EAU66100
Wheel switch “ ”
When the main screen is set to
STREET MODE, use the wheel switch
to scroll and reset the information dis-
play items.
When the main screen is set to TRACK
MODE, use the wheel switch to scroll
and reset the information display items
and to activate the lap timer.
When the display has been changed to
the MENU screen, use the wheel
switch to navigate the setting modules
and make setting changes.
Operate the wheel switch as follows.
Rotate up - rotate the wheel upward to
scroll up/left or increase a setting value.
Rotate down - rotate the wheel down-
ward to scroll down/right or decrease a
setting value. Short push
- briefly press the switch in-
ward to make and confirm selections.
Long push - press the switch inward
for one second to reset an information
display item or to access and exit the
MENU screen.
TIP
See page 4-8 for more information
on the main screen and its func-
tions.

See page 4-13 for more informa-
tion on the MENU screen and howto make setting changes.
EAU4939G
Indicator ligh ts and warning
lights
EAU11022
Turn signal indicator light “ ”
This indicator light flashes when a turn1. Neutral indicator light “ ”
2. Immobilizer system indicator light “ ”
3. Fuel level warning light “ ”
4. Oil pressure and coolant temperature warning light “ ”
5. Auxiliary system warning light “ ”
6. Stability control indicator light “SC”
7. Left turn signal indicator light “ ”
8. Engine trouble warning light “ ”
9. Right turn signal indicator light “ ”
10.Shift indicator light
11.High beam indicator light “ ”
12.ABS warning light “ ”
19 8
2 3 4 610
11
12
7
5
ABS
BX4-9-E2.book 5 ページ ２０１８年９月６日　木曜日　午後４時３９分

Instrument and control functions
4-8
1
2
34
5
6
7
8
9
10
11
12 coolant temperature warning
icon will come on. Let the en-
gine cool. Check the coolant
level (see page 7-39).

If the engine oil pressure is low,
the oil pressure warning icon
will come on. Check the oil level
(see page 7-12).

If the warning light remains on
after letting the engine cool and
confirming the proper oil level,
have a Yamaha dealer check the
vehicle. Do not continue to op-erate the vehicle!
EAU83700
Auxiliary system warning light “ ”
This warning light comes on if a prob-
lem is detected in a non-engine-related
system. TIPWhen the vehicle is turned on, this light
should come on for a few seconds and
then go off. Otherwise, have a Yamahadealer check the vehicle.
EAU85780
DisplayThe display has two different main
screen display modes, STREET
MODE and TRACK MODE. Most of the
functions are viewable in either mode,
but the layout differs slightly. The fol-
lowing items can be found on the dis-
play.
Speedometer

Tachometer

Information display

Transmission gear display

Front brake pressure indicator

Acceleration indicator

YRC setting display MODE/PWR/
TCS/SCS

YRC setting display LCS/QS/LIF

Clock

Revolution peak hold indicator

Lap timer

Various warning icons

Error mode warning “Err”
TIPThis model uses a thin-film-transistor
liquid-crystal display (TFT LCD) for
good contrast and readability in various
lighting conditions. However, due to the nature of this technology, it is normal
for a small number of pixels to be inac-
tive.
STREET MODE1. YRC items LCS/QS/LIF
2. Speedometer
3. Clock
4. Revolution peak hold indicator
5. Front brake pressure indicator
6. Acceleration indicator
7. Transmission gear display
8. YRC items MODE/PWR/TCS/SCS
9. Information display
10.Tachometer
1
y2
GPS
N
LCS
QS
LIF
ODO
123456
km
TRIP-1
1234.5
km
km/h
·1000 r/min
12 :
00
PWR
1
TCS
2
SCS
3
T -
1
MODE -
A
4
8 756
1
23
10
9
BX4-9-E2.book 8 ページ ２０１８年９月６日　木曜日　午後４時３９分

Instrument and control functions
4-12
1
2
34
5
6
7
8
9
10
11
12 To use the lap timer
1. Short push the wheel switch. The
information display item will flash
for five seconds.
2. While the information display item is flashing, rotate the wheel switch
upward. The lap timer will flash for
five seconds.
3. While the lap timer is flashing, long push the wheel switch to activate
the lap timer or stop the lap timer.
4. When the lap timer has been acti- vated, press the Pass/LAP switch
to start the lap timer.
TIP
The engine must be running to use
the lap timer.

Set the information display to
FASTEST or AVERAGE for addi-
tional lap time information.

Accessing the MENU screen will
automatically stop the lap timer.

Whenever the lap timer is stopped,
the current lap will not be record-
ed.

The lap time record can be viewedand reset from the MENU screen. Warning icons
When an error is detected, the following
error-related warning icons will then be
viewable.
Auxiliary system warning “ ”
This icon appears if a problem is de-
tected in a non-engine-related system.
Coolant temperature warning “ ”
This icon appears if the coolant temper-
ature reaches 117
C (242 F) or high-
er. Stop the vehicle and turn off the
engine. Allow the engine to cool.
1. Lap time
2. Latest lap time indicator “LATEST”
3. Information display item
4. Lap number
QS
LIF
N
12GPS
12 34
LAP 01
ODO
km
123456
MODE -
A
LCS
QS
LIF
LATEST
·1000 r/min
12
:
00
km/h
123
PWR
1
TCS
2
SCS
3
T -
1
km/h
123
GEAR
4
3
12
1. Auxiliary system warning “ ”
2. Coolant temperature warning “ ”
3. Oil pressure warning “ ”
4. Error mode warning “Err”
QS
LIF
GPS
LCS
QS
LIF
·1000 r/min
12:
00



31
4
2
Err
BX4-9-E2.book 12 ページ ２０１８年９月６日　木曜日　午後４時３９分

Instrument and control functions
4-41
1
2
345
6
7
8
9
10
11
12
EAU70641
Auxiliary DC connectorThis vehicle is equipped with an auxilia-
ry DC connector. Consult your Yamaha
dealer before installing any accesso-
ries.
EAU15306
SidestandThe sidestand is located on the left side
of the frame. Raise the sidestand or
lower it with your foot while holding the
vehicle upright.TIPThe built-in sidestand switch is part of
the ignition circuit cut-off system, which
cuts the ignition in certain situations.
(See the following section for an expla-
nation of the ignition circuit cut-off sys-tem.)
WARNING
EWA10242
The vehicle must not be ridden with
the sidestand down, or if the sides-
tand cannot be properly moved up
(or does not stay up), otherwise the
sidestand could contact the ground
and distract the operator, resulting
in a possible loss of control.
Yamaha’s ignition circuit cut-off
system has been designed to assist
the operator in fulfilling the respon-
sibility of raising the sidestand be-
fore starting off. Therefore, check
this system regularly and have a Yamaha dealer repair it if it does not
function properly.
BX4-9-E2.book 41 ページ ２０１８年９月６日　木曜日　午後４時３９分

6-1
1
2
3
4
567
8
9
10
11
12
Operation and important riding points
EAU15952
Read the Owner’s Manual carefully to
become familiar with all controls. If
there is a control or function you do not
understand, ask your Yamaha dealer.
WARNING
EWA10272
Failure to familiarize yourself with
the controls can lead to loss of con-
trol, which could cause an accidentor injury.
EAU73461
TIPThis model is equipped with:
an inertial measurement unit (IMU)
that will stop the engine in case of
turnover. In this case, turn the
main switch off (and then back on)
before attempting to restart the en-
gine. Failing to do so will prevent
the engine from starting even
though the engine will crank when
the start switch is pushed.

an engine auto-stop system. The
engine stops automatically if left
idling for 20 minutes. In this case,
simply push the start switch to re-start the engine.
EAU79303
Starting the engineIn order for the ignition circuit cut-off
system (page 4-42) to enable starting,
one of the following conditions must be
met:
The transmission is in the neutral
position.

The transmission is in gear with
the clutch lever pulled and the sid-
estand up.
To start the engine
1. Insert the key into the main switch.
2. Set the Stop/Run/Start switch to “”.
3. Turn the main switch (key) to “ON”.
4. Confirm the following warning lights and indicator lights perform a
self-check.

Engine trouble warning light

Oil pressure and coolant tem-
perature warning light

ABS warning light

Fuel level warning light

Auxiliary system warning light

Shift indicator light

Stability control indicator light
BX4-9-E2.book 1 ページ ２０１８年９月６日　木曜日　午後４時３９分

Periodic maintenance and adjustment7-35
1
2
3
4
5
678
9
10
11
12
3. Turn the key to “ON” and turn on
the electrical circuit in question to
check if the device operates. 4. If the fuse immediately blows
again, have a Yamaha dealer
check the electrical system.
EAU67122
Vehicle lightsThis model is equipped with full-LED
lighting.
The headlights, auxiliary lights, turn sig-
nals, brake/tail light, and license plate
light are all LED. There are no user re-
placeable bulbs.
If a light does not come on, check the
fuses and then have a Yamaha dealer
check the vehicle.NOTICE
ECA16581
Do not affix any type of tinted film orstickers to the headlight lens.
Specified fuses:Main fuse: 50.0 A
Terminal fuse 1:
2.0 A
Headlight fuse: 7.5 A
Signaling system fuse: 7.5 A
Ignition fuse:
15.0 A
Radiator fan motor fuse: 15.0 A
Sub radiator fan motor fuse: 10.0 A
ABS motor fuse:
30.0 A
Hazard fuse: 7.5 A
ABS ECU fuse: 7.5 A
ABS solenoid fuse:
15.0 A
Fuel injection system fuse: 15.0 A
Backup fuse: 7.5 A
Electronic throttle valve fuse: 7.5 A
1. Auxiliary light
2. Headlight
12
1
2
BX4-9-E2.book 35 ページ ２０１８年９月６日　木曜日　午後４時３９分

Periodic maintenance and adjustment
7-36
1
2
3
4
5
67
8
9
10
11
12
TIP
The right headlight comes on
when Pass/LAP switch “ /LAP”
is pushed or the dimmer switch is
set to “ ” (high beam).

The auxiliary lights were designed
to fade out as your R1 goes tosleep.
EAU67131
Supporting the motorcycleSince this model is not equipped with a
centerstand, use maintenance stands
when removing the front or rear wheel
or when performing other maintenance
that requires the motorcycle to stand up
right.
Check that the motorcycle is in a stable
and level position before starting any
maintenance.
EAU25872
TroubleshootingAlthough Yamaha motorcycles receive
a thorough inspection before shipment
from the factory, trouble may occur dur-
ing operation. Any problem in the fuel,
compression, or ignition systems, for
example, can cause poor starting and
loss of power.
The following troubleshooting charts
represent quick and easy procedures
for checking these vital systems your-
self. However, should your motorcycle
require any repair, take it to a Yamaha
dealer, whose skilled technicians have
the necessary tools, experience, and
know-how to service the motorcycle
properly.
Use only genuine Yamaha replace-
ment parts. Imitation parts may look like
Yamaha parts, but they are often inferi-
or, have a shorter service life and can
lead to expensive repair bills.
WARNING
EWA15142
When checking the fuel system, do
not smoke, and make sure there are
no open flames or sparks in the ar-
ea, including pilot lights from water
1. Maintenance stand (example)
1
BX4-9-E2.book 36 ページ ２０１８年９月６日　木曜日　午後４時３９分

Specifications
9-2
1
2
3
4
5
6
7
89
10
11
12
Loading:Maximum load: 187 kg (412 lb)
The vehicle's maximum load is the combined
weight of the rider, passenger, cargo and any
accessories.Unified brake system:Operation: Activated by front brakeFront brake:Type:Hydraulic dual disc brakeRear brake:Type:
Hydraulic single disc brakeFront suspension:Type:Telescopic forkRear suspension:Type:Swingarm (link suspension)Electrical system:System voltage:
12 VBattery:Model:YTZ7S
Voltage, capacity:
12 V, 6.0 Ah (10 HR)Bulb wattage:Headlight:LED
Brake/tail light:
LED Front turn signal light:
LED
Rear turn signal light:
LED
Auxiliary light: LED
License plate light: LED
BX4-9-E2.book 2 ページ ２０１８年９月６日　木曜日　午後４時３９分

11-1
1
2
3
4
5
6
7
8
9
1011
12
IndexAABS warning light.................................... 4-6
Air filter element .................................... 7-17
Auxiliary DC connector ......................... 4-41
Auxiliary system warning light ................. 4-8BBattery................................................... 7-32
Brake and clutch levers, checking and lubricating ........................................... 7-29
Brake and shift pedals, checking and
lubricating ........................................... 7-28
Brake fluid, changing ............................ 7-25
Brake fluid level, checking .................... 7-24
Brake lever ............................................ 4-27
Brake lever free play, checking ............. 7-23
Brake light switches .............................. 7-23
Brake pedal ........................................... 4-28
Brake system ........................................ 4-28CCables, checking and lubricating .......... 7-28
Canister................................................. 7-12
Care ........................................................ 8-1
Catalytic converter ................................ 4-33
Clutch lever ........................................... 4-26
Clutch lever free play, adjusting ............ 7-22
Coolant.................................................. 7-16
Cowlings and panels, removing and installing................................................ 7-9DData recording, vehicle ......................... 10-2
Diagnostic connector ............................ 10-2
Dimmer switch ........................................ 4-4
Display, main screen............................... 4-8
Display, menu screen ........................... 4-13 Document storage ................................ 4-35
Drive chain, cleaning and lubricating .... 7-27
Drive chain slack .................................. 7-26
EEngine break-in ...................................... 6-3
Engine idling speed, checking .............. 7-18
Engine oil and oil fi
lter cartridge ........... 7-12
Engine serial number............................ 10-1
Engine trouble warning light ................... 4-6
EXUP system ....................................... 4-40FFront and rear brake pads, checking .... 7-24
Front fork, adjusting .............................. 4-36
Front fork, checking .............................. 7-30
Fuel....................................................... 4-31
Fuel consumption, tips for reducing........ 6-3
Fuel level warning light ........................... 4-6
Fuel tank cap ........................................ 4-30
Fuel tank overflow hose........................ 4-32
Fuses, replacing ................................... 7-33GGlossary ................................................. 3-4HHandlebar switches ................................ 4-3
Hazard switch ......................................... 4-4
High beam indicator light ........................ 4-6
Horn switch ............................................. 4-4IIdentification numbers .......................... 10-1
Ignition circuit cut-off system ................ 4-42
Immobilizer system ................................. 4-1
Immobilizer system indicator light........... 4-7
Indicator lights and warning lights .......... 4-5
MMain switch/steering lock ........................ 4-2
Maintenance and lubrication, periodic..... 7-5
Maintenance, emission control system ... 7-3
Matte color, caution ................................. 8-1
Model label ............................................ 10-2NNeutral indicator light .............................. 4-6OOil pressure and coolant temperature
warning light.......................................... 4-7PParking .................................................... 6-4
Part locations .......................................... 2-1
Pass/LAP switch ..................................... 4-4RRear view mirrors .................................. 4-36SSafety information ................................... 1-1
Seats ..................................................... 4-34
Shift indicator light ................................... 4-6
Shifting .................................................... 6-2
Shift pedal ............................................. 4-27
Shock absorber assembly, adjusting .... 4-38
Sidestand .............................................. 4-41
Sidestand, checking an d lubricating...... 7-30
Spark plugs, checking ........................... 7-11
Special features ...................................... 3-1
Specifications .......................................... 9-1
Stability control indicator light.................. 4-7
Starting the engine .................................. 6-1
Steering, checking................................. 7-31
Stop/Run/Start switch.............................. 4-4
Storage.................................................... 8-4
BX4-9-E2.book 1 ページ ２０１８年９月６日　木曜日　午後４時３９分
