fog light bulb Acura ILX Hybrid 2013 Owner's Manual

77
uuIndicatorsu
Continued
Instrument Panel
Indicator
Name
On/Blinking
Explanation
Message
IMA System
Indicator
●Comes on for a few seconds when
you set the power mode to ON.●Comes on if there is a problem with
the hybrid system.
●Remains on or does not come on at all -
Avoid high speed driving and have the
vehicle checked by a dealer as soon as
possible.
2If the IMA Indicator Comes On P. 339
Turn Signal
Indicators
●The turn signal indicators blink when
you operate the turn signal lever.●If you press the hazard warning
button, both indicators and all turn
signals blink at the same time.
●Does not blink or blinks rapidly - A turn
signal light bulb has blown. Change the
bulb immediately.
2Replacing Light Bulbs P. 286, 288
—
High-Beam
Indicator
●Comes on when the high beam
headlights are on.
—
—
Lights On
Indicator
●Comes on whenever the light switch
is on, or in AUTO when the exterior
lights are on.
●If you set the power mode to ACCESSORY
or VEHICLE OFF (LOCK) while the exterior
lights are on, a chime sounds when the
driver's door is opened.
—
Fog Light
Indicator
●Comes on when the fog lights are
on.
—
—

282Maintenance
Replacing Light BulbsHeadlight BulbsWhen replacing, use the following bulbs.
1.Remove the engine compartment cover.
2Engine Compartment Cover P. 270
2.Push the tab to remove the coupler.
3.Rotate the old bulb to the left to remove.
4.Insert a new bulb into the headlight
assembly and turn it to the right.
5.Insert the coupler into the connector of the
bulb.
High voltage can remain in the circuit for a long period of time after the light is
switched off. Do not attempt to inspect or replace the high voltage discharge type
bulbs yourself. Ask a dealer to inspect and replace low beam headlights.
High beam headlight:
60 W (HB3)
Low beam headlight:
55 W (H11 for halogen bulb Type)35 W (D2S for high voltage discharge type)
■High Beam Headlight
1Headlight BulbsNOTICEHalogen bulbs get very hot when lit.
Oil, perspiration, or a scratch on the glass can cause
the bulb to overheat and shatter.
The headlight aim is set by the factory, and does not
need to be adjusted. However, if you regularly carry
heavy items in the trunk or tow a trailer, have the
aiming readjusted at a dealer or by a qualified
technician.
The HB3 type is a halogen bulb.
When replacing a bulb, handle it by its base, and
protect the glass from contact with your skin or hard
objects. If you touch the glass, clean it with
denatured alcohol and a clean cloth.
The exterior lights' inside lenses (headlights, brake
lamps, etc.) may fog temporarily after a vehicle wash
or while driving in the rain. This does not impact the
exterior light function.
However, if you see a large amount of water or ice
accumulated inside the lenses, have your vehicle
inspected by a dealer.
BulbTab
Coupler
Driver sideAll models
■Low Beam HeadlightsHigh Voltage Discharge Types

uuReplacing Light BulbsuFog Light Bulbs
284Maintenance
4.Pull the tab to remove the coupler.
5.Rotate the old bulb to the left to remove.
6.Insert a new bulb into the headlight
assembly and turn it to the right.
7.Insert the coupler into the connector of the
bulb.
Fog Light BulbsWhen replacing, use the following bulbs.
1.Remove the screw using a Phillips-head
screwdriver.
uThe screw does not drop.
Coupler
Bulb
Tab
All models
Fog Light: 55 W (H11)
1Fog Light BulbsNOTICEHalogen bulbs get very hot when lit. Oil, perspiration,
or a scratch on the glass can cause the bulb to
overheat and shatter.
The fog lights are halogen bulbs.
When replacing a bulb, handle it by its plastic case,
and protect the glass from contact with your skin or
hard objects. If you touch the glass, clean it with
denatured alcohol and a clean cloth.
Dropping
prevention

285
uuReplacing Light BulbsuFog Light Bulbs
Maintenance
2.Insert a flat-tip screwdriver into the tab at
the inside edge of the cover, then pull
straight out as indicated to remove the
cover.
3.Remove the screws using a Phillips-head
screwdriver and carefully pull the fog light
assembly out of the bumper.
4.Push the tab to remove the coupler.
5.Rotate the old bulb to the left to remove.
6.Insert a new bulb into the fog light
assembly and turn it to the right.
7.Insert the coupler into the connector of the
bulb.
CoverScrewsCouplerBulb
Tab

340Handling the Unexpected
FusesFuse LocationsIf any electrical devices are not working, set
the power mode to VEHICLE OFF (LOCK)
and check to see if any applicable fuse is
blown.
Fuse locations are shown on the fuse box
cover.
Locate the fuse in question by the fuse
number and box cover number.
Located near the brake fluid reservoir. Push
the tabs to open the box.■Engine Compartment Fuse Box
■Circuit protected and fuse rating
Circuit Protected
Amps
1
EPS
70 A
Booster Motor
40 A
ABS/VSA Motor
30 A
ABS/VSA FSR
30 A
WIPER
30 A
Main Fuse
100 A
2
IG Main
50 A
Fuse Box Main 60 A
Fuse Box Main 2
60 A
Headlight Main 30 A
ST/MG SW
*1
30 A
Rear Defogger 30 A
−−
Blower 40 A
−−
Sub Fan Motor 20 A
Main Fan Motor 20 A
3
−
−
4 IG Coil 2 15 A
5
Starter DIAG, ST MG
7.5 A
6 IG Coil 1 15 A
7
−
−
8− −
9
−
−
10 − −
*1: Models with halogen bulb low beam
headlights
*2: Models with discharge headlights11
Oil Level
7.5 A
12 Fog Lights 20 A
13
IMA 1
7.5 A
14 Hazard 10 A
15
FI Sub
15 A
16 IG Coil 20 A
17
Stop
15 A
18 Horn 10 A
19
IMA 2
10 A
20Right Headlight Low Beam
*1
Right Headlight Low Beam
(HID)
*2
10 A
15 A
21
IGP
15 A
22 DBW 15 A
23
Left Headlight Low Beam
*1
Left Headlight Low Beam
(HID)
*2
10 A
15 A
24 Booster SOL 15 A
25
MG Clutch
7.5 A
26 WASHER 15 A
27
SMALL
20 A
28 Interior Lights 7.5 A
29
Backup
10 A
Circuit Protected
Amps

346Information
Specifications■Vehicle SpecificationsModel
Acura ILX Hybrid
No. of Passengers:
Front 2
Rear 3
Total 5
Weights:Gross Vehicle
Weight Rating
3,968 lbs (1,800 kg)
Gross Axle Weight
Rating (Front)
2,138 lbs (970 kg)
Gross Axle Weight
Rating (Rear)
1,962 lbs (890 kg)
Air Conditioning:
Refrigerant Type HFC-134a (R-134a)
Charge Quantity 13.2 – 15.0 oz (375 – 425 g)
Lubricant Type SE-10Y
■Engine Specifications
■Fuel
■12 Volt Battery
■Washer FluidDisplacement
91 cu-in (1,497 cm
3)
Spark Plugs NGK DILFR6J11
Fuel:
Type
Premium unleaded gasoline, Pump octane
number of 91 or higher
Fuel Tank Capacity 13.2 US gal (50 ℓ)
Capacity/Type
32AH(5)/40AH(20)
Tank Capacity
U.S.: 2.6 US qt (2.5 ℓ)
Canada: 5.12 US qt (4.85 ℓ)
■Light Bulbs*1: Vehicle with discharge headlights
*2: Vehicle with halogen bulb low beam headlightsHeadlights (Low Beam)
35W (D2S)
*1
55W (H11)
*2
Headlights (High Beam) 60W (HB3)Fog Lights
55W (H11)
Front Turn Signal Lights 21W
Parking/Side Marker Lights
5W
Brake/Rear Side Marker/Taillight 21/5W
Back-Up Lights
16W
Rear Turn Signal Lights 21W
High-Mount Brake Light
LED
Rear License Plate Light 5W
Trunk Light
5W
Interior Lights
Map Light LED
Ceiling Light 8W
Foot light
1.4W
Glove Box light LED
Vanity Mirror light
2W

358Index
Maintenance (Checking the 12 Volt
Battery) .................................................. 303
Maintenance (Replacing).......................... 304
Belts (Seat).................................................. 32
Beverage Holders...................................... 143
Bluetooth® Audio..................................... 176
Bluetooth® HandsFreeLink®..................... 189
Booster Seats (For Children)....................... 65
Brake System............................................. 245
Anti-lock Brake System (ABS) ................... 247
Brake Assist System ................................. 248
Brake System Indicator....................... 71, 338
Fluid ........................................................ 280
Foot Brake ............................................... 246
Indicator ............................................ 71, 338
Parking Brake .......................................... 245
Brightness Control (Instrument Panel).... 131
Bulb Replacement..................................... 282
Back-Up Light Bulbs ................................. 290
Brake Light, Taillight, Rear Turn Signal Light
and Rear Side Marker Light Bulbs ........... 288
Bulb Specifications ................................... 346
Fog Lights ................................................ 284
Front Turn Signal Light Bulbs ................... 286
Headlights ............................................... 282
High-Mount Brake Light .......................... 291
Parking/Side Marker Light Bulbs ............... 287
Rear License Plate Light............................ 291
CCarbon Monoxide Gas............................... 66
Carrying Cargo................................. 221, 223
CD Player................................................... 165
Certification Label.................................... 348
Changing Bulbs........................................ 282
Charge/Assist Gauge.................................. 86
Charging System Indicator................. 72, 336
Child Safety................................................. 54
Childproof Door Locks............................. 112
Emergency Trunk Opener ........................ 117
Child Seat.................................................... 54
Booster Seats ............................................ 65
Child Seat for Infants................................. 56
Child Seat for Small Children ..................... 57
Installing a Child Seat with a Lap/Shoulder Seat
Belt ......................................................... 61
Larger Children ......................................... 64
Rear-facing Child Seat ............................... 56
Selecting a Child Seat ................................ 58
Using a Tether ........................................... 63
Childproof Door Locks............................. 112
Cleaning the Exterior............................... 308
Cleaning the Interior................................ 306
Client Service Information....................... 356
Climate Control System............................ 146
Changing the Mode ................................ 146
Defrosting the Windshield and
Windows ............................................... 147
Dust and Pollen Filter............................... 305
Recirculation/Fresh Air Mode ................... 146Sensors ................................................... 149
Synchronized Mode ................................ 148
Using Automatic Climate Control ............ 146
Clock......................................................... 104
Coat Hook................................................ 144
Compact Spare Tire (Optional)............... 321
Console Compartment............................. 142
Controls.................................................... 103
Coolant (Engine)...................................... 277
Adding to the Radiator ........................... 278
Adding to the Reserve Tank .................... 277
Low Temperature Indicator ....................... 79
Overheating ............................................ 334
Creep Aid System..................................... 228
Creeping................................................... 230
Cruise Control.......................................... 237
Indicator ................................................... 80
Cup Holders.............................................. 143
Customized Features................................. 95
DDaytime Running Lights.......................... 129
Dead Battery............................................ 331
Defrosting the Windshield and
Windows................................................. 147
Devices that Emit Radio Waves............... 349
Dimming
Headlights .............................................. 126
Rearview Mirror ...................................... 133
Dipstick (Engine Oil)................................ 273

360Index
Locations ......................................... 340, 341GGasoline (Fuel)
Economy ................................................. 256
Gauge ....................................................... 86
Information ............................................. 254
Instant Fuel Economy ................................. 91
Low Fuel Indicator ..................................... 73
Refueling ................................................. 254
Gauges......................................................... 86
Glass (care)................................................ 308
Glove Box.................................................. 142HHalogen Bulbs................................... 282, 283
Handling the Unexpected........................ 311
HandsFreeLink® (HFL)............................... 189
Automatic Import of Cellular Phonebook and
Call History ............................................ 205
Automatic Transferring ............................ 203
Caller’s ID Information ............................. 203
HFL Buttons ............................................. 189
HFL Menus .............................................. 191
HFL Status Display.................................... 190
Making a Call .......................................... 208
Options During a Call .............................. 212
Phone Setup ............................................ 196
Receiving a Call ....................................... 211Speed Dial ............................................... 206
Text Message .................................. 201, 213
To Clear the System ................................ 204
To Create a Security PIN .......................... 202
Hazard Warning Button.............................. 2
Head Restraints........................................ 138
Headlights................................................. 126
Aiming .................................................... 282
Automatic Operation............................... 127
Dimming ......................................... 126, 129
Operating................................................ 126
Heaters (Seat)........................................... 145
HFL (HandsFreeLink®)............................... 189
High-Beam Indicator.................................. 77
Hill Start Assist System............................. 228
HomeLink® Universal Transceiver............ 187
IIdentification Numbers............................ 348
Engine and Transmission ......................... 348
Vehicle Identification ............................... 348
Illumination Control................................. 131
Knob ....................................................... 131
IMA Battery Charge Level Indicator/Power
Flow Monitor............................................ 93
IMA System Indicator................................. 77
Immobilizer System.................................. 118
Indicator.................................................... 78
Indicators.................................................... 70
ABS (Anti-lock Brake System)..................... 73Auto Idle Stop........................................... 75
Brake System ............................................ 71
Charging System............................... 72, 336
CRUISE CONTROL ............................. 80, 238
CRUISE MAIN.................................... 80, 237
Door and Trunk Open ......................... 31, 75
Door Open................................................ 31
ECON Mode ..................................... 80, 236
EPS (Electric Power Steering)
System ............................................ 75, 338
Fog Light .................................................. 77
High-Beam................................................ 77
IMA System .............................................. 77
Immobilizer System ................................... 78
Keyless Access System............................... 79
Lights On .................................................. 77
Low Fuel ................................................... 73
Low Oil Pressure ............................... 75, 336
Low Temperature...................................... 79
Low Tire Pressure/TPMS .................... 76, 242
Maintenance Minder............................... 263
Malfunction Indicator Lamp .............. 71, 337
Parking Brake and Brake System ....... 70, 338
Seat Belt Reminder.............................. 33, 73
Security System Alarm............................... 79
Shift Lever Position.................................... 72
Side Airbag Off ................................... 52, 78
Supplemental Restraint System ........... 50, 74
System Message ....................................... 76
Transmission ............................................. 72
Turn Signal ............................................... 77

361Index
VSA® (Vehicle Stability Assist)
System ............................................ 74, 240
VSA® OFF.......................................... 74, 241
Information.............................................. 345
Information Buttons............................ 87, 95
Instant Fuel Economy................................ 91
Instrument Panel........................................ 69
Brightness Control .................................. 131
Interior Lights........................................... 141
Interior Rearview Mirror......................... 133
Internet Radio.......................................... 171
iPhone®..................................................... 186
iPod®......................................................... 168JJack (Wheel Nut Wrench)........................ 324
Jump Starting........................................... 331KKey Number Tag...................................... 106
Keyless Access System.............................. 108
Keyless Lockout Prevention..................... 110
Keys........................................................... 105
Lockout Prevention ................................. 110
Number Tag............................................ 106
Rear Door Won’t Open ........................... 112
Remote Transmitter ................................ 107
Types and Functions................................ 105
Won’t Turn ............................................... 22Kickdown.................................................. 230
LL Mode Operation.................................... 235
Language (HFL)......................................... 190
LATCH (Child Seats).................................... 59
Lights................................................. 126, 282
Automatic ............................................... 127
Bulb Replacement.................................... 282
Daytime Running Lights ........................... 129
Fog Lights................................................ 129
High-Beam Indicator .................................. 77
Interior .................................................... 141
Light Switches ......................................... 126
Lights On Indicator .................................... 77
Turn Signals............................................. 126
Limitations for Manual Operation.......... 190
Load Limits................................................ 223
Locking and Unlocking............................ 105
Auto Door Locking/Unlocking .................. 113
Childproof Door Locks ............................. 112
From Inside.............................................. 111
From Outside........................................... 107
Keys ........................................................ 105
Using a Key ............................................. 110
Lockout Prevention System...................... 110
Low Battery Charge (12 volt)................... 336
Low Fuel Indicator...................................... 73
Low Keyless Access Remote Signal
Strength.................................................. 106Low Oil Pressure Indicator................. 75, 336
Low Temperature Indicator....................... 79
Lower Anchor............................................. 59
Lubricant Specifications Chart................. 346
Luggage (Maximum Load Limit)............. 223
MMaintenance............................................. 259
Battery .................................................... 303
Brake Fluid .............................................. 280
Cleaning ................................................. 306
Climate Control....................................... 305
Coolant ................................................... 277
Maintenance Minder
TM............................ 263
Oil ........................................................... 272
Precautions ............................................. 260
Radiator .................................................. 278
Remote Transmitter ................................. 304
Replacing Light Bulbs .............................. 282
Safety...................................................... 261
Service Items ........................................... 266
Tires ........................................................ 294
Transmission Fluid ................................... 279
Under the Hood ...................................... 268
Maintenance MinderTM............................ 263
Malfunction Indicator Lamp.............. 71, 337
Map Lights................................................ 141
Maximum Load Limit............................... 223
Meters, Gauges........................................... 86

364Index
Troubleshooting....................................... 311
Blown Fuse ...................................... 340, 341
Brake Pedal Vibrates .................................. 23
Buzzer Sounds When Opening Door .......... 23
Emergency Towing .................................. 343
Engine Does Not Start.............................. 328
Noise When Braking .................................. 23
Overheating............................................. 334
Premium Gasoline.................................... 254
Puncture/Flat Tire ..................................... 313
Rear Door Won’t Open ...................... 22, 112
Shift Lever Won’t Move ........................... 333
Warning Indicators .................................... 70
Trunk......................................................... 114
Lid ........................................................... 114
Light Bulb ................................................ 346
Turn Signals............................................... 126
Indicators (Instrument Panel) ...................... 77UUnlocking the Doors................................. 107
Unlocking the Front Doors from the
Inside......................................................... 15
USB Adapter Cable........................... 152, 153
USB Flash Drives........................................ 186
Using the Keyless Access System.............. 108VVanity Mirrors............................................... 5Vehicle Identification Number................ 348
Vehicle Stability Assist (VSA®).................. 240
Off Button............................................... 241
Off Indicator.............................................. 74
System Indicator ........................................ 74
Viscosity (Oil).................................... 272, 347
VSA® (Vehicle Stability Assist).................. 240
WWallpaper......................................... 100, 157
Wallpaper Setup....................................... 178
Warning and Information Messages......... 81
Warning Indicator On/Blinking............... 336
Warning Labels........................................... 67
Warranties (Warranty Manual provided
separately).............................................. 353
Watts......................................................... 346
Wear Indicators (Tire).............................. 299
Wheel Nut Wrench (Jack Handle)........... 324
Window Washers..................................... 130
Adding/Refilling Fluid .............................. 281
Switch ..................................................... 130
Windows (Opening and Closing)............ 120
Windshield................................................ 130
Cleaning ................................................. 309
Defrosting/Defogging .............................. 147
Washer Fluid ........................................... 281
Wiper Blades ........................................... 292
Wipers and Washers................................ 130Winter Tires.............................................. 302
Snow Tires .............................................. 302
Tire Chains.............................................. 302
Wipers and Washers................................ 130
Checking and Maintaining Wiper Blades . 292
WMA................................................. 165, 173
Worn Tires................................................ 294
XXM® Radio................................................ 163
