Safety information
2-4
2Aftermarket Parts, Accessories, an
d
Mo difications
While you may find aftermarket prod-
ucts similar in design and quality to
genuine Yamaha accessories, recog-
nize that some aftermarket accesso-
ries or modifications are not suitable
because of potential safety hazards to
you or others. Installing aftermarket
products or having other modifications
performed to your vehicle that change
any of the vehicle’s design or operation
characteristics can put you and others
at greater risk of serious injury or
death. You are responsible for injuries
related to changes in the vehicle.
Keep the following guidelines in mind,
as well as those provided under “Load-
ing” when mounting accessories.  Never install accessories that
would impair the performance of
your motorcycle. Carefully inspect
the accessory before using it to
make sure that it does not in any
way reduce ground clearance or
cornering clearance, limit suspen-
sion travel, steering travel or con-
trol operation.
• Accessories fitted to the han- dlebar or the front fork area can
create instability due to improp-
er weight distribution. If acces-
sories are added to the
handlebar or front fork area,
they must be as lightweight as
possible and should be kept to
a minimum.
• Bulky or large accessories may seriously affect the stability of
the motorcycle. Wind may at- tempt to lift the motorcycle, or
the motorcycle may become
unstable in cross winds.
• Certain accessories can dis- place the operator from his or
her normal riding position. This
improper position limits the
freedom of movement of the
operator and may limit control
ability, therefore, such accesso-
ries are not recommended.
 Use caution when adding electri-
cal accessories. If electrical ac-
cessories exceed the capacity of
the motorcycle’s electrical sys-
tem, an electric failure could re-
sult, which could cause a
dangerous loss of lights or engine
power.
Aftermarket Tires an d Rims
The tires and rims that came with your
motorcycle were designed to match
the performance capabilities and to
provide the best combination of han-
dling, braking, and comfort. Other
tires, rims, sizes, and combinations
may not be appropriate. Refer to page
7-14 for tire specifications and more in-
formation on replacing your tires.
Transportin g the Motorcycle
Be sure to observe following instruc-
tions before transporting the motorcy-
cle in another vehicle.  Remove all loose items from the
motorcycle.
 Check that the fuel cock (if
equipped) is in the “OFF” position
and that there are no fuel leaks.
UBR881E0.book Page 4 Tuesday, April 2, 2019 9:44 AM

Specifications
9-1
9
Dimensions:
Overall length:1615 mm (63.6 in)
Overall width:
760 mm (29.9 in)
Overall height: 1000 mm (39.4 in)
Seat height: 755 mm (29.7 in)
Wheelbase:
1140 mm (44.9 in)
Ground clearance: 265 mm (10.43 in)
Wei ght:
Curb weight:
61 kg (134 lb)
Maximum rider weight:
50.0 kg (110 lb)
Engine:
Combustion cycle:
2-stroke
Cooling system:
Liquid cooled
Number of cylinders: Single cylinder
Displacement: 65 cm³
Bore × stroke:
43.5 × 43.6 mm (1.71 × 1.72 in)
Starting system: Kickstarter
Engine oil:
Engine oil:
YAMALUBE 2R
Recommended brand:
Transmission oil:
Type: Motor oil SAE 10W-30 type SE or higher or
Gear oil SAE 85W GL-3
Quantity: 0.50 L (0.53 US qt, 0.44 Imp.qt)
Coolant quantity:
Radiator (including all routes):
0.38 L (0.40 US qt, 0.33 Imp.qt)
Fuel:
Recommended fuel:Unleaded gasoline (E10 acceptable)
Octane number (RON):
98
Fuel tank capacity: 3.5 L (0.9 US gal, 0.8 Imp.gal)
Car buretor:
Type × quantity:
PWK28 × 1
Drivetrain:
Gear ratio:
1st:
2.455 (27/11)
2nd: 1.882 (32/17)
3rd: 1.529 (26/17)
4th:
1.263 (24/19)
5th: 1.095 (23/21)
6th: 0.960 (24/25)
Front tire:
Type:With tube
Size: 60/100-14 30M
Manufacturer/model:
MAXXIS/MAXXCROSS SI
Rear tire:
Type:With tube
Size:
80/100-12 41M
Manufacturer/model: MAXXIS/MAXXCROSS SI
Front brake:
Type:
Hydraulic single disc brake
Rear brake:
Type:
Hydraulic single disc brake
Front suspension:
Type:Telescopic fork
Rear suspension:
Type:
Swingarm
