Instrument
s an d Control s
This section gives information about the controls and displays that
contribute to the daily operation of

your Acura. All the essential controls
are within easy reach.
Control Locations............................ 52

Indicator Lights................................ 53

Gauges.............................................. 57

Speedometer................................ 57

Tachometer.................................. 57
Odometer...................................... 57

Trip Meter.................................... 57

Fuel Gauge................................... 58

Temperature Gauge....................
58

Maintenance Require
d

Indicator.................................... 59

Controls Near the Steering
Wheel........................................ 60

Headlights.................................... 61
Instrument Panel Brightness.....

62

Turn S
ignals.................................

62

Windshield Wipers.

..................... 63

Windshield Washers..................
. 63

Hazard Warning...........................
64

Rear Windo
w Defogger.............. 64

Steering Wheel Adjustment....... 65

Steering Wheel Controls................ 66
Cruise Control.............................. 66
Keys and Locks................................ 69
Keys............................................... 69

Immobilizer System..................... 69
Ignition Switch............................. 70

Power Door Locks....................... 72
Childproof Door Locks............... 73

Trunk............................................ 73

Glove Box..................................... 75

Seat Adjustments............................. 75
Driver's Seat Height
Adjustment............................... 76

Driver's Lumbar Support............ 76

Head Restraints........................... 77

Folding Rear Seat............................ 77

Power Windows............................... 79

Moonroof.......................................... 80

Mirrors.............................................. 81
Adjusting the Power Mirrors..... 81

Parking Brake.................................. 82

Digital Clock..................................... 83

Beverage Holder.............................. 84 Console Compartment.................... 85
Cigarette Lighter............................. 85
Ashtrays............................................ 86
Interior Lights.................................. 87
Instrument s an d Control s

Foldin
g Rea r Sea t
To fold down the seat-back from
inside the car, insert the master key
in the lock on the rear shelf. Turn
the key clockwise, pull down the top of the seat-back, then release the
key. To release the seat-back from inside
the trunk, pull the release loop under
the rear shelf.
To lock the seat-back upright, push it
firmly against the rear shelf. Make
sure it is latched in place by pulling
on the top of the seat. Make sure all items in the trunk, or
items extending through the opening
into the back seat, are secured.
Loose items can fly forward and
cause injury if you have to brake
hard. See Carryin
g Carg o on page

127.

Never drive with the seat-back
folded down and the trunk lid open. See Carbo n Monoxid e Hazar d on

page 49 .

Instrument s an d Control s RELEAS
E
Pul
l
MASTE
R KE Y

Digita
l Cloc k

The digital clock displays the time
with the ignition switch ON (II). To see the time with the ignition off,
press and hold the wide button next
to the clock. To set the clock:
1. Turn the ignition switch ON (II) to

display the time.

2. Swing down the front cover of the wide button next to the clock
display. You will see H, M, and
RESET buttons.
3. Press and hold the H button until
the hour advances to the desired
hour.
4. Press and hold the M button until the numbers advance to the

desired minutes.

You can use the RESET button to quickly set the time to the nearest
hour. If the displayed time is before
the half hour, pressing RESET
button sets the clock back to the previous hour. If the displayed time
is after the half hour, pressing the RESET button sets the clock for- ward to the beginning of the next
hour.
For example: 1:06 would RESET to 1:00. 1:52 would RESET to 2:00.

Instrument s an d Control s

RESE
T
HM

Coolin
g Syste m

1. Make sure the engine and radiator are cool.
2. Turn the radiator cap counter- clockwise, without pressing down
on it, until it stops. This relieves
any pressure remaining in the
cooling system.
3. Remove the radiator cap by pushing down and turning
counterclockwise.
4. The coolant level should be up tothe base of the filler neck. Add
coolant if it is low.
5. Put the radiator cap back on. Tighten it fully. 6. Pour coolant into the reserve tank.
Fill it to halfway between the MAX
and MIN marks. Put the cap back
on the reserve tank.

CONTINUED

Maintenanc e
RADIATO
R CA P
RESERVE TAN K

Light
s
Replacin g a Headligh t Bul b
Your car has two bulbs on each side, four in total. Make sure you arereplacing the bulb that is burned out.
Your car uses halogen headlight bulbs. When replacing a bulb, handleit by its plastic case and protect the
glass from contact "with your skin or hard objects. If you touch the glass,clean it with denatured alcohol and a
clean cloth.

Halogen headlight bulbs get very hot
when lit. Oil, perspiration, or a scratch
on the glass can cause the bulb to
overheat and shatter.
1. Open the hood.
If you need to change the high
beam headlight bulb on the
passenger's side, remove the
radiator reserve tank by pulling itstraight up.
2. To disconnect the bulb from the electrical harness, push on the end
of the lock tab to release the
connector then push the connec-
tor straight down. 3. Turn the bulb about one-eighth
turn counterclockwise to unlock it
from the headlight assembly.
4. Remove the bulb by pulling it straight out of its recess.
5. Align the tabs on the new bulb with the slots in the headlightassembly and push it into place.
6. Turn the bulb clockwise to lock it in place. Do not force it. Check theseating of the bulb's tabs in the
slots if the bulb will not return to
its original position.
7. Reinstall the harness connector on the bulb connector. Make sure it
locks in place.
Turn on the headlights to test the new bulb.
8. (Passenger's side) Reinstall the radiator reserve tank.

Maintenanc e

NOTIC
E

Light
s

Replacin g Fron t Tur n Signal /
Parkin g an d Sid e Marke r Ligh t
Bulb s
1. Use a Phillips-head screwdriver to loosen the fight assembly's
mounting screw.
2. Remove the light assembly from the bumper. 3. Remove the socket of the burned-
out bulb from the light assembly
by turning it one-quarter turn
counterclockwise.
4. To remove the front bulb, push it in slightly and turn it counterclock-
wise. To remove the side bulb, pull
it straight out of its socket. 5. Install the new bulb in the socket.
6. Insert the socket back into the
light assembly. Turn it clockwise
to lock it in place.
7. Test the lights to make sure the new bulb is working.
8. Put the light assembly into the bumper. Make sure the tab on the
light assembly fits into the bumperslot. Tighten the mounting screw.
Maintenance

SCRE
W

Light
s

Replacin g a High-moun t Brak e
Ligh t Bul b
1. Open the trunk and remove the socket from the light assembly by
turning it one-quarter turn counter-
clockwise.

2. Remove the burned-out bulb by pulling it straight out of the socket.
3. Install the new bulb and reinstall the socket. Make sure the new
bulb is working. Replacin
g Rea r Bulb s
(i n Fenders )
1. Open the trunk.
2. Undo the six fasteners (two "A" type and four "B" type) and
remove the trunk wall cover. Referto pages 205 and 206 for removal
of the fasteners.
3. Remove a "B" type fastener from
the wall lining and pull off the

lining.
Maintenanc e B
Typ e
A
Typ e

Light
s
4. Remove the socket by turning it one-quarter turn counterclockwise.
5. If the turn signal light bulb or tail/stoplight bulb is burned out,remove it by pushing it in and
turning counterclockwise. If the side marker light bulb is burned
out, remove it by pulling it straight
out of its socket. 6. Install the new bulb in the reverse
order of removal.
7. Push the socket into the light assembly and turn it clockwise
until it locks.
8. Test the lights to make sure the new bulb is working.
9. Install the wall lining and the trunk wall cover and secure them with
the fasteners. Refer to page206 for reinstallation of the
fasteners. Removal and Reinstallation of
Fasteners
(A Type)

Removal:

Turn the center of the fastener one- quarter turn counterclockwise using
a coin or a screwdriver. The center
will come out slightly. Then remove the fastener.

CONTINUED

Maintenanc e

Light
s

Replacin g Rea r Bulb s (i n Trun k

Lid )
1. Open the trunk.
2. Use a Phillips-head screwdriver to remove the two screws from the
bulb holder. Remove the holder
from the taillight assembly. 3. Try the tail/stoplight and back-up
lights to verify which bulb needs
replacing. Remove that bulb from
the socket by pushing it in slightly and turning it counterclockwise.
4. Install the new bulb in the socket. Test it to make sure it works.
5. Reinstall the bulb holder assembly. Install the two screws and tighten
them securely. Replacin
g a Rea r Licens e Bul b
1. Remove the two screws and remove the license light assembly.
2. Remove the socket from the light assembly by turning it one-quarterturn counterclockwise.
3. Pull the bulb straight out of its socket. Push the new bulb in until
it bottoms in the socket.

Maintenance

CONTINUED

Changin
g a Fla t Tir e

6. Turn the jack's end bracket counterclockwise to loosen it, then
remove the jack. 7. Loosen the four wheel nuts 1/2
turn with the wheel wrench. 8. Find the jacking point nearest the
wheel you are removing. Place the
jack under the jacking point. Turn the end bracket clockwise until the top of the jack contacts the
jacking point. Make sure the
jacking point tab is resting in the
jack notch.
Takin g Car e o f th e Unexpecte d JACKIN
G POIN T

JAC K
