Emission Group Identification Test Group and Evaporative Family
K20Z2 engine Model:
Example:
’06 Model
’07 Model
’08 Model
’09 Model Test Group:
a. Model Year
b. Manufacturer Subcode c. Family Type
d. Displacement Group e. Sequence Characters
Evaporative Family:
a. Model Year
b. Manufacturer Subcode c. Family Type
d. Canister Working Capacity Group e. Sequence Characters
1-9
Under-hood Emission Control Label
TO EVAP
CA N IS TE R
EVAP CANISTER
PURGE V ALVE
VERS
RE SE R VO I R
EVAP
VA LVE DE PURGE
D U PR ES E RV O I R EV A P
PC V V A L V E
SOUPAPE RGC
FRONT
AV ANT
THIS V EHICLE CONFORMS TO U.S. EPA TIER 2 BIN 5
REGULATIONS APPLICABLE TO 2006 MODEL YEAR
NEW PASSENGER CARS AND CALIFORNIA APPLICA BLE
TO 2 006 MODEL Y EAR NEW LEV IILEV PASS ENGER C ARS .
TWC, A/F SENSOR, HO2S, EGR, SFI
CE VEH ICU LE EST CONFORME A UX LOIS EPA TIER 2 DES ETA TS-UNIS
APPLICA BLES POUR LES VEHICULES DE BIN 5 POUR LES NOUV ELLES VEHICULES
VO ITURES D E TOURISME D’ A NNEE MO DELE 2006 ET A UX LOIS DE LA CA LIFORNIE
APPLICA BLES POUR LES NOUV EA UX VEHICU LES LEVII LEV VOITURES DE TOURISME
D’ ANN EE MOD ELE 2006. TWC, A/F SENSOR, HO2S, EGR, SFI
VALVE LASH
(COL D)
NO OTHER ADJUSTMENTS NEEDED. IN
EX
: 0.23 0.02 mm
: 0.30 0.02 mm
J EU D ES SOUP APES (MOUTEUR FROID)
AUCUN AUTRE REGLACE NECESSAIRE. ADM
ECM
: 0.23 0.02 mm
: 0.30 0.02 mm
VEHICLE EMISSION CONTROL INFORMATION
INFORMATIONS-DISPOSITIFS ANTI-POLLUTION
INFORMATION
HOND A MOTOR CO. , LTD.
HOND A MOTOR CO. , LTD.
RR A-C 00
MORMES S UR LES EMIS SIONS D’ECHAPPEMENT : LEVII, LEV (ACCREDITATION ET EN SERVICE)
: TIER 2-BIN 5 (ACCREDITATION ET EN SERVICE)
EPA ARBZN
6 6
THE FACTO RY INSTALLED LONG LIFE COOLANT MUST BE REPLA CED ACCORDING TO
MAINTENA NCE MINDER SUB COD E 5, OR AT 1 0 YEA RS WHICHEVER COMES FIEST.
THEREAFTER EVERY 5 YEARS.
WHEN ADD IN G OR REPL ACING TH E COOLA NT, A LWAYS USE ACURA RECOMMENDED
GENUINE L ONG-L IF E ANTI FREEZE / COOL ANT TYPE 2. THIS COOLA NT IS PRE MIX ED WITH
50% DISTILLED WA TER. IT D OES NOT REQUIRE A NY ADDITIONA L MIXING.
NEV ER DILUTE THE COO LANT, OR TH E LIFE OF THE ENGINE MAY BE SERIOUSL Y SHORTENED.
CH EC K O R A DD T HE C O O LAN T A T TH E RE SE RV E TAN K, N O T T HE R ADI AT O R.
FOR F URTHER INFORMATION ON THE COOLING SYSTEM, READ THE OWNER’S MA NUAL OR
CHECK WITH YOUR ACURA DEALER.
LORS D E L’APPOINT OU DE REMPLACEMENT DU LIQUID E DE REFROID ISSEMENT.
TOUJOURS UTILISER L’ANTIGEL /L IQUIDE D E REFRO IDISSEMENT TYPE 2 LONGUE D UREE
ACURA D’ORIGINE RECOMMENDE CE LIQUIDE DE REFROIDISSEMENT EST MELANGE A U
PREALABLE AV EC 50 % D’EA U DISTILLEE. IL N’EX IGE A UCUN MEL ANGE ADD ITIONNEL .
NE JAMA IS D IL UER LE L IQUIDE D E REFROIDISSEMENT, LA DUREE D E VIE DU MOTEUR
POURRAIT EN ETRE A FFECTEE. LE LIQUIDE D E REFROIDISSEMENT L ONGUE DUREE INSTAL LE A L ’USINE DOIT ETRE
RENLA CE CONFORMEMENT AU CODE SECONDAIRE 5 DE L ’A ID E-MEMOIRE D’ENTRETIEN
OU A PRES 10 ANS, SELON LA PREMIERE EVENTUA LITE.PU IS TOUS LES 5 ANS.
CONTROLER L ES NIV EAUX ET FA IRE L’APPOIN T A U V ASE D ’EXPAN SIO N. J AMA IS AU RAD IATEUR.
POUR TOUTE INFORMATION COMPLEMENTAIRE SUR LE CIRCUIT DE REFROIDISSEMENT, SE
REFERER A U MANUEL D’UTILISATEUR OU PRENDRE CONTACT AVEC UN CONCESSIONNAIRE ACURA.
6HNXV02. 4FKC6HNXR0106BBA
2.0L
6HNXV0 2. 4F A6 6HN XR 010 6BBA
ACCREDITATION OBD II 2.0LOBD II CERTIFIED
EXHAUST EMISSIONS STANDARDS : L EVII, LEV (CERTIFICATION AND IN-USE)
: TIER 2-BIN 5 (CERTIFICATION AND IN-USE)
EPA
ARB
T HIS SPARK IGNIT ION SYSTEM
CO M PLIES W ITH CANADIAN ICES 0 02 .
CE SYSTEME D’ALLUMAGE PAR
ALANORMENMB 002DUCANADA.ETINCELLE DE VEHICULE ES T CONFORMERENSEIGNEMENTS
108
’06-07 Models
’08-09 Models
TH E FA CTORY INSTA LLED LONG -LIFE COO LA NT MUST BE REPLACED A CCORDING TO
MAINTENA NCE MINDER SUB CODE 5, OR A T 10 YEARS WHICHEVER COMES FIEST.
TH ER EA FT ER E VE RY 5 YE AR S .
W HEN A DDIN G O R REPLACING TH E CO OLANT, A LWA YS USE H onda RECOMMENDED
G ENUIN E LON G-LIFE AN TI-FREEZE / COO LA NT TYPE 2. THIS COO LA NT IS PRE-MIX ED WITH
50% D ISTILLED WATER. IT DO ES N OT REQUIRE ANY AD DITION AL MIX ING.
NEV ER D ILU TE TH E CO OLANT, OR THE LIFE OF THE EN GINE MAY BE SERIOUSLY SH ORTENED .
C HE CK OR AD D TH E COO LA NT AT T HE R ES ER V E TAN K, NOT T HE R ADIA TO R.
FOR FURTH ER INFORMATION ON TH E COO LING SYSTEM, READ TH E OWNER’S MANUA L OR
CHECK WITH YOUR H onda D EA LER.
LORS DE L’APPOIN T OU DU REMPLACEMENT D U LIQUID E DE REFRO IDISSEMENT.
TOUJOURS UTILISER L’AN TIGEL /LIQU IDE DE REFROIDISSEMEN T TYPE 2 LON GUE DU REE
H onda D ’ORIG IN E RECO MMAND E CE LIQUID E DE REFRO IDISSEMENT EST MELANGE A U
PREALABLE AVEC 50 % D’EA U DISTILLEE. IL N’EX IGE AU CUN MELA NGE A DDITIONNEL.
NE JAMA IS DILUER LE LIQU ID E DE REFROIDISSEMEN T, LA D UREE DE V IE DU MOTEUR
P OUR RA IT EN ET RE A FFE CT EE . LE LIQUID E DE REFROIDISSEMEN T LON GUE DU REE INSTALLE A L’U SINE D OIT ETRE
RENLACE CO NFORMEMEN T AU CO DE SECOND AIRE 5 DE L’AID E-MEMOIRE D’ENTRETIEN
OU APRES 10 ANS, SELON LA PREMIERE EVENTU ALITE.PUIS TOUS LES 5 ANS.
CONTROLER LES NIVEA UX ET FAIRE L’APPOINT AU VASE D ’EXPANSION. JAMA IS AU RAD IA TEUR.
POUR TOUTE INFORMATION COMPLEMENTAIRE SUR LE CIRCUIT DE REFROID ISSEMENT, SE
REFERER AU MANU EL D’UTILISA TEUR OU PREND RE CONTA CT AVEC UN CONCESSIONNAIRE Honda.INFORMATION
RENSEIGNEMENTS VEHICLE EMISSION CONTROL INFORMATION
INFORMATIONS-DISPOSITIFS ANTI-POLLUTION
RRA-C02
U. S. EPA : T2B5 LDV OBD : CA OBD I I
OBD : CA OBD I I FUEL : GASOLINE
ARB : LEV I I LEV PC FUEL : GASOLINE
TWC, A/F SENSOR, HO2S, EGR, SFI
8HNXV02. 4FKC 8HNXR0106BBY 2. 0L
CONFORMS TO REGULATIONS :
2008MY
LOIS EPA : T2B5 LDV OBD : CA OBD I I
OBD : CA OBD I I CARBURANT : ESSENCE
ARB : LEV I I LEV PC CARBURANT : ESSENCE
TWC, A/F SENSOR, HO2S, EGR, SFI
8HNXV02. 4FKC 8HNXR0106BBY 2. 0L
CONFORME AUX NORMES : D’ ANNEE MODELE 2008
T HIS SPA RK IGNITI ON SY ST EM COMP LIES W ITH CA NADIAN ICE S-00 2.
CE SYSTEME D’ A LLUMAGE PAR ETINCELLE DE VEH ICULE EST CONFORME A LA NORME NMB-002 DU CANAD A.
HNX
902.0 V VA9
HNX
90106 RVEA
ab c d e
ab c d e
THIS VEHICLE CONFORMS TO U.S. EPA TIER 2 BIN 5
REGULATIONS APPLICABLE TO 2006 MODEL YEAR
NEW PASSENGER CARS AND CALIFORNIA
REGULATIONS APPLICABLE TO 2006 MODEL YEAR
NEW LEV II LEV PASSENGER CARS.
THIS VEHICLE CONFORMS TO U.S. EPA TIER 2 BIN 5
REGULATIONS APPLICABLE TO 2007 MODEL YEAR
NEW PASSENGER CARS AND CALIFORNIA
REGULATIONS APPLICABLE TO 2007 MODEL YEAR
NEW LEV II LEV PASSENGER CARS.
CONFORMS TO REGULATIONS: 2008 MY
CONFORMS TO REGULATIONS: 2009 MY 6: ’06
7: ’07
8: ’08
9: ’09
HNX: HONDA
V: LDV
FKC: ’06 model, ’08 model
HKC: ’07 model
VA9: ’09 model
6: ’06
7: ’07
8: ’08
9: ’09
HNX: HONDA
R: EVAP/ORVR
BBA: ’06 model
BBY: ’07 model, ’08 model
VEA: ’09 model
08/08/21 14:06:02 61SNR030_010_0009
ProCarManuals.com
DYNOMITE -2009-
Page 11 of 2893
ÃŽ
ÃŽ
ÃŽ
(#' )
¶
¶ ¶
¶
Emission Group Identification Test Group and Evaporative Family
K20Z3 engine Model:
Example:
’07 Model
’08 Model
’09 Model Test Group:
a. Model Year
b. Manufacturer Subcode c. Family Type
d. Displacement Group e. Sequence Characters
Evaporative Family:
a. Model Year
b. Manufacturer Subcode c. Family Type
d. Canister Working Capacity Group e. Sequence Characters
1-10 General Information
Under-hood Emission Control Label (cont’d)
EVAP CANISTER
PURGE VALVE TO EVAP
CANIST ER
PCV VALVE FRONT
SOUPAPE RGC AVANT VERS
RE SE RVOIR
EVAP
VALVE DE PURGE
DU RES ERVOIR EVAPVEHICLE EMISSION CONTROL INFORMATION
HONDA MOTOR CO. , LTD.
RRB-C103
2
6 5
THIS VEHICLE CO NFORMS TO U.S. EPA TIER 2 BIN 5
REG ULATI ONS APPLICABLE TO 2007 MODEL YEAR
N EW PASSEN GER CARS AND CALIFORNIA REGULATIONS APPL ICABLE
TO 2007 MODEL YEAR NEW LEVII LEV PASSENG ER CARS.
CE VEHICUL E EST CONF ORME AUX L OIS EPA TIER 2 DES ETATS-UNIS
APPLICABLES POUR LES VEHICULES DE BIN 5 POUR LES NOUVEAUX VEHICULES
VOITURES DE TOURISME D’ ANNEE MODELE 2007 ET AUX LOIS DE LA CALIFORNIE
APPLICABL ES POUR LES NOUVEAUX VEHICUL ES LEVII LEV VOITURES DE TOURISME
D ’ AN NEE MOD ELE 2 007 .THE FACTORY INSTALLED LONG-LIFE COOLANT MUS T BE REPLACED ACCORDING TO
MAINTENANCE MINDER SUB CODE 5, OR AT 1 0 YEARS WHICHEVER COMES FIEST.
THEREAF TER EVERY 5 YEARS.
WHEN ADDING OR REPLACING THE COOLANT, ALWAYS USE ACURA RECOMMENDED
GENUINE L ONG-LIFE ANTI-F REEZE / COOL ANT TYPE 2. THIS COOL ANT IS PRE-MIXED WITH
50% DISTILLED WATER. IT DOES NOT REQUIRE ANY ADDITIONAL MIXING.
NEVER DILUTE THE COOLANT, OR THE LIFE OF THE ENGINE MAY BE SERIOUSLY SHORTENED.
CHECK OR ADD THE COOL ANT AT THE RESERVE TANK, NOT THE RADIATOR.
FOR FURTHER INFORMATION ON THE COOLING SYSTEM, READ THE OWNER’S MANUAL OR
CH ECK W ITH YOU R AC URA DEA LER.
LORS DE L’APPOINT OU DU REMPLACEMENT DU LIQUIDE DE REFROIDISSEMENT.
TOUJOURS UTILISER L’ANTIGEL /LIQUIDE DE REFROIDISSEMENT TYPE 2 LONGUE DUREE
ACURA D’ORIGINE RECOMMANDE CE LIQUIDE DE REFROIDISSEMENT EST MELANGE AU
PREAL ABL E AVEC 5 0 % D’EAU DISTIL LEE. IL N’EXIGE AUCUN MEL ANGE ADDITIONNEL .
NE JAMAIS DILUER LE LIQUIDE DE REFROIDISSEMENT, LA DUREE DE VIE DU MOTEUR
POURRAIT EN ETRE AFFECTEE. LE LIQUIDE DE REFROIDISSEMENT LONGUE DUREE INSTALLE A L’USINE DOIT ETRE
RENLACE CONFORMEMENT AU CODE SECONDAIRE 5 DE L’AIDE-MEMOIRE D’ENTRETIEN
OU APRES 10 ANS, S EL ON L A PREMIERE EVENTUALITE.PUIS TOUS LES 5 ANS.
CONTROLER LES NIVEAUX ET FAIRE L’APPOINT AU VASE D’EXPANSION. JAMAIS AU RADIATEUR.
PO UR TOUTE INF ORMATI ON CO MPLEMEN TAI RE SU R L E CI RCU IT DE REFRO IDI SSEMEN T, SE
REFERER AU MANUEL D’UTILISATEUR OU PRENDRE CONTACT AVEC UN CONCESSIONNAIRE ACURA.
INFORMATIONS-DISPOSITIFS ANTI-POLLUTION
TWC, A/F SE NSOR, HO2S, SF I 7HNXV02. 4HKC
7HNXR0106BBY
OBD II CERTIFIED 2.0L
7HNXV02. 4HKC
7HNXR0106BBY
ACCREDITATION OBD II 2.0L
TWC , A/F SENSOR, HO2 S, S F I
THIS SPA RK IG NITION SYSTEM
CO MPL IES WITH CA NA DIA N ICES-0 0 2.CE SYSTE ME D’A LLUMAGE PAR
ETI NCE LLE DE VEHI CULE EST CONFORM E
ALANORMENMB-002 DUCANADA.
VALVE LASH
(COLD) NO O TH ER A D J USTME NTS NEED ED . IN
EX
: 0 .2 3 0.0 2 mm
: 0 .2 7 0.0 2 mm
JEU DES SOU PA PES
(M OTE UR FRO ID ) AUCU N AUTRE REGLACE NECESSAIRE. ADM
ECH
: 0 .23 0 .0 2 m m
: 0.2 7 0 .0 2 m m NORMESSURLESEMISSIONS D’ECHAPPEMENT
: LEVI I, LEV (ACCREDITATIO N ET EN SERVICE)
: TI ER 2 BIN 5 (ACCREDITATION E T E N SERVI CE )
EPA ARBEX HA UST EMISS IONS S TA NDA RD S
: LEVII, LEV (C ERTIFIC ATION AND IN-USE)
: TIER 2 BIN 5 (CER TIFICA TION AND IN- USE)
EP A
ARB
INFORMATION
RENSEIGNEMENTS
108
’07 Model
’08-09 Models
THE FACTORY INSTALLED LONG-LIFE COOLANT MUST BE REPLACED ACCORDING TO
MAINTENANCE MINDER SUB CODE 5, OR AT 10 YEARS W HICHEVER COM ES FIEST.
THEREAFTER EVE RY 5 YEARS.
WHEN ADDING OR REPLACING THE COOLANT, ALWAYS USE ACURA RECOMMENDED
GEN UIN E LONG -LIFE A NTI-FREEZE / CO OLA NT TYPE 2. TH IS COO LAN T IS PRE-MIXED WITH
50% DISTILLED WATER. IT DOES NOT REQUIRE ANY ADDITIONAL MIXING.
NEVER D ILUTE TH E COO LA NT, OR THE LIFE O F TH E EN GINE MAY BE SERIOU SLY SH ORTEN ED .
CHECK OR ADD THE COOLANT AT THE RESERVE TANK, NOT THE RADIATOR.
FOR FURTH ER INFORMA TION ON TH E COOLING SYSTEM, READ THE OWN ER’S MAN UA L OR
CHECK WITH YOUR A CURA DEA LER.
LORS DE L’APPOINT OU DU REMPLACEMENT DU LIQUIDE DE REFROIDISSEMENT.
TOUJO URS UTILISER L’AN TIGEL /LIQUID E D E REFROID ISSEMENT TYPE 2 LON GUE D UREE
ACURA D’ORIGINE RECOMMANDE CE LIQUIDE DE REFROIDISSEMENT EST MELANGE AU
PREA LABLE AV EC 50 % D ’EA U D ISTILLEE. IL N’EX IGE AU CUN MELA NGE A DD ITION NEL.
NE JA MA IS D ILU ER LE LIQUID E D E REFROIDISSEMENT, LA D UREE D E VIE DU MOTEU R
POURRAIT EN ETRE AFFECTEE.
LE LIQUIDE D E REFROIDISSEMENT LON GUE D UREE INSTA LLE A L’U SINE D OIT ETRE
RENLACE CONFORMEMENT AU CODE SECONDAIRE 5 DE L’AIDE-MEMOIRE D’ENTRETIEN
OU APRES 10 ANS, SELON LA PREMIERE EVENTUALITE.PUIS TOUS LES 5 ANS.
C ON TR OLER LES N IVEAU X ET FAIR E L’A PPOIN T AU VA SE D’EXPANS IO N. JAMAIS A U R ADIATEUR .
PO UR TOUTE INFO RMATION CO MPLEMENTA IRE SUR LE CIRCUIT D E REFROID ISSEMENT, SE
REFERER AU MA NUEL D ’UTILISATEUR OU PRENDRE CON TA CT AV EC UN CONCESSIONN AIRE A CURA .INFORMATION
RENSEIGNEMENTS VEHICLE EMISSION CONTROL INFORMATION
INFORMATIONS-DISPOSITIFS ANTI-POLLUTION
HONDA MOTOR CO. , LTD.RRB-C11108
U. S. EPA : T2B5 LDV OBD : CA OBD I I
OBD : CA OBD I I FUEL : GASOLINE
ARB : LEV I I LEV PC FUEL : GASOLINE
TW C, A/F SENSOR, HO2S, SFI
8HNXV02. 4FKC 8HNXR0106BBY 2. 0L
CONFORMS TO REGULATIONS : 2008MY
LOIS EPA : T2B5 LDV OBD : CA OBD I I
OBD : CA OBD I I CARBURANT : ESSENCE
ARB : LEV I I LEV PC CARBURANT : ESSENCE
TW C, A/F SENSOR, HO2S, SFI
8HNXV02. 4FKC 8HNXR0106BBY 2. 0L
CONFORME AUX NORMES : D’ ANNEE MODELE 2008
THIS S PAR K IGNI TION S YS TEM COM PLIE S W ITH CA NADIAN ICES -00 2.
CE SY STEME D’ A LLUMAGE PAR ETINCELLE DE VEHIC ULE EST C ONFORME A LA NORME NMB-002 DU C ANADA .
HNX
902.0 V VA9
HNX
90106 RVEA
ab c d e
ab c d e
THIS VEHICLE CONFORMS TO U.S. EPA TIER 2 BIN 5
REGULATIONS APPLICABLE TO 2007 MODEL YEAR
NEW PASSENGER CARS AND CALIFORNIA
REGULATIONS APPLICABLE TO 2007 MODEL YEAR
NEW LEV II LEV PASSENGER CARS.
CONFORMS TO REGULATIONS: 2008 MY
CONFORMS TO REGULATIONS: 2009 MY 7: ’07
8: ’08
9: ’09
HNX: HONDA
V: LDV
HKC: ’07 model
FKC: ’08 model
VA9: ’09 model
7: ’07
8: ’08
9: ’09
HNX: HONDA
R: EVAP/ORVR
BBY: ’07 model, ’08 model
VEA: ’09 model
08/08/21 14:06:04 61SNR030_010_0010
ProCarManuals.com
DYNOMITE -2009-
Page 105 of 2893
5-6Engine Assembly
Engine Removal (cont’d)
C
B
D
A B
C
A
D
D A
B
C
27. Drain the engine oil (see page 8-10).
28. Drain the transmission fluid: Manual transmission (see step 3 on page 13-5)
Automatic transmission (see step 3 on page14-232)
29. Disconnect the air fuel ratio (A/F) sensor connector (A).
30. Remove the grommet (B), then disconnect the secondary heated oxygen sensor (secondary
HO2S) connector (C).
31. Remove the three way catalytic converter (TWC) (D).
32. A/T model: Remove the shift cable. Do not bend the cables excessively (see step 39 on page 14-239).
33. Separate the stabilizer links (see page 18-25).
34. Separate the knuckles from the lower arms (see step 6 on page 18-21).
35. Remove the driveshafts (see page 16-4). Coat all precision-finished surfaces with new engine oil. Tie
plastic bags over the driveshaft ends. 36. Remove the steering gearbox bracket (A).
37. Remove the steering gearbox mounting bolt (B),
the stiffener mounting bolt (C), and the stiffener (D).
38. Remove the steering gearbox mounting bolt (A), the stiffener mounting bolt (B), and the stiffener (C).
39. Remove the harness clamp (D) from the subframe.
08/08/21 14:20:24 61SNR030_050_0006
ProCarManuals.com
DYNOMITE -2009-
Page 119 of 2893
ÃŽ
5-20Engine Assembly
Engine Installation (cont’d)
D
A
B
10x1.25mm
59 N·m
(6.0 kgf·m, 43 lbf·ft)
C
10x1.25mm
54 N·m
(5.5 kgf·m, 40 lbf·ft)
A
B
C
10x1.25mm
59 N·m
(6.0 kgf·m, 43 lbf·ft)
D
10x1.25mm
54 N·m
(5.5 kgf·m, 40 lbf·ft)
10x1.25mm
38 N·m
(3.9 kgf·m, 28 lbf·ft)
E
F
A
D
B
B
C
10x1.25mm
33 N·m (3.4 kgf·m, 25 lbf·ft)
8x1.25mm
22 N·m (2.2 kgf·m, 16 lbf·ft)
29. Install the stiffener (A), then tighten the steering gearbox mounting bolt (B) and the stiffener
mounting bolt (C).
30. Install the harness clamp (D) to the subframe.
31. Install the steering gearbox bracket (A).
32. Install the stiffener (B), then tighten the steering gearbox mounting bolt (C) and the stiffener
mounting bolt (D).
33. A/T model: Install the shift cable (see step 19 on page 14-245).
34. Install a new set ring on the end of each driveshaft, then install the driveshafts (see page 16-20). Make
sure each ring ‘‘clicks’’ into place in the differential
and the intermediate shaft. 35. Connect the lower arms to the knuckles (see step 9
on page 18-16).
36. Connect the stab ilizer links (see page 18-25).
37. Install the three way catalytic converter (TWC) (A). Use the new gaskets (B) and the new self-locking
nuts (C).
38. Connect the air fuel ratio (A/F) sensor connector (D).
39. Connect the secondary heated oxygen sensor (secondary HO2S) connector (E), then install the
grommet (F).
40. Install the splash shield.
Replace.
Replace.
Replace.
08/08/21 14:20:34 61SNR030_050_0020
ProCarManuals.com
DYNOMITE -2009-
Page 338 of 2893
(#' )
Electronic Control Systems
Self-diagnosisOne Drive Cycle Detection Method
Two Drive Cycle Detection Method
Fail-safe Function
MIL Bulb Check and Readiness Code Condition
Self Shut Down (SSD) Mode
11-15
System Description
The functions of the fuel and emission control systems are managed by the engine control module (ECM) on vehicles
with manual transmissions or the powertrain control module (PCM) on vehicles with automatic transmissions.
The ECM/PCM detects a failure of a signal from a sensor or another control unit and stores a Temporary DTC or a DTC.
Depending on the failure, a DTC is stored in either the first or the second drive cycle (K20Z3 engine: DTC P0457, turns
on the malfunction indicator lamp (MIL) during the third drive cycle). When a DTC is stored, the ECM/PCM turns on the
malfunction indicator lamp (MIL) by a signal sent to the gauge via F-CAN. When an abnormality occurs in the signal from a sensor or from another control unit, the ECM/PCM stores a DTC
and turns on the MIL immediately.
When an abnormality occurs in the signal from a sensor or from another control unit in the first drive cycle, the
ECM/PCM stores a Temporary DTC. If the failure continues in the second drive cycle, the ECM/PCM stores a DTC and
turns on the MIL.
When an abnormality occurs in the signal from a sensor or another control unit, the ECM/PCM ignores the signal and
substitutes a pre-programmed value that allows the engine to continue running. This causes a DTC to be stored and
the MIL to come on.
When the ignition switch is turned to ON (II), the ECM/PCM turns on the MIL via the F-CAN circuit for about 15 to
20 seconds to check the bulb condition. If any readiness codes are not set to complete, the MIL flashes five times. If all
readiness codes are set to complete, the MIL goes off.
After the ignition switch is turned to LOCK (0), the ECM/PCM stays on (about 30 minutes). If the ECM/PCM connector is
disconnected during this time, the ECM/PCM may be damaged. To cancel this mode, disconnect the negative cable
from the battery or jump the SCS line with the HDS after the ignition switch is turned to LOCK (0).
(cont’d)
08/08/21 14:12:37 61SNR030_110_0015
ProCarManuals.com
DYNOMITE -2009-
Page 351 of 2893
Î Ú
ECM/PCM Inputs and Outputs at Connector B ( ) (44P)
Terminal
numberWire color Terminal name DescriptionSignal
11-28Fuel and Emissions Systems
System Description (cont’d)
NOTE: Standard battery voltage is about 12 V.
1BLK/RED
(BLK) PG2 (POWER GROUND) Ground circuit for ECM/
PCMLess than 1.0 V at all times
2 BLU/RED EGR (EXHAUST GAS RECIRCULATION (EGR)
VALVE) Drives EGR valve With EGR operating: duty controlled
With EGR not operating: about 0 V
3 YEL/BLU PCS (EVAPORATIVE EMISSION (EVAP)
CANISTER PURGE VALVE) Drives EVAP canister purge
valve
With engine running, engine coolant below 60 °C
(140 °F): battery voltage
With engine running, engine coolant above 60 °C
(140 °F): duty controlled
4 BLK/WHT SO2SHTC (SECONDARY HEATED OXYGEN SENSOR
(SECONDARY HO2S)
HEATER (SENSOR 2)) Drives secondary HO2S
heater (sensor 2)
With ignition switch ON (II): battery voltage
With warmed up engine running: duty controlled
7 YEL/RED OPSW (OIL PRESSURE SWITCH) Detects engine oil pressure
signalWith ignition switch OFF: about 0 V
With engine running: battery voltage
8 BLU/RED OP2SW (2ND CLUTCH TRANSMISSION FLUID
PRESSURE SWITCH) Detects 2nd clutch
transmission fluid pressure
switch inputWith ignition switch ON (II):
Without 2nd clutch pressure: about 5.0 V
With 2nd clutch pressure: about 0 V
9 BLU/WHT OP3SW (3RD CLUTCH TRANSMISSION FLUID
PRESSURE SWITCH) Detects 3rd clutch
transmission fluid pressure
switch inputWith ignition switch ON (II):
Without 3rd clutch pressure: about 5.0 V
With 3rd clutch pressure: about 0 V
10 BLU/BLK SHA (SHIFT SOLENOID VALVE A) Drives shift solenoid
valve AWith engine running in R, D, and S (in 1st, 4th, or
5th gears): battery voltage
With engine running in P, N, D, and S (in 2nd and
3rd gears): about 0 V
11 GRN/WHT SHB (SHIFT SOLENOID VALVE B) Drives shift solenoid
valve BWith engine running in P, R, N, D, and S (in 1st and
2nd gears): battery voltage
With engine running in D and S (in 3rd, 4th, 5th
gears): about 0 V
12 RED/BLK ATPN (TRANSMISSION RANGE SWITCH N) Detects transmission range
switch N position signal
inputIn N: about 0 V
In any position other than N: about 5.0 V
13 BLU/BLK ATPP (TRANSMISSION RANGE SWITCH P) Detects transmission range
switch P position signal
inputIn P: about 0 V
In any position other than P: about 5.0 V
14 WHT ATPR (TRANSMISSION RANGE SWITCH R) Detects transmission range
switch R position signal
inputIn R: about 0 V
In any position other than R: about 5.0 V
15 RED ATPS (TRANSMISSION RANGE SWITCH S) Detects transmission range
switch S position signal
inputIn S: about 0 V
In any position other than S: battery voltage
1: A/T
4: K20Z2 engine
5: ’07-09 models
5
4
1
1
1
1
1
1
1
1
Terminal side of female terminals
08/08/21 14:12:43 61SNR030_110_0028
ProCarManuals.com
DYNOMITE -2009-
Page 375 of 2893
ÃŽ
´
µ´
µ
ECM/PCM Circuit Diagram (K20Z2 engine) (cont’d)
11-52 Fuel and Emissions Systems
System Description (cont’d)
A/F SENSOR
(SENSOR 1)
2
RED
C29
AFS RED
C30
AFS RED/YEL
C9
AFSHTC 1
RED/BLU
3
BLU
4
Q
10
C101
SECONDARY
HO2S
(SENSOR 2)
3
4
C27
SHO2S
B4
SO2SHTC H
P
I
OIL PRESSURE
SWITCH
B7
OPSW
YEL/RED
A25 1
3
BRN
VCC4
A17 1
YEL
APSA
A35 2
BLU
SG4
A24 6
GRY
VCC5
A18 4
PUR
APSB
A34 5
LT BLU
SG5 9
5 THROTTLE
ACTUATOR
1 6
WHT/RED 2
13
4
6
5
BLU
RED/BLK RED/BLK
GRN RED/BLU
BLU/RED GRN/YEL
C4
ETCSM
C3
ETCSM C39
SG3 C21
TPSB
C12
VCC3
C20
TPSA
GRN BLU
GRNPUR
R
WHT/GRN
3 (2) *81 (5) *8
2 (6) *8 BLK
YEL
C209
AB
1 2
THROTTLE BODY
APP SENSOR A/B
BLK/WHT
WHT
PNK TP SENSOR
AB
BRN
PNK WHT
BLU/RED
GRN/YEL
14
15
19
23
18
*8: ’09 model
08/08/21 14:13:49 61SNR030_110_0052
ProCarManuals.com
DYNOMITE -2009-
Page 386 of 2893
ÃŽ
´
µ´
µ
11-63
A/F SENSOR
(SENSOR 1)
2
RED
C29
AFS RED
C30
AFS RED/YEL
C9
AFSHTC 1
RED/BLU
3
BLU
4
L
10
SECONDARY
HO2S
(SENSOR 2)
2
1
3
4
C27
SHO2S
B4
SO2SHTC E
K
F
OIL PRESSURE
SWITCH
B7
OPSW
YEL/RED
A25 1
3
BRN
VCC4
A17 1
YEL
APSA
A35 2
BLU
SG4
A24 6
GRY
VCC5
A18 4
PUR
APSB
A34 5
LT BLU
SG5 9
5
APP SENSOR A/BTHROTTLE
ACTUATOR
23
18
BLK/WHT WHT/RED 2
13
4
6
5
BLU
RED/BLK RED/BLK
GRN RED/BLU
BLU/RED
GRN/YEL
C4
ETCSM
C3
ETCSM C39
SG3 C21
TPSB
C12
VCC3
C20
TPSA
GRN BLU
GRN
PUR
M
WHT/GRN
1(5)*8BLK
YEL
C101
C209
AB
A
B
TP SENSOR
C101 THROTTLE BODY
WHT
PNK
BLU/RED
GRN/YEL
14
15
19
1
6 3 (2) *8
2 (6) *8BRN
PNK WHT
*8: ’09 model
(cont’d)
08/08/21 14:15:28 61SNR030_110_0063
ProCarManuals.com
DYNOMITE -2009-
Page 427 of 2893
(#'
)
µ
µ µ
µ µ
µ
µ
µ
YES
NO
YES
NO
YES
NO
YES
NO
DTC P0137:
11-10411-104PGM-FI System
DTC Troubleshooting (cont’d)
31. Reconnect all connectors.
32. Update the ECM/PCM if it does not have the latest
software (see page 11-227), or substitute a known-
good ECM/PCM (see page 11-7).
33. Start the engine, and let it idle.
34. Check for Temporary DTCs or DTCs with the HDS.
Check for poor connections or loose
terminals at the A/F sensor (Sensor 1), the PGM-FI
subrelay, and the ECM/PCM. If the ECM/PCM was
updated, substitute a known-good ECM/PCM
(see page 11-7), then go to step 33. If the ECM/PCM
was substituted, go to step 1.
Go to step 35.
35. Monitor the OBD STATUS for DTC P0135 in the DTCs MENU with the HDS.
If the ECM/PCM was updated,
troubleshooting is complete. If the ECM/PCM was
substituted, replace the original ECM/PCM
(see page 11-228). If any other Temporary DTCs or
DTCs were indicated in step 34, go to the indicated
DTC’s troubleshooting.
If the screen indicates FAILED, check for poor
connections or loose terminals at the A/F sensor
(Sensor 1), the PGM-FI subrelay, and the ECM/PCM.
If the ECM/PCM was updated, substitute a known-
good ECM/PCM (see page 11-7), then go to step 33.
If the ECM/PCM was substituted, go to step 1. If the
screen indicates NOT COMPLETED, keep idling
until a result comes on. NOTE:
Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).
Information marked with an asterisk( ) applies to ’07-09 models.
1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Start the engine. Hold the engine speed at 3,000 rpm (A/T in P or N, M/T in neutral) until the
radiator fan comes on, then let it idle.
4. Check the HO2S S2 in the DATA LIST with the HDS.
Go to step 5.
Intermittent failure, the system is OK at this
time. Check for poor connections or loose terminals
at the secondary HO2S (Sensor 2) and the ECM/
PCM.
5. Turn the ignition switch to LOCK (0).
6. Remove the center console (see page 20-92).
7. Disconnect the secondary HO2S (Sensor 2) 4P connector.
8. Turn the ignition switch to ON (II).
9. Check the HO2S S2 in the DATA LIST with the HDS.
Go to step 10.
Go to step 14.
10. Turn the ignition switch to LOCK (0).
11. Jump the SCS line with the HDS.
12. Disconnect ECM/PCM connector C (44P).Secondary HO2S (Sensor 2)
Circuit Low Voltage
Is DT C P0135 ind icated ?
Does t he scr een i nd i cat e PASSE D? Does t he v ol t age st ay at 0.29 ( 0.05 ) V or l ess?
Does t he v ol t age st ay at 0.29 ( 0.05 ) V or l ess?
08/08/21 14:17:21 61SNR030_110_0104
ProCarManuals.com
DYNOMITE -2009-
Page 455 of 2893
(#'
)
µ
µ
µ
µ µ
µ
µ
µ
DTC P0365:
YES
NO
YES
NO YES
NO
YES
NO
11-132PGM-FI System
DTC Troubleshooting (cont’d)
CMP SENSOR B 3P CONNECTOR
IGP (YEL/BLK) CMPB (GRN)
CMP SENSOR B 3P CONNECTOR
IGP
(YEL/BLK)
LG
(BRN/YEL)
CMP SENSOR B 3P CONNECTOR
CMP Sensor B No Signal
NOTE: Before you troubleshoot, record all freeze data
and any on-board snapshot, and review the general
troubleshooting information (see page 11-3).
1. Turn the ignition switch to ON (II).
2. Clear the DTC with the HDS.
3. Start the engine.
4. Check for Temporary DTCs or DTCs with the HDS.
Go to step 5.
Intermittent failure, the system is OK at this
time. Check for poor connections or loose terminals
at CMP sensor B and the ECM/PCM.
5. Turn the ignition switch to LOCK (0).
6. Disconnect the CMP sensor B 3P connector.
7. Turn the ignition switch to ON (II).
8. Measure the voltage between CMP sensor B 3P connector terminal No. 3 and body ground.
Go to step 9.
Repair open in the wire between CMP sensor
BandPGM-FImainrelay1,thengotostep18. 9. Measure the voltage between CMP sensor B 3P
connector terminal No. 1 and body ground.
Go to step 10.
Go to step 11.
10. Measure the voltage between CMP sensor 3P connector terminals No. 2 and No. 3.
Go to step 16.
Repair open in the wire between CMP sensor
B and G101; A/T model (see page 22-16), M/T
model (see page 22-18), then go to step 18.
Wire side of female terminals Wire side of female terminals
Wire side of female terminals
I s DT C P0365 i nd i cat ed ?
Is there battery voltage? Is t her e about 5 V ?
Is there battery voltage?
08/08/21 14:18:55 61SNR030_110_0132
ProCarManuals.com
DYNOMITE -2009-
