TABLE OF CONTENTS
LOCATION OF THE WARNING AND
SPECIFICATION LABELS ............................ 1-1
SAFETY INFORMATION .............................. 2-1
DESCRIPTION .............................................. 3-1Left view ...................................................... 3-1
Right view.................................................... 3-2
Controls and instruments ............................ 3-3
INSTRUMENT AND CONTROL
FUNCTIONS .................................................. 4-1 Main switch ................................................ 4-1
Indicator lights and warning lights .............. 4-2
Self-diagnosis device ................................. 4-3
Handlebar switches .................................... 4-4
Throttle lever .............................................. 4-4
Speed limiter .............................................. 4-5
Clutch lever ................................................ 4-6
Brake lever (YFM700RE) ............................ 4-6
Brake lever (YFM700RSE).......................... 4-7
Brake pedal ................................................ 4-7
Parking brake lever .................................... 4-8
Shift pedal .................................................. 4-9 Reverse knob “REV” ...................................4-9
Fuel tank cap ............................................4-10
Fuel ...........................................................4-10
Seat ..........................................................4-12
Adjusting the front shock absorber
assemblies (YFM700RE) .........................4-13
Adjusting the front shock absorber assemblies (YFM700RSE) ......................4-15
Adjusting the rear shock absorber assembly (YFM700RE)............................4-20
Adjusting the rear shock absorber assembly (YFM700RSE) .........................4-22
PRE-OPERATION CHECKS ..........................5-1 Fuel .............................................................5-4
Engine oil ....................................................5-4
Coolant .......................................................5-4
Front and rear brakes .................................5-4
Throttle lever ...............................................5-5
Drive chain ..................................................5-5
Tires ............................................................5-5
Chassis fasteners .......................................5-7
Instruments, lights and switches .................5-7U1PE61E0.book Page 1 Thursday, April 4, 2013 6:18 PM
Page 9 of 162

OPERATION .................................................. 6-1Starting the engine ..................................... 6-1
Shifting ....................................................... 6-2
Operating the reverse knob and driving in reverse ..................................................... 6-4
Engine break-in .......................................... 6-5
Parking ....................................................... 6-6
Parking on a slope ..................................... 6-6
Accessories and loading ............................ 6-7
RIDING YOUR ATV ...................................... 7-1 GETTING TO KNOW YOUR ATV............... 7-2
RIDE WITH CARE AND GOOD JUDGMENT .............................................. 7-2
BE CAREFUL WHERE YOU RIDE ............. 7-9
TURNING YOUR ATV .............................. 7-12
CLIMBING UPHILL ................................... 7-13
RIDING DOWNHILL.................................. 7-16
CROSSING A SLOPE............................... 7-18
CROSSING THROUGH SHALLOW WATER ................................................... 7-19
RIDING OVER ROUGH TERRAIN ........... 7-20
SLIDING AND SKIDDING ......................... 7-21
WHAT TO DO IF... .................................... 7-22
WHAT TO DO... ........................................ 7-22 PERIODIC MAINTENANCE AND
ADJUSTMENT................................................8-1
Owner’s manual and tool kit .......................8-2
Periodic maintenance chart for the emission control system ...........................8-3
General maintenance and lubrication chart ..........................................................8-5
Removing and installing the panel ............8-10
Checking the spark plug ...........................8-10
Engine oil and oil filter element .................8-13
Coolant .....................................................8-17
Cleaning the air filter element ...................8-21
Cleaning the spark arrester ......................8-25
Adjusting the engine idling speed .............8-27
Adjusting the throttle lever free play .........8-28
Valve clearance ........................................8-29
Adjusting the reverse lock release cable .......................................................8-29
Brakes .......................................................8-29
Checking the front and rear brake pads ...8-30
Checking the brake fluid level ...................8-31
Changing the brake fluid ...........................8-34
Checking the front brake lever free play ...8-34
Checking the brake pedal height ..............8-34
Adjusting the parking brake free play .......8-35
Brake light switches ..................................8-36
Adjusting the clutch lever free play ...........8-37U1PE61E0.book Page 2 Thursday, April 4, 2013 6:18 PM
Page 10 of 162

Drive chain slack ...................................... 8-38
Lubricating the drive chain ....................... 8-40
Checking and lubricating the cables ........ 8-41
Checking and lubricating the brake and clutch levers ........................................... 8-42
Checking the shift pedal ........................... 8-42
Checking and lubricating the brake pedal ...................................................... 8-42
Checking the wheel hub bearings ............ 8-42
Lubricating the swingarm pivots ............... 8-43
Lubricating the rear suspension relay arm and connecting arm pivoting points ........ 8-43
Lubricating the upper and lower arm pivots ...................................................... 8-44
Lubricating the steering shaft ................... 8-45
Battery ...................................................... 8-46
Replacing a fuse ...................................... 8-48
Replacing a headlight bulb ....................... 8-50
Adjusting a headlight beam ...................... 8-52
Tail/brake light .......................................... 8-52
Removing a wheel .................................... 8-52
Installing a wheel ...................................... 8-53
Troubleshooting ....................................... 8-54
Troubleshooting charts ............................. 8-55
CLEANING AND STORAGE .......................... 9-1 Cleaning ..................................................... 9-1 Storage .......................................................9-2
SPECIFICATIONS .......................................10-1
CONSUMER INFORMATION.......................11-1 Identification numbers ...............................11-1
U1PE61E0.book Page 3 Thursday, April 4, 2013 6:18 PM
Page 28 of 162

3-3
3
EBU17712Controls and instruments
TIPThe ATV you have purchased may differ slightly
from the figures shown in this manual.
1. Clutch lever
2. Parking brake lever
3. Main switch
4. Front brake fluid reservoir
5. Brake lever
6. Throttle lever
7. Reverse knob
8. Fuel tank cap
9. Handlebar switches
12 3
4
5
67
8
9
U1PE61E0.book Page 3 Thursday, April 4, 2013 6:18 PM
Page 34 of 162

4-6
43. Tighten the locknut.
EBU18382Clutch lever The clutch lever is located on the left handlebar
and the ignition circuit cut-off system is incorporat-
ed in the clutch lever holder. To disengage the
clutch, pull the clutch lever toward the handlebar
grip. To engage the clutch, release the clutch lever.
The clutch lever should be pulled rapidly and re- leased slowly for smooth clutch operation. (See
page 6-1 for a description of the ignition circuit cut-
off system.)
EBU18411Brake lever (YFM700RE)The brake lever is located at the right handlebar
grip. To apply the front brake, pull the brake lever
toward the handlebar grip.
1. Locknut
2. Adjusting screw
3. No more than 12 mm (0.47 in)
3
12
(a)
(b)
1. Clutch lever
