INSP
ADJ
3-7
RADIATOR CAP INSPECTION
cC
9
Do not mix more than one type of ethyl-
ene glycol antifreeze containing corro-
sion inhibitors for aluminum engine.
9Do not use water containing impurities
or oil.
7. Install:
9Radiator cap
Start the engine and warm it up for a sev-
eral minutes.
8. Check:
9Coolant level
Coolant level lowAdd coolant.
EC355000
RADIATOR CAP INSPECTION
1. Inspect:
9Seal (radiator cap) 1
9Valve and valve seat 2
Crack/DamageReplace.
Exist fur deposits 3Clean or replace.
Handling notes of coolant:
The coolant is harmful so it should be handled
with special care.
w
9
When coolant splashes to your eye.
Thoroughly wash your eye with water
and see your doctor.
9When coolant splashes to your clothes.
Quickly wash it away with water and then
with soap.
9When coolant is swallowed.
Quickly make him vomit and take him to
a doctor.
5NX-9-30-3A 6/5/01 3:59 PM Page 22

INSP
ADJ
3-10
THROTTLE CABLE ADJUSTMENT/
THROTTLE LUBRICATION
EC35A001
THROTTLE CABLE ADJUSTMENT
1. Check:
9Throttle grip free play a
Out of specificationAdjust.
2. Adjust:
9Throttle grip free play
EC35S002
THROTTLE LUBRICATION
1. Remove:
9Cap cover 1
9Throttle cable cap 2
2. Apply:
9Lithium soap base grease
On the throttle cable end a, tube guide
cable winding portion band roller sliding
surface c.
Throttle grip free play adjustment steps:
9Loosen the locknut 1.
9Turn the adjuster 2until the specified free
play is obtained.
9Tighten the locknut.
NOTE:
Before adjusting the throttle cable free play,
the engine idle speed should be adjusted.
w
After adjusting, turn the handlebar to
right and left and make sure that the
engine idling does not run faster.
Throttle grip free play ?a:
3~5 mm (0.12~0.20 in)
5NX-9-30-3A 6/5/01 3:59 PM Page 28

INSP
ADJ
3-12
TRANSMISSION OIL LEVEL CHECK
3. Inspect:
9Air filter element
DamageReplace.
4. Apply:
9Foam-air-filter oil or engine mixing oil
To the element.
NOTE:
Squeeze out the excess oil. Element should be
wet but not dripping.
5. Install:
9Filter guide 1
NOTE:
Align the projection aon filter guide with the
hole bin air filter element.
6. Apply:
9Lithium soap base grease
On the matching surface aon air filter ele-
ment.
7. Install:
9Air filter element 1
9Washer
9Fitting bolt
NOTE:
Align the projection aon filter guide with the
hole bin air filter case.
EC35H002
TRANSMISSION OIL LEVEL CHECK
1. Start the engine, warm it up for several min-
utes and wait for five minutes.
2. Place the machine on a level place and hold
it up on upright position by placing the suit-
able stand under the engine.
2 Nm (0.2 m•kg, 1.4 ft•lb)
5NX-9-30-3A 6/5/01 3:59 PM Page 32

INSP
ADJ
3-13
TRANSMISSION OIL REPLACEMENT
3. Check:
9Transmission oil level
EC35K002
TRANSMISSION OIL REPLACEMENT
1. Start the engine and warm it up for several
minutes and wait for five minute.
2. Place the machine on a level place and hold
it on upright position by placing the suitable
stand under the engine.
3. Place a suitable container under the engine.
Transmission oil level checking steps:
9Remove the oil check bolt 1.
9Inspect the oil level.
NOTE:
Be sure the machine is positioned straight
up when inspecting the oil level.
w
Never attempt to remove the oil check bolt
just after high speed operation. The heat-
ed oil could spout out, causing danger.
Wait until the oil cools down.
Oil flows outOil level is correct.
Oil does not flow outOil level is low.
Add transmission
oil until oil flows
out.
9Inspect the gasket (oil check bolt), replace if
damaged.
9Tighten the oil check bolt.
Recommended oil:
Yamalube 4 (10W-30) or SAE
10W-30 type SE motor oil
Oil check bolt:
10 Nm (1.0 m•kg, 7.2 ft•lb)
5NX-9-30-3A 6/5/01 3:59 PM Page 34

3-25
DRIVE CHAIN SLACK ADJUSTMENT
INSP
ADJ
EC36A060
DRIVE CHAIN SLACK ADJUSTMENT
1. Elevate the rear wheel by placing the suit-
able stand under the engine.
2. Check:
9Drive chain slack a
Above the seal guard installation bolt.
Out of specification Adjust
NOTE:
Before checking and/or adjusting, rotate the rear
wheel through several revolutions and check the
slack several times to find the tightest point. Check
and/or adjust chain slack with rear wheel in this
“tight chain” position.
Drive chain slack:
40~50 mm (1.6~2.0 in)
Drive chain lubricant:
SAE 10W-30 motor oil or suitable
chain lubricants
5. Install:
9Drive chain 1
9Joint 2
9Master link clip 3
cC
Be sure to install the master link clip to the
direction as shown.
aTurning direction
6. Lubricate:
9Drive chain
5NX-9-30-3B 6/5/01 4:06 PM Page 18

3-35
STEERING HEAD INSPECTION AND ADJUSTMENT
INSP
ADJ
2. Inspect:
9Bearing free play
Exist play Replace.
EC36U013
STEERING HEAD INSPECTION AND
ADJUSTMENT
1. Elevate the front wheel by placing a suitable
stand under the engine.
2. Check:
9Steering shaft
Grasp the bottom of the forks and gently
rock the fork assembly back and forth.
Free play Adjust steering head.
3. Check:
9Steering smooth action
Turn the handlebar lock to lock.
Unsmooth action Adjust steering ring
nut.
4. Adjust:
9Steering ring nut
Steering ring nut adjustment steps:
9Remove the number plate.
9Remove the handlebar and handle crown.
9Loosen the ring nut 1using the ring nut
wrench 2.
9Tighten the ring nut 3using ring nut
wrench 4.
NOTE:
Set the torque wrench to the ring nut wrench
so that they form a right angle.
Ring nut wrench:
YU-33975/90890-01403
5NX-9-30-3B 6/5/01 4:06 PM Page 38

3-38
ELECTRICAL/SPARK PLUG INSPECTION
INSP
ADJ
EC370000
ELECTRICAL
EC371001
SPARK PLUG INSPECTION
1. Remove:
9Spark plug
2. Inspect:
9Electrode 1
Wear/Damage Replace.
9Insulator color 2
Normal condition is a medium to light tan
color.
Distinctly different color Check the
engine condition.
NOTE:
When the engine runs for many hours at low
speeds, the spark plug insulator will become
sooty, even if the engine and carburetor are in
good operating condition.
3. Measure:
9Plug gap a
Use a wire gauge or thickness gauge.
Out of specification Regap.
4. Clean the plug with a spark plug cleaner if
necessary.
5. Tighten:
9Spark plug
NOTE:
9Before installing a spark plug, clean the
gasket surface and plug surface.
9Finger-tighten athe spark plug before
torquing to specification b.
Spark plug gap:
0.5~0.6 mm (0.020~0.024 in)
Standard spark plug:
BR8EG (NGK)
20 Nm (2.0 m•kg, 14 ft•lb)
5NX-9-30-3B 6/5/01 4:06 PM Page 44

4-29
CYLINDER HEAD, CYLINDER AND PISTONENG
7. Install:
9O-ring 1
9Side holder 2
9Screw (side holder) 3
9YPVS breather hose 4
NOTE:
9Apply the lithium soap base grease on the O-
rings.
9Install the side holder with its projection a
facing upward.
8. Install:
9Gasket (power valve cover) 1
9Power valve cover 2
9Screw (power valve cover) 3
NOTE:
9Install the gasket with its cut afacing down-
ward and the seal print side toward the power
valve cover.
9Install the power valve cover so that the arrow
mark bfaces upward.
EC475233
Piston ring and piston
1. Install:
9Piston ring 1
NOTE:
9Take care not to scratch the piston or damage
the piston ring.
9Align the piston ring gap with the pin 2.
9After installing the piston ring, check the
smooth movement of it.
2. Install:
9Gasket (cylinder) 1
9Small end bearing 2
9Dowel pin 3
NOTE:
9Apply the engine oil onto the bearing (crank-
shaft and connecting rod) and connecting rod
big end washers.
9Install the gasket with the seal print side
toward the crankcase.
4 Nm (0.4 m•kg, 2.9 ft•lb)
4 Nm (0.4 m•kg, 2.9 ft•lb)
5NX-9-30-4B 6/7/01 1:56 PM Page 4

4-30
CYLINDER HEAD, CYLINDER AND PISTONENG
EC475382
Cylinder head and cylinder
1. Apply:
9Engine oil
To piston 1piston ring 2and cylinder sur-
face.
2. Install:
9Cylinder 1
cC
Make sure the piston rings are properly
positioned. Install the cylinder with one
hand while compressing the piston rings
with the other hand.
NOTE:
After installing, check the smooth movement of
the piston.
3. Install:
9Nut (cylinder) 1
NOTE:
Tighten the nuts in stage, using a crisscross pat-
tern.
3. Install:
9Piston 1
9Piston pin 2
9Piston pin clip 3
NOTE:
9The arrow aon the piston dome must point to
exhaust side.
9Before installing the piston pin clip, cover the
crankcase with a clean rag to prevent the pis-
ton pin clip from falling into the crankcase cavi-
ty.
cC
Do not allow the clip open ends to meet the
piston pin slot b b
.
35 Nm (3.5 m•kg, 25 ft•lb)
5NX-9-30-4B 6/7/01 1:56 PM Page 6

4-66
CRANKCASE AND CRANKSHAFTENG
NOTE:
9Make appropriate bolts 3as shown available
by yourself and attach the tool with them.
9Fully tighten the tool holding bolts, but make
sure the tool body is parallel with the case. If
necessary, one screw may be backed out
slightly to level tool body.
9As pressure is applied, alternately tap on the
front engine mounting boss and transmission
shafts.
cC
Use soft hammer to tap on the case half.
Tap only on reinforced portions of case. Do
not tap on gasket mating surface. Work
slowly and carefully. Make sure the case
halves separate evenly. If one end “hangs
up”, take pressure off the push screw,
realign, and start over. If the cases do not
separate, check for a remaining case
screw or fitting. Do not force.
EC4N3000
REMOVAL POINTS
EC4N3100
Segment
1. Remove:
9Bolt (segment) 1
9Segment 2
NOTE:
Turn the segment counterclockwise until it stops
and loosen the bolt.
EC4N3212
Crankcase
1. Remove:
9Crankcase (right) 1
Use the crankcase separating tool 2.
Crankcase separating tool:
YU-1135-A/90890-01135
5NX-9-30-4C 6/5/01 4:25 PM Page 34
