stop start Acura MDX 2007 Owner's Manual

Make any steering wheel
adjustments before you start driving.Move the steering wheel in, out, up,
or down by pushing and holding the
adjustment switch in that direction.Release the switch when the
steering wheel reaches the desired
position. Make sure the steering
wheel points towards your chest, not
toward your face, and that you can
see the instrument panel gauges and
indicators.
Steering Wheel A djustments
124
ADJUSTMENT SWITCH
Adjusting the steering wheel
position while driving may
cause you to lose control of the
vehicle and be seriously injured
inacrash.
Adjust the steering wheel only
when the vehicle is stopped.
 — — y

y
()-  y
y

µ
CONT INUED
The windows will operate f or up to
10 minutes af ter you turn of f the
ignition switch. Opening either f ront
door cancels this f unction.To open either f ront
window f ully, push the window
switch f irmly down to the second
detent, then release it. The window
automatically goes down all the way.
To stop the window f rom going all
the way down, pull back on the
window switch briefly.
Turn the ignition switch to the ON
(II) position to raise or lower any
window. To open a window, push the
switchdownandholdit.Releasethe
switch when you want the window to
stop. Pull back on the switch and
hold it to close the window.
In the HI setting, the heater turns off
when the seat gets warm, and turns
back on after the seat’s temperature
drops.
In the LO setting, the heater runs
continuously. It does not cycle with
temperature changes.
Follow these precautions when using
the seat heaters:
Use the HI setting only to heat the
seats quickly, because it draws
large amounts of current f rom the
battery.
If the engine is lef t idling f or an
extended period, do not use the
seat heaters even on the LO
setting. It can weaken the battery,
causing hard starting. AUTO
Seat Heaters, Power Windows
Inst rument s and Cont rols
147
DRIVER’S WINDOW
SWITCH
MAIN SWITCH
Closing a power window on
someone’s hands or fingers can
cause serious injury.
Make sure your passengers are
away from the windows before
closing them.
 — — y
   y
()-  y
y

µIf your vehicle’s battery is
disconnected or goes dead, or the
driver’s window f use is removed, the
AUTO f unction may be disabled. If
the AUTO f unction is disabled, the
power window system will need to be
reset af ter reconnecting the battery
or installing the f use.
Start the engine. Push down and
hold the driver’s window switch
until the window is f ully open.
Pull and hold the driver’s window
switch to close the window
completely, then hold the switch
f or about 2 seconds.
If the power windows do not operate
properly af ter resetting, have your
vehicle checked by your dealer.
If either f ront
window senses any obstacle while it
is closing automatically, it will
reverse direction and then stop. To
close the window, remove the
obstacle, then use the window switch
again.
Auto reverse stops sensing when the
window is almost closed. You should
always check that all passengers and
objects are away from the window
bef ore closing it.
To close either f ront window f ully,
pull back the window switch f irmly
to the second detent, then release it.
The window automatically goes all
the way up. To stop the window f rom
going all the way up, push down on
the window switch briefly.
When you push the MAIN switch in,
the switch is off, and the passenger
windows cannot be raised or lowered.
To cancel this f eature, push on the
switch again to get it to pop out.
Keep the MAIN switch of f when you
have children in the vehicle so they
do not injure themselves by
operating the windows
unintentionally.
1.
2.
AUTO REVERSE
Power Windows
148
 — — y
   y
()-  y
y

You can open and close the windows
and moonroof with the key in the
driver’s door lock.Insert the key in the driver’s door
lock.
Turn the key clockwise, then
release it. Turnthekeyclockwiseagain,and
hold it. All f our windows and
moonroof start to open. To stop
the windows and the moonroof ,
release the key.
When the windows or moonroof
stops bef ore opening f ully, to open
the windows and moonroof f urther,
turnandholdthekeyagain
(within 5 seconds).
To close: Insert the key in the driver’s door
lock.
Turn the key counterclockwise,
then release it.
Turn the key counterclockwise
again, and hold it. All four
windows and the moonroof start to
close. To stop the windows and
the moonroof , release the key.
To open:
You can open all of the windows and
the moonroof f rom outside with the
remote transmitter.
Press the UNLOCK button once
to unlock the driver’s door.
Press the UNLOCK button a
second time, and hold it. All the
doors unlock, and all f our windows
and moonroof start to open. To
stop the windows and moonroof ,
release the button.
To open the windows and
moonroof f urther, press the
button again and hold it. If the
windows and the moonroof stop
bef ore the desired position, repeat
steps 1 and 2.
You cannot close the windows or the
moonroof with the remote
transmitter. 1.
2.
2.
3. 3.
1.
2.
3. 4.
1.
CONT INUED
Power Windows, Moonroof
Opening/Closing the Windows
and Moonroof with the K ey
Opening the Windows and
Moonroof with the Remote
Transmitter
Inst rument s and Cont rols
149
 — — y
  y
()-  y
y

NOTE:
If a f ile on an MP3 or WMA disc is
protected by digital rights
management (DRM), the audio unit
displays CD FORMAT, and then
skips to the next f ile.Your vehicle’s in-dash disc changer
holdsuptosixdiscs.
You cannot load and play 3-inch
(8-cm) discs in this unit.
When the disc load indicator turns
green and ‘‘LOAD’’ appears in the
display again, insert the next disc
in the slot. Do not try to insert a
disc until ‘‘LOAD’’ appears. You
could damage the audio unit.
Repeat this until all six positions
are loaded. If you are not loading
all six positions, the system begins
playing the last disc loaded.
You can also load a disc into an
empty position while a disc is playing
by pressing the appropriate preset
button. The system stops playing the
current disc and starts the loading
sequence. It then plays the disc just
loaded.
Press the LOAD button until you
hear a beep and see ‘‘LOAD’’ in
the display. To load only one disc,
press and release the LOAD
button.
The disc number f or an empty
position begins blinking.
Insert the disc into the disc slot
when the green disc load indicator
comes on. Insert it only about
half way; the drive will pull it in the
rest of the way. You will see
‘‘BUSY’’ in the display while the
disc load indicator turns red and
blinks as the disc is loaded.
1.
2.
3.
4.
5.
Playing Discs (Models without navigation system)
L oading Discs
190
 — — y
 y
()-  y
y

To load multiple discs in one
operation:Insert a disc into the slot. Insert it
only about half way; the drive will
pull it in the rest of the way. You
will see the ‘‘BUSY’’ in audio
display. When you insert the f irst
disc, the changer will start to play
the disc.
When ‘‘LOAD’’ appears in the
audio display again, insert the next
disc into the slot.
Repeat this until all six positions
are loaded. If you are not loading
all six positions, the system will then begin playing the last disc
loaded.
If you stop loading discs bef ore all
six positions are f illed, the system
will wait f or 10 seconds, stop the load
operation, and begin playing the last
disc loaded.
To load a single disc:
With the ignition in the
ACCESSORY (I) or the ON (II)
position, press and hold the LOAD
button until you hear a beep and
see ‘‘LOAD’’ in the upper display,
then release the button.
Press and release the LOAD
button.
‘‘NO DISC’’ is shown on the screen
foranemptypositioninthe
changer. When the green load
indicator comes on and you see
the ‘‘LOAD’’ in the audio display,
insert the disc into the slot. Insert
it only about half way; the drive will
pull it in the rest of the way.You can select the position to load a
disc. Turn the interf ace knob or
press a preset button to select the
position, then press ENTER on the
selector. This starts the loading
sequence. If you do not select the
position, the system loads the disc to
the f irst empty position in numerical
order.
If you press the LOAD button while
a disc is playing, the system will stop
playing that disc and start the
loading sequence. It will then play
the disc just loaded.
1.
1.
2.
3.
4. 2.
Playing Discs (Models with navigation system)
L oading Discs in the Changer
218
 — — y
 y
()-  y y

Once the security system is set,
opening any door, the tailgate, or the
hood without using the key or the
remote transmitter, will cause it to
alarm. It also alarms if the radio is
removed f rom the dashboard or the
wiring is cut.The security system will not set if
the hood, tailgate, or any door is not
f ully closed. If the system will not set,
check that the doors, the tailgate and
the hood are f ully closed.
Do not attempt to alter this system
or add other devices to it.
The security system helps to protect
your vehicle and valuables f rom thef t.
The horn sounds and a combination
of headlights, parking lights, side
marker lights, and taillights f lash if
someone attempts to break into your
vehicleorremovetheradio.This
alarm continues f or 2 minutes, then
it stops. To reset an alarming system
bef ore the 2 minutes have elapsed,
unlock the driver’s door with the key
or the remote transmitter.
The security system automatically
sets 15 seconds after you lock the
doors, hood, and the tailgate. For the
system to activate, you must lock the
doorsandthetailgatefromthe
outside with the key, the lock tab,
the door lock switch, or the remote
transmitter. The security system
indicator in the instrument panel
starts blinking immediately to show
you the system is setting itself .
Security System
Features
265
SECURITY SYSTEM INDICATOR
 — — y

y
()-  y  y

µ
µ µ
µ To
avoid transmission damage, come
to a complete stop before shifting
into Park. The shift lever must be in
Park before you can remove the key
from the ignition switch.
Press the brake
pedal and press the release button
on the front of the shift lever to shift
fr om Park to reverse. To shift from
reverse to neutral, come to a
completestop,andthenshift.Press
the release button before shifting
into reverse from neutral.
Use neutral if you
need to restart a stalled engine, or if
it is necessary to stop briefly with
the engine idling. Shift to the Park
position if you need to leave your
vehicle for any reason. Press on the
brake pedal when you are moving
the shift lever from neutral to
another gear. Use
this position for
your norm al driving. The
transmission automatically selects a
suitable gear (1 through 5) for your
sp eed and acceleration. You may
notice the transmission shifting up at
higher engine speeds when the
engine is cold. This helps the engine
warm up faster.
This position mechani-
cally locks the transmission. Use
Park whenever you are turning off or
starting the engine. To shift out of
Park, you must press on the brake
pedal and press the release button
on the shif t lever. Make sure your
f oot is of f the accelerator pedal.
If you have done all of the above and
still cannot move the lever out of
Park, see on
page . 338
Do this:
Press the brake pedal, and
press the shift lever release
button.
Press the shift lever release
button.
Move the shift lever.
To shift from:
PtoR
RtoP
NtoR
DtoD DtoD DtoN
NtoDRtoN
3
3
Automatic Transmission
Reverse (R)
Neutral (N) Drive (D)
Park (P) Shif t L ock Release
334
 — — y

y
()-  y y

µ
´
With the shif t lever in ‘‘D’’ position,
you can select the Sequential
SportShift mode to shift gears much
like a manual transmission, but
without a clutch pedal.
To enter the Sequential SportShif t
mode, move the shif t lever f urther to
the driver’s side. To return to ‘‘D,’’
move the shift lever to the
passenger’s side.
In Sequential SportShif t mode, each
time you push f orward on the shif t
lever, the transmission shifts to a
higher gear. Pull back on the lever to
downshif t. The number of the gear
selected is displayed on the
instrument panel.
When you move the shif t lever f rom
‘‘D’’ to ‘‘M’’ position, the display
shows the selected gear. The transmission remains in the
selectedgear(5,4,3,2,or1).There
is no automatic downshif t when you
push the accelerator pedal to the
f loor. When you accelerate away f rom a
stop, the transmission starts in f irst
gear. You have to manually upshift
between f irst and f if th gears. Make
sure you upshif t bef ore the engine
speed reaches the tachometer’s red
zone.
CONT INUED
Sequential SportShif t Mode
Automatic Transmission
Driving
335
SELECTED GEAR
( ) DOWN SHIFT
( ) UP SHIFT
 — — y

y
()-  y  y

à
à
à
àà
à
à
The table shows the speed ranges
f or upshif ting and downshif ting. When you are in Sequential
SportShif t mode, and the vehicle is
stopped, push f orward on the shif t
lever to shif t to second gear. You
will see ‘‘2’’ in the display. Starting
out in second gear will help to
reduce wheelspin in deep snow or
on a slippery surf ace.
If you start out in second gear, the
transmission will be f ixed in that
gear.
To shift from
12
23
34
45 To shift from
32
43
54
Speed range
over 0 mph
(0 km/h)
over 10 mph
(16 km/h)
over 19 mph
(31 km/h)
over 37 mph
(60 km/h) Speed range
under 60 mph
(96 km/h)
under 93 mph
(150 km/h)
under 118 mph
(190 km/h)
The transmission will not
automatically downshif t to f irst gear
even when the vehicle speed is
under 10 mph (16 km/h). You need
to shif t down to f irst gear manually.
CONT INUED
St art ing in Second Gear
Automatic Transmission
Driving
337
 — — y
 y
()-  y y
