engine YAMAHA YZF-R1 2001 Service Manual

7-1
7
7-MOTORCYCLE CARE AND STORAGE
EAU03539
Care While the open design of a motorcycle
reveals the attractiveness of the tech-
nology, it also makes it more vulnera-
ble. Rust and corrosion can develop
even if high-quality components are
used. A rusty exhaust pipe may go un-
noticed on a car, however, it detracts
from the overall appearance of a
motorcycle. Frequent and proper care
does not only comply with the terms of
the warranty, but it will also keep your
motorcycle looking good, extend its life
and optimize its performance.Before cleaning
1. Cover the muffler outlet with a
plastic bag after the engine has
cooled down.
2. Make sure that all caps and covers
as well as all electrical couplers
and connectors, including the
spark plug caps, are tightly
installed.
3. Remove extremely stubborn dirt,
like oil burnt onto the crankcase,
with a degreasing agent and a
brush, but never apply such prod-
ucts onto seals, gaskets, sprock-
ets, the drive chain and wheel
axles. Always rinse the dirt and
degreaser off with water.Cleaning
ECA00056
CAUTION:@ l
Avoid using strong acidic wheel
cleaners, especially on spoked
wheels. If such products are
used on hard-to-remove dirt, do
not leave the cleaner on the af-
fected area any longer than in-
structed. Also, thoroughly rinse
the area off with water, immedi-
ately dry it, and then apply a
corrosion protection spray.
l
Improper cleaning can damage
windshields, cowlings, panels,
other plastic parts, and the muf-
fler. Use only a soft, clean cloth
or sponge with mild detergent
and water to clean plastic. How-
ever, if the muffler cannot be
thoroughly cleaned with mild
detergent, alkaline products
and a soft brush may be used.
E_5jj.book Page 1 Friday, September 8, 2000 3:33 PM

MOTORCYCLE CARE AND STORAGE
7-2
7
l
Do not use any harsh chemical
products on plastic parts or the
muffler. Be sure to avoid using
cloths or sponges which have
been in contact with strong or
abrasive cleaning products, sol-
vent or thinner, fuel (gasoline),
rust removers or inhibitors,
brake fluid, antifreeze or
electrolyte.
l
Do not use high-pressure wash-
ers or steam-jet cleaners since
they cause water seepage and
deterioration in the following ar-
eas: seals (of wheel and swing-
arm bearings, fork and brakes),
storage compartments, electric
components (couplers, connec-
tors, instruments, switches and
lights), breather hoses and
vents.
l
For motorcycles equipped with
a windshield: Do not use strong
cleaners or hard sponges as
they will cause dulling or
scratching. Some cleaning
compounds for plastic may
leave scratches on the wind-
shield. Test the product on a
small hidden part of the wind-
shield to make sure that it does
not leave any marks. If the wind-
shield is scratched, use a quali-
ty plastic polishing compound
after washing.
@After normal useRemove dirt with warm water, a mild
detergent, and a soft, clean sponge,
and then rinse thoroughly with clean
water. Use a toothbrush or bottlebrush
for hard-to-reach areas. Stubborn dirt
and insects will come off more easily if
the area is covered with a wet cloth for
a few minutes before cleaning.After riding in the rain, near the sea or
on salt-sprayed roadsSince sea salt or salt sprayed on roads
during winter are extremely corrosive in
combination with water, carry out the
following steps after each ride in the
rain, near the sea or on salt-sprayed
roads.NOTE:@ Salt sprayed on roads in the winter may
remain well into spring. @1. Clean the motorcycle with cold
water and a mild detergent, after
the engine has cooled down.
ECA00012
CAUTION:@ Do not use warm water since it in-
creases the corrosive action of the
salt. @2. After drying the motorcycle, apply
a corrosion protection spray on all
metal, including chrome- and nick-
el-plated, surfaces (except the tita-
nium muffler) to prevent corrosion.
E_5jj.book Page 2 Friday, September 8, 2000 3:33 PM

MOTORCYCLE CARE AND STORAGE
7-5
7a. Remove the spark plug caps and
spark plugs.
b. Pour a teaspoonful of engine oil
into each spark plug bore.
c. Install the spark plug caps onto the
spark plugs, and then place the
spark plugs on the cylinder head
so that the electrodes are ground-
ed. (This will limit sparking during
the next step.)
d. Turn the engine over several times
with the starter. (This will coat the
cylinder walls with oil.)
e. Remove the spark plug caps from
the spark plugs, and then install
the spark plugs and the spark plug
caps.
EWA00003
WARNING
@ To prevent damage or injury from
sparking, make sure to ground the
spark plug electrodes while turning
the engine over. @
6. Lubricate all control cables and
the pivoting points of all levers and
pedals as well as of the sidestand/
centerstand.
7. Check and, if necessary, correct
the tire air pressure, and then lift
the motorcycle so that both of its
wheels are off the ground. Alterna-
tively, turn the wheels a little every
month in order to prevent the tires
from becoming degraded in one
spot.
8. Cover the muffler outlet with a
plastic bag to prevent moisture
from entering it.9. Remove the battery and fully
charge it. Store it in a cool, dry
place and charge it once a month.
Do not store the battery in an ex-
cessively cold or warm place (less
than 0°C or more than 30°C). For
more information on storing the
battery, see page 6-33.
NOTE:@ Make any necessary repairs before
storing the motorcycle. @
E_5jj.book Page 5 Friday, September 8, 2000 3:33 PM

8-1
8
EAU01038
8-SPECIFICATIONSSpecificationsCS-01E
Model YZF-R1
Dimensions
Overall length 2,035 mm
Overall width 695 mm
Overall height 1,105 mm
Seat height 815 mm
Wheelbase 1,395 mm
Ground clearance 140 mm
Minimum turning radius 3,400 mm
Basic weight (with oil and full
fuel tank)
194 kg
Engine
Engine type Liquid-cooled 4-stroke, DOHC
Cylinder arrangement Forward-inclined parallel
4-cylinder
Displacement 998 cm
3
Bore ´ stroke 74 ´ 58 mm
Compression ratio 11.8:1
Starting system Electric starter
Lubrication system Wet sumpEngine oil
Ty p e
Recommended engine oil
classification API Service SE, SF, SG or
higher
Quantity
Without oil filter cartridge
replacement 2.7 L
With oil filter car tridge
replacement 2.9 L
Total amount (dry engine) 3.6 L
-20 -10 0
10 20 30
40
50 ˚C
SAE 10W-30
SAE 15W-40SAE 20W-40SAE 20W-50
SAE 10W-40
CAUTION:Be sure to use motor oils that do not contain anti-friction
modifiers. Passenger car motor oils (often labeled
“ENERGY CONSERVING II”) contain anti-friction additives
which will cause clutch and/or starter clutch slippage, result-
ing in reduced component life and poor engine performance.
E_5jj.book Page 1 Friday, September 8, 2000 3:33 PM

INDEXAAir filter element, cleaning ...................... 6-15
Anti-theft alarm (optional) .........................3-8BBattery ................................................... 6-33
Brake and clutch levers, checking and
lubricating ............................................ 6-30
Brake fluid, changing ............................. 6-26
Brake fluid level, checking...................... 6-25
Brake lever............................................. 3-11
Brake light switch (rear), adjusting ......... 6-24
Brake pads, checking............................. 6-24
Brake pedal............................................ 3-11
Brake pedal, lubricating.......................... 6-30
Brake pedal position, adjusting .............. 6-23CCables, checking and lubricating............ 6-29
Carburetors, adjusting............................ 6-17
Care.........................................................7-1
Clutch lever ............................................ 3-10
Clutch lever free play, adjusting ............. 6-22
Conversion table ......................................8-5
Coolant .................................................. 6-12
Changing .......................................... 6-13
Checking .......................................... 6-12
Coolant temperature warning light............3-3
Cowlings and panels, removing and
installing ................................................6-5DDimmer switch .........................................3-9
Drive chain, lubricating ........................... 6-28
Drive chain slack ................................... 6-27
Adjusting .......................................... 6-27
Checking .......................................... 6-27EEngine break-in ....................................... 5-4
Engine oil and oil filter cartridge ............... 6-9
Engine stop switch................................... 3-9
EXUP system ........................................ 3-22FFront and rear suspension settings ........ 3-21
Front fork, adjusting ............................... 3-16
Front fork, checking ............................... 6-31
Fuel ....................................................... 3-12
Fuel consumption, tips for reducing ......... 5-4
Fuel level warning light ............................ 3-2
Fuel tank breather hose ......................... 3-13
Fuel tank cap ......................................... 3-11
Fuses, replacing .................................... 6-34HHandlebar switches ................................. 3-9
Headlight bulb, replacing ....................... 6-35
Helmet holders ...................................... 3-15
High beam indicator light ......................... 3-2
Horn switch ............................................. 3-9IIdentification numbers ............................. 9-1
Idling speed, adjusting ........................... 6-18
Ignition circuit cut-off system.................. 3-23
Indicator and warning lights ..................... 3-2
KKey identification number .........................9-1LLight switch ..............................................3-9
Luggage strap holders ...........................3-22MMain switch/steering lock .........................3-1
Model label ..............................................9-2NNeutral indicator light ...............................3-2OOil level warning light ...............................3-3PParking.....................................................5-5
Part locations ...........................................2-1
Pass switch ..............................................3-9
Periodic maintenance and lubrication
chart ......................................................6-2
Pre-operation check list ............................4-1SSafety information ....................................1-1
Seats .....................................................3-14
Passenger seat .................................. 3-14
Rider seat .........................................3-14
Self-diagnosis devices .............................3-7
Shifting .....................................................5-3
Shift pedal ..............................................3-10
Shift points (for Switzerland only) .............5-4
Shock absorber assembly, adjusting ......3-18
Sidestand ...............................................3-23
E_5jj.book Page 1 Friday, September 8, 2000 3:33 PM

INDEX
Sidestand, checking and lubricating....... 6-30
Spark plugs, checking ............................. 6-7
Specifications .......................................... 8-1
Speedometer unit .................................... 3-6
Starter (choke) lever .............................. 3-13
Starting a cold engine .............................. 5-1
Starting a warm engine ............................ 5-3
Start switch ............................................ 3-10
Steering, checking ................................. 6-32
Storage.................................................... 7-4
Storage compartment ............................ 3-16
Supporting the motorcycle ..................... 6-38
Suspension (rear), lubricating ................ 6-31TTachometer ............................................. 3-7
Tail/brake light bulb, replacing ............... 6-37
Throttle cable free play, adjusting .......... 6-18
Throttle grip and cable, checking and
lubricating............................................ 6-29
Tires ...................................................... 6-19
Tool kit..................................................... 6-1
Troubleshooting..................................... 6-42
Troubleshooting charts .......................... 6-43
Turn signal indicator light ......................... 3-2
Turn signal light bulb, replacing ............. 6-37
Turn signal switch .................................... 3-9VValve clearance, adjusting ..................... 6-19
Vehicle identification number ................... 9-1
WWheel bearings, checking ..................... 6-32
Wheel (front) ......................................... 6-39
Installing .......................................... 6-40
Removing ........................................ 6-39
Wheel (rear) .......................................... 6-41
Installing .......................................... 6-42
Removing ........................................ 6-41
Wheels .................................................. 6-22
E_5jj.book Page 2 Friday, September 8, 2000 3:33 PM
