check engine YAMAHA YZF-R1 2015 Owner's Manual

PERIODIC MAINTENANCE AND ADJUSTMENT
7-17
1
2
3
4
5
67
8
9
10
11
12 specified torque.
15. Pour the specified coolant into the radiator until it is full.
16. Install the radiator cap.
17. Start the engine, let it idle for sev-
eral minutes, and then turn it off.
18. Remove the radiator cap to check the coolant level in the radiator. If
necessary, add sufficient coolant
until it reaches the top of the radia-
tor, and then install the radiator
cap.
19. Start the engine, and then check the vehicle for coolant leakage. If
coolant is leaking, have a Yamaha
dealer check the cooling system.
20. Install the cowling and panel.
EAU36765
Air filter elementThe air filter element must be replaced
at the intervals specified in the periodic
maintenance and lubrication chart.
Have a Yamaha dealer replace the air
filter element.
EAU44735
Checking the engine idling
speedCheck the engine idling speed and, if
necessary, have it corrected by a
Yamaha dealer.
Tightening torque: Air bleed bolt:10 Nm (1.0 m·kgf, 7.2 ft·lbf)
Engine idling speed:
1200–1400 r/min
2CR-9-E0_1.book 17 ページ ２０１５年１月５日　月曜日　午前１１時５４分

PERIODIC MAINTENANCE AND ADJUSTMENT
7-18
1
2
3
4
5
678
9
10
11
12
EAU21385
Checking the throttle grip free
playThe throttle grip free play should mea-
sure 3.0–5.0 mm (0.12–0.20 in) at the
inner edge of the throttle grip. Periodi-
cally check the throttle grip free play
and, if necessary, have a Yamaha
dealer adjust it.
EAU21402
Valve clearanceThe valve clearance changes with use,
resulting in improper air-fuel mixture
and/or engine noise. To prevent this
from occurring, the valve clearance
must be adjusted by a Yamaha dealer
at the intervals specified in the periodic
maintenance and lubrication chart.
EAU2177A
TiresTires are the only contact between the
vehicle and the road. Safety in all con-
ditions of riding depends on a relatively
small area of road contact. Therefore, it
is essential to maintain the tires in good
condition at all times and replace them
at the appropriate time with the speci-
fied tires.
Tire air pressure
The tire air pressure should be checked
and, if necessary, adjusted before each
ride.
WARNING
EWA10504
Operation of this vehicle with im-
proper tire pressure may cause se-
vere injury or death from loss of
control.
The tire air pressure must be
checked and adjusted on cold
tires (i.e., when the temperature
of the tires equals the ambient
temperature).

The tire air pressure must be ad-
justed in accordance with the
riding speed and with the total
1. Throttle grip free play
1
2CR-9-E0_1.book 18 ページ ２０１５年１月５日　月曜日　午前１１時５４分

PERIODIC MAINTENANCE AND ADJUSTMENT
7-27
1
2
3
4
5
67
8
9
10
11
12
EAU23026
Cleaning and l ubricating the
drive chainThe drive chain must be cleaned and
lubricated at the intervals specified in
the periodic maintenance and lubrica-
tion chart, otherwise it will quickly wear
out, especially when riding in dusty or
wet areas. Service the drive chain as
follows.NOTICE
ECA10584
The drive chain must be lubricated
after washing the motorcycle, ridingin the rain or riding in wet areas.
1. Clean the drive chain with kero- sene and a small soft brush.
NOTICE: To prevent damaging
the O-rings, do not clean the
drive chain with steam cleaners,
high-pressure washers or inap-
propriate solvents.
[ECA11122]
2. Wipe the drive chain dry.
3. Thoroughly lubricate the drive chain with a special O-ring chain
lubricant. NOTICE: Do not use
engine oil or any other lubri-
cants for the drive chain, as they may contain substances that
could damage the O-rings.
[ECA11112]
EAU23098
Checking and lubricating the
cablesThe operation of all control cables and
the condition of the cables should be
checked before each ride, and the ca-
bles and cable ends should be lubricat-
ed if necessary. If a cable is damaged
or does not move smoothly, have a
Yamaha dealer check or replace it.
WARNING! Damage to the outer
housing of cables may result in in-
ternal rusting and cause interfer-
ence with cable movement. Replace
damaged cables as soon as possi-
ble to prevent unsafe condi-
tions.
[EWA10712]
Recommended lubricant:
Yamaha cable lubricant or other suit-
able cable lubricant
2CR-9-E0_1.book 27 ページ ２０１５年１月５日　月曜日　午前１１時５４分

PERIODIC MAINTENANCE AND ADJUSTMENT
7-31
1
2
3
4
5
67
8
9
10
11
12
EAU23285
Checking the steeringWorn or loose steering bearings may
cause danger. Therefore, the operation
of the steering must be checked as fol-
lows at the intervals specified in the pe-
riodic maintenance and lubrication
chart. 1. Raise the front wheel off the ground. (See page 7-36.)
WARNING! To avoid injury, se-
curely support the vehicle so
there is no danger of it falling
over.
[EWA10752]
2. Hold the lower ends of the frontfork legs and try to move them for-
ward and backward. If any free
play can be felt, have a Yamaha
dealer check or repair the steering.
EAU23292
Checking the w heel bearingsThe front and rear wheel bearings must
be checked at the intervals specified in
the periodic maintenance and lubrica-
tion chart. If there is play in the wheel
hub or if the wheel does not turn
smoothly, have a Yamaha dealer check
the wheel bearings.
EAU68230
BatteryNOTICE
ECA22960
Use only the specified genuine
YAMAHA battery. Using a different
battery may cause the IMU to fail andthe engine to stall.
The battery is located under the rider
seat. (See page 4-36.)NOTICE
ECA22970
The IMU is located under the battery.
It is not user serviceable and very
sensitive, so we advise against re-1. Positive battery lead (red)
2. Negative battery lead (black)
3. Battery
1
2
3
2CR-9-E0_1.book 31 ページ ２０１５年１月５日　月曜日　午前１１時５４分

PERIODIC MAINTENANCE AND ADJUSTMENT
7-37
1
2
3
4
5
67
8
9
10
11
12
EAU42505
Troubleshooting chartsStarting problems or poor engine performance
Check the fuel level in
the fuel tank.1. Fuel
There is enough fuel.
There is no fuel.
Check the battery.
Supply fuel.
The engine does not start.
Check the battery.
Remove the spark plugs
and check the electrodes.3. Ignition
Wipe off with a dry cloth and correct the
spark plug gaps, or replace the spark plugs.
Have a Yamaha dealer check the vehicle.
Operate the electric starter.4. Compression
There is compression.
There is no compression.
The engine does not start.
Have a Yamaha dealer check the vehicle.Have a Yamaha dealer check the vehicle.
The engine does not start.
Check the compression.
Operate the electric starter.2. Battery
The engine turns over
quickly.
The engine turns over
slowly.
The engine does not start.
Check the ignition.
The battery is good.Check the battery lead connections,
and have a Yamaha dealer charge
the battery if necessary.
DryWet
Operate the electric starter.
2CR-9-E0_1.book 37 ページ ２０１５年１月５日　月曜日　午前１１時５４分

PERIODIC MAINTENANCE AND ADJUSTMENT
7-38
1
2
3
4
5
678
9
10
11
12
Engine overheating
WARNING
EWAT1041

Do not remove the radiator cap when the engine and radiator are hot. Scalding hot fluid and steam may be
blown out under pressure, which could cause serious injury. Be sure to wait until the engine has cooled.

Place a thick rag, like a towel, over the radiator cap, and then slowly rotate the cap counterclockwise to the de-
tent to allow any residual pressure to escape. When the hissing sound has stopped, press down on the capwhile turning it counterclockwise, and then remove the cap.
TIPIf coolant is not available, tap water can be temporarily
used instead, provided that it is changed to the recommended coolantas soon as possible.
Wait until the
engine has cooled.
Check the coolant level in the
reservoir and radiator.
The coolant level
is OK.The coolant level is low.
Check the cooling system
for leakage.
Have a Yamaha dealer checkand repair the cooling system.Add coolant. (See TIP.)
Start the engine. If the engine overheats again,
have a
Yamaha dealer check
and repair the cooling system.
There is
leakage.
There is
no leakage.
2CR-9-E0_1.book 38 ページ ２０１５年１月５日　月曜日　午前１１時５４分

MOTORCYCLE CARE AND STORAGE
8-4
1
2
3
4
5
6
789
10
11
12
EAU26183
StorageShort-term
Always store your motorcycle in a cool,
dry place and, if necessary, protect it
against dust with a porous cover. Be
sure the engine and the exhaust sys-
tem are cool before covering the motor-
cycle.NOTICE
ECA10811

Storing the motorcycle in a
poorly ventilated room or cover-
ing it with a tarp, while it is still
wet, will allow water and humid-
ity to seep in and cause rust.

To prevent corrosion, avoid
damp cellars, stables (because
of the presence of ammonia)
and areas where strong chemi-cals are stored.
Long-term
Before storing your motorcycle for sev-
eral months: 1. Follow all the instructions in the “Care” section of this chapter. 2. Fill up the fuel tank and add fuel
stabilizer (if available) to prevent
the fuel tank from rusting and the
fuel from deteriorating.
3. Perform the following steps to pro- tect the cylinders, piston rings, etc.
from corrosion.
a. Remove the spark plug caps and spark plugs.
b. Pour a teaspoonful of engine oil into each spark plug bore.
c. Install the spark plug caps onto the spark plugs, and then place
the spark plugs on the cylinder
head so that the electrodes are
grounded. (This will limit spark-
ing during the next step.)
d. Turn the engine over several times with the starter. (This will
coat the cylinder walls with oil.)
WARNING! To prevent dam-
age or injury from sparking,
make sure to ground the
spark plug electrodes while
turning the engine
over.
[EWA10952]
e. Remove the spark plug capsfrom the spark plugs, and then
install the spark plugs and the spark plug caps.
4. Lubricate all control cables and the pivoting points of all levers and
pedals as well as of the sidestand/
centerstand.
5. Check and, if necessary, correct the tire air pressure, and then lift
the motorcycle so that both of its
wheels are off the ground. Alterna-
tively, turn the wheels a little every
month in order to prevent the tires
from becoming degraded in one
spot.
6. Cover the muffler outlet with a plastic bag to prevent moisture
from entering it.
7. Remove the battery and fully charge it. Store it in a cool, dry
place and charge it once a month.
Do not store the battery in an ex-
cessively cold or warm place [less
than 0 C (30 F) or more than 30
 C (90 F)]. For more information
on storing the battery, see page
7-31.
TIPMake any necessary repairs beforestoring the motorcycle.
2CR-9-E0_1.book 4 ページ ２０１５年１月５日　月曜日　午前１１時５４分

11-1
1
2
3
4
5
6
7
8
9
101112
INDEX
AABS warning light ...................................... 4-6
Air filter element....................................... 7-17
Auxiliary DC connector ............................ 4-48BBattery ..................................................... 7-31
Brake and clutch levers, checking and lubricating .............................................. 7-29
Brake and shift pedals, checking and lubricating .............................................. 7-28
Brake fluid, changing ............................... 7-25
Brake fluid level, checking ....................... 7-24
Brake lever .............................................. 4-30
Brake lever free play, checking ............... 7-22
Brake light switches ................................. 7-23
Brake pedal ............................................. 4-31
Brake system ........................................... 4-31CCables, checking and lubricating ............. 7-27
Care ........................................................... 8-1
Catalytic converter ................................... 4-35
CCU ......................................................... 4-37
Clutch lever.............................................. 4-29
Clutch lever free play, adjusting .............. 7-22
Coolant .................................................... 7-14
Cowlings and panels, removing and installing .................................................. 7-8DDimmer switch ........................................... 4-4
Display, main screen ................................. 4-8
Display, menu screen .............................. 4-14
Document storage ................................... 4-38
Drive chain, cleaning and lubricating ....... 7-27
Drive chain slack ..................................... 7-25
EEngine break-in ......................................... 6-4
Engine idling speed, checking................. 7-17
Engine oil and oil filter cartridge .............. 7-12
Engine serial number .............................. 10-1
Engine trouble and system warning light ......................................................... 4-8
EXUP system .......................................... 4-45FFront and rear brake pads, checking ...... 7-23
Front fork, adjusting ................................ 4-39
Front fork, checking................................. 7-30
Fuel ......................................................... 4-33
Fuel consumption, tips for reducing .......... 6-4
Fuel level warning light .............................. 4-6
Fuel tank breather hose and overflow
hose ...................................................... 4-35
Fuel tank cap........................................... 4-33
Fuses, replacing ...................................... 7-33GGlossary .................................................... 3-3HHandlebar switches ................................... 4-3
Hazard switch............................................ 4-4
High beam indicator light ........................... 4-6
Horn switch ............................................... 4-4IIdentification numbers ............................. 10-1
Ignition circuit cut-off system ................... 4-46
Immobilizer system ................................... 4-1
Immobilizer system indicator light ............. 4-7
Indicator lights and warning lights ............. 4-6MMain switch/steering lock .......................... 4-2 Maintenance and lubrication, periodic .......7-4
Maintenance, emission control system ......7-3
Matte color, caution ...................................8-1
Model label ..............................................10-2
NNeutral indicator light .................................4-6OOil pressure and coolant temperature
warning light ............................................4-7PParking.......................................................6-5
Part locations .............................................2-1
Pass/LAP switch ........................................4-4RRear view mirrors..................................... 4-39SSafety information ......................................1-1
Seats........................................................ 4-36
Shifting .......................................................6-2
Shift pedal ................................................4-30
Shift timing indicator light ...........................4-7
Shock absorber assembly, adjusting .......4-41
Sidestand .................................................4-45
Sidestand, checking and lubricating ........7-29
Spark plugs, checking ..............................7-11
Special features .........................................3-1
Specifications.............................................9-1
Stability control indicator light ....................4-7
Starting the engine.....................................6-1
Steering, checking ................................... 7-31
Stop/Run/Start switch ................................4-4
Storage ......................................................8-4
Supporting the motorcycle .......................7-36
Swingarm pivots, lubricating .................... 7-30
2CR-9-E0_1.book 1 ページ ２０１５年１月５日　月曜日　午前１１時５４分
