YAMAHA YXZ1000R 2017 Owners Manual

10-5
10
Electrical system:Ignition system:TCI
Charging system:
AC magnetoBattery:Model:U1-H11L
Voltage, capacity:
12 V, 28.0 AhBulb voltage, wattage × quantity:Headlight:
LED
Tail/brake light:
LED
Neutral indicator light: LED
High beam indicator light: LED
Reverse indicator light:
LED
Coolant temperature warning light: LED
Engine trouble warning light: LED
Parking brake indicator light:
LED
Differential gear lock indicator light: LED
EPS warning light: LED Helmet/Seat belt indicator light:
14 V, 0.85 W × 2
Shift timing indicator light: LED
Half clutch indicator light:
LED
Launch system indicator light: LED
YCC-S system warning light: LED
Fuses:Main fuse:50.0 A
Fuel injection system fuse: 15.0 A
EPS fuse:
40.0 A
Headlight fuse: 15.0 A
Signaling system fuse: 10.0 A
Ignition fuse:
15.0 A
Auxiliary DC jack fuse: 10.0 A
Accessory fuse: 10.0 A
YCC-S motor control fuse:
30.0 A
Backup fuse: 10.0 A
UB577AE0.book Page 5 Wednesday, June 8, 2016 9:35 AM

10-6
10
Four-wheel-drive motor fuse:10.0 A
Radiator fan motor fuse: 30.0 AEBU33221For Europe only
The figures quoted are emission levels and
are not necessarily safe working levels. Whilst
there is a correlation between the emission
and exposure levels, this cannot be used reli-
ably to determine whether or not further pre-
cautions are required. Factors that influence
the actual level of exposure of work-force in-
clude the characteristics of the work room,
the other sources of noise, etc. i.e. the num-
ber of machines and other adjacent process-
es, and the length of time for which an
operator is exposed to the noise. Also the
permissible exposure level can vary from
country. This information, however, will en-
able the user of the machine to make a better
evaluation of the hazard and risk.UB577AE0.book Page 6 Wednesday, June 8, 2016 9:35 AM

11-1
11
EBU32770
CONSUMER INFORMATION
EBU33320Identification number recordsRecord the vehicle identification number and
model label information in the spaces provid-
ed for assistance when ordering spare parts
from a Yamaha dealer or for reference, in
case the vehicle is stolen.
VEHICLE IDENTIFICATION NUMBER:
MODEL LABEL INFORMATION:EBU32800Vehicle identification number
The vehicle identification number is stamped
into the frame.The vehicle identification number is used to
identify your vehicle.
EBU33331Model label
The model label can be found under the driver
seat. Record the information on this label in
the space provided. This information will be
needed to order spare parts from your
Yamaha dealer.1. Vehicle identification number
1
UB577AE0.book Page 1 Wednesday, June 8, 2016 9:35 AM

11-2
11
1. Model label
1
UB577AE0.book Page 2 Wednesday, June 8, 2016 9:35 AM

12-1
12
INDEX
AAccelerator pedal ......................................................... 4-20
Accelerator pedal, checking ........................................ 8-48
Accelerator pedal, Pre-operation check ........................ 5-6
Air filter ......................................................................... 8-37
Air filter case hoses, cleaning ...................................... 8-41
Auxiliary DC jack .......................................................... 4-54
Axle boots .................................................................... 8-35BBasic guide for safe use ................................................ 7-1
Battery, Periodic maintenance .................................... 8-56
Bead lock, checking and tightening (YXZ10YESH) ..... 8-54
Brake and YCC-S clutch fluid levels, checking ........... 8-45
Brake fluid, replacing ................................................... 8-47
Brake light switch ........................................................ 8-50
Brake pedal .................................................................. 4-21
Brake pedal, checking ................................................. 8-48
Brakes, Periodic maintenance ..................................... 8-44
Brakes, Pre-operation check ......................................... 5-3CCable, inspecting and lubrication ................................ 8-50
Cargo bed .................................................................... 4-32
Cleaning ......................................................................... 9-1
Control cables, Pre-operation check ............................. 5-8
Coolant, Periodic maintenance ................................... 8-33
Coolant, Pre-operation check ........................................ 5-6
Coolant temperature warning light ................................ 4-4
Cup holders ................................................................. 4-31
DDifferential gear lock indicator light ............................... 4-3
Differential gear oil, Periodic maintenance .................. 8-31
Differential gear, Pre-operation check ........................... 5-6
Doors ........................................................................... 4-25
Drive mode, selecting .................................................... 6-9
Driver seat position ...................................................... 4-27
Drive select lever and shift paddles, Pre-operation check ........................................................................... 5-7
Drive shaft universal joint, lubrication .......................... 8-53
Drivetrain icon ................................................................ 4-3EEngine break-in .............................................................. 6-1
Engine oil and oil filter, Periodic maintenance ............. 8-15
Engine oil, Pre-operation check .................................... 5-5
Engine trouble warning light .......................................... 4-5
EPS warning light .......................................................... 4-5FFinal gear oil, Periodic maintenance ............................ 8-29
Final gear, Pre-operation check .................................... 5-6
Fittings and fasteners, Pre-operation check ................. 5-8
Flag pole bracket ......................................................... 4-33
Front and rear brake pads, checking .......................... 8-44
Fuel, Pre-operation check ............................................. 5-3
Fuel tank cap ............................................................... 4-24
Fuse, replacing ............................................................ 8-61GGlove compartment ..................................................... 4-28HHalf clutch indicator light ............................................... 4-6
Headlight beam, adjusting ........................................... 8-63
UB577AE0.book Page 1 Wednesday, June 8, 2016 9:35 AM

12-2
12
Headlights .................................................................... 8-63
Helmet indicator light .....................................................4-9
High beam indicator light ............................................... 4-3
Hood ............................................................................ 8-10IIdentification number records ...................................... 11-1
Indicator lights and warning lights ................................. 4-2
Instruments, lights and switches, Pre-operation check ........................................................................... 5-8JJump-starting ............................................................... 8-59LLabel locations ............................................................... 1-1
Launch system indicator light ........................................ 4-6
Launch system operation ............................................... 6-7
Light switch .................................................................. 4-19
Loading ........................................................................6-11MMain switch .................................................................... 4-1
Maintenance and lubrication chart ................................8-6
Maintenance chart, emission control system ................ 8-4
Model label ................................................................... 11-1
Multi-function meter unit ................................................ 4-9NNeutral indicator light .....................................................4-2OOn-Command drive knob ............................................ 4-20
Owner’s manual and tool kit .......................................... 8-2PPanels .......................................................................... 8-10
Parking ......................................................................... 6-11 Parking brake indicator light .......................................... 4-3
Parking brake lever ...................................................... 4-21
Parking brake lever free play, adjusting ....................... 8-49
Parking brake pads, checking ..................................... 8-45
Passenger handhold, Pre-operation check ................... 5-7
Pedal, lubrication ......................................................... 8-51
RRear knuckle upper and lower pivot, lubrication ......... 8-53
Reverse indicator light ................................................... 4-2SSafety information .......................................................... 2-1
Seat belt indicator light .................................................. 4-9
Seat belts ..................................................................... 4-28
Seat belts, Pre-operation check .................................... 5-7
Seats ............................................................................ 4-25
Shifting and reverse driving ........................................... 6-3
Shifting, drive select lever and shift paddle ................. 4-23
Shift timing indicator light .............................................. 4-4
Shock absorber assemblies, adjusting the front ......... 4-33
Shock absorber assemblies, adjusting the rear ........... 4-43
Spark arrester, cleaning ............................................... 8-42
Spark plugs, checking ................................................. 8-35
Specifications .............................................................. 10-1
Stabilizer bushes, checking ......................................... 8-51
Starting the engine ......................................................... 6-2
Steering, Pre-operation check ....................................... 5-7
Steering shaft, lubrication ............................................ 8-53
Steering wheel position ................................................ 4-27
Storage .......................................................................... 9-2
Storage compartments ................................................ 4-29TTail/brake light ............................................................. 8-64
UB577AE0.book Page 2 Wednesday, June 8, 2016 9:35 AM

12-3
12
Tire, replacing .............................................................. 8-55
Tires, Pre-operation check ............................................ 5-8
Transmission oil ........................................................... 8-26
Transmission, Pre-operation check ............................... 5-6
Troubleshooting ........................................................... 8-64
Troubleshooting charts ................................................ 8-66UUpper and lower arm pivot, lubrication ....................... 8-52VValve clearance ............................................................ 8-44
Vehicle identification number ...................................... 11-1WWheel installation ......................................................... 8-56
Wheel removal ............................................................. 8-54YYCC-S clutch ............................................................... 8-47
YCC-S clutch, Pre-operation check .............................. 5-8
YCC-S system ............................................................. 4-22
YCC-S system warning light .......................................... 4-7
UB577AE0.book Page 3 Wednesday, June 8, 2016 9:35 AM

Original instructions
PRINTED IN USA
2016.06-0.3× 1 CR
(E)
