PERIODIC MAINTENANCE AND MINOR REPAIR
6-17
617. Remove the radiator cap to check
the coolant level in the radiator. If
necessary, add sufficient coolant
until it reaches the top of the radia-
tor, and then install the radiator
cap.
18. Start the engine, and then check
the vehicle for coolant leakage. If
coolant is leaking, have a Yamaha
dealer check the cooling system.
19. Install the panel and the cowlings.
EAU04256*
Checking the air filter element The air filter element should be
checked at the intervals specified in the
periodic maintenance and lubrication
chart. Check the air filter element more
frequently if you are riding in unusually
wet or dusty areas.
1. Remove the rider seat. (See
page 3-13 for rider seat removal
and installation procedures.)
2. Remove the fuel tank bolts and
slightly lift the fuel tank.3. Turn the fuel cock lever to “OFF”,
and then disconnect the hoses
and the fuel sender coupler.
NOTE:_ Before removing the hoses, mark them
to ensure that they will be reinstalled in
their correct positions. _
1. Bolt (× 2)
1. Fuel cock
2. Hose (× 2)
3. Fuel sender coupler
U5MTE1.book Page 17 Monday, August 6, 2001 6:10 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-18
6 4. Tilt the front of the fuel tank back to
position the tank away from the air
filter case, and then support the
tank as shown.5. Remove the air filter case cover by
removing the screws.6. Pull the air filter element out.
7. Check the condition of the air filter
element and replace it if it is dam-
aged or excessively dusty.
1. Screw (× 6)
2. Air filter case cover
1. Air filter element
U5MTE1.book Page 18 Monday, August 6, 2001 6:10 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-19
68. Insert the element into the air filter
case.
EC000082*
CAUTION:_

Make sure that the air filter ele-
ment is properly seated in the
air filter case.


The engine should never be op-
erated without the air filter ele-
ment installed, otherwise the
pistons and/or cylinders may
become excessively worn.
_9. Install the air filter case cover by
installing the screws.
10. Connect the fuel sender coupler
and the hoses, turn the fuel cock
lever to “ON”, place the fuel tank in
the original position, and then in-
stall the bolts.
EW000131
WARNING
_ Make sure that the fuel hoses and
vacuum hose are properly connect-
ed and routed, and not pinched. Re-
place any damaged hoses. _11. Install the rider seat.
EAU01335
Air intake duct Check that the screen of the intake
duct is not blocked. Clean the screen if
necessary.1. Air intake duct
U5MTE1.book Page 19 Monday, August 6, 2001 6:10 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-20
6
EAU00630
Adjusting the carburetors The carburetors are important parts of
the engine and require very sophisti-
cated adjustment. Therefore, most car-
buretor adjustments should be left to a
Yamaha dealer, who has the neces-
sary professional knowledge and expe-
rience. The adjustment described in
the following section, however, may be
serviced by the owner as part of routine
maintenance.
EC000095
CAUTION:@ The carburetors have been set and
extensively tested at the Yamaha
factory. Changing these settings
without sufficient technical knowl-
edge may result in poor perfor-
mance of or damage to the engine. @
EAU00632
Adjusting the engine idling
speed The engine idling speed must be
checked and, if necessary, adjusted as
follows at the intervals specified in the
periodic maintenance and lubrication
chart.
1. Start the engine and warm it up for
several minutes at 1,000–
2,000 r/min while occasionally rev-
ving it to 4,000–5,000 r/min.NOTE:@ The engine is warm when it quickly re-
sponds to the throttle. @
2. Check the engine idling speed
and, if necessary, adjust it to spec-
ification by turning the throttle stop
screw. To increase the engine
idling speed, turn the screw in di-
rection
a. To decrease the engine
idling speed, turn the screw in
direction
b.NOTE:@ If the specified idling speed cannot be
obtained as described above, have a
Yamaha dealer make the adjustment. @ 1. Throttle stop screwEngine idling speed:
1,250–1,350 r/min
U5MTE1.book Page 20 Monday, August 6, 2001 6:10 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-21
6
EAU00635
Adjusting the throttle cable
free play The throttle cable free play should
measure 6–8 mm at the throttle grip.
Periodically check the throttle cable
free play and, if necessary, have a
Yamaha dealer adjust it.
EAU00637
Adjusting the valve clearance The valve clearance changes with use,
resulting in improper air-fuel mixture
and/or engine noise. To prevent this
from occurring, the valve clearance
must be adjusted by a Yamaha dealer
at the intervals specified in the periodic
maintenance and lubrication chart.
EAU00658
Tires To maximize the performance, durabil-
ity, and safe operation of your motor-
cycle, note the following points
regarding the specified tires.
Tire air pressure
The tire air pressure should be
checked and, if necessary, adjusted
before each ride.
EW000082
WARNING
@

The tire air pressure must be
checked and adjusted on cold
tires (i.e., when the temperature
of the tires equals the ambient
temperature).


The tire air pressure must be
adjusted in accordance with the
riding speed and with the total
weight of rider, passenger, car-
go, and accessories approved
for this model.
@
a. Throttle cable free playU5MTE1.book Page 21 Monday, August 6, 2001 6:10 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-22
6
CE-01E
CE-07EEWA00012
WARNING
@ Because loading has an enormous
impact on the handling, braking,
performance and safety characteris-
tics of your motorcycle, you should
keep the following precautions in
mind.

NEVER OVERLOAD THE
MOTORCYCLE! Operation of an
overloaded motorcycle may re-
sult in tire damage, loss of con-
trol, or severe injury. Make sure
that the total weight of rider,
passenger, cargo, and accesso-
ries does not exceed the speci-
fied maximum load for the
vehicle.


Do not carry along loosely
packed items, which can shift
during a ride.


Securely pack the heaviest
items close to the center of the
motorcycle and distribute the
weight evenly on both sides.


Adjust the suspension and tire
air pressure with regard to the
load.


Check the tire condition and air
pressure before each ride.
@
Tire air pressure
(measured on cold tires)
Load* Front Rear
Up to 90 kg250 kPa
2.50 kgf/cm
2
2.50 bar250 kPa
2.50 kgf/cm
2
2.50 bar
90 kg–maximum250 kPa
2.50 kgf/cm
2
2.50 bar290 kPa
2.90 kgf/cm
2
2.90 bar
High-speed riding250 kPa
2.50 kgf/cm
2
2.50 bar250 kPa
2.50 kgf/cm
2
2.50 bar
Maximum load* 189 kg
* Total weight of rider, passenger, cargo and
accessories
U5MTE1.book Page 22 Monday, August 6, 2001 6:10 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-23
6Tire inspection
The tires must be checked before each
ride. If the center tread depth reaches
the specified limit, if the tire has a nail
or glass fragments in it, or if the side-
wall is cracked, have a Yamaha dealer
replace the tire immediately.
CE-08ENOTE:@ The tire tread depth limits may differ
from country to country. Always comply
with the local regulations. @
EW000079
WARNING
@

Have a Yamaha dealer replace
excessively worn tires. Besides
being illegal, operating the
motorcycle with excessively
worn tires decreases riding sta-
bility and can lead to loss of
control.


The replacement of all wheel-
and brake-related parts, includ-
ing the tires, should be left to a
Yamaha dealer, who has the
necessary professional knowl-
edge and experience.
@
Tire information
This motorcycle is equipped with cast
wheels and tubeless tires with valves.
EW000080
WARNING
@

The front and rear tires should
be of the same make and de-
sign, otherwise the handling
characteristics of the motor-
cycle cannot be guaranteed.


After extensive tests, only the
tires listed below have been ap-
proved for this model by
Yamaha Motor Co., Ltd.
1. Tire sidewall
a. Tire tread depthMinimum tire tread depth
(front and rear)1.6 mm
1. Tire air valve
2. Tire air valve core
3. Tire air valve cap with seal
U5MTE1.book Page 23 Monday, August 6, 2001 6:10 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-24
6


Always make sure that the valve
caps are securely installed to
prevent air pressure leakage.


Use only the tire valves and
valve cores listed below to
avoid tire deflation during a
high-speed ride.
@CE-10E
CE-14EEAU00684
WARNING
@ This motorcycle is fitted with super-
high-speed tires. Note the following
points in order to make the most ef-
ficient use of these tires.

Use only the specified replace-
ment tires. Other tires may run
the danger of bursting at super
high speeds.


Brand-new tires can have a rela-
tively poor grip on certain road
surfaces until they have been
“broken in”. Therefore, it is ad-
visable before doing any high-
speed riding to ride conserva-
tively for approximately 100 km
after installing a new tire.


The tires must be warmed up
before a high-speed run.


Always adjust the tire air pres-
sure according to the operating
conditions.
@
EAU03773
Cast wheels To maximize the performance, durabil-
ity, and safe operation of your motor-
cycle, note the following points
regarding the specified wheels.

The wheel rims should be checked
for cracks, bends or warpage be-
fore each ride. If any damage is
found, have a Yamaha dealer re-
place the wheel. Do not attempt
even the smallest repair to the
wheel. A deformed or cracked
wheel must be replaced.


The wheel should be balanced
whenever either the tire or wheel
has been changed or replaced. An
unbalanced wheel can result in
poor performance, adverse han-
dling characteristics, and a short-
ened tire life.


Ride at moderate speeds after
changing a tire since the tire sur-
face must first be “broken in” for it
to develop its optimal characteris-
tics.
FRONT
Manufacturer Size Model
Michelin
120/60 ZR17 (55W)
Pilot SPORT B
120/60 ZR17 M/C (55W)
Dunlop
120/60 ZR17 (55W)
D207FJ
120/60 ZR17 M/C (55W)
REAR
Manufacturer Size Model
Michelin
180/55 ZR17 (73W)
Pilot SPORT B
180/55 ZR17 M/C (73W)
Dunlop
180/55 ZR17 (73W)
D207N
180/55 ZR17 M/C (73W)FRONT & REAR
Tire air valve TR412
Valve core #9000A (original)
U5MTE1.book Page 24 Monday, August 6, 2001 6:10 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-25
6
EAU01356
Adjusting the clutch lever free
play The clutch lever free play should mea-
sure 10–15 mm as shown. Periodically
check the clutch lever free play and, if
necessary, adjust it as follows.
To increase the clutch lever free play,
turn the adjusting bolt at the clutch le-
ver in direction
a. To decrease the
clutch lever free play, turn the adjusting
bolt in direction
b.
NOTE:@ If the specified clutch lever free play
cannot be obtained as described
above, proceed as follows. @1. Fully turn the adjusting bolt at the
clutch lever in direction
a to loos-
en the clutch cable.
2. Remove cowling A. (See page 6-6
for cowling removal and installa-
tion procedures.)
3. Loosen the locknut at the crank-
case.
4. To increase the clutch lever free
play, turn the adjusting nut in di-
rection
a. To decrease the clutch
lever free play, turn the adjusting
nut in direction
b.
5. Tighten the locknut.
6. Install the cowling.
1. Clutch lever free play adjusting bolt
c. Clutch lever free play
1. Locknut
2. Clutch lever free play adjusting nut
(crankcase)
U5MTE1.book Page 25 Monday, August 6, 2001 6:10 PM

PERIODIC MAINTENANCE AND MINOR REPAIR
6-26
6
EAU01357
Adjusting the brake pedal
position The top of the brake pedal should be
positioned approximately 7–11 mm be-
low the bottom of the footrest bracket
as shown. Periodically check the brake
pedal position and, if necessary, have
a Yamaha dealer adjust it.
EW000109
WARNING
_ A soft or spongy feeling in the brake
pedal can indicate the presence of
air in the hydraulic system. If there
is air in the hydraulic system, have a
Yamaha dealer bleed the system be-
fore operating the motorcycle. Air in
the hydraulic system will diminish
the braking performance, which
may result in loss of control and an
accident. _
EAU00713
Adjusting the rear brake light
switch The rear brake light switch, which is ac-
tivated by the brake pedal, is properly
adjusted when the brake light comes
on just before braking takes effect. If
necessary, adjust the brake light switch
as follows.
Turn the adjusting nut while holding the
rear brake light switch in place. To
make the brake light come on earlier,
turn the adjusting nut in direction
a. To
make the brake light come on later,
turn the adjusting nut in direction
b.
a. Distance between brake pedal and footrest
bracket
1. Rear brake light switch
2. Rear brake light switch adjusting nut
U5MTE1.book Page 26 Monday, August 6, 2001 6:10 PM
