PERIODIC MAINTENANCE AND ADJUSTMENT
7-3
7
√
5 *Cylinder • Check cylinder for score marks or wear.
Clean.
√
Replace. √
NO. ITEM ROUTINE
After
break-in Every
race Every
third race Every
fifth race As
required
6 *Clutch Check clutch housing, friction plates, clutch plates
and clutch springs for wear or damage.
Adjust. √
√
Replace. √
7 *Transmission Change the transmission oil.
√
Check transmission for damage. √
Replace bearings. √
8 *Shift forks, guide bars,
shift cam
Replace if necessary. Check all parts for wear and damage.
√
9 *Rotor nut
(flywheel
magneto) Tighten.
√√√
10 *Kickstarter system Check idle gear for damage.
√
Replace if necessary.
11 *Exhaust system Check exhaust pipe and muffler for carbon deposits.
√
√
Clean. √
√
√
√
√
12
*Crankshaft Check crankshaft for carbon deposits and damage.
Clean.
U1SN83E0.book Page 3 Monday, September 8, 2014 2:36 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
7-17
7
WARNING
EWA14391
Have a Yamaha dealer replace
excessively worn tires. Operat-
in g the motorcycle with exces-
sively worn tires decreases
ri din g sta bility an d can lead to
loss of control.
 The replacement of all wheel-
and b rake-relate d parts, inclu d-
in g the tires, shoul d b e left to a
Yamaha dealer, who has the
necessary professional knowl-
e dge an d experience. 
It is not recommen ded to patch
a punctured tube. If unavoi d-
a b le, however, patch the tu be
very carefully an d replace it as
soon as possi ble with a hi gh-
quality pro duct.
EAU48322
Spoke wheels
WARNING
EWA10611
The wheels on this mo del are not
d esi gne d for use with tu beless tires.
Do not attempt to use tu beless tires
on this mo del.To maximize the performance, durabil-
ity, and safe operation of your motor-
cycle, note the following points
regarding the specified wheels.
 The wheel rims should be
checked for cracks, bends, warp-
age or other damage and the
spokes for looseness or damage
before each ride. If any damage is
found, have a Yamaha dealer re-
place the wheel. Do not attempt
even the smallest repair to the
wheel. A deformed or cracked
wheel must be replaced.
 The wheel should be balanced
whenever either the tire or wheel
has been changed or replaced. An
unbalanced wheel can result in
poor performance, adverse han-
dling characteristics, and a short-
ened tire life.
Front tire:
Size:
YZ85 70/100-17 40M
YZ85F 70/100-17 40M
YZ85LW 70/100-19 42M
YZ85LWF 70/100-19 42M
Manufacturer/model:
DUNLOP/MX51F
Rear tire: Size:
YZ85 90/100-14 49M
YZ85F 90/100-14 49M
YZ85LW 90/100-16 52M
YZ85LWF 90/100-16 52M
Manufacturer/model: DUNLOP/MX51
U1SN83E0.book Page 17 Monday, September 8, 2014 2:36 PM

PERIODIC MAINTENANCE AND ADJUSTMENT
7-22
7
EAU51721
Changin g the brake flui dHave a Yamaha dealer change the
brake fluid at the intervals specified in
the periodic maintenance and lubrica-
tion chart. In addition, have the oil seals
of the master cylinders and calipers as
well as the brake hoses replaced at the
intervals listed below or whenever they
are damaged or leaking.
 Oil seals: Replace every two
years.
 Brake hoses: Replace every four
years.
EAU22762
Drive chain slackThe drive chain slack should be
checked before each ride and adjusted
if necessary.
EAU41413
To check the drive chain slack
1. Install the removable sidestand and place the motorcycle on it.TIPWhen checking and adjusting the drive
chain slack, there should be no weight
on the motorcycle.2. Shift the transmission into theneutral position.
3. Measure the drive chain slack as shown. 4. If the drive chain slack is incorrect,
adjust it as follows.
EAU41484
To a djust the drive chain slack
Consult a Yamaha dealer before ad-
justing the drive chain slack. 1. Loosen the axle nut and the lock- nut on each side of the swingarm.
2. To tighten the drive chain, turn the drive chain slack adjusting bolt on
each side of the swingarm in di-
rection (a). To loosen the drive
chain, turn the adjusting bolt on
each side of the swingarm in di-
rection (b), and then push the rear
wheel forward. NOTICE: Improp-
er drive chain slack will over-
Drive chain slack:
35.0–45.0 mm (1.38–1.77 in)
1. Drive chain slack
U1SN83E0.book Page 22 Monday, September 8, 2014 2:36 PM

SPECIFICATIONS
9-1
9
Dimensions:Overall length:YZ85 1821 mm (71.7 in)
YZ85F 1821 mm (71.7 in)
YZ85LW 1899 mm (74.8 in)
YZ85LWF 1899 mm (74.8 in)
Overall width:
758 mm (29.8 in)
Overall height: YZ85 1126 mm (44.3 in)
YZ85F 1126 mm (44.3 in)
YZ85LW 1156 mm (45.5 in)
YZ85LWF 1156 mm (45.5 in)
Seat height: YZ85 841 mm (33.1 in)
YZ85F 841 mm (33.1 in)
YZ85LW 873 mm (34.4 in)
YZ85LWF 873 mm (34.4 in)
Wheelbase:
YZ85 1257 mm (49.5 in)
YZ85F 1257 mm (49.5 in)
YZ85LW 1285 mm (50.6 in)
YZ85LWF 1285 mm (50.6 in)
Ground clearance: YZ85 330 mm (12.99 in)
YZ85F 330 mm (12.99 in)
YZ85LW 360 mm (14.17 in)
YZ85LWF 360 mm (14.17 in)Wei ght:Curb weight:
YZ85 71 kg (157 lb)
YZ85F 71 kg (157 lb)
YZ85LW 73 kg (161 lb)
YZ85LWF 73 kg (161 lb)
Engine:Engine type:
Liquid cooled 2-stroke
Cylinder arrangement:
Single cylinder
Displacement: 85 cm³
Bore × stroke:
47.5 × 47.8 mm (1.87 × 1.88 in)
Compression ratio:
8.1 : 1
Starting system: Kickstarter
Lubrication system: PremixEngine oil:Type:
YAMALUBE 2RTransmission oil:Type:
YAMALUBE 4 (10W-40) or SAE 10W-40
Oil change quantity: 0.50 L (0.53 US qt, 0.44 Imp.qt)Coolant quantity:Radiator (including all routes):
0.54 L (0.57 US qt, 0.48 Imp.qt)Air filter:Air filter element:Wet elementFuel:Recommended fuel:Premium unleaded gasoline only
Fuel tank capacity: 5.0 L (1.32 US gal, 1.10 Imp.gal)
Car buretor:Type × quantity:
PWK28 x 1Spark plu g(s):Manufacturer/model:
NGK/BR10EG
Spark plug gap: 0.5–0.6 mm (0.020–0.024 in)Clutch:Clutch type:Wet, multiple-discTransmission:Primary reduction ratio:
3.611 (65/18)
Final drive: Chain
Secondary reduction ratio: YZ85 3.428 (48/14)
YZ85F 3.428 (48/14)
YZ85LW 3.714 (52/14)
YZ85LWF 3.714 (52/14)
Transmission type:
Constant mesh 6-speed
Operation: Left foot operation
Gear ratio: 1st:2.454 (27/11)
2nd: 1.882 (32/17)
3rd:
1.529 (26/17)
4th: 1.294 (22/17)
