SPEC
2 - 1
GENERAL SPECIFICATIONS
EC200000
SPECIFICATIONS
EC211000
GENERAL SPECIFICATIONS
Model name: YZ85 YZ85LW
YZ85P1 (USA)
YZ85LC (EUROPE)
YZ85(P)
(CDN, AUS, NZ, ZA)YZ85LW (EUROPE)
YZ85LWP (AUS, NZ)
Model code number: YZ85 YZ85LW
5PA1
(USA, CDN, EUROPE,
NZ, ZA)
5PA2
(AUS)5SH1
(EUROPE, NZ)
5SH2
(AUS)
Dimensions: YZ85 YZ85LW
Overall length 1,821 mm (71.7 in) 1,896 mm (74.4 in)
(USA, S, NZ, ZA)
1,818 mm (71.6 in)
(F, D, I, GB, E, CDN,
AUS)
Overall width 758 mm (28.9 in)¬
Overall height 1,161 mm (45.7 in) 1,204 mm (47.4 in)
Seat height 864 mm (34.0 in) 902 mm (35.0 in)
Wheelbase 1,258 mm (49.5 in) 1,278 mm (50.3 in)
(USA, S, NZ, ZA)
1,255 mm (49.4 in)
(F, D, I, GB, E, CDN,
AUS)
Minimum ground clearance 351 mm (13.8 in) 391 mm (15.4 in)
Basic weight: YZ85 YZ85LW
With oil and full fuel tank 71 kg (156.5 lb) 73.9 kg (162.9 lb)
Engine:
Engine type Liquid cooled 2-stroke, gasoline
Cylinder arrangement Single cylinder, forward inclined
Displacement 84.7 cm
3 (2.98 lmp oz, 2.86 US oz)
Bore ´ stroke 47.5 ´ 47.8 mm (1.870 ´ 1.882 in)
Compression ratio 8.2 : 1
Starting system Kickstarter
Lubrication system: Premix (30 : 1) (Yamalube 2-R)
Oil type or grade (2-cycle):
Transmission oil Yamalube 4 (10W-30) or SAE 10W-30 type SE
motor oil
Periodic oil change 0.50 L (0.44 lmp qt, 0.52 US qt)
Total amount 0.55 L (0.48 lmp qt, 0.58 US qt)
Coolant capacity (including all routes): 0.54 L (0.48 Imp qt, 0.57 US qt)
Air filter: Wet type element
2
2
3 - 6
INSP
ADJ
COOLANT REPLACEMENT
COOLANT REPLACEMENT
WARNING
Do not remove the radiator cap when the
engine is hot.
CAUTION:
Take care so that coolant does not splash
on painted surfaces. If it splashes, wash it
away with water.
1. Place a container under the engine.
2. Remove:
lCoolant drain bolt 1
3. Remove:
lRadiator cap
Drain the coolant completely.
4. Clean:
lCooling system
Thoroughly flush the cooling system with
clean tap water.
5. Install:
lCopper washer
lCoolant drain bolt
5PA30030
T R..10 Nm (1.0 m · kg, 7.2 ft · lb)
6. Fill:
lRadiator
lEngine
To specified level.
Recommended coolant:
High quality ethylene glycol
anti-freeze containing anti-
corrosion for aluminum engine
Coolant
1 and water (soft water)
2
mixing ratio:
50 %/50 %
Coolant capacity:
0.54 L (0.48 Imp qt, 0.57 US qt)
5PA30040
