navigation Acura ILX 2013 Navigation Manual

67
XX
Entering a Destination
XAddress
Navigation
HDEST/ROUTE button
X Address
X Change Province
Rotate i to select a province from
the list. Press u.
HDEST/ROUTE button
X Address
X Postal Code
1.Enter the postal code of your
destination.
2.Move r to select LIST.
■Selecting the State or Province
1Selecting the State or Province
Move w or y to select the following areas:•USA for the U.S. mainland, Hawaii, and Puerto
Rico•Canada/AK for Canada and Alaska•Mexico
■Selecting a City by Postal Code
1Selecting a City by Postal Code
If your city is not listed, it may be part of a larger
metropolitan area. Try entering the street first.
Continued

68
XX
Entering a Destination
XAddress
Navigation
3.Rotate i to select the destination
city from the list. Press u.X
Next, you are prompted to enter
a street name. 2Selecting a Street
P. 69
HDEST/ROUTE button
X Address
X City
The name of the city where you are currently located is displayed.
1.Enter the name of a different city,
or move r to select OK for the
current city.
X
Move r to select LIST to display
a list of cities.
■Selecting a City
1Selecting a City
Vehicle position may not be displayed when:•The automobile is travelling off-road.•The vehicle position data cannot be updated.
You do not need to enter spaces or symbols
(e.g., &, -, %). Partial matches are supported
(e.g., “ANGELES” to find “LOS ANGELES”).

69
XX
Entering a Destination
XAddress
Navigation
2.Rotate i to select your
destination city from the list. Press
u.X
A list of matching hits is
automatically displayed after
you enter several letters, with
the closest match at the top of
the list. Matching letters are in
yellow.
X
Next, you are prompted to enter
a street name. 2Selecting a Street
P. 69
HDEST/ROUTE button
X Address
X Street
1.Enter the name of your destination
street.
X
Do not enter the street type
(e.g., street, road, avenue) or
direction (e.g., north, south,
east, west).
X
Move r to select LIST to display
a list of streets.
1Selecting a City
If your city is not listed, it may be part of a larger
metropolitan area. Try entering the street first.
Non-detailed area mark: Try entering the
street first and then select the city.■Selecting a Street
1Selecting a Street
When entering the names of major highways,
you can use the following abbreviations. For
Trans-Canada and Provincial highways, use
“Hwy” (HWY-7). For County roads, use “CR”
(CR-32). For Regional Roads, use “RR” (RR-5).
For interstates, use an “I” (e.g., I-10). For U.S.
freeways, use “US” (e.g., US-18). For state
freeways, use the two-character state
designation (e.g., CA-101). For county roads, use
the appropriate designation (e.g., G-2).
Continued

70
XX
Entering a Destination
XAddress
Navigation
2.Rotate i to select your
destination street from the list.
Press u.X
A list of matching hits is
automatically displayed after
you enter several letters, with
the closest match at the top of
the list. Matching letters are in
yellow.
3.Enter the street number. Move r
to select OK.
X
Only valid street numbers can be
entered.
4.Set the route to your destination.
2Calculating the Route
P. 87
1Selecting a Street
If you did not select a city first and there is more
than one city with the specified street, a list of
cities is displayed.
Rotate i to select the desired city from the list.
Press u.

71
XX
Entering a Destination
XAddress Book
Navigation
Address BookHDEST/ROUTE button
X Address Book
Select an address stored in your address book to use as the destination.
1.Rotate i to select your
destination from the list. Press u.
2.Set the route to your destination.
2Calculating the Route
P. 87
X
Move w or y to display only
the entries in a category: ALL,
BUSINESS, PERSONAL, or other
categories you have created. 2Selecting an Address Book
Category
P. 40
1Address Book
If you have PIN-protected your address book,
enter your PIN when prompted. Move r to
select OK. PINs are optional.
2PIN Numbers P. 42
You can select New Address on the Select an
address screen to add an entry to the address
book.
2Adding an Address Book Entry P. 37

72
XX
Entering a Destination
XPrevious Destinations
Navigation
Previous DestinationsHDEST/ROUTE button
X Previous Destinations
Select an address from a list of your 50 most recent destinations to use as the
destination. The list is displayed with the most recent destination at the top.
1.Rotate i to select a destination
from the list. Press u.
2.Set the route to your destination.
2Calculating the Route
P. 87
1Previous Destinations
If Previous Destinations is greyed out, there are
no previous destinations entered.
Your home addresses and addresses stored in
your address book are not added to the list of
previous destinations.
You can delete unwanted previous destinations
from the list.
2Previous Destinations P. 43

73
XX
Entering a Destination
XPlace Name
Navigation
Place NameHDEST/ROUTE button
X Place Name
Enter the name of a place (e.g., business, hotel, restaurant) stored in the map
database to use as the destination.
1.Enter a place name.
2.Move r to select LIST to display a
list of matching hits.
3.Rotate i to select a place name
from the list. Press u.
X
If the place name is in multiple
categories, the categories are
displayed when you select it. 2Place Name in Multiple
Categories
P. 74
4.Set the route to your destination.
2Calculating the Route
P. 87
1Place Name
This option is convenient if you know the exact
name of a place.
Move e to select OPTION to enter symbols and
accented letters, move y to select SPACE to
enter a space character, or move w to select
DELETE to remove the last character.
Once a name is entered and selected, move r to
select SORT BY NAME or SORT BY DISTANCE.
Matching letters are in yellow.
Restaurants with a z icon have a ZAGAT®
review. Move y to select z to view the
complete ZAGAT® review.
2ZAGAT P. 80
Continued

74
XX
Entering a Destination
XPlace Name
Navigation
If the place name is in multiple categories in the map database, the following screen
is displayed.
1.Rotate i to select a place name.
Press u.
2.Rotate i to select a subcategory.
Press u.■Place Name in Multiple Categories
1Place Name in Multiple Categories
Move r to select SORT BY CITY or SORT BY
DISTANCE. Matching letters are in yellow.

75
XX
Entering a Destination
XPlace Name
Navigation
3.Rotate i to select a place. Press
u.
4.Set the route to your destination. 2Calculating the Route
P. 87

76
XX
Entering a Destination
XPlace Category
Navigation
Place CategoryHDEST/ROUTE button
X Place Category
Select the category of a place (e.g., Banking, Lodging, Restaurant) stored in the map
database to search for the destination.
1.Rotate i to select a category.
Press u.
2.Rotate i to select a subcategory.
Press u.
X
Move w or y to change the
main category. 2List of Categories
P. 228
1Place Category
This option is convenient if you do not know the
exact name of a place or if you want to narrow
down the number of matches returned for places
with a common name.
You can store up to 30 favourite subcategories.
Move y to select My Favorites to access your
favourites.
2My Favorites P. 78
Advanced helps you to search the subcategory.
When you enter a keyword and select LIST, the
list of appropriate subcategories is displayed.
