Protectin
g Childre n

If the shoulder part of the belt rests
over the child's collarbone and
against the center of the chest, as shown, the child is large enough to
wear the seat belt.
However, if the belt touches or
crosses the child's neck, the child
needs to use a booster seat. Do not let a child wear a seat belt
across the neck. This could result in
serious neck injuries during a crash.
Do not let a child put the shoulder
part of a seat belt behind the back or under the arm. This could cause
very serious injuries during a crash. It also increases the chance that the
child will slide under the belt in a
crash and be injured.

Do not put any accessories on a seat
belt. Devices intended to improve
occupant comfort or reposition the
shoulder part of a seat belt, severely
compromise the protective capability
of the seat belt and increase the
chance of serious injury in a crash.

Two children should never use the

same seat belt. If they do, they could
be very seriously injured in a crash.
Using a Booster Seat

If a child needs a booster seat, we
recommend choosing a style that
allows the child to use the lap/ shoulder belt directly, without a
shield, as shown.
Whichever style you select, follow the booster seat maker's instructions.
Drive r an d Passenge r Safet y

Protectin
g Childre n

A child may continue using a booster seat until the tops of the ears are
even with the top of the seat-back. A
child of this height should be tall enough to use the lap/shoulder belt
without a booster.When Can a Larger Child Sit in Front
The National Highway Traffic Safety
Administration and Transport Canada recommend that all children
ages 12 and under be properly
restrained in a back seat.
The back seat is the safest place for a child of any age or size.
In addition, the passenger's airbag
poses serious risks to children. If the seat is too far forward, or the child's
head is thrown forward during a collision, or the child is unrestrainedor out of position, an inflating airbag
can kill or seriously injure the child.
Of course, children vary widely. And
while age may be one indicator of
when a child can safely ride in the front, there are other important
factors you should consider.
Physical Size
Physically, a child must be large
enough for the lap/shoulder belt to
properly fit over the hips, chest, and shoulder (see pages 16 and 37). If
the seat belt does not fit properly,
the child should not sit in the front.

Maturity

To safely ride in front, a child must
be able to follow the rules, includingsitting properly and wearing the seat
belt properly throughout a ride.

CONTINUED

Drive r an d Passenge r Safet y

Protectin
g Childre n
If you decide that a child can safely
ride up front, be sure to: Carefully read the owner's manual
and make sure you understand all seat belt instructions and all safety
information.
Move the vehicle seat to the rear-
most position.
Have the child sit up straight, back
against the seat, and feet on or
near the floor. Check that the child's seat belt is
properly positioned and secured. Supervise the child. Even mature
children sometimes need to be
reminded to fasten the seat belts
or sit properly. Using
Child Seats wit h Tether s
Your Acura has two tether anchorage points on the rear panel
for securing a tether-style child seat
to the car.
Since a tether can provide additionalsecurity, we recommend using a
tether whenever one is required or
available.
Attach the tether strap hook to the
tether anchorage point and tighten
the strap according to the child seat
maker's instructions.

Drive r an d Passenge r Safet y
CARG
O ARE A

Protectin
g Childre n
Drive r an d Passenge r Safet y

If you are not sure how to reinstall
the tether hardware, contact your
Acura dealer.
When reinstalling tether hardware, make sure the toothed washer is on
the bottom of the bolt. Tighten the
bolt to:
16 lbf.ft (22 N.m , 2.2 kgf.m)

If a torque wrench was not used, see
your Acura dealer as soon as possible to verify proper

reinstallation.

Additiona
l Informatio n Abou t You r Sea t Belt s
Sea t Bel t Syste m Component s
Your seat belt system includes lap/ shoulder belts in all four seating
positions.
The seat belt system alsoincludes a light on the
instrument panel to remind you and
your passengers to fasten your belts. If the driver's seat belt is not
fastened before the ignition is turned ON (II), the light will come on and a
beeper will also sound. The beeper
will stop after a few seconds, but the light will stay on until the driver's seat belt is fastened.
Lap/Shoulde
r Bel t

This seat belt has a single belt that goes over your shoulder, across yourchest and across your hips. To fasten the belt, insert the latch
plate into the buckle, then tug on the
belt to make sure the buckle is

latched.

To unlock the belt, push the red PRESS button on the buckle.Guide the belt across your body to
the door pillar. After exiting the car,
be sure the belt is out of the way and
will not get closed in the door.
Drive r an d Passenge r Safet y

Additiona
l Informatio n Abou t You r Sea t Belt s
All seat belts have an emergency locking retractor. In normal driving,
the retractor lets you move freely in
your seat while it keeps some tension on the belt. During a collisionor sudden stop, the retractor
automatically locks the belt to help
restrain your body.
The seat belts in all seating positions except the driver's have an additional
locking mechanism that must be activated to secure a child seat. (See
pages 30 and 34 for instructions on
how to secure child seats with this
type of seat belt.)
If the shoulder part of the belt is
pulled all the way out, the locking mechanism will activate. The belt
will retract, but it will not allow the passenger to move freely. To deactivate the locking
mechanism, unlatch the buckle and
let the seat belt fully retract. To refasten the belt, pull it out only as
far as needed.
See page 16 for instructions on how
to wear the lap/shoulder belt
properly. Sea
t Belt Maintenanc e
For safety, you should check the
condition of your seat belts regularly.
Pull each belt out fully and look for
frays, cuts, burns, and wear. Check that the latches work smoothly and
that the lap/shoulder belts retracteasily. Any belt not in good condition
or not working properly will not
provide good protection and should
be replaced as soon as possible.U.S. Models
Acura provides a lifetime warranty on seat belts. Acura will repair or
replace any seat belt component that
fails to function properly during normal use.

Please see your Acura WarrantyInformation booklet for details.

CONTINUED
Drive r an d Passenge r Safet y

Additiona
l Informatio n Abou t You r Sea t Belt s
If a seat belt is worn during a crash,
you should have your dealer inspect the belt, and replace it if necessary.
A belt that has been worn during a crash may not provide the same levelof protection in a subsequent crash.
The dealer should also inspect the anchors for damage and replace
them if needed.
For information on how to clean yourseat belts, see page 218.
Drive r an d Passenge r Safet y Not checking or maintaining
seat belts can result in serious injury or death if the seat belts
do not work properly when
needed.

Check your seat belts regularly
and have any problem
corrected as soon as possible.

Additiona
l Informatio n Abou t You r SR S
SR S Component s
Your Supplemental Restraint System (SRS) includes:
Two front airbags. The driver'sairbag is stored in the center of
the steering wheel; the front
passenger's airbag is stored in the dashboard. Both are marked "SRS
AIRBAG." Sensors that can detect a
moderate to severe frontal
collision.
A sophisticated electronic system
that continually monitors thesensors, control unit, the airbag
activators, and all related wiring
when the ignition is ON (II). An indicator light on the
instrument panel that alerts you to
a possible problem with the
system (see page 47).
Emergency backup power in case your car's electrical system isdisconnected in a crash. Ho
w Your Airbag s Work
If you ever have a moderate to severe frontal collision, the sensors
will detect rapid deceleration and signal the control unit to instantly
inflate the airbags.
During a crash, your seat belt helps
restrain your lower body and torso.
Your airbag provides a cushion to help restrain and protect your headand chest.

Driver an d Passenge r Safet y

CONTINUED

Additiona
l Informatio n Abou t You r SR S
Since both airbags use the same sensors, both airbags normally
inflate at the same time. However, it
is possible for only one airbag to
inflate.
This can occur when the severity of a collision is at the margin, or
threshold, that determines whetheror not the airbags will deploy. In
such cases, the seat belt will providesufficient protection, and the
supplemental protection offered by
the airbag would be minimal.
After inflating, the airbagsimmediately deflate, so they won't
interfere with the driver's visibility,or the ability to steer or operate
other controls.
The total time for inflation and deflation is approximately one-tenth
of a second, so fast that most
occupants are not aware that the
airbags deployed until they see them
lying in their laps. After a crash, you may see what
looks like smoke. This is actually
powder from the airbag's surface.
Although the powder is not harmful, people with respiratory problemsmay experience some temporarydiscomfort. If this occurs, get out of
the car as soon as it is safe to do so.U.S. Owners
For additional information on how
your airbags work, see the booklet titled SRS: What You Need to Know
About Airbags that came with your

owner's manual.

Canadian Owners
For additional information on how
your airbags work, ask your dealer for a copy of the booklet titled SRS:
What You Need to Know About Airbags.

Drive r an d Passenge r Safet y

Additiona
l Informatio n Abou t You r SR S

Ho w th e SR S Indicato r Ligh t
Work s
The purpose of the SRSlight is to alert you to a
potential problem with your Supplemental Restraint System.
When you turn the ignition ON (II), this indicator will light up briefly
then go out. This tells you that thesystem is working properly.
However, if the light comes on at any other time, you should have the
system checked by your dealer. For

example:

If the SRS indicator light does not
come on after you turn the ignitionON (II).
If the light stays on after the
engine starts. If the light comes on or flashes on
and off while you drive.
If you see any of these indications,
your airbags may not deploy when
you need them. See your Acura dealer as soon as possible. SR
S Servic e
Your Supplemental Restraint System is virtually maintenance-free, and
there are no parts you can safely service. However, you must have
your car serviced if:

Your airbags ever inflate. The

airbags and the control unit must
be replaced. Do not try to remove or replace the airbags yourself.
This must be done by an Acura dealer or a knowledgeable body
shop.

The SRS indicator light alerts you

to a problem. Take your car to an

authorized Acura dealer as soon as
possible. If you ignore this indication, the airbags might not
inflate when you need them.

Drive r an d Passenge r Safet y

Ignoring the SRS indicator light
can result in serious injury or

death if the airbags do not
inflate when needed.

Have your vehicle checked by a
dealer as soon as possible if

the SRS light alerts you to a
potential problem.

S

R
S
