ContentsThis owner’s manual should be considered a permanent part of the
vehicle and should remain with the vehicle when it is sold.
This owner’s manual covers all models of your vehicle. You may find
descriptions of equipment and features that are not on your
particular model.
Images throughout this owner’s manual (including the front cover)
represent features and equipment that are available on some, but
not all, models. Your particular model may not have some of these
features.
This owner’s manual is for vehicles sold in the United States and
Canada.
The information and specifications included in this publication were
in effect at the time of approval for printing. Honda Motor Co., Ltd.
reserves the right, however, to discontinue or change specifications
or design at any time without notice and without incurring any
obligation.
2Safe Driving P. 25For Safe Driving P. 26 Seat Belts P. 31 Airbags P. 392Instrument Panel P. 69Indicators P. 70 Gauges and Multi-Information Display (MID) P. 972Controls P. 113Clock P. 114 Locking and Unlocking the Doors P. 115
Opening and Closing the Moonroof P. 140
Adjusting the Seats P. 1612 Features P. 199Audio System P. 200 Audio System Basic Operation P. 205
Customized Features P. 249 HomeLink® Universal Transceiver P. 2672 Driving P. 305Before Driving P. 306 Towing a Trailer P. 311Parking Your Vehicle P. 381
Multi-View Rear Camera
* P. 386
2Maintenance P. 391Before Performing Maintenance P. 392 Maintenance Minder
TM P. 395
Checking and Maintaining Wiper Blades P. 417
Climate Control System Maintenance P. 435 Cleaning P. 436
2 Handling the Unexpected P. 441Tools P. 442 If a Tire Goes Flat P. 443
Overheating P. 468 Indicator, Coming On/Blinking P. 470When You Cannot Open the Tailgate P. 4822Information P. 483Specifications P. 484 Identification Numbers P. 486
Emissions Testing P. 489 Warranty Coverages P. 491

4Quick Reference Guide
Quick Reference GuideVisual Index
❙Steering Wheel Adjustments
(P157)
❙ENGINE START/STOP Button
(P141)
❙Navigation System
*
() See the Navigation System Manual❙Audio/Information Screen
(P212)
❙Hazard Warning Button❙On Demand Multi-Use Display
TM
(P206)❙Audio System
(P200)
❙System Indicators
(P70)
❙Gauges
(P97)
❙Multi-Information Display
(MID)
(P98)
❙Climate Control System
(P185)
❙Rear Defogger/Heated Door Mirror
Button
(P154)
❙
(Vehicle Stability Assist (VSA ®)
System OFF) Button
(P363)
❙Lane Departure Warning (LDW)
Button
* (P355)
❙Parking Sensor System Button
* (P383)
❙Collision Mitigation Braking System
TM
(CMBS
TM) OFF Button
* (P379)
❙Headlight Washer Button
* (P152)
❙Heated Windshield Button
* (P154)
❙
(Surround View Camera) Button
*
() See the Navigation System ManualCanadian models

10Quick Reference Guide
Instrument Panel
(P69)
System Indicators
Malfunction Indicator
Lamp
Low Oil Pressure
Indicator
Charging System
IndicatorAnti-lock Brake System
(
ABS ) Indicator
Vehicle Stability Assist
(VSA ®) System
Indicator
VSA ® OFF Indicator
Speed-sensitive Electric
Power Steering (EPS)
System Indicator
Lights Indicators
Lights On Indicator
High Beam Indicator
Immobilizer System
Indicator
Seat Belt Reminder
Indicator
System Indicators
System Message
IndicatorParking Brake and
Brake System
Indicator (Red)
Supplemental
Restraint System
Indicator
Low Fuel Indicator
Gauges
(P97)
/Multi-Information Display (MID)
(P98)
/System Indicators
(P70)
Low Tire Pressure/
TPMS Indicator Turn Signal and
Hazard Warning
Indicators
Keyless Access System
Indicator
Temperature
Gauge Security
System
Alarm
IndicatorFuel
Gauge
Tachometer
MID
Speedometer
Shift Lever Position
IndicatorGear Position Indicator Brake System
Indicator (Amber)
SH-AWD
Indicator
*
Blind Spot Information
(BSI) Indicator
*
System Indicators
Collision Mitigation
Brake System
TM
( CMBS
TM) Indicator
*
Forward Collision
Warning ( FCW)
Indicator
*
Lane Departure
Warning ( LDW)
Indicator
*
Lane Keeping Assist System
( LKAS ) Indicator
*
Adaptive Cruise Control ( ACC)
with Low Speed Follow (LSF)
Indicator
*
U.S.
Canada U.S.
Canada

14Quick Reference Guide
Climate Control System
(P185)
● Press the AUTO button to activate the climate control system.
● Press the button to turn the system on or off.
● Press the button to defrost the windshield.
The climate control system is voice operable. See the Navigation System Manual for
complete details.
Models with navigation systemDriver’s Side
Temperature
Control Switch
Air flows from floor and
windshield defroster vents. Air flows from floor vents. Air flows from floor and
dashboard vents. Air flows from dashboard vents.AUTO Button Passenger’s Side
Temperature
Control Switch
(On/Off) ButtonDriver’s Side
Temperature Icon Passenger’s Side
Temperature Icon On Demand
Multi-Use
Display
TM
(Windshield Defroster) Button
A/C
(Air
Conditioning) and
SYNC
(Synchronized) Icon Recirculation/
Fresh Air Mode
Icon
Fan Control Icon
REAR
(Rear Climate
Control) Icon
Vent Mode
Control Icon
Rear Climate Control
(P196)
● Press the AUTO button to activate the
rear climate control system.
● Press the button to turn the system
on or off.
Rear Temperature
Control Buttons /
(Fan Control)
ButtonAUTO Button
(On/Off)
ButtonMode Control Button
Air flows from the rear floor vents. Air flow from the rear console
vents and floor vents. Air flows from the rear console vents.

15Quick Reference Guide
Features
(P199)
Audio system
(P200)
For navigation system operation
() See the Navigation System Manual
*1:Icons that appear on the screen vary by the source selected.
Audio/Information Screen
Interface Dial/ENTER Button
(Power) Button
CD Slot
(CD Eject) ButtonSETTINGS Button
VOL
(Volume) Knob
BACK Button
MENU Button
AUDIO
Button
INFO
Button
On Demand Multi-Use Display
TM
PHONE
Button
(Tune Down) Icon
*1
(Skip/Seek) Icon
*1
Audio Source
*1
(Skip/Seek) Icon
*1
Presets
*1
(Tune Up) Icon
*1
More
*1
Button
Shortcuts
*1

uuFor Safe Driving uYour Vehicle’s Safety Features
30Safe Driving
For the safety of you and your passengers, make a habit of checking these items
each time before you drive.
• After everyone has entered the vehicle, be sure all doors and the tailgate are
closed and locked. Locking the doors and the tailgate helps prevent an occupant
from being ejected and an outsider from unexpectedly opening a door or the
tailgate.
2 Locking/Unlocking the Doors from the Inside P. 124
•Adjust your seat to a position suitable for driving. Be sure the front seats are
adjusted as far to the rear as possible while allowing the driver to control the
vehicle. Sitting too close to a front airbag can result in serious or fatal injury in a
crash.
2 Adjusting the Seats P. 161
•Adjust head restraints to the proper position. Head restraints are most effective
when the center of the head restraint aligns with the center of your head. Taller
persons should adjust their head restraint to the highest position.
2 Adjusting the Head Restraints P. 164
•Always wear your seat belt, and make sure you wear it properly. Confirm that any
passengers are properly belted as well.
2 Fastening a Seat Belt P. 34
•Protect children by using seat belts or child seats according to a child’s age, height
and weight.
2 Child Safety P. 54
■
Safety Checklist
1Safety Checklist
If the door and/or tailgate open message appears on
the multi-information display (MID), a door and/or
the tailgate is not completely closed. Close all doors
and the tailgate tightly until the message disappears.

33
uuSeat Belts uAbout Your Seat Belts
Safe Driving
The front seats are equipped with automatic
seat belt tensioners to enhance safety.
The tensioners automatically tighten the front
seat belts during a moderate-to-severe frontal
collision, sometimes even if the collision is not
severe enough to inflate the front airbags or
the driver’s knee airbag.
Are the motor-powered pretensioners that
start to retract the front seat belts when the
CMBS
TM, brake assist system, or VSA ® system
is in operation. They may also activate when
you steer the vehicle hard, or the vehicle is
impacted. After retracted, the seat belts are
slackened to their original positions.
As convenient features, the e-pretensioners
slightly retract the seat belts when you latch
the seat belt buckle, depress the brake pedal
more aggressively than you normally do, or
make a sharp turn, and fully retract when you
release the seat belt buckle.
■
Automatic Seat Belt Tensioners
1 Automatic Seat Belt Tensioners
The seat belt tensioners can only operate once.
If a tensioner is activated, the SRS indicator will come
on. Have a dealer replace the tensioner and
thoroughly inspect the seat belt system as it may not
offer protection in a subsequent crash.
During a moderate-to-severe side impact, the
tensioner on that side of the vehicle also activates.
■
Seat Belt e-pretensioners
*
1Seat Belt e-pretensioners
*
If only the e-pretensioners were activated, no
components need to be replaced.
The e-pretensioners may not work if:•A warning message for e-pretensioners appears on
multi-information display.•Vehicle Stability Assist (VSA ®) System Indicator is
on.
* Not available on all models

69
Instrument Panel
This chapter describes the buttons, indicators, and gauges that are used while driving.
Indicators............................................ 70
Multi-Information Display (MID) Warning and Information Messages ............... 84
Gauges and Multi-Information Display (MID)Gauges .............................................. 97
MID ................................................... 98

75
uuIndicators u
Continued
Instrument Panel
Indicator
Name
On/Blinking
Explanation
Message
Vehicle Stability
Assist (VSA ®)
System Indicator
●Comes on for a few seconds when
you set the power mode to ON,
then goes off.●Blinks when VSA ®, or trailer stability
assist is active.●Comes on if there is a problem with
the VSA ®, hill start assist, trailer
stability assist or brake lighting
system.
●Stays on constantly - Have your vehicle
checked by a dealer.
2 Vehicle Stability Assist (VSA ®), aka
Electronic Stability Control (ESC),
System P. 362
2 Trailer Stability Assist
* P. 319
2 Hill start assist system P. 328
●When Trailer Stability Assist Problem is
displayed on the MID, the VSA ® does not
activate.
VSA ® OFF
Indicator
●Comes on for a few seconds when
you set the power mode to ON,
then goes off.●Comes on when you deactivate
VSA ®.
2 VSA ® On and Off P. 363
—
* Not available on all models

84
uuIndicators uMulti-Information Display (MID) Warning and Information Messages
Instrument Panel
Multi-Information Display (MID) Warning and Information MessagesThe following messages appear only on the MID. Roll the multi-function steering-wheel controls to see the message again with th e system
message indicator on.
Message
Condition
Explanation
●Appears if any door or the tailgate is not completely
closed.
●Goes off when all doors and the tailgate are closed.
●Appears when the fuel fill cap is loose or is not installed.
2 Tighten Fuel Cap Message P. 471
