torque YAMAHA YXZ1000R SS 2019 User Guide

8-25
8
TIPAn oil filter wrench is available from a Yamaha
dealer. 7. Apply a light coat of clean engine oil to
the O-ring of the new oil filter cartridge.TIPMake sure that the O-ring is properly seated.
8. Install the new oil filter cartridge, and thentighten to the specified torque.
1. Oil filter cartridge
2. Oil filter wrench
2
1
1. O-ringTightening torque:Oil filter cartridge:17 N·m (1.7 kgf·m, 13 lb·ft)
1
UB5H7AE0.book Page 25 Wednesday, July 4, 2018 1:37 PM

8-26
8
9. Follow steps 10–20 of the “To change theengine oil” section for the oil filling proce-
dure.
10. Slide the front portion of the center bot- tom panel into place as shown, and then
hook the left and right sides of the center
bottom panel into place.
11. Install the center bottom panel bolts, andthen tighten them to the specified torque.1. Torque wrench
1
1. Center bottom panel
1. Center bottom panel
1
1
UB5H7AE0.book Page 26 Wednesday, July 4, 2018 1:37 PM

8-27
8
12. Install the rear bottom panel by installingthe bolts, and then tightening them to the
specified torque.
1. Bolt A
2. Bolt B
3. Bolt C
1
2
3
1. Bolt A
2. Bolt B
3. Bolt CTightening torques:Bolt A:7 N·m (0.7 kgf·m, 5.2 lb·ft)
Bolt B: 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Bolt C: 7 N·m (0.7 kgf·m, 5.2 lb·ft)1
3
2
3
UB5H7AE0.book Page 27 Wednesday, July 4, 2018 1:37 PM

8-28
8
13. Install the side panel bolts, and then tight-en them to the specified torque.
EBU35107Transmission oilCheck the oil level and change the transmis-
sion oil at the intervals specified in the general
maintenance and lubrication chart.
1. Rear bottom panel
2. Bolt A
3. Bolt BTightening torques:Bolt A:7 N·m (0.7 kgf·m, 5.2 lb·ft)
Bolt B: 7 N·m (0.7 kgf·m, 5.2 lb·ft)
3
1
2
2
1. Bolt BTightening torque: Bolt B:7 N·m (0.7 kgf·m, 5.2 lb·ft)
1
1
UB5H7AE0.book Page 28 Wednesday, July 4, 2018 1:37 PM

8-30
8
TIPAdd a sufficient amount to raise to the maxi-
mum level mark, but do not overfill. 5. Check the O-ring for damage, and re-place it if necessary.
6. Install the transmission oil filler cap.
7. Install the panel.
To change the transmission oil 1. Place an oil pan under the transmission case to collect the used oil.
2. Remove the transmission oil filler cap.
3. Remove the transmission oil drain bolt and gasket.
TIPOil will flow out immediately when the drain
bolt is loosened. Take care not to lose the
bolt. 4. After draining the oil, install the transmis-sion oil drain bolt with a new gasket.
5. Tighten the drain bolt to the specified torque.1. Transmission oil drain bolt
2. Gasket2
1
UB5H7AE0.book Page 30 Wednesday, July 4, 2018 1:37 PM

8-31
8
6. Check the O-ring for damage, and re-place it if necessary.
7. Refill the transmission with the specified amount of the recommended oil.
8. Install the transmission oil filler cap.
9. Start the engine and let it idle while checking for oil leakage.
10. Stop the engine and check the oil level one last time.EBU36053Final gear oilCheck the oil level and change the final gear
oil at the intervals specified in the general
maintenance and lubrication chart.
NOTICEECB03590When checking or changing the final gear
oil, make sure that no foreign material en-
ters the final gear case. If necessary, clean
the final gear oil filler bolt and surrounding
area. TIPIf the recommended gear oil is not available,
SAE 80W-90 API GL-4 or GL-5 hypoid gear
oil may be used instead. Checking the final gear oil level1. Park the vehicle on a level surface.
Tightening torque: Transmission oil drain bolt:20 N·m (2.0 kgf·m, 15 lb·ft)
Recommended oil:SAE 80 API GL-4 Hypoid gear oil
Oil quantity: 0.47 L (0.50 US qt, 0.41 Imp.qt)
UB5H7AE0.book Page 31 Wednesday, July 4, 2018 1:37 PM

8-32
8
2. Remove the final gear oil filler bolt and itsgasket, and then check the oil level in the
final gear case. The oil level should be at
the brim of the filler hole.
3. If the oil is below the brim of the filler hole, add sufficient oil of the recommended
type to raise it to the correct level.
4. Check the gasket for damage, and re- place it if necessary. 5. Install the oil filler bolt and its gasket, and
then tighten the bolt to the specified
torque.
Changing the final gear oil 1. Park the vehicle on a level surface.
2. Place an oil pan under the final gear case
to collect the used oil.
3. Remove the final gear oil filler bolt, the fi-
nal gear oil drain bolt and their gasket to
drain the oil.1. Final gear oil
2. Gasket
3. Final gear oil filler bolt
4. Correct oil level
24
3
1
Tightening torque:Final gear oil filler bolt:23 N·m (2.3 kgf·m, 17 lb·ft)
UB5H7AE0.book Page 32 Wednesday, July 4, 2018 1:37 PM

8-33
8
4. Install the drain bolt and its new gasket,and then tighten the bolt to the specified
torque.
5. Refill with the recommended final gear oil up to the brim of the filler hole.
6. Check the oil filler bolt gasket for dam- age, and replace it if necessary. 7. Install the oil filler bolt and its gasket, and
then tighten the bolt to the specified
torque.
8. Check for oil leakage. If oil leakage is found, check for the cause.
EBU36063Differential gear oilCheck the oil level and change the differential
gear oil at the intervals specified in the gener-
al maintenance and lubrication chart.NOTICEECB03600When checking or changing the differen-
tial gear oil, make sure that no foreign ma-
terial enters the differential gear case. If
necessary, clean the differential gear oil
filler bolt and surrounding area.
1. Final gear oil drain bolt
2. GasketTightening torque:Final gear oil drain bolt:23 N·m (2.3 kgf·m, 17 lb·ft)
21
Tightening torque:Final gear oil filler bolt:23 N·m (2.3 kgf·m, 17 lb·ft)
UB5H7AE0.book Page 33 Wednesday, July 4, 2018 1:37 PM

8-34
8
TIPIf the recommended gear oil is not available,
SAE 80W-90 API GL-4 or GL-5 hypoid gear
oil may be used instead. Checking the differential gear oil level1. Park the vehicle on a level surface.
2. Remove the differential gear oil filler bolt and its gasket, and then check the oil lev-
el. It should be up to the brim of the filler
hole. 3. If the level is low, add sufficient oil of the
recommended type to raise it to the
specified level.
4. Check the gasket for damage, and re- place it if necessary.
5. Install the differential gear oil filler bolt
and its gasket, and then tighten the bolt
to the specified torque.
Recommended oil:SAE 80 API GL-4 Hypoid gear oil
Oil quantity: 0.18 L (0.19 US qt, 0.16 Imp.qt)
1. Differential gear oil filler bolt
2. Gasket
3. Differential gear oil
4. Correct oil level
1
2
3
4
UB5H7AE0.book Page 34 Wednesday, July 4, 2018 1:37 PM

8-35
8
Changing the differential gear oil1. Park the vehicle on a level surface.
2. Place an oil pan under the differential
gear case to collect the used oil.
3. Remove the differential gear oil filler bolt,
the differential gear oil drain bolt and their
gasket to drain the oil. 4. Install the differential gear oil drain bolt
and its new gasket, and then tighten the
bolt to the specified torque.
5. Refill the differential gear case with the recommended oil.
6. Check the oil filler bolt gasket for dam- age, and replace it if necessary.
7. Install the differential gear oil filler bolt and its gasket, and then tighten the bolt
to the specified torque.
8. Check for oil leakage. If oil leakage is found, check for the cause.Tightening torque:Differential gear oil filler bolt:23 N·m (2.3 kgf·m, 17 lb·ft)1. Differential gear oil drain bolt
2. Gasket
1 2
Tightening torque:Differential gear oil drain bolt:9.8 N·m (0.98 kgf·m, 7.2 lb·ft)
Tightening torque: Differential gear oil filler bolt:23 N·m (2.3 kgf·m, 17 lb·ft)
