly from those shown in the figures of this
manual.
U5LP61.book Page 1 Monday, August 27, 2001 3:49 PM

5-1
EBU00113
PRE-OPERATION CHECKS
Before using this machine, check the following points:
ITEM ROUTINE PAGE
Front brakeCheck operation, free play, fluid level and fluid leakage.
Fill with DOT 4 brake fluid if necessary.5-5 ~ 5-7,
8-59 ~ 8-67
Rear brakeCheck operation, fluid level and fluid leakage.
Fill with DOT 4 brake fluid if necessary.5-5 ~ 5-7,
8-59 ~ 8-65, 8-69
ClutchCheck operation, condition and lever free play. 8-77
Parking brakeCheck operation, condition and cable free play. 8-71 ~ 8-73
FuelCheck fuel level.
Fill with fuel if necessary.5-9 ~ 5-11
Engine oilCheck oil level.
Fill with oil if necessary.5-13 ~ 5-15,
8-17 ~ 8-29
Coolant reservoirCheck coolant level.
Fill with coolant if necessary.5-17 ~ 5-19,
8-31 ~ 8-39
Drive chainCheck chain slack and condition.
Adjust if necessary.5-19, 8-77 ~ 8-83
ThrottleCheck for proper throttle cable operation and free play. 5-21, 8-55
Wheels and tiresCheck tire pressure, wear and damage.5-23 ~ 5-29,
8-95 ~ 8-97
Fittings and fastenersCheck all fittings and fasteners. 5-21
LightsCheck for proper operation. 5-21, 8-107 ~ 8-117
U5LP61.book Page 1 Monday, August 27, 2001 3:49 PM

5-13
EBU00947
Engine oil
Make sure the engine oil is at the specified level.
Fill with oil as necessary. (See pages 8-17 ~ 8-29
for details.)
Recommended oil:
Recommended engine oil classification:
API Service SE, SF, SG type or higher
-20˚ -10˚ 0˚
10˚20˚ 30˚40˚50˚C
10W/30
15W/4020W/4020W/50
10W/40
5W/30
U5LP61.book Page 13 Monday, August 27, 2001 3:49 PM

5-15
CAUTION:_ Be sure to use motor oils that do not contain
anti-friction modifiers. Passenger car motor
oils (often labeled “ENERGY CONSERVING II”)
contain anti-friction additives which will cause
clutch and/or starter clutch slippage, resulting
in reduced component life and poor engine
performance. _
Oil quantity:
Total amount:
2.3 L
Periodic oil change:
1.9 L
With oil filter replacement:
1.95 L
U5LP61.book Page 15 Monday, August 27, 2001 3:49 PM

8-7
EBU00262
PERIODIC MAINTENANCE/LUBRICATION
ITEM ROUTINEINITIAL EVERY
1
month3
months6
months6
months1
year
Valves*•Check valve clearance.
•Adjust if necessary.
Cooling system•Check coolant leakage.
•Repair if necessary.
•Replace coolant every 24 months.Spark plug•Check condition.
•Adjust gap and clean.
•Replace if necessary.Air filter element•Clean.
•Replace if necessary.Every 20~40 hours
(More often in wet or dusty areas.)
Carburetors*•Check starter (choke) operation.
•Adjust engine idling speed and synchronization.Crankcase breather
system*•Check breather hose for cracks or damage.
•Replace if necessary.Exhaust system*•Check for leakage.
•Tighten if necessary.
•Replace gasket if necessary.Fuel line*•Check fuel hose for cracks or damage.
•Replace if necessary.Engine oil
•Replace (Warm engine before draining.)Engine oil filter cartridge
•Replace if necessary.Drive chain
•Check and adjust slack/alignment/clean/lube.Front brake•Check free play/operation/fluid leakage/
See NOTE Page 8-8.
•Correct if necessary.Rear brake*•Check operation/fluid leakage/See NOTE Page 8-8.
•Correct if necessary.U5LP61.book Page 7 Monday, August 27, 2001 3:49 PM

8-17 1. Engine oil tank
2. Engine oil tank filler cap
3. Maximum level mark
4. Minimum level mark
1. Réservoir d’huile de moteur
2. Bouchon de remplissage de l’huile de moteur
3. Repère de niveau maximum
4. Repère de niveau minimum
1. Depósito de aceite de motor
2. Tapa de relleno del depósito de aceite de motor
3. Marca de nivel máximo
4. Marca de nivel mínimo
EBU01014
Engine oil and oil filter cartridge
The engine oil level should be checked before
each ride. In addition, the oil must be changed and
the oil filter cartridge replaced at the intervals
specified in the periodic maintenance and lubrica-
tion chart.
To check the engine oil level
1. Place the ATV on a level surface.
2. Start the engine, warm it up until the engine
oil has reached a normal temperature of
60°C, let it continue to idle for ten seconds,
and then turn the engine off.NOTE:_ To achieve the proper engine oil temperature for
an accurate oil level reading, the engine must
have first completely cooled down, and then
warmed up again for several minutes to normal
operating temperature. _3. Wait a few minutes until the oil settles, re-
move the engine oil tank filler cap, wipe the
dipstick clean with a clean rag, insert it back
into the filler hole (without screwing it in), and
then remove it again to check the oil level.
U5LP61.book Page 17 Monday, August 27, 2001 3:49 PM

8-19
NOTE:_ The engine oil should be between the minimum
and maximum level marks. _4. If the engine oil is below the minimum level
mark, add sufficient oil of the recommended
type to raise it to the correct level.NOTE:_ When adding oil, be careful not to overfill the en-
gine oil tank; the oil level rises faster starting from
the half-level-portion on the dipstick. _5. Insert the dipstick into the oil filler hole, and
then tighten the oil filler cap.CAUTION:_ Make sure that the oil filler cap is securely
tightened, otherwise oil may seep out when
the engine is running. _
U5LP61.book Page 19 Monday, August 27, 2001 3:49 PM

8-21 1. Engine guard 2. Bolt (× 6)
1. Protège-carter 2. Boulon (× 6)
1. Protector del motor 2. Perno (× 6)
To change the engine oil (with or without oil fil-
ter cartridge replacement)
1. Remove the engine guard by removing the
bolts.
2. Start the engine, warm it up for several min-
utes, and then turn it off.
3. Place an oil pan under the engine to collect
the used oil.
U5LP61.book Page 21 Monday, August 27, 2001 3:49 PM
