Acura ILX 2013 Navigation Manual

120
XX
Changing Your Destination
XEntering a New Destination
Navigation
3.Rotate i to select an option.
Press u.X
The route is automatically
recalculated and displayed on
the map screen.
The following options are available:
•New Dest.: Sets the location as your new destination.
•Waypoint: Sets the location as a new waypoint.

121Navigation
Resuming Your TripStop your vehicle en route (e.g., to rest, stop for gas, etc.), and then continue on
your route.
If you did not complete your route, the Continue Trip screen is displayed when you
restart your vehicle.
Rotate i to select OK. Press u.
XYou can continue on the same
route.
•Route Pref.: Changes the route preferences (calculating method).
2Changing the Route Preference
P. 88
•View Routes: Displays three different routes.
2Viewing the Routes
P. 88
•DESTINATION MAP: Move r to select DESTINATION MAP to display a map of
the destination.
2Calculating the Route on the Destination Map
P. 89
1Resuming Your Trip
The Continue Trip screen has the same options
as when you calculate a route.
2Calculating the Route P. 87
To cancel your destination, press the CANCEL
button.
Add to Address Book
You can add the destination address to the
address book.
2Adding an Address Book Entry P. 37
Add to Dest. List
You can add the address to the Destination List.
2Editing the Destination List P. 116
Call
You can place a phone call to the destination
phone number.
2Bluetooth® HandsFreeLink® P. 162

122

123
Audio
This section describes how to operate the audio system. You can play
music from a wide array of media sources, and control the audio system
using the audio buttons, the Interface Dial, or voice control.
Audio System.................................................. 124
About Your Audio System .............................. 124
Auxiliary Input Jack ........................................ 124
Audio System Theft Protection ....................... 125
Playing FM/AM Radio..................................... 126
Selecting FM/AM Mode.................................. 126
Audio Screen Control ..................................... 126
Audio Menu .................................................. 127
Radio Data System (RDS) ................................ 128
Playing XM® Radio......................................... 130
Selecting XM Mode........................................ 130
Audio Screen Control ..................................... 130
Audio Menu .................................................. 131
XM® Radio Service ........................................ 132
Playing a Disc................................................... 133
Selecting Disc Mode ....................................... 133
Audio Screen Control ..................................... 133
Audio Menu .................................................. 134Playing MP3/WMA/AAC Discs ........................ 135
Recommended Discs ...................................... 136
Playing Hard Disc Drive (HDD) Audio............ 137
Selecting HDD Mode ...................................... 137
Audio Screen Control ..................................... 138
Audio Menu ................................................... 138
Recording a Music CD to HDD........................ 140
Searching for Music........................................ 142
Editing a Playlist or Album .............................. 143
Editing Track Information ............................... 144
Displaying Music Information ......................... 145
Updating Gracenote® Album Info .................. 146
Playing an iPod®............................................. 147
Selecting iPod® Mode .................................... 148
Audio Screen Control ..................................... 148
Audio Menu ................................................... 149
Searching for Music........................................ 150Searching for Music Using Song By Voice™
(SBV)............................................................... 151
Playing a USB Flash Drive............................... 152
Selecting USB Mode....................................... 153
Audio Screen Control..................................... 153
Audio Menu .................................................. 154
Playing Tracks in Folders................................. 155
Playing Bluetooth® Audio............................. 156
Selecting Bluetooth® Audio Mode ................ 156
Switching to HFL Mode .................................. 157
Audio Screen Control..................................... 157
Adjusting the Sound....................................... 158
Audio Remote Controls.................................. 159
Steering Wheel Controls ................................ 159

124Audio
Audio SystemAbout Your Audio SystemThe audio system features FM/AM radio and XM® Radio. It can also play audio discs,
WMA/MP3/AAC tracks, iPod®, USB flash drives, and Bluetooth® devices.
The audio system is operable from the buttons and switches on the panel, or the
remote controls on the steering wheel.2Audio Remote Controls
P. 159
2Audio System
P. 6
Auxiliary Input JackUse the jack in the center console compartment to connect standard audio devices.
1.Open the AUX cover.
2.Connect a standard audio device to
the input jack using a 3.5 mm
stereo miniplug.
X
The audio system automatically
switches to the AUX mode.
1About Your Audio System
You can operate the audio system by voice
commands.
2Audio Commands P. 221
In some cases, the name of the artist, album, or
track may not appear correctly.
State or local laws may prohibit the operation of
handheld electronic devices while operating a
vehicle.
XM® Radio is available on a subscription basis
only.
2XM® Radio Service P. 132
XM® Radio is available in the United States and
Canada, except Hawaii, Alaska, Puerto Rico, and
Mexico.
XM is a registered trademark of Sirius XM®
Radio, Inc.
Video CDs, DVD-Videos, and 8-cm mini discs are
not supported.
iPod® is a registered trademark owned by Apple
Inc.
Remote ControliPod
USB Flash
Drive
1Auxiliary Input Jack
To switch the mode, press any of the other audio
mode buttons. You can return to the AUX mode
by pressing the HDD/AUX button.
You cannot use the auxiliary input jack if you
replace the audio system.

125
XX
Audio System
XAudio System Theft Protection
Audio
Audio System Theft ProtectionThe system is disabled when it is disconnected from the power source, such as when
the battery is disconnected or goes dead.
■Reactivating the System
1.Set the power mode to ON, and turn on the system.X
If you set the power mode to ACCESSORY, you will be requested to enter the
security code. See step 3.
2.Press and hold the VOL 9 (Volume/Power) button again for more than two
seconds.
X
The system is reactivated when the system’s control unit recognizes that the
system is in your vehicle.
X
If the control unit fails to recognize, “ENTER CODE” appears on the navigation
screen.
3.Enter the security code.
X
If you do not enter the code correctly after 10 tries, leave the system for one
hour before trying again, or visit a dealer to have the system reset.
1Audio System Theft Protection
Find the audio system’s security code and serial
number label in your Owner’s Manual kit.
Do not store the label in your vehicle. If you lose
the label, you must first retrieve the serial
number, and then obtain the code from a dealer.

126Audio
Playing FM/AM RadioSelecting FM/AM Mode1.Press the FM/AM button.X
Press the FM/AM button again, if necessary, to select the frequency band (AM,
FM1, FM2).
2.Select a station using the Preset buttons and the bars (SKIP, TUNE, SCAN/A.SEL).
X
On the FM bands, you can also use the CATEGORY bar and TITLE button to
select a station provided by the Radio Data System (RDS).
X
The band and frequency are displayed on the display.
Audio Screen ControlHAUDIO button (in FM/AM mode)
Control the audio system through the navigation screen.
1.Move e to select a frequency band
(AM, FM1, or FM2).
2.Rotate i to select a preset
station. Press u.
X
Press and hold u until a beep
sounds to store the current
station in a preset button.
X
Move r to select AUDIO
MENU. 2Audio Menu
P. 127
1Playing FM/AM Radio
d “Display audio screen”
You can control the radio using voice
commands.
2Radio Commands P. 221
A visual guide helps you operate the audio
system.
2System Controls P. 4
2Basic Operation P. 6
The ST indicator comes on the display for stereo
FM broadcasts. Stereo reproduction in AM is not
available.
The radio can receive the complete AM and FM
bands:
AM band: 530 to 1710 kHz
FM band: 87.7 to 107.9 MHz
You can store six AM stations and 12 FM stations
in the preset buttons. FM1 and FM2 let you store
six stations each.
Stereo indicatorFrequency band
Preset stations

127
XX
Playing FM/AM Radio
XAudio Menu
Audio
Audio MenuHAUDIO button (in FM/AM mode)
X AUDIO MENU
Rotate i to select an item. Press u.
The following items are available:
•Sound Setup: Displays the sound preferences screen.
2Adjusting the Sound
P. 158
•Read Radio Text: Displays the text information broadcast by the current RDS
station.
2Radio Text Display
P. 129
•RDS Search: Searches for programmes by RDS category.
2Searching for Programmes by RDS Category
P. 128
•Scan: Scans for stations with a strong signal in the current band and plays a 10-
second sample. Select Scan again to stop scanning and play the current selection.
•A.Sel (Auto Select): When set to ON, scans and automatically stores up to six
AM stations and 12 FM stations with a strong signal in the preset buttons.
•Tune: Tunes the radio to the frequency you select. Rotate i to select a
frequency.
1Audio Menu
The A.SEL indicator comes on the display when
A.Sel is ON. If you do not like the stations Auto
Select has stored, you can change the
frequencies stored in the preset buttons
manually. Set A.Sel to OFF to restore the
previous preset button settings.

128
XX
Playing FM/AM Radio
XRadio Data System (RDS)
Audio
Radio Data System (RDS)Provides text data information related to your selected RDS capable FM station.
Press the TITLE button to turn RDS information on or off. When set to ON, the name
of the FM station is displayed on the display. When set to OFF, the frequency of the
station is displayed.
HAUDIO button (in FM/AM mode)
X AUDIO MENU
X RDS Search
Search for FM stations with a strong signal that are broadcast the selected RDS
category information.
1.Move w or y to select a search
method (Seek up, Seek down,
Scan).
2.Rotate i to select a category.
Press u.
X
Scanning for stations in that
category begins. When an RDS
station is found, it begins to
play.
X
If there are no RDS-capable
stations in the area, “NOTHING”
briefly appears on the display.
■RDS Info Display■Searching for Programmes by RDS Category

129
XX
Playing FM/AM Radio
XRadio Data System (RDS)
Audio
HAUDIO button (in FM/AM mode)
X AUDIO MENU
X Read Radio Text
Display the radio text information of the selected RDS station.
■Radio Text Display
1Radio Text Display
The RDS indicator comes on the display when the
selected RDS station is broadcasting text data.
