9-5
6. Clean the seat with a vinyl upholstery
cleaner to keep the cover pliable and
glossy.
7. Automotive type wax may be applied to all
painted and chrome plated surfaces. Avoid
combination cleaner-waxes. Many contain
abrasives which may mar the paint or pro-
tective finish.
When finished, start the engine and let it
idle for several minutes.
w
Wet brakes may have reduced stopping abili-
ty, increasing the chance of an accident.
Test the brakes after washing. Apply the
brakes several times at slow speeds to let
friction dry out the linings.
5NE-9-61 9~ 4/26/01 1:30 PM Page 302

9-7
EBU00427
B. STORAGE
Long term storage (60 days or more) of your
machine will require some preventive proce-
dures to guard against deterioration. After thor-
oughly cleaning the machine, prepare for stor-
age as follows:
1. Fill the fuel tank with fresh fuel and add
fuel stabilizer (if available).
NOTE:
Use of fuel stabilizer eliminates the need to
drain the fuel system. Consult a Yamaha dealer
if the fuel system is to be drained instead.
2. Remove the spark plug, pour about one
tablespoon of SAE 10W30 or 20W40
motor oil in the spark plug hole and rein-
stall the spark plug. Ground the spark plug
wire and turn the engine over several times
to coat the cylinder wall with oil.
3. Lubricate all control cables.
5NE-9-61 9~ 4/26/01 1:30 PM Page 304

10-1
Model YFM80
Dimensions:
Overall length 1,520 mm
Overall width 825 mm
Overall height 960 mm
Seat height 650 mm
Wheelbase 1,030 mm
Minimum ground clearance 100 mm
Minimum turning radius 2,000 mm
Basic weight:
With oil and full fuel tank 116 kg
Engine:
Type Air-cooled 4-stroke, SOHC
Cylinder arrangement Single cylinder, forward-inclined
Displacement 79 cm
3
Bore × Stroke 47.0 ×45.6 mm
Compression ratio 9.6 : 1
Starting system Electric starter
Lubrication system: Wet sump
EBU00428
SPECIFICATIONS
5NE-9-61 9~ 4/26/01 1:30 PM Page 308

10-2
10
MODEL YFM80
Engine oil:
Type
Recommended engine oil classification: API Service SE, SF, SG type or higher
Quantity:
Periodic oil change 0.80 L
Total amount0.95 L
cC
Be sure to use motor oils that do not contain
anti-friction modifiers. Passenger car motor
oils (often labeled “Energy Conserving”) con-
tain anti-friction additives which will cause
clutch and/or starter clutch slippage, result-
ing in reduced component life and poor
engine performance.
–20° 10° 20° 30° 40°
10W30
10W40
20W40
20W5050°C
0° –10°
5W30
15W40
