display Acura MDX 2014 Owner's Guide

106
uuGauges and Multi-Information Display (MID)uMID
Instrument Panel
Exit
Door SetupIDS SetupDefault AllLighting Setup
Key And Remote Unlock Mode
Auto Door LockAuto Door Unlock
Keyless Lock Answer BackSecurity Relock Timer
Interior Light Dimming Time
Headlight Auto Off TimerAuto Light Sensitivity
Roll
PushPush
RollRollRollRoll
Roll
Roll
Power Tailgate Setup
Push
Power Open By Outer Handle
Keyless Open Mode
Push
Maintenance Info.
Roll
Push
Preferred IDS Mode
RollRollRoll

107
uuGauges and Multi-Information Display (MID)uMID
Continued
Instrument Panel
■List of customizable options
*1:Default SettingSetup Group Customizable Features Description Selectable SettingsDriver Assist
System
Setup
*
Forward Collision
Warning Distance
*
Changes at which distance FCW
* or CMBS
TM * alerts, or
turns FCW
* on and off.
Long/Normal
*1/Short/Off
ACC Forward Vehicle
Detect Beep
*
Causes the system to beep when the system detects a
vehicle, or when the vehicle goes out of the ACC with
LSF range.
On/Off
*1
ACC Display Speed Unit
*
Changes the speed unit for ACC with LSF on the MID.
mph
*1/km/h (U.S.)
mph/km/h
*1 (Canada)
Lane Keeping Assist
Suspend Beep
*
Causes the system to beep when the LKAS is suspended.
On/Off
*1
Blind Spot Info
*
Changes the setting for the blind spot information.
Audible And Visual
Alert
*1/Visual Alert/Off
Meter SetupLanguage SelectionChanges the displayed language.English*1/Francais/Español
Adjust Outside Temp.
DisplayAdjusts the temperature reading by a few degrees.-5°F ~ ±0°F*1 ~ +5°F (U.S.)
-3°C
~ ±0°C
*1 ~ +3°C
(Canada)
“Trip A” Reset TimingChanges the setting of how to reset trip meter A, average
fuel economy A, average speed A, and elapsed time A.When Refueled/IGN Off/
Manually Reset
*1
“Trip B” Reset TimingChanges the setting of how to reset trip meter B, average
fuel economy B, average speed B, and elapsed time B.When Refueled/IGN Off/
Manually Reset
*1
Turn by Turn Display
*
Select whether the turn-by-turn display comes on during
the route guidance.On
*1/Off
* Not available on all models

108
uuGauges and Multi-Information Display (MID)uMID
Instrument Panel
*1: Default SettingSetup Group Customizable Features Description Selectable SettingsDriving
Position
Setup
Memory Position Link
Turns the driving position memory system on and
off.
On
*1/Off
Steering Wheel
Movement At Entry/Exit
Moves the steering wheel fully up when you get in/
get out of the vehicle. Turns this feature on and off.
On
*1/Off
Auto Seatbelt Tension
*
Turns the setting for the automatic seat belt e-
pretensioner activation on and off.
On
*1/Off
Keyless
Access
SetupDoor Unlock ModeChanges which doors unlock when you grab the
driver’s door handle.Driver Door Only
*1/All Doors
Keyless Access Light
FlashCauses some exterior lights to flash when you
unlock/lock the doors.On
*1/Off
Keyless Access BeepCauses the beeper to sound when you unlock/lock
the doors.On*1/Off
Remote Start System On/
Off
*
Turns the remote engine start feature on and off.On
*1/Off
* Not available on all models

109
uuGauges and Multi-Information Display (MID)uMID
Continued
Instrument Panel
*1: Default SettingSetup Group Customizable Features Description Selectable SettingsLighting
Setup
Interior Light Dimming
Time
Changes the length of time the interior lights stay on
after you close the doors.
60sec/30sec
*1/15sec
Headlight Auto Off
Timer
Changes the length of time the exterior lights stay
on after you close the driver’s door.
60sec/30sec/15sec
*1/0sec
Auto Light Sensitivity
Changes the timing for the headlights to come on.
Max/High/Mid
*1/Low/Min
Door SetupAuto Door LockChanges the setting for the automatic locking
feature.With Vehicle Speed
*1/Shift
From P/Off
Auto Door UnlockChanges the setting for when the doors unlock
automatically.All Doors When Driver’s
Door Opens
*1/All Doors
When Shifted To Park/All
Doors When Ignition
Switched Off/Off
Key And Remote Unlock
ModeSets up either the driver’s door or all doors to unlock
on the first operation of the remote or built-in key.Driver Door*1/All Doors
Keyless Lock Answer
BackLOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.On
*1/Off
Security Relock TimerChanges the time it takes for the doors to relock and
the security system to set after you unlock the
vehicle without opening any door.90sec/60sec/30sec
*1

110
uuGauges and Multi-Information Display (MID)uMID
Instrument Panel
*1: Default SettingSetup Group Customizable Features Description Selectable SettingsPower
Tailgate
Setup
Power Open By Outer
Handle
Changes the setting to open power tailgate by
tailgate outer handle.
On (Power/Manual)
*1/Off
(Manual Only)
Keyless Open Mode
Changes the keyless setting for when the power
tailgate opens.
Anytime
*1/When Unlocked
IDS Setup
Preferred IDS Mode
Changes the IDS mode setting for when you set the
power mode to ON.
Last Used
*1/Comfort/Normal/
Sport
Maintenance
Info.
Maintenance Reset
Resets/Cancels the engine oil life display when you
have performed the maintenance service.
Cancel/Reset
Default All—Cancels/Resets all the customized settings as
default.Cancel/Set

111
uuGauges and Multi-Information Display (MID)uMID
Continued
Instrument Panel
■Example of customization settings
The steps for changing the “Trip A” Reset Timing setting to When Refueled are
shown below. The default setting for “Trip A” Reset Timing is Manually Reset.
1.Roll the multi-function steering-wheel
controls to select Vehicle Settings, then
push the multi-function steering-wheel
controls.
2.Roll the multi-function steering-wheel
controls until Meter Setup appears on the
display.
3.Push the multi-function steering-wheel
controls.
uLanguage Selection appears first on
the display.

112
uuGauges and Multi-Information Display (MID)uMID
Instrument Panel
4.Roll the multi-function steering-wheel
controls until “Trip A” Reset Timing
appears on the display, then push the multi-
function steering-wheel controls.
uThe display switches to the
customization setup screen, where you
can select When Refueled, IGN Off,
Manually Reset, or Exit.
5.Roll the multi-function steering-wheel
controls and select When Refueled, then
push the multi-function steering-wheel
controls.
uThe When Refueled Setup screen
appears, then the display returns to the
customization menu screen.
6.Roll the multi-function steering-wheel
controls until Exit appears on the display,
then push the multi-function steering-
wheel controls.
7.Repeat Step 6 until you return to the
normal screen.

114Controls
ClockAdjusting the ClockYou can adjust the time manually in the audio/information screen, with the power
mode in ON.■Using the Settings menu on the audio/information screen
1.Press the SETTINGS button.
2.Rotate to select System Settings, then
press .
uRepeat the procedure to select Clock
Adjustment.
3.Rotate to change hour, then press .
4.Rotate to change minute, then press
.■Adjusting the Time
1Clock
These indications are used to show how to operate
the interface dial.
Rotate to select.
Press to enter.
You can customize the clock display to show the 12
hour clock or 24 hour clock.
2Customized Features P. 248
You can turn the clock display in the audio/
information screen on and off.
2Customized Features P. 248
The clock is automatically updated through the
navigation system, so the time does not need to be
adjusted.Models with navigation system

uuLocking and Unlocking the DoorsuLocking/Unlocking the Doors from the Outside
120Controls
■Unlocking the doors and tailgate
Grab the driver’s door handle:
uThe driver’s door unlocks.
uSome exterior lights flash twice and the
beeper sounds twice.
Grab the front passenger’s or rear
* door
handle:
uAll the doors unlock.
uSome exterior lights flash twice and the
beeper sounds twice.
Press and hold the tailgate outer handle:
uAll doors and the tailgate unlock and
open.
uSome exterior lights flash twice and the
beeper sounds twice.
2Opening/Closing the Tailgate Using the
Tailgate Outer Handle P. 129
1Using the Keyless Access System
When you go into the keyless access system working
range with all the doors locked, the LED puddle lights
come on for 30 seconds.
The lights do not come on if you have previously
stayed within the range for more than two minutes,
or the doors have been locked for a few days.
The feature activates again after you drive the
vehicle, then lock the doors.
If you do not open a door within 30 seconds of
unlocking the vehicle, the doors will automatically
relock.
The light flash, beeper, and unlock settings can be
customized using the audio/information screen or
multi-information display (MID).
2Customized Features P. 104, 248
You can also unlock and open with the power
tailgate.
2Opening/Closing the Tailgate Using the
Tailgate Outer Handle P. 129Models with navigation system
Tailgate Outer
Handle
* Not available on all models

153
uuOperating the Switches Around the Steering WheeluBrightness Control
Controls
Brightness Control
When the power mode is in ON, you can use
the
(+ or
(- button to adjust instrument
panel brightness.
To brighten: Press the
(+ button.
To dim: Press the
(- button.
You will hear a beep when the brightness
reaches minimum or maximum. The MID will
return to its original state several seconds after
you adjust the brightness.
■Brightness level indicator
The brightness level is shown on the MID
while you are adjusting it.
1Brightness Control
Instrument panel brightness varies, depending on
whether the exterior lights are on or off. The
instrument panel dims to reduce glare when they are
on.
When it is bright outside and the headlight
integration with the wiper is activated, the
instrument panel brightness does not change.
Rolling the multi-function steering-wheel controls
switches the display.
If you press the
(+ button until the brightness display
is up to max, the beeper sounds. This cancels the
reduced instrument panel brightness when the
parking lights are on.
The brightness can be set differently for when the
exterior lights are on, and when they are off.
(+ Button
(- Button
