length YAMAHA YFM90R 2020 Owners Manual

8-23
8
EBU24334Adjusting the front brake lever free
playPeriodically check the front brake lever free play
and adjust if necessary.1. Loosen the upper locknut and fully turn in the upper adjusting bolt.
2. Loosen the lower locknut.
3. Turn the lower adjusting bolt in direction (a) to increase the lever free play, and in direction
(b) to decrease it. 4. Tighten the lower locknut.
5. While applying the front brake, turn out the
upper adjusting bolt until the upper and lower
cable lengths are equal. The cable joint will
become vertical.1. Front brake lever free playFront brake lever free play:20.0–25.0 mm (0.79–0.98 in)
1
1. Upper locknut
2. Upper adjusting bolt
3. Lower locknut
4. Lower adjusting bolt
1 2
4
3 (a)
(b)
UBD364E0.book Page 23 Monday, January 28, 2019 9:30 AM

10-1
10
EBU25963
SPECIFICATIONS
Dimensions:Overall length:1485 mm (58.5 in)
Overall width: 1020 mm (40.2 in)
Overall height:
955 mm (37.6 in)
Seat height: 750 mm (29.5 in)
Wheelbase: 1030 mm (40.6 in)
Ground clearance:
210 mm (8.3 in)
Minimum turning radius: 3.0 m (9.84 ft)
Maximum water depth: 20 cm (8 in)Weight:Curb weight:126.5 kg (279 lb)Loading:Maximum loading limit:
82.0 kg (181 lb)
(Total weight of rider, cargo, accessories, and tongue)Noise and vibration level:Noise level (77/311/EEC):73.0 dB(A) at 3500 r/min Uncertainty of measurement:
0.4 dB(A)
Vibration on seat (EN1032, ISO5008): 1.5 m/s²
Uncertainty of measurement: 0.3 m/s²
Vibration on handle (EN1032, ISO5008):
5.2 m/s²
Uncertainty of measurement: 1.3 m/s²
Engine:Combustion cycle:
4-stroke
Cooling system: Air cooled
Valve train: SOHC
Number of cylinders:
Single cylinder
Displacement: 90 cm³
Bore × stroke:
47.0 × 51.8 mm (1.85 × 2.04 in)
Compression ratio:
9.2 : 1
Starting system: Electric starter and kickstarter
Lubrication system: Wet sump
UBD364E0.book Page 1 Monday, January 28, 2019 9:30 AM

10-4
10
Electrical system:System voltage:12 V
Ignition system:
CDI
Charging system: AC magnetoBattery:Model:
GTX5L-BS
Voltage, capacity: 12 V, 4.0 AhLights:Neutral indicator light:
3.5 W
Reverse indicator light: 3.5 WFuses:Main fuse:
7.5 AEBU30403Noise and vibration levels statement (for Eu-
rope)
The figures quoted are emission levels and are not
necessarily safe working levels. Whilst there is a
correlation between the emission and exposure
levels, this cannot be used reliably to determine
whether or not further precautions are required. Factors that influence the actual level of exposure
of work-force include the characteristics of the
work room, the other sources of noise, etc. i.e. the
number of machines and other adjacent process-
es, and the length of time for which an operator is
exposed to the noise. Also the permissible expo-
sure level can vary from country. This information,
however, will enable the user of the machine to
make a better evaluation of the hazard and risk.
EBU38670CO2 emissions levels statement (for Europe)
This CO2 measurement results from testing over a
fixed test cycle under laboratory conditions a(n)
(parent) engine representative of the engine type
(engine family) and shall not imply or express any
guarantee of the performance of a particular en-
gine.
