YAMAHA YZF-R1 2006 Owners Manual

CONSUMER INFORMATION
9-1
9
EAU26351
Identification numbers Record the key identification number,
vehicle identification number and mod-
el label information in the spaces pro-
vided below for assistance when
ordering spare parts from a Yamaha
dealer or for reference in case the vehi-
cle is stolen.
KEY IDENTIFICATION NUMBER:
VEHICLE IDENTIFICATION
NUMBER:
MODEL LABEL INFORMATION:
EAU26381
Key identification number
The key identification number is
stamped into the key tag. Record this
number in the space provided and use
it for reference when ordering a new
key.
EAU26400
Vehicle identification number
The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.NOTE:
The vehicle identification number is
used to identify your motorcycle and
may be used to register your motor-
cycle with the licensing authority in yourarea.
1. Key identification number
2. Code re-registering key (red bow)
3. Standard keys (black bow)
1. Vehicle identification number
U4B1E0E0.book Page 1 Wednesday, October 12, 2005 2:32 PM

CONSUMER INFORMATION
9-2
9
EAU33941
Model label
The model label is affixed to the frame
under the passenger seat. (See page
3-19.) Record the information on this la-
bel in the space provided. This informa-
tion will be needed when ordering
spare parts from a Yamaha dealer.
WARNING
EWA12371
Do not touch either muffler bracket,
located under the muffler bracket
covers, until the exhaust system hascooled.1. Model label
1. Muffler bracket cover
2. Muffler bracket
U4B1E0E0.book Page 2 Wednesday, October 12, 2005 2:32 PM
