2005 MDX Online Reference Owner's Manual
Use these links (and links throughout this manual) to navigate through\
this reference.
For a printed owner's manual, click on authorized manuals or go to www.h\
elminc.com.
Contents

Introduction ........................................................................\
............................................................... i
A Few Words About Safety........................................................................\
........................................ ii
Your Vehicle at a Glance........................................................................\
........................................... 4
Driver and Passenger Safety ........................................................................\
.................................... 7
Seat belts, SRS, and child protection.
Instruments and Controls........................................................................\
......................................... 57
Indicators, gauges, dashboard, and steering column.
Features ........................................................................\
..................................................................... 105
Climate, audio, rear entertainment, steering wheel, secruity, cruise con\
trol, HomeLink and Onstar
Before Driving........................................................................\
.......................................................... 185
Fuel, vehicle break-in, and cargo loading.
Driving ........................................................................\
..................................................................... . 197
Engine and transmission operation.
Maintenance........................................................................\
............................................................. 227
Schedules, fluid checking, minor services, and vehicle storage.
Taking Care of the Unexpected........................................................................\
.............................. 259
Flat tire, dead battery, overheating, fuses.
Technical Information........................................................................\
............................................ . 281
Vehicle specifications, tires, fuels, and emissions controls.
Warranty and Customer Relations (U.S. and Canada)................................................................ 295
Warranty and contact information.
Authorized Manuals (U.S. only)........................................................................\
.............................. 299
How to order.
Index........................................................................\
........................................................................\
..... I
Service Information Summary
Fluid capacities and tire pressures.
Important Handling Information. ........................................................................\
................... iii

If you see any of these indications,
the airbags and seat belt tensioners
may not work properly when you
need them.
The SRS indicator alerts
you to a potential problem
with your airbags, sensors, or seat
belt tensioners.
When you turn the ignition switch to
ON (II), this indicator will come on
brief ly then go out. This tells you the
system is working properly.
If the indicator comes on at any
other time, or does not come on at all,
you should have the system checked
by your dealer. For example:
If the SRS indicator does not come
on after you turn the ignition to
ON (II).
If the indicator stays on after the
engine starts.
If the indicator comes on or
flashesonandoff whileyoudrive. This indicator
alerts you that the
passenger’s side airbag has been
automatically shut off. It does
mean there is a problem with your
side airbags.
When you turn the ignition switch to
ON (II), the indicator should come
on brief ly and go out (see page ).
If it doesn’t come on, stays on, or
comes on while driving without a
passenger in the f ront seat, have the
system checked. 60
How the Side Airbag Of f
Indicator Works
How the SRS Indicator Works
not
Additional Inf ormation About Your Airbags
32
U.S.
CanadaIgnoring the SRS indicator can
result in serious injury or death
if the airbag systems, or
tensioners do not work properly.
Have your vehicle checked by a
dealer as soon as possible if
the SRS indicator alerts you to
a possible problem.

This indicator has two f unctions:This indicator comes on when you
turn the ignition switch to ON (II).
It is a reminder to check the
parking brake. A beeper sounds if
you try to drive with the parking
brake not fully released. Driving
with the parking brake not fully
released can damage the brakes
and tires. This indicator comes on f or a f ew
seconds when you turn the ignition
switch to ON (II). It will go of f if you
have inserted a properly-coded
ignition key. If it is not a properly-
coded key, the indicator will blink
and the engine will not start (see
page ).
This indicator also blinks several
times when you turn the ignition
switch f rom ON (II) to ACCESSORY
(I) or LOCK (0).
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to ON (II), and when
the ignition switch is turned to
START (III). If it comes on at any
other time, there is a problem in the
ABS. If this happens, have your
vehicle checked by your dealer. With
the indicator on, your vehicle still
has normal braking ability but no
anti-lock. For more inf ormation, see
page .
If the indicator remains on after
you have f ully released the
parking brake while the engine is
running, or if it comes on while
driving, it can indicate a problem
in the brake system. For complete
inf ormation, see page .
1.
2.
20980
274
Instrument Panel Indicators
Parking Brake and Brake System
Indicator Anti-lock Brake System
(A BS) Indicator
Immobilizer System
Indicator
Inst rument s and Cont rols
61
U.S. Canada

This indicator monitors the
temperature of the automatic
transmission f luid. The indicator
should come on f or a f ew seconds
when you turn the ignition switch to
ON (II). If it comes on while driving,
it indicates the transmission f luid
temperature is too high. Pull to the
side of the road when it is saf e, shif t
to Park, and let the engine idle until
the indicator goes out.This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to ON (II). If this
indicator comes on at any other time,
there is a problem in the 4WD
system. Take the vehicle to your
dealer to have it checked.
If the indicator blinks while driving,
pull to the side of the road when it is
saf e, shif t to Park, and let the engine
idle until the indicator goes out.
This indicator reminds you that the
exterior lights are on. It comes on
when the light switch is in either the
or position. This indicator
will also come on when the light
switch is in AUTO and the lights
turn on automatically.
If you turn the ignition switch to
ACCESSORY (I) or LOCK (0)
without turning of f the light switch,
this indicator will remain on. A
reminder chime will also sound when
you open the driver’s door.
U.S. models only
U.S. Models except Touring
Lights On Indicator A/T Temperature
IndicatorVTM-4 Indicator
Instrument Panel Indicators
64
Continuing to drive with the VTM-4
indicator blinking may cause serious
damage to the system.
Continuing to drive with the A/T
Temperature indicator on may cause
serious damage to the transmission.

This meter shows the number of
miles (U.S.) or kilometers (Canada)
driven since you last reset it.This shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise to
about the middle of the gauge. In
severe driving conditions, the pointer
mayrisetotheupperwhitemark.If
it reaches the red (Hot) mark, pull
safely to the side of the road. Turn to
page f or instructions and
precautions on checking the engine’s
cooling system.
To reset a trip meter, display it, and
then press and hold the Reset button
until the number resets to ‘‘0.0’’.
Both trip meters will reset if the
vehicle’s battery goes dead or is
disconnected. There are two trip meters: Trip A
and Trip B. Switch between these
displays by pressing the Select
button repeatedly. Each trip meter
works independently, so you can
keep track of two dif f erent distances.
When you turn the ignition switch to
ON (II), what you last selected is
displayed.
270
Gauges
Trip Meter Temperature Gauge
Inst rument s and Cont rols
69
SELECT BUTTON
RESET BUTTON

µIf the driver’s
window senses any obstacle while it
is closing automatically, it will
reverse direction and then stop. To
close the window, remove the
obstacle, then use the window switch
again.
Auto reverse stops sensing when the
window is almost closed. You should
always check that all passengers and
objects are away from the window
bef ore closing it. If your vehicle’s battery is
disconnected or goes dead, or the
driver’s window f use is removed, the
AUTO f unction will be disabled. The
power window system needs to be
reset af ter reconnecting the battery
or installing the f use.
Start the engine. Push down and
hold the driver’s window switch
until the window is f ully open.
Pull and hold the driver’s window
switch to close the window
completely, then hold the switch
f or a second or two more.
If the power windows do not operate
properly af ter resetting, have your
vehicle checked by your dealer. To open the moonroof , pull back the
moonroof switch f irmly.
To close the moonroof f ully, push
the switch forward.
1.
2.
CONT INUED
A UT O REVERSE
Moonroof
Power Windows, Moonroof
Inst rument s and Cont rols
93
MOONROOF SWITCH

There are various types of DVDs
available. Some of them are not
compatible with your system.
The DVD player in your Rear
Entertainment System can play
DVDs and CDs bearing the above
marks on their packages or jackets.
Those packages or jackets should
also bear the designation of ‘‘1’’ or
‘‘ALL’’. DVD-ROMs cannot be played
in this system.If you see an error message in the display while operating the DVD player,
f ind the cause in the chart below. If you cannot clear the message, take your
vehicle to your dealer.
Error Message
Cause Solution
FOCUS Error
Mechanical Error, or a
DVD has been loaded in
the CD player
High Temperature
Low Vehicle Battery
VoltagePress the EJECT button and pull out the DVD.
Check if it is inserted correctly in the DVD
Player.MakesuretheDVDisnotscratchedor
damaged.
Press the EJECT button and pull out the DVD.
Check it for damage or deformation.
If the DVD cannot be pulled out, or the error
message does not disappear after the DVD is
ejected, see your dealer.
Do not try to force the DVD out of the player.
Will disappear when the temperature returns to
normal.
Run the engine to recharge the battery.
Playable DVDs
DVD Player Error Messages
Rear Entertainment System
Features
141

Bef ore you begin driving your
vehicle, you should know what
gasoline to use and how to check the
levels of important f luids. You also
need to know how to properly store
luggage or packages. The
inf ormation in this section will help
you. If you plan to add any
accessories to your vehicle, please
read the information in this section
first..............................
Break-in Period .186
...............................
Gasoline Type .186
.........
Service Station Procedures . 187
....................................
Ref ueling .187
Opening and Closing the ........................................
hood .188
...................................
Oil Check .189
.............
Engine Coolant Check . 190
...............................
Fuel Economy .190
...
Accessories and Modif ications . 191
.............................
Carrying Cargo .193
Bef ore Driving
Bef ore Driving
185

Lif t the hood up most of the way.
The hydraulic supports will lif t it
uptherestof thewayandholdit
up.Wait a f ew minutes af ter turning the
engine of f bef ore you check the oil. Remove the dipstick again, and
check the level. It should be
between the upper and lower
marks.
If it is near or below the lower mark,
see on page .
To close the hood, lower the hood to
about a f oot (30 cm) above the
f ender, then press down f irmly with
your hands. Make sure it is securely
latched.
Remove the dipstick (orange loop).
Wipe the dipstick with a clean
cloth or paper towel.
Insert it all the way back in its hole.
1.
3.
3. 2.4.
237
Service Station Procedure
A dding Oil
Oil Check
Bef ore Driving
189
DIPSTICK
UPPER MARK
LOWER MARK

Look at the coolant level in the
radiator reserve tank. Make sure it is
between the MAX and MIN lines. If
it is below the MIN line, seeon page f or
inf ormation on adding the proper
coolant. Always maintain your vehicle
according to the maintenance
schedule. See
(see page
). Try to maintain a constant speed.
Everytimeyouslowdownand
speed up, your vehicle uses extra
fuel.Usethecruisecontrolwhen
appropriate.
Combine several short trips into
one.
The air conditioning puts an extra
load on the engine which makes it
usemorefuel.Usethefresh-air
ventilation when possible.
The build-up of snow or mud on
your vehicle’s underside adds
weight and rolling resistance.
Frequent cleaning helps your f uel
mileage and reduces the chance of
corrosion.
Drive moderately. Rapid
acceleration, abrupt cornering and
hard braking use more f uel.
Always drive in the highest gear
possible. an underinf lated tire
causes more ‘‘rolling resistance,’’
which uses more f uel.
Refer to on page f or inf ormation
about checking other items on your
vehicle. 240
230 230
For example,
Service Station Procedures, Fuel Economy
Engine Coolant Check
A dding
Engine Coolant Improving Fuel Economy
Owner’s
Maintenance Checks
Owner’s Maintenance
Checks
190
RESERVE TANK
MAX MIN
