To lock all doors and the tailgate,
press the bottom of the master door
lock switch on either f ront door, pull
the lock tab above the driver’s door
handle, or use the key on the outside
lock on the driver’s door.
Pressing the top of either master
door lock switch will unlock all doors
and the tailgate.All doors and the tailgate can be
locked f rom the outside by using the
key in the driver’s door lock. To
unlock only the driver’s door, insert
the key, turn the key, and release it.
The remaining doors and the tailgate
unlock when you turn the key a
second time within a f ew seconds.To change the ‘‘KEY AND REMOTE
UNLOCK MODE’’ setting, see page
.
When the vehicle speed reaches
about 10 mph (about 15 km/h) or
more, all the doors lock
automatically.
To change the ‘‘AUTO DOOR
LOCK’’ setting, see page .
When you shif t to P af ter driving, the
driver’s door unlocks.
To change the ‘‘AUTO DOOR
UNLOCK’’ setting, see page .
The lock tab on any passenger’s door
locks and unlocks that door. 109
106107
Door L ocks
130
UNLOCK
LOCK LOCK
UNLOCK
\f—\f—\fy\fy
()-
\fy\f
y
2008 MDX

With any door and the tailgate open
andthekeyintheignition,both
master door lock switches are
disabled. They are not disabled if all
thedoorsandthetailgateareclosed.
If you try to lock an open driver’s
door by pulling the lock tab rearward
the lock tab on the driver’s door pops
out.To open the tailgate, push up inside
the handle, then lift up. To close the
tailgate, use the inner handle to pull
it down, then press down on the back
edge.
Keep the tailgate closed at all times
while driving to avoid damaging the
tailgate and to prevent exhaust gas
f rom getting into the interior. Seeon page
.
The childproof door locks are
designed to prevent children seated
in the rear f rom accidentally opening
the rear doors. Each rear door has a
lock lever near the edge. With the
lever in the LOCK position (lever is
down), the door cannot be opened
fromtheinsideregardlessof the
position of the lock tab. To open the
door, push the lock tab f orward and
use the outside door handle.
58
Door L ocks, T ailgat e
L ockout Prevent ionChildproof Door L ocks
Carbon Monoxide Hazard
Tailgate
Inst rument s and Cont rols
131
LOCK
\f—\f—\fy\f\fy
()-
\fy\f
y
2008 MDX

µ
If youcannotopenthetailgate,
remove the cover on the back of the
tailgate(seepage).Pushthe
release lever to the right as shown,
then pull the outer handle to open
the tailgate. Press this button once to
lock all doors and the tailgate. Some
exterior lights will f lash. When you
push LOCK twice within 5 seconds,
you will hear a beep to verify that the
doors and tailgate are locked and the
security system has set. This button
does not work if any door or tailgate
is not f ully closed. To change the ‘‘KEYLESS LOCK
ACKNOWLEDGEMENT’’ setting,
see page .
134 110
CONT INUED
MDX, Technology, and U.S. Sport
Packages models
Tailgate, Remote Transmitter
LOCK
Remote Transmitter
Inst rument s and Cont rols
135
UNLOCK
BUTTON
PANIC
BUTTON
LOCK
BUTTON
UNLOCK
BUTTON
PANIC
BUTTONLOCK
BUTTON
U.S. Entertainment Packages and
Canadian Elite Package models
TAILGATE
BUTTON
MDX, Technology, and U.S. Sport
Packages models
\f—\f—\fy\fy
()-
\fy\f
\fy
2008 MDX

µµµ
Press this button once
to unlock the driver’s door. Push it
twice to unlock the other doors.
Some exterior lights will f lash twice
when you push the button. If you do
not open any door or the tailgate
within 30 seconds, they will
automatically relock.
To change the ‘‘KEY AND REMOTE
UNLOCK MODE’’ setting, see page
.
To change the ‘‘SECURITY
RELOCK TIMER’’ setting, see page . When you press the UNLOCK
button, the f ront and rear individual
map lights and the cargo area light,
depending on their switch positions,
will come on (see page ). If you
do not open any door or the tailgate,
the lights stay on for about 30
seconds, then go out. If you relock
thedoorsandthetailgatewiththe
remote transmitter before 30
seconds have elapsed, the lights will
go of f immediately.
Press and hold the
TAILGATE button to open or close
the power tailgate. When the tailgate
begins to move, you will hear a beep,
and some f ront and rear lights will
flash.
If you push the same button again
while the tailgate is opening or
closing, three beeps sound, the
tailgate stops moving, reverses direction and stops in the f ully
opened or f ully closed position.
Press and hold this
button for about 1 second to attract
attention; the horn will sound, and
the exterior lights will f lash f or about
30 seconds. To cancel panic mode,
press any other button on the remote
transmitter, or turn the ignition
switch to the ON (II) position. Panic
mode does not work when the key is
in the ignition switch.
109
111 160
U.S. Entertainment Packages and
Canadian Elite Package models
Remote Transmitter
UNL OCK
TAILGATEPA NIC
136
\f—\f—\fy\fy
()-
\fy\f

y
2008 MDX

Avoid dropping or throwing the
transmitter.
Protect the transmitter from
extreme temperature.
Do not immerse the transmitter in
any liquid.
If you lose a transmitter, the
replacement needs to be
reprogrammed by your dealer.If it takes several pushes on the
button to lock or unlock the doors
and the tailgate, replace the battery
as soon as possible.
To replace the battery:Remove the screw at the base of
the transmitter with a small
Phillips-head screwdriver.
Separate the keypad from the
transmitter by pushing any button
f rom outside.
Battery type: CR1616
1.
2.
CONT INUED
Remote Transmitter CareReplacing the Transmitter
Battery
Remote Transmitter
Inst rument s and Cont rols
137
KEYPAD
SCREW
\f—\f—\fy\fy
()-
\fy\f
y
2008 MDX

µ
Remove the old battery and note
the polarity. Make sure the
polarity of the new battery is the
same ( side f acing up), then
insert it in the keypad.
An improperly disposed of battery
can hurt the environment.
Always conf irm local regulations
for battery disposal.
Snap the two halves of the keypad,
then install the parts in reverse
order.
Place a cloth on the edge of the
keypad, and remove the upper half
by caref ully prying on the edge
with a small f lat-tip screwdriver. 4.
5.
3.
As required by the FCC: This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
Remote Transmitter
138
BATTERY
\f—\f—\fy\f\f\fy
()-
\fy\f
y
2008 MDX

Here are the settings activated with
the remote;Driving position memory
(see page ).
When you unlock the driver’s door
with your remote, each remote
activates the keyless memory
settings related to that remote. The
driver’s ID (MEMORY 1 or
MEMORY 2) is shown on the back
of each remote. When you unlock and open the
driver’s door with the remote
transmitter, the driver’s seat (except
the power lumbar feature) and
outside mirrors start to move to the
positions stored in memory. The
indicator in the related memory
button to the remote comes on.Audio system settings
(see page ).
Climate control settings
(see page ).
Customized settings
(see page ).
To turn the keyless memory settings
back on, repeat this procedure. The
LED will blink once to indicate the
f eature has been turned on.
To turn of f this f eature, press and
hold the LOCK and UNLOCK
buttonsatthesametime.TheLED
in the remote will blink twice. Then
release the buttons. Doing this
cancels the keyless memory settings
f or that remote and restores the
def ault settings.
You will also see the ‘‘WELCOME
DRIVER 1’’ or ‘‘WELCOME
DRIVER 2’’ message on the multi-
inf ormation display, depending on
which linked remote transmitter is
used.
The steering wheel will move to the
stored position when you insert the
key into the ignition switch.
83
200 157
171
K eyless Memory Settings
Remote Transmitter
Inst rument s and Cont rols
139
TM
\f—\f—\fy\f\f
y
()-
\fy\f
y
2008 MDX

You can open and close the windows
and moonroof with the key in the
driver’s door lock.Insert the key in the driver’s door
lock.
Turn the key clockwise, then
release it. Turnthekeyclockwiseagain,and
hold it. All f our windows and the
moonroof start to open. To stop
the windows and the moonroof ,
release the key.
To open:
You can open all of the windows and
the moonroof f rom outside with the
remote transmitter.
You cannot close the windows or the
moonroof with the remote
transmitter.
To open the windows and
moonroof f urther, press the
button again (within 10 seconds of
step 1) and hold it. If the windows
and the moonroof stop bef ore the
desired position, repeat steps 1
and 2.
Press the UNLOCK button a
second time, and hold it. All the
doors unlock, and all f our windows
and moonroof start to open. To
stop the windows and moonroof ,
release the button.
Press the UNLOCK button once
to unlock the driver’s door.
To open the windows and the
moonroof f urther, turn and hold
the key again (within 10 seconds
of step 2).
To close: Insert the key in the driver’s door
lock.
Turn the key counterclockwise,
then release it.
Turn the key counterclockwise
again, and hold it. All four
windows and the moonroof start to
close. To stop the windows and
the moonroof , release the key.
1.
2.
2.
3. 3.
1.
2.
3.
4.
1.
CONT INUED
Opening/Closing the Windows
and Moonroof with the K ey
Opening the Windows and
Moonroof with the Remote
Transmitter
Power Windows
Inst rument s and Cont rols
151
\f—\f—\fy\f\f
y
()-
\fy\f
y
2008 MDX

To open the moonroof f ully, pull
back the moonroof switch f irmly.
The moonroof opens all the way. To
stop the moonroof f rom opening
f ully, push the switch brief ly.To tilt up the moonroof , push on the
center of the moonroof switch. To
stop the moonroof f rom tilting up
f ully, push the switch brief ly.
To close the moonroof f ully, f irmly
push the moonroof switch f orward,
then release it. The moonroof
automatically closes all the way. To
stop the moonroof f rom closing,
push the switch briefly.
To open or close the moonroof
partially, pull back or push f orward
the moonroof switch lightly and hold
it. The moonroof will stop when you
release the switch.
To close the windows and the
moonroof f urther, turn and hold
the key again (within 10 seconds
of step 2).
Auto reverse does not work when
closing the windows and moonroof
with the key.
NOTE: If the windows and the
moonroof stop bef ore the desired
position, repeat steps 2 and 3.
4. Moonroof
Power Windows, Moonroof
152
MOONROOF SWITCH
\f—\f—\fy\f\fy
()-
\fy\f
y
2008 MDX

The individual map lights in the
f ront can be turned on and of f by
pressing the lenses.
The light control switch has three
positions: OFF, Door Activated, and
ON.
Withanydoororthetailgateleft
open, the lights stay on about 3
minutes, then go out. After all doors are closed tightly, the
lights dim slightly, then f ade out in
about 30 seconds.
To change the ‘‘INTERIOR LIGHT
DIMMING TIME’’ setting, see page
.
The lights also come on when the
key is removed f rom the ignition
switch.
The individual map lights in the
second row and the cargo area
light in the third row cannot be
turned on.
The individual map lights in the
f ront and second rows come on
whenanydoororthetailgateis
opened, or when the remote
transmitter is used to unlock the
doors (see page ). When the
doors and the tailgate are closed,
eachlightcanbeturnedonandoff
by pushing the lens.
The cargo area light comes on
whenanydoororthetailgateis
opened if the light control switch
is in the door activated (center)
position. When the doors and the
tailgate are closed, the cargo area
lightcanbeturnedonwiththe
switch in the light.
The individual door lights or the
tailgate lights will operate when a
door or the tailgate is opened. 136
101
When the switch is in the OFF position: When the switch is in the door activated
position:
CONT INUED
L ight Control Switch
Interior Lights
Inst rument s and Cont rols
159
DOOR ACTIVATED POSITION
OFF ON
——y
y
()-
y
y
2008 MDX
