Page 7 of 110
TABLE OF CONTENTS
Checking the wheel bearings ....... 6-33
Battery .......................................... 6-33
Replacing the fuses ...................... 6-35
Replacing a headlight bulb ........... 6-36
Tail/brake light .............................. 6-37
Replacing a turn signal light bulb ........................................... 6-37
Replacing the license plate light
bulb ........................................... 6-38
Auxiliary light ................................ 6-39
Supporting the motorcycle ............ 6-39
Front wheel ................................... 6-40
Rear wheel ................................... 6-42
Troubleshooting ............................ 6-44
Troubleshooting charts ................. 6-45
MOTORCYCLE CARE AND
STORAGE .......................................... 7-1
Matte color caution ......................... 7-1
Care ................................................ 7-1
Storage ...........................................7-4
SPECIFICATIONS ............................. 8-1
CONSUMER INFORMATION ............. 9-1
Identification numbers .................... 9-1
U1JSE1E0.book Page 2 Wednesday, June 6, 2012 10:05 AM
Page 87 of 110
PERIODIC MAINTENANCE AND ADJUSTMENT
6-36
6
EAU39013
Replacing a headlight bulb This model is equipped with halogen
bulb headlights. If a headlight bulb
burns out, replace it as follows.NOTICE
ECA10650
Take care not to damage the follow-
ing parts:●
Headlight bulb
Do not touch the glass part of
the headlight bulb to keep it free
from oil, otherwise the transpar-
ency of the glass, the luminosity
of the bulb, and the bulb life will
be adversely affected. Thor-
oughly clean off any dirt and fin-
gerprints on the headlight bulb
using a cloth moistened with al-
cohol or thinner.
●
Headlight lens
Do not affix any type of tinted
film or stickers to the headlight
lens.
Do not use a headlight bulb of a
wattage higher than specified.
1. Remove the headlight bulb cover
by turning it counterclockwise.
2. Disconnect the headlight coupler. 3. Unhook the headlight bulb holder,
and then remove the burnt-out
bulb.
4. Place a new headlight bulb into po- sition, and then secure it with the
bulb holder.
5. Connect the headlight coupler.1. Do not touch the glass part of the bulb.
1. Headlight bulb cover
1
1. Headlight coupler
1. Headlight bulb holder
U1JSE1E0.book Page 36 Wednesday, June 6, 2012 10:05 AM
Page 88 of 110
PERIODIC MAINTENANCE AND ADJUSTMENT
6-37
66. Install the headlight bulb cover by
turning it clockwise.
7. Have a Yamaha dealer adjust the headlight beam if necessary.
EAU24181
Tail/brake light This model is equipped with an LED-
type tail/brake light.
If the tail/brake light does not come on,
have a Yamaha dealer check it.
EAU24204
Replacing a turn signal light
bulb 1. Remove the turn signal light lensby removing the screw.
2. Remove the burnt-out bulb by pushing it in and turning it counter-
clockwise.1. Turn signal light lens
2. Screw
21
U1JSE1E0.book Page 37 Wednesday, June 6, 2012 10:05 AM
Page 89 of 110
PERIODIC MAINTENANCE AND ADJUSTMENT
6-38
6
3. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
4. Install the lens by installing the screw. NOTICE: Do not over-
tighten the screw, otherwise the
lens may break.
[ECA11191] EAU24313
Replacing the license plate
light bulb 1. Remove the license plate light unit
by removing the screws.
2. Remove the license plate light bulb socket (together with the bulb) by
pulling it out. 3. Remove the burnt-out bulb by pull-
ing it out.
4. Insert a new bulb into the socket.
5. Install the socket (together with the bulb) by pushing it in.
6. Install the license plate light unit by installing the screws.
1. Turn signal light bulb
1. Screw
2. License plate light unit
1
2
1. License plate light bulb
2. License plate light bulb socket
1
2
U1JSE1E0.book Page 38 Wednesday, June 6, 2012 10:05 AM
Page 105 of 110
SPECIFICATIONS
8-3
8
Charging system:AC magnetoBattery:Model:
YTZ10S
Voltage, capacity: 12 V, 8.6 AhHeadlight:Bulb type:
Halogen bulbBulb voltage, wattage × quantity:Headlight:
12 V, 55.0 W × 2
Tail/brake light:
LED
Front turn signal light: 12 V, 10.0 W × 2
Rear turn signal light: 12 V, 10.0 W × 2
Auxiliary light:
LED
License plate light: 12 V, 5.0 W × 1
Meter lighting: LED
Neutral indicator light:
LED
High beam indicator light: LED
Oil level warning light: LED
Turn signal indicator light:
LED Fuel level warning light:
LED
Coolant temperature warning light: LED
Engine trouble warning light:
LED
Immobilizer system indicator light: LED
Shift timing indicator light: LED
Fuses:Main fuse:50.0 A
Headlight fuse: 15.0 A
Taillight fuse:
7.5 A
Signaling system fuse: 10.0 A
Ignition fuse: 15.0 A
Radiator fan fuse:
15.0 A × 2
Fuel injection system fuse: 15.0 A
Backup fuse: 7.5 A
Electronic throttle valve fuse:
7.5 A
U1JSE1E0.book Page 3 Wednesday, June 6, 2012 10:05 AM
Page 107 of 110
INDEX
AAir filter element.................................... 6-19
Auxiliary light ........................................ 6-39BBattery .................................................. 6-33
Brake and clutch levers, checking and lubricating ..................... 6-31
Brake and shift pedals, checking and lubricating ..................... 6-30
Brake fluid, changing ............................ 6-27
Brake fluid level, checking .................... 6-25
Brake lever ........................................... 3-16
Brake lever free play, checking ............ 6-24
Brake light switches .............................. 6-24
Brake pedal .......................................... 3-16CCables, checking and lubricating .......... 6-29
Care ........................................................ 7-1
Catalytic converters .............................. 3-19
Clutch lever........................................... 3-15
Clutch lever free play, adjusting ........... 6-23
Coolant ................................................. 6-16
Coolant temperature warning light.......... 3-5
Cowlings and panels, removing and installing......................... 6-8DDimmer switch ...................................... 3-14
Drive chain, cleaning and lubricating .... 6-29
Drive chain slack .................................. 6-27EEngine break-in ...................................... 5-3
Engine idling speed, checking .............. 6-19
Engine oil and oil filter cartridge ........... 6-13
Engine stop switch................................ 3-14 Engine trouble warning light .................... 3-7
EXUP system ........................................ 3-27
FFront and rear brake pads, checking .... 6-25
Front fork, adjusting .............................. 3-22
Front fork, checking...............................6-32
Fuel ....................................................... 3-17
Fuel consumption, tips for reducing ........ 5-3
Fuel level warning light............................ 3-4
Fuel tank breather hose and
overflow hose ...................................... 3-19
Fuel tank cap......................................... 3-17
Fuses, replacing .................................... 6-35HHandlebar switches ............................... 3-14
Hazard switch........................................ 3-15
Headlight bulb, replacing....................... 6-36
Helmet holding cable.............................3-21
High beam indicator light......................... 3-4
Horn switch ........................................... 3-14IIdentification numbers ............................. 9-1
Ignition circuit cut-off system ................. 3-28
Immobilizer system .................................3-1
Immobilizer system indicator light ........... 3-7
Indicator lights and warning lights ........... 3-4LLicense plate light bulb, replacing ......... 6-38
Luggage strap holders .......................... 3-27MMain switch/steering lock ........................ 3-2
Maintenance and lubrication, periodic..... 6-4
Maintenance, emission control system ... 6-3
Matte color, caution .................................7-1 Model label ............................................. 9-1
Multi-function meter unit ......................... 3-8
NNeutral indicator light .............................. 3-4OOil level warning light .............................. 3-4PParking.................................................... 5-4
Part locations .......................................... 2-1
Pass switch ........................................... 3-14RRear view mirrors.................................. 3-22SSafety information ................................... 1-1
Seats..................................................... 3-20
Shifting .................................................... 5-2
Shift pedal ............................................. 3-15
Shift timing indicator light ........................ 3-7
Shock absorber assembly, adjusting .... 3-24
Sidestand .............................................. 3-28
Sidestand, checking and lubricating ..... 6-31
Spark plugs, checking........................... 6-12
Specifications.......................................... 8-1
Starting the engine.................................. 5-1
Start switch ........................................... 3-14
Steering, checking ................................ 6-33
Storage ................................................... 7-4
Supporting the motorcycle .................... 6-39
Swingarm pivots, lubricating ................. 6-32TTail/brake light ...................................... 6-37
Throttle grip and cable,
checking and lubricating ..................... 6-30
Throttle grip free play, checking............ 6-19
U1JSE1E0.book Page 1 Wednesday, June 6, 2012 10:05 AM
Page 108 of 110
INDEXTires ...................................................... 6-20
Tool kit .................................................... 6-2
Troubleshooting .................................... 6-44
Troubleshooting charts ......................... 6-45
Turn signal indicator lights ...................... 3-4
Turn signal light bulb, replacing ............ 6-37
Turn signal switch ................................. 3-14VValve clearance .................................... 6-20
Vehicle identification number .................. 9-1WWheel bearings, checking ..................... 6-33
Wheel (front) ......................................... 6-40
Wheel (rear) .......................................... 6-42
Wheels .................................................. 6-23
U1JSE1E0.book Page 2 Wednesday, June 6, 2012 10:05 AM
