immobilizer Acura MDX 2006 Owner's Manual

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach............................
Control Locations .58
............................
Instrument Panel .59
..........
Instrument Panel Indicators . 60
.............................................
Gauges .68
Controls Near the Steering ...........................................
Wheel .70
Windshield Wipers and ...................................
Washers .71
Rear Window Wiper and .....................................
Washer .73
...........
Turn Signal and Headlights . 74
........
Instrument Panel Brightness . 76
.................
Hazard Warning Button . 76
.................
Rear Window Def ogger . 77
.........................................
Fog Light .77
..........
Steering Wheel Adjustment . 78
..................................................
Keys .79
........................
Immobilizer System .80
................................
Ignition Switch .81
......................................
Door Locks .82
.......................
Remote Transmitter .83
.................................................
Seats .86
....................................
Seat Heaters .91
..............................
Power Windows .92
.........................................
Moonroof .93
.................................
Parking Brake .94 .............................................
Mirrors .95
Driving Position Memory ..........................................
System .97
.................................
Interior Lights .99
.........
Interior Convenience Items . 101
.....................
Beverage Holders .102
.............
Console Compartment . 102
..................................
Glove Box .102
...................
Rear Compartment . 103
.............................
Cargo Hooks .103
...................................
Sun Visor .103
............................
Vanity Mirror .103
........
Accessory Power Sockets . 104
Instruments and Controls
Inst rument s and Cont rols
57

ÃŽ
ÃŽ
ÃŽ
CONT INUED
The U.S. instrument panel is shown. Dif f erences f or the Canadian models are noted in the text.
Instrument Panel
Inst rument s and Cont rols
59
VEHICLE STABILITY ASSIST
SYSTEM (VSA) INDICATOR
MALFUNCTION INDICATOR
LAMP
LOW OIL PRESSURE
INDICATOR
IMMOBILIZER SYSTEM
INDICATORSUPPLEMENTAL RESTRAINT
SYSTEM INDICATOR
DOOR AND TAILGATE
OPEN MONITOR
TIRE PRESSURE MONITOR
LOW FUEL INDICATOR LIGHTS ON
INDICATOR
WASHER LEVEL
INDICATOR
SEAT BELT
REMINDER
INDICATOR PARKING
BRAKE AND
BRAKE
SYSTEM
INDICATOR
TPMS INDICATOR
LOW TIRE PRESSURE
INDICATOR
BRAKE LAMP
INDICATOR
VSA ACTIVATION
INDICATOR ANTI-LOCK BRAKE SYSTEM
INDICATOR
CRUISE CONTROL
INDICATOR
HIGH BEAM INDICATOR
MAINTENANCE
REQUIRED
INDICATOR
VTM- 4INDICATOR
A/T TEMPERATURE
INDICATOR CHARGING SYSTEM
INDICATOR (P.60)
(P.60)
(P.67) (P.64)
(P.64) (P.62)/
(P.66)
(P. 63)
(P.65) (P.
62)
(P. 65) (P.
61)
(P.66)
(P.
66)
(P.60)
(P.60) (P.64) (P.63)
(P.61) (P.
60)
(P.63)
(P.63) (P.
61)
SIDE AIRBAG OFF
INDICATOR
(P.273)

This indicator has two f unctions:This indicator comes on when you
turn the ignition switch to the ON
(II) position. It is a reminder to
check the parking brake. A beeper
sounds if you try to drive with the
parking brake not f ully released.
Driving with the parking brake not
fully released can damage the
brakes and tires. This indicator comes on f or a f ew
seconds when you turn the ignition
switch to the ON (II) position. It will
gooffifyouhaveinserteda
properly-coded ignition key. If it is
not a properly-coded key, the
indicator will blink and the engine
will not start (see page ).
This indicator also blinks several
times when you turn the ignition
switch f rom the ON (II) position to
the ACCESSORY (I) or the LOCK
(0) position.
If the indicator remains on after
you have f ully released the
parking brake while the engine is
running, or if it comes on while
driving, it can indicate a problem
in the brake system. For complete
inf ormation, see page . This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position, and when the ignition
switch is turned to the START (III)
position. If it comes on at any other
time, there is a problem with the
ABS. If this happens, have your
vehicle checked at a dealer. With the
indicator on, your vehicle still has
normal braking ability but no anti-
lock brakes. For more inf ormation,
see page .
1.
2. 80
211
274
Instrument Panel Indicators
Parking Brake and Brake System
Indicator Anti-lock Brake System
(A BS) Indicator
Immobilizer System
Indicator
Inst rument s and Cont rols
61
U.S. Canada

The master key fits all the locks on
your vehicle. The valet key works
only in the ignition and the door
locks. You can keep the glove box
locked when you leave your vehicle
and the valet key at a parking f acility.Youshouldhavereceivedakey
number tag with your keys. You will
need this key number if you ever
have to get a lost key replaced. Use
only Acura-approved key blanks.
These keys contain electronic
circuits that are activated by the
immobilizer system. They will not
work to start the engine if the
circuits are damaged.
Protect the keys f rom direct
sunlight, high temperature, and
high humidity.
Donotdropthekeysorsetheavy
objects on them.
Keep the keys away f rom liquids.
If they get wet, dry them
immediately with a sof t cloth.
The keys do not contain batteries.
Do not try to take them apart.
Keys
Inst rument s and Cont rols
79
KEY
NUMBER
TAG MASTER
KEYS
(BLACK) VALET KEY
(GRAY)

The immobilizer system protects
your vehicle f rom thef t. If an
improperly-coded key (or other
device) is used, the engine will not
start.
When you turn the ignition switch to
the ON (II) position, the immobilizer
system indicator should come on f or
a f ew seconds, then go out. If the
indicator starts to blink, it means the
system does not recognize the
coding of the key. Turn the ignition
switch to the LOCK (0) position,
remove the key, reinsert it, and turn
the ignition switch to the ON (II)
position again.The system may not recognize your
key’s coding if another immobilizer
key or other metal object (i.e. key
f ob) is near the ignition switch when
you insert the key.
Do not attempt to alter this system
or add other devices to it. Electrical
problems could result that may make
your vehicle undrivable.
If you have lost your key and you
cannot start the engine, contact your
dealer. If the system repeatedly does not
recognize the coding of your key,
contact your dealer.As required by the FCC:
This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
Immobilizer System
80

Apply the parking brake.
In cold weather, turn of f all
electrical accessories to reduce
the drain on the battery.
Make sure the shif t lever is in
Park. Press on the brake pedal.Without touching the accelerator
pedal, turn the ignition key to the
START (III) position. Do not hold
the key in the START (III)
position f or more than 15 seconds
at a time. If the engine does not
start right away, pause for at least
10 seconds bef ore trying again.If the engine does not start within
15 seconds, or starts but stalls
right away, repeat step 4 with the
accelerator pedal pressed halfway
down. If the engine starts, release
pressure on the accelerator pedal
so the engine does not race.
If the engine fails to start, press
the accelerator pedal all the way
down, and hold it there while
starting to clear flooding. If the
engine still does not start, return
to step 5.
5.
6.
1.
2.
3.
4.
Starting the Engine
Driving
201
T he immobilizer system protects your
vehicle f rom thef t. If an improperly-
coded key (or other device) is used, the
engine’s f uel system is disabled. For
more inf ormation, see page .
The engine is harder to start in cold
weather. Also, the thinner air f ound at
altitudes above 8,000 f eet (2,400
meters) adds to this problem.
80

Diagnosing why the engine won’t
start f alls into two areas, depending
on what you hear when you turn the
ignition switch to the START (III)
position:You hear nothing, or almost
nothing. The engine’s starter
motor does not operate at all, or
operates very slowly.
You can hear the starter motor
operating normally, or the starter
motor sounds like it is spinning
f aster than normal, but the engine
does not start up and run.
When you turn the ignition switch to
the START (III) position, you do not
hear the normal noise of the engine
trying to start. You may hear a
clicking sound or series of clicks, or
nothing at all. Check the transmission interlock.
The transmission must be in Park
or neutral or the starter will not
operate.
Turn the ignition switch to the ON
(II) position. Turn on the
headlights, and check their
brightness. If the headlights are
very dim or do not come on at all,
the battery is discharged. See
on page . If the headlights dim noticeably or
go out when you try to start the
engine, either the battery is dis-
charged or the connections are
corroded. Check the condition of
the battery and terminal connec-
tions (see page ). You can
then try jump starting the vehicle
f rom a booster battery (see page
).
In this case, the starter motor’s
speed sounds normal, or even f aster
than normal, when you turn the
ignition switch to the START (III)
position, but the engine does not run. Are you using a properly coded
key? An improperly coded key will
cause the immobilizer system
indicator in the dash panel to blink
rapidly(seepage ).
Check these things: Turn the ignition switch to the
START (III) position. If the
headlights do not dim, check the
condition of the f uses. If the f uses
areOK,thereisprobably
something wrong with the
electrical circuit for the ignition
switch or starter motor. You will
need a qualif ied technician to
determine the problem (see
on page ). 80
268
257
268
275
CONT INUED
If Your Engine Won’t Start
Nothing Happens or the Starter
Motor Operates Very Slowly Jump Starting
T he Starter Operates Normally
Emergency T owing
T aking Care of t he Unexpect ed
267

µ
ÃŽ
ÃŽ
ÃŽ ÃŽ
Circuits Protected
No. Amps. No. Amps. Circuits Protected Circuits Protected
No. Amps.
Horn
Auto Wipers
1
2
3 7.5 A
7.5 A
7.5 A
1
2
3
4
5
6
7
8
9
10
11
12
13 15 A
10 A
7.5 A
7.5 A 10 A
15 A
7.5 A
7.5 A 10 A
7.5 A 15 A
30 A Fuel Pump
SRS
Heater Control, A/C Clutch
Relay, Cooling Fan Relay
Power Mirror
Daytime Running Light /
Rear Wiper
ECU(PCM),CruiseControl
OPDS, OnStar
ACC Relay
Back-up Lights, Instrument
Lights, TPMS
Turn Signals
IG Coil
Front Wiper
Not Used Moonroof
Driver’s Power Seat Sliding
Passenger’s Power Seat
Reclining
Daytime Running Light,
OnStar
Driver’s side Rear Power
Window
Front Passenger’s Power
Window
Front Accessory Socket,
HFL, OnStar
Small Light
Interior Light, TPMS, HFL
Power Door Lock
Back Up, Clock
Heated Seat
Driver’s Power Window
Passenger’s Side Rear
Power Window
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16 30 A
20 A
20 A
20 A
20 A
10 A
20 A
20 A
15 A
15 A
10 A
20 A
7.5 A 20 A
20 A
20 A
: Canadian models
Canadian models
:
ELD Unit, Immobilizer Control
Unit, VSA Control Unit, Alternator Driver’s Power Seat Reclining
Passenger’s Power Seat Sliding
Fuse Locations
280
Driver’s Side INTERIOR FUSE BOX
Passenger’s Side
Front Front
Driver’s Side
Auxiliary

...............
Gas Mileage, Improving . 192
.........................................
Gasoline .188
...............
Fuel Reserve Indicator . 63
...........................................
Gauge .68
................
Octane Requirement . 188
........................
Tank, Filling the .189
................
Gas Station Procedures . 189
Gauges ...
Engine Coolant Temperature . 69
...............................................
Fuel .68
...............................
Speedometer .68
.................................
Tachometer .68
GAWR (Gross Axle Weight .......................................
Rating) .216
GCWR (Gross Combined Weight .......................................
Rating) .216
............
Gearshif t Lever Positions . 202
......................................
Glove Box .102
GVWR (Gross Vehicle Weight .......................................
Rating) .216 .............
Halogen Headlight Bulbs . 245
.............................
HandsFreeLink .161
..............................
HFL Buttons .162
..............
Hazard Warning Flashers . 76
........................................
Headlights .74
........................................
Aiming .245
....................
Automatic Lighting .75
............
Daytime Running Lights . 76
..................
High Beam Indicator . 63
...........
High Beams, Turning on . 74
............
Low Beams, Turning on . 74
.........................
Reminder Chime .74
........
Replacing Halogen Bulbs . 245
...................................
Turning on .74
...................................
Headphones .142
..............................
Head Restraints .88
.................................
Heated Mirror .96
.................................
Heaters, Seats .91
.....................
Heating and Cooling .106
.................
High-Low Beam Switch . 74
HomeLink Universal ................................
Transceiver .156
.......................
Hood, Opening the .190
..................................................
Horn .70 ...
Identif ication Number, Vehicle . 282
Ignition ..............................................
Keys .79
...........................................
Switch .81
............
Timing Control System . 290
........................
Immobilizer System .80
.........
Important Safety Precautions . 8
.........
Indicators, Instrument Panel . 60
...............
ABS (Anti-lock Brake) . 61
....................................
A/T Temp .64
Brake (Parking and Brake ....................................
System) .61
.................................
Brake Lamp .62
........................
Charging System .60
.............................
Cruise Control .63
DRL (Daytime Running ......................................
Lights) .63
...................................
High Beam .63
........
Key (Immobilizer System) . 61
.....................................
Lights On .64
......................................
Low Fuel .63
........................
Low Oil Pressure .60
......................
Low Tire Pressure .66
...............
Maintenance Required . 67
Index
GHI
IV
