INSTRUMENT AND CONTROL FUNCTIONS
3-7
3To set the clock:
1. Push the “SELECT” button and
“RESET” button together for at
least two seconds.
2 When the hour digits start flashing,
push the “RESET” button to set
the hours.
3. Push the “SELECT” button, and
the minute digits will start flashing.
4. Push the “RESET” button to set
the minutes.
5. Push the “SELECT” button and
then release it to start the clock.
EAU00101
TachometerThe electric tachometer allows the rider
to monitor the engine speed and keep it
within the ideal power range.
EC000003
CAUTION:@ Do not operate the engine in the ta-
chometer red zone.
Red zone: 11,750 r/min and above @
EAU03271
Self-diagnosis devices This model is equipped with a self-di-
agnosis device for the following electri-
cal circuits:l
throttle position sensor
l
speed sensor
l
EXUP system
If any of those circuits are defective,
the tachometer will repeatedly display
the following error code:
CB-23E
1. Tachometer
2. Red zone
0 r/min for
3 seconds
Circuit-specific
number of r/min
for 2.5 seconds
(See the table
below.)
Current
engine
speed for
3 seconds
E_5jj.book Page 7 Friday, September 8, 2000 3:33 PM
INSTRUMENT AND CONTROL FUNCTIONS
3-8
3 Use the chart below to identify the
faulty electrical circuit.
CB-26EIf the tachometer displays such an er-
ror code, note the circuit-specific num-
ber of r/min, and then have a Yamaha
dealer check the motorcycle.
EC000004
CAUTION:@ When the tachometer displays an
error code, the motorcycle should
be checked as soon as possible in
order to avoid engine damage. @
This model is also equipped with a self-
diagnosis device for the fuel level warn-
ing light circuit. If the fuel level warning
light circuit is defective, the following
cycle will be repeated until the malfunc-
tion is corrected: The warning light will
flash eight times, then go off for three
seconds. If this occurs, have a Yamaha
dealer check the motorcycle.
EAU00109
Anti-theft alarm (optional)This motorcycle can be equipped with
an optional anti-theft alarm by a
Yamaha dealer. Contact a Yamaha
dealer for more information.
Specific r/min
Faulty electrical circuit
3,000 r/min
Throttle position sensor
4,000 r/min
Speed sensor
7,000 r/min
EXUP system
