Acura ILX 2013 Navigation Manual

20System Setup
Start-upThe navigation system starts automatically when you set the power mode to
ACCESSORY or ON. At start-up, the following Confirmation screen is displayed.
1.Move y to select CHANGE
LANGUAGE.
X
If you do not need to change
the system language, proceed to
step 3.
2.Rotate i to change the system
language. Press u.
3.Press u to select OK.
X
Your current position is
displayed on the map screen.
X
If you have set any calendar
event reminders, they are
displayed. Proceed to step 4.
1Start-up
If the navigation system loses power at any time,
you may need to press and hold the VOL 9
(Volume/Power) button for more than two
seconds, or you may be prompted for the five-
digit security code.
2System Initialisation P. 206
You can change the system language at any
time.
2Language P. 31
“OK” on the Confirmation screen cannot be
selected by using a voice command. If you do not
press u within 30 seconds, the screen goes
blank (or displays your wallpaper screen and you
cannot use voice commands). Press any
navigation or voice control button to continue.
2Wallpapers Setting P. 32

21
XX
Start-up
X
System Setup
4.Rotate i to select an option.
Press u.X
Your current position is
displayed on the map screen.
The following options are available:
•Remind Later: Displays the reminder again next time you start the vehicle.
•OK: Turns the reminder off.
Certain manual functions are disabled
or inoperable while the vehicle is in
motion. You cannot select a grayed-
out option until the vehicle is stopped.
Voice commands are still operable
while the vehicle is in motion.
1Start-up
You can set a calendar event reminder.
2Calendar P. 184
Remind Later
You can skip the reminder by pressing the
CANCEL button.
■Limitations for Manual Operation
Disabled option

22System Setup
Voice Control SystemYour vehicle has a voice control system that allows hands-free operation of most of
the navigation system functions. You can also control the audio and climate control
system, and make and receive phone calls using Bluetooth® HandsFreeLink®.
The voice control system uses the d (Talk) and K (Back) buttons on the steering
wheel and a microphone near the map lights on the ceiling.
A “Voice Info” feature provides a tutorial that explains how to use the voice control
system. 2Voice Help
P. 5
Command InputIf the system does not understand a command or you wait too long to give a
command, the system asks you to repeat the command.
When you give a command, the system generally either repeats the command as a
confirmation or asks you for further information. If you do not wish to hear this
feedback, you can turn it off. However, listening to the feedback will help familiarise
you with the way the system expects commands to be phrased. 2Basic Settings
P. 26
If the system cannot perform a command or the command is not appropriate for the
screen you are on, the system beeps.
On character input screens, a list of possible characters is displayed if the system
does not recognize your command.
You can find out which voice commands are available for a particular screen using
the d Help command. The system will display and read the list of available
commands to you.
1d (Talk) Button
When you press the d (Talk) button, a helpful
prompt asks what you would like to do. Press
and release the d (Talk) button again to bypass
this prompt and give a command.1Command Input
The audio system is muted while using the voice
control system.

23
XX
Voice Control System
XVoice Recognition
System Setup
Voice RecognitionTo achieve optimum voice recognition when using either the navigation voice
control system or Bluetooth® HandsFreeLink®:
•Make sure the correct screen is displayed for the voice command that you are
using. 2Voice Commands
P. 218
•Close the windows and moonroof.
•Adjust the dashboard and side vents so air does not blow onto the microphone on
the ceiling.
•Speak clearly in a clear, natural speaking voice without pausing between words.
•Reduce any background noise if possible. The system may misinterpret your
command if more than one person is speaking at the same time.
•Refer to the Voice Info tutorial.
2Voice Help
P. 5
1Voice Recognition
The voice control system can only be used from
the driver’s seat because the microphone unit
removes noises from the front passenger’s side.

24System Setup
Interface SettingsDisplay and Volume SettingsHINFO button
X Set up
Use the Main Setup screen to adjust the display and volume.
1.Rotate i to select an item. Press
u.
2.Rotate i to make the
adjustment. Press u.
The following items are available:
•Brightness: Adjusts the screen’s brightness.
•Contrast: Adjusts the screen’s contrast.
•Black Level: Adjusts the screen’s black level.
•Volume: Adjusts the navigation system volume level.
1Display and Volume Settings
You can set separate daytime and night time
settings for Brightness, Contrast, and Black
Level. Adjust each setting when the display is in
either daytime or night time mode.
You can set the display and volume settings
using voice commands.
2Main Setup Screen Commands P. 224
Volume
If you set Volume to OFF, you will not hear
route guidance or voice command confirmations.
If you then select Voice in the Map Menu, you
will hear route guidance at the default volume.

25
XX
Interface Settings
XInterface Dial Feedback
System Setup
Interface Dial FeedbackHINFO button
X Set up
X Interface Dial Feedback
Set if and when the system reads aloud a selection made using the Interface Dial.
Rotate i to select an option. Press
u.
The following options are available:
•ON: Always reads the selection.
•AUTO (factory default): Reads the selection only when the vehicle is moving.
•OFF: Disables the feature.
1Interface Dial Feedback
You can use this feature to minimise the need to
look at the screen while operating the Interface
Dial.
You can set the interface dial feedback settings
using voice commands on the Setup screen.
2Main Setup Screen Commands P. 224

26
XX
Interface Settings
XBasic Settings
System Setup
Basic SettingsHINFO button
X Set up
X Other
X Basic Settings
Set the map units to either miles or kilometers, and control the voice feedback from
the navigation system.
Rotate i to select an item. Press u.
The following items are available:
•Units: Sets the map units to either miles or kilometers (factory default).
•Voice Recognition Tutor: Turns the voice feedback feature on or off.
ON (factory default): Provides voice control system confirmation or prompts.
OFF: Disables the feature.
•Display Voice Command Tips: Alerts you when manual control of the system is
disabled to prevent distraction while driving. Only voice commands are available.
ON (factory default): Displays a message reminding you to use voice commands.
OFF: Disables the message. Inoperable items are still grayed out on the screen.
•Verbal Reminder: Turns the verbal reminders on or off.
ON (factory default): Provides warning voice messages when:
– Driving with the parking brake on.
– Driving without wearing the driver and/or passenger seat belt.
OFF: Disables the feature.

27
XX
Interface Settings
XColour
System Setup
ColourHINFO button
X Set up
X Other
X Colour
Choose the colour of the navigation map and system menus.
Rotate i to select an item. Press u.
The following items are available:
•Map Colour: Sets the colour of the map screen.
2Map Colour
P. 28
•Menu Colour: Sets the colour of the menu screens.
2Menu Colour
P. 28
Continued

28
XX
Interface Settings
XColour
System Setup
HINFO button
X Set up
X Other
X Colour
X Map Colour
Set separate map colours for Day and Night modes.
1.Rotate i to select Day or Night.
Press u.
2.Rotate i to select a colour for
the map screen. Press u.
HINFO button
X Set up
X Other
X Colour
X Menu Colour
Set separate menu colours for Day and Night modes.
1.Rotate i to select Day or Night.
Press u.
2.Rotate i to select a colour for
the menu screens. Press u.
■Map Colour
1Map Colour
For Day mode
Set to WHITE (factory default is BEIGE) to obtain
the best daytime display contrast.
For Night mode
Set to BLACK (factory default) to obtain the best
night time display contrast.
■Menu Colour
1Menu Colour
For Day mode
Set to WHITE (factory default) to obtain the best
daytime display contrast.
For Night mode
Set to BLACK (factory default) to obtain the best
night time display contrast.

29
XX
Interface Settings
XColour
System Setup
Set the screen brightness separately for Day and Night modes. Press the
a

(Display mode) button to cycle through the display modes (Day to Night to Off).
1.Press the a button.X
The Brightness bar is displayed
for a few seconds.
X
Rotate i to adjust the
brightness. Press u.
2.Press the a button again.
X
Repeat the procedure to switch
the display modes.
■Switching Display Mode Manually
1Switching Display Mode Manually
A visual guide helps you see the difference
between Day and Night modes.
2Day or Night Mode P. 11
Recommended Settings•Select mid-range for the dash illumination.•Select WHITE for the map Day display and
BLACK for the map Night display.
Continued
