CHASREAR SHOCK ABSORBER
2. Install:
lBushing 1
lCollar 2
lDust seal 3
NOTE:
lApply the molybdenum disulfide grease on
the bearing.
lApply the lithium soap base grease on the
bushing, collars and dust seals.
lInstall the dust seals with their lips facing
outward.
3. Install:
lRear shock absorber
4. Install:
lBolt (rear shock absorber-frame) 1
lNut (rear shock absorber-frame) 2
NOTE:
Apply the molybdenum disulfide grease on the
bolt.
5. Install:
lWasher 1
lBolt (rear shock absorber-relay arm) 2
NOTE:
lApply the molybdenum disulfide grease on
the bolt.
lInsert the bolt from right side.
6. Install:
lRear frame 1
lBolt (rear frame) 2
lBolt (reservoir tank) 3
T R..56 Nm (5.6 m · kg, 40 ft · lb)
T R..53 Nm (5.3 m · kg, 38 ft · lb)
T R..29 Nm (2.9 m · kg, 21 ft · lb)
T R..10 Nm (1.0 m · kg, 7.2 ft · lb)
7. Tighten:
lScrew (air filter joint) 1
1
T R..3 Nm (0.3 m · kg, 2.2 ft · lb)
